TP User Guide 1 ‘iVAC Pro Tool Plus’ User Guide BCTINT Ltd. WWW.BCTINT.com WWW.iVACswitch.com This User Guide covers the programming, setup and use of the ‘iVAC Pro Tool Plus’ (‘Tool Plus’). It also covers the General Description and Features of the ‘IVAC Pro System’. TP User Guide 2 Table of Contents: 1. Warnings Please read the operating instructions before use. The ‘Tool Plus’ is intended for indoor use, in dry locations only. The ‘Tool Plus’ is powered from an AC to DC 5V USB adapter The USB Adapter should only be connected to AC mains circuits at the rated volt- age. 1 Warnings. 2 General Description of ‘iVAC Pro System’ 3 ‘iVAC Pro Tool Plus’ 4 Physical Features 5 Modes of Operation 6 Program Switch 7 System Address 8 Multi Tool Operation 9 Tool Address 10 Active Current sense level 11 Sensitivity Adjustment. 12 System Test 13 ‘Tool Plus’ Features 14 Specifications. 15 Regulatory Compliance 16 Warranty 17 Contact TP User Guide 3 2. General Description of ‘iVAC Pro System’ The ‘iVAC Pro System’ consists of two groups of product. The first group consists of units that transmit information and a second group of units that receive the transmitted information. At the present time the first group that transmit information are the ‘iVAC Pro Remote’ and three versions of the ‘iVAC Pro Tool’ units. The ‘Tool Plus’, the ‘iVAC Pro Tool’, and the ‘iVAC Pro Tool HP’. The ‘Tool’ units. The units that receive the information are the ‘iVAC Pro Switch’ which controls the Dust Collector and the ‘iVAC Pro Blast Gate’. The ‘Tool’ units monitor the status of its associated power tool. When the power tool turns on it sends a digital wireless signal instructing the ‘iVAC Pro Switch’ to turn on the Dust Collector and the ‘iVAC Pro Blast Gate’ to open. .The following discussions relate to communications with an ‘iVAC Pro Switch’ although the same actions/response apply to the ‘iVAC Pro Blast Gate’. This User Guide will focus on the ‘Tool Plus’. TP User Guide 4 3 ‘Tool Plus’ The ‘Tool Plus’ unit is used to identify the powered on state of its associated power tool. The ‘Tool Plus’ is physically clamped to the power cord of the power tool. The method of detecting the status of the power tool is by means of sensing the magnetic field around the power cord when the power tool is turned on or off. The ‘Tool Plus’ is powered by +5VDC. This power is obtained from either a UL FCC approved AC to DC 5volt USB adaptor, or an associated ‘iVAC Pro System’ unit. If a ‘Tool Plus’ unit is in the Auto Mode when the associated power tool is pow- ered on, the ‘Tool Plus’ unit will transmit an instruction, by means of a digital wireless signal, to the ‘iVAC Pro Switch’ instructing it to turn on and apply power to the Dust Collector. When the power tool has been turned off, the ‘Tool Plus’ units will transmit an instruction to the ‘iVAC Pro Switch’ telling it to turn off. The range for radio communications between the ‘Tool Plus’ and the ‘iVAC Pro Switch’ is forty feet. When mounting the ‘iVAC Pro units’ they should not be mounted on large metal objects, since this can affect the communication range. TP User Guide 5 4. Physical Features TP User Guide 6 5 Modes of Operation The ‘Tool Plus’ has three modes of operation; AUTO – OFF – ON, as set by the Mode Switch. In the AUTO mode the ‘Tool Plus’ transmits information to an ‘iVAC Pro Switch’ each time the connected power tool is turned on or off. When in AUTO Mode the ‘Tool Plus’ senses the current in the power cable of the power tool it is attached to. If the power tool is on, the LED will be on, and the LED will be off if the power tool is off When the power tool turns on or off the LED will flash for about 3 seconds indicating it is transmitting the appropriate ON or OFF command As the Mode Switch is transferred from AUTO to OFF, a transmission is sent to the ‘iVAC Pro Switch’, instructing it to turn off. The LED will flash during the RF transmission As the Mode Switch is moved from OFF to ON, a transmission is sent to the ‘iVAC Pro Switch’, instructing it to turn on. The LED will flash during the RF transmission. As the Mode Switch is transferred from ON to OFF, a transmission is sent to the ‘iVAC Pro Switch’, instructing it to turn off. The LED will flash during the RF transmission. As the Mode Switch is moved from OFF to AUTO, a transmission is sent to the ‘iVAC Pro Switch’. The command sent will be an ON command if the power tool is on or an OFF command if the power tool is off The LED will flash during the RF transmission. TP User Guide 7 CAUTION: It is important to NOT change the Mode Switch while the ‘Tool Plus’ is transmit- ting. You must wait until the LED stops flashing before moving the Mode Switch from Auto to OFF, OFF to ON, ON to OFF or OFF to AUTO. NOTE When in OFF or ON Mode the LED indicates how much current is flowing to the power tool. This indication is dependent on the setting of the Sensitivity control. Once the Sensitivity of the ‘Tool Plus’ has been properly set up, see section 11 below, LED = Off Power tool is off LED Flashing The LED has two flash rates, both rates are faster than the flash rate when the ‘Tool Plus’ is transmitting RF commands. LED = ON Power tool is on TP User Guide 8 6 Program Switch The Program Switch is accessed through the Program Switch Cover located in the top surface of the unit. It enables the programming of the System Address and the Tool Address. Changes to the Program Switch must be performed with the Mode Switch in the OFF position. Changes to the Program switch with the Mode switch in AUTO mode will be ig- nored. TP User Guide 9 7 System Address A System consists of up to eight ‘Tool Plus’ units that can control one ‘iVAC Pro Switch’ By means of the Program Switch, the ‘Tool Plus’ can be assigned to work on one of four System Addresses, A, B, C or D. The System Address is to enable up to four systems to operate independently while within communication range of each other. All units required to operate as a System must be…
