YCK-DR750-2CHLTECAR DASHCAM

ENGLISH DR750-2CH LTE Manual 2 BLACKVUE Table of Contents Introduction .................................................................5 Important safety information ....................................6 Overview ......................................................................9 In the box .....................................................................................................................9 At a glance .................................................................................................................10 Front camera ................................................................................................................................... 10 Removing and inserting the front camera ................................................................................ 13 Rear camera..................................................................................................................................... 14 Removing and inserting the rear camera .................................................................................. 14 Installation .................................................................15 Installing the BlackVue dashcam ..........................................................................15 Playing and Managing Videos ..................................19 Playing and managing video files using your smartphone (Android/iOS) .......................................................................... 19 Opening video files ..................................................................................................19 BLACKVUE WI-FI screen composition ...................................................................21 Playing video ............................................................................................................22 Playing back videos ....................................................................................................................... 22 Identify video files by recording type ........................................................................................ 22 Checking the displayed time & GPS data .................................................................................. 24 Real-time streaming video (Live View) ................................................................25 Managing videos .....................................................................................................26 Managing videos in BLACKVUE WI-FI ........................................................................................ 26 Copy to Internal Memory ............................................................................................................................................. 26 Managing videos in INTERNAL MEMORY .................................................................................. 27 Deleting videos .............................................................................................................................................................. 28 Creating a new folder ................................................................................................................................................... 28 Copying and pasting videos ....................................................................................................................................... 28 Moving videos ............................................................................................................................................................... 29 Renaming a video ......................................................................................................................................................... 29 Uploading, sharing or emailing a video ................................................................................................................... 29 Playing and managing video files using your computer (Windows/Mac) ....................................................................... 30 Removing the microSD card ..................................................................................30 Opening video files in BlackVue Viewer ..............................................................31 Viewer screen composition ....................................................................................32 Windows Viewer ............................................................................................................................. 32 Mac Viewer ...................................................................................................................................... 33 Playing video ............................................................................................................34 Playing back videos ....................................................................................................................... 34 Identify video files by recording type ........................................................................................ 34 Checking the displayed time ....................................................................................................... 36 Using BlackVue Viewer .................................................................................................................. 36 Exploring the timeline and G-Sensor graph ............................................................................. 37 Zoom options ................................................................................................................................. 38 Checking the GPS data .................................................................................................................. 39 Managing videos......................................................................................................40 Capturing or printing a still image from video ......................................................................... 40 Del…

Text truncated - open the document above for the full version.

Date: June 19, 2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: YCK-DR750-2CHLTE To whom it may concern: We, the undersigned, hereby authorize SGS Korea Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Pittasoft Co., Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Kim, Kwang Jo Title: Research Advisor Signature: On behalf of Company: Pittasoft Co., Ltd. Telephone: 82-10-8998-8734

Date: June 19, 2020 To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Pittasoft Co., Ltd. 7F, BYC HIGH CITY Building A 131, Gasan Digital-ro, Geumcheon-gu, Seoul, South Korea Regarding: Confidentiality Request regarding application for FCC ID : YCK-DR750-2CHLTE LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Kim, Kwang Jo Research Advisor Pittasoft Co., Ltd.

Letter of Declaration Product Equality 24 June 2020 We, Pittasoft Co., Ltd., as a manufacturer hereby declare that the variant models have the following differences in supported features. Model Name Information Basic Model DR750-2CH LTE - Basic model Variant Models DR750-2CH IR LTE - Rear camera IR model DR750-2CH Truck LTE - Rear camera truck model DR750-1CH LTE - Non rear camera model DR750S-2CH LTE - Just variant model name add DR750X-2CH LTE DR750G-2CH LTE Kim Kwang Jo Research Advisor, HW Team, R&D Center Pittasoft Co., Ltd.

Front View of EUT Rear View of EUT Inside of EUT Front View of Front CAM Rear View of Front CAM Front View of Main Board Rear View of Main Board Front View of Module Rear View of Module Front View of Motion Sensor Rear View of Motion Sensor Front View of Power Board Rear View of Power Board Front View of Sub Board Rear View of Sub Board

DR750-2CH LTE_Product_NA 1.2020.05.08 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including Interference that may cause undesired operation. Contains FCC ID : XMR201605EC25A Contains IC ID : 10224A-201611EC25A

Front View of EUT Rear View of EUT Inside of EUT Front View of Front CAM Rear View of Front CAM Front View of Main Board Rear View of Main Board Front View of Module Rear View of Module Front View of Motion Sensor Rear View of Motion Sensor Front View of Power Board Rear View of Power Board Front View of Sub Board Rear View of Sub Board

Test Report No. : F690501-RF-EMG000235 Page : 2 of 12 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) Contents 1. General Information ................................................................................................... 4 1.1 Client Information ................................................................................................ 4 1.2 Test Laboratory ................................................................................................... 4 1.3 General Information of E.U.T. ............................................................................. 4 1.4 Operating Modes and Conditions ........................................................................ 5 1.5 Auxiliary Equipments .......................................................................................... 5 1.6 Cable List ............................................................................................................ 5 1.7 System Configurations ........................................................................................ 5 1.8 Test System Layout ............................................................................................ 5 1.9 Modifications ....................................................................................................... 5 1.10 Applicable Standards for Testing ...................................................................... 5 1.11 Summary of Test Results .................................................................................. 5 2. Emission Test ............................................................................................................ 6 2.1 Test Results ........................................................................................................ 6 2.2 Test Method and Limits ....................................................................................... 6 2.2.1 Test Method ............................................................................................... 6 2.2.2 Test Limits .................................................................................................. 6 2.3 Radiated Emission .............................................................................................. 7 2.3.1 Test Equipments ........................................................................................ 7 2.3.2 Test Site ..................................................................................................... 7 2.3.3 Environment Conditions and data .............................................................. 7 Appendix A : Radiated Emission ................................................................................. 11 Test Report No. : F690501-RF-EMG000235 Page : 3 of 12 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) Revision History Revision Report Number Description 0 F690501-RF-EMG000235 Initial 1 2 Test Report No. : F690501-RF-EMG000235 Page : 4 of 12 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) 1. General Information 1.1 Client Information Applicant : Pittasoft Co., Ltd. - Address of Applicant : A 4th floor, ABN Tower, 331, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Republic of Korea Manufacturer : Pittasoft Co., Ltd. - Address of Manufacturer : A 4th floor, ABN Tower, 331, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Republic of Korea Factory : SMT SCOUT Co., Ltd. - Address of Factory : 38 Dangjeong-ro, Gunpo-si, Gyeonggi-do, Republic of Korea, 15849 1.2 Test Laboratory Name and Address : SGS Korea Co., Ltd. - Giheung 1 Laboratory : 35, Giheungdanji-ro 121beon-gil, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea - Giheung 2 Laboratory : 23, Giheungdanji-ro 24beon-gil, Giheung-gu,Yongin-si, Gyeonggi-do, Republic of Korea - Gunpo Laboratory : 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 15807, Republic of Korea. Phone : + 82 31 428 5700 Fax : + 82 31 427 2370 e-mail : [email protected] 1.3 General Information of E.U.T. Classification Description Product Name CAR DASHCAM Model Name DR750-2CH LTE Alt.Model Name DR750-2CH IR LTE, DR750-2CH Truck LTE, DR750-1CH LTE, DR750S-2CH LTE, DR750X-2CH LTE, DR750G-2CH LTE Model Differences Model Name Differences DR750-2CH IR LTE Rear camera IR model DR750-2CH Truck LTE Rear camera Truck model DR750-1CH LTE Non rear camera model DR750S-2CH LTE, DR750X-2CH LTE, DR750G-2CH LTE Just variant model name add. Serial No. DR7LNAAJ400063 Highest Internal Frequency 1 850 ㎒ ~ 1 990 ㎒ EMI Classification Class B Test Voltage 12 Vd.c., 24 Vd.c. (for Battery) Operating Voltage 12 Vd.c., 24 Vd.c. 1 A (Minimum 12 Vd.c. ~ Maximum 24 Vd.c.) Operating Temperature (-)20 °C ~ (+)70 °C S/W Version DR750-2CH LTE V1.000 H/W Version DR750-2CH LTE REV1.1 Function This device is an LTE connection used in Dash Cam. Test Report No. : F690501-RF-EMG000235 Page : 5 of 12 EMC5101-01A(2017.07.06)(2) A4(210mm*297mm) 1.4 Operating Modes and Conditions Operating Mode Conditions 1) Operating at 12 V CAM operating and LTE 2 Band idle status at 12 V 2) Operating at 24 V CAM operating and LTE 2 Band idle status at 24 V 1.5 Auxiliary Equipments Description Model Serial No. Manufacturer Car Battery - - - BLACKVUE Full HD RC100F RC7LNAAJ400033 Pittasoft Co., Ltd. 1.6 Cable List Start END Cable Spec. Used core Name I/O Port Name I/O Port Length Shield Car Battery DC OUT EUT DC IN 3.6 Unshield No EUT DC OUT BLACKVUE Full HD DC IN 3.1 Unshield No 1.7 System Configurations Description Model Serial No. Manufacturer Front CAM DR750_2CH_LTE_FRONT_ CAM_Rev0.1 - PITTASOFT Co., Ltd. Main Board DR750_2CH_LTE_EU_Main_Rev 0.1 - PITTASOFT Co., Ltd. Module - - - Motion Sensor DR750-2CH_LTE_EU_MOTION_ SENSOR_Rev0.1 - PITTASOFT Co., Ltd. Power Board DR750- 2CH_LTE_EU_POWER_Rev0.1 - PITTASOFT Co., Ltd. Sub Board - - - 1.8 Test System Layout 1.9 Modifications - There was no modified item during the test. 1.10 Applicable Standards for Testing tandards Status Deviation FCC Part 15 Subpart B Applicable No Deviation 1.11 Summary of Test Results Test Item Basic Standard…

Text truncated - open the document above for the full version.

Radiated Emission (Below 1 ㎓ ) _ Front Radiated Emission (Below 1 ㎓ ) _ Rear Radiated Emission ( Above 1 ㎓ ) _ Front Radiated Emission ( Above 1 ㎓ ) _ Rear
