YGN-RF2BTN001UG3



DATE:August,17,2015 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID:YGN-RF2BTN001U ProductName:G3 RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommissionsrules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: (Listherethedocumentsforwhichyouareseekingconfidentiality–forexample...)  Schematics Blockdiagram Operationdescription Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. Dated this Agencyagreementexpirationdate:August17,2015toAugust16,2016 By:GregANeff SignaturePrinted Title:GM Onbehalfof:AmericanTechnologyComponentsInc. Telephone:(574)262-1258

Product Similarity Declaration To Whom it may Concern, We, American Technology Components Inc. hereby declare that our product (G3) Model Number: G3-E, G3-H. All models are same except model name. Model G3-E was selected for test. Please contact me if you have any question. Signture: Manufacture: American Technology Components Inc. Date: 2015-8-17 All models are electrically identical except model name is different.

Drawing All Dimension Version WuXi Contact Electronics Co ., Ltd 無錫康泰電子有限公司 Drawing No P/N Scale Weight Q'TY Material Date Date Name Approval Quality Check Revision/ Description 27 18 18 53 Aoter 031409(0)-10-06 2015-08-11 1:2 FCC label MM A-00 g PCS 1 FCC 标签 AP-SUB-100 (G3) 433.92MHz

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10- g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 76.7dBuV/m @3m Ant gain 0dBi ; so Ant numeric gain=1 So pt ={ [10 ( 76.7 /20) /10 6 x3] 2 /30x1 }x1000 mW =0.014 mW So (0.014 mW/5mm) x √0.43392 GHz = 0.002 <3 Then SAR evaluation is not required

Report No. : EED32H000971 Page 1 of 19 TEST REPORT Product : G3 Trade mark : Genesis 3 Model/Type reference : G3-E, G3-H Serial number : N/A Ratings : DC 3V FCC ID : YGN-RF2BTN001U Report number : EED32H000971 Date : Aug. 12, 2015 Regulations : See below Test Standards Results 47 CFR FCC Part 15 Subpart C 15.231: 2014 PASS Prepared for: American Technology Components Inc. 2905 LaVanture Place, Elkhart, IN 46514, United States Prepared by: Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date: Aug. 12, 2015 Sheek Luo Lab supervisor Check No.: 2093605500 Report No. : EED32H000971 Page 2 of 19 TABLE OF CONTENTS 1.CERTIFICATION INFORMATION ............................................................................................................... 3 2.TEST SUMMARY ........................................................................................................................................ 3 3.MEASUREMENT UNCERTAINTY .............................................................................................................. 4 4.PRODUCT INFORMATION ......................................................................................................................... 4 5.TEST EQUIPMENT LIST ............................................................................................................................. 5 6.SUPPORT EQUIPMENT LIST .................................................................................................................... 5 7.OPERATION CHARACTERISTICS ............................................................................................................ 6 7.1.LIMITS ................................................................................................................................................. 6 7.2.BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 6 7.3.TEST PROCEDURE ........................................................................................................................... 6 7.4.TEST RESULT .................................................................................................................................... 6 8.20DB/ 99% BANDWIDTH MEASUREMENT .............................................................................................. 8 8.1.LIMITS ................................................................................................................................................. 8 8.2.BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 8 8.3.TEST PROCEDURE ........................................................................................................................... 8 8.4.TEST RESULT .................................................................................................................................... 8 9.RADIATED EMISSION MEASUREMENT ................................................................................................. 10 9.1.LIMITS ............................................................................................................................................... 10 9.2.BLOCK DIAGRAM OF TEST SETUP ................................................................................................ 10 9.3.TEST PROCEDURE ......................................................................................................................... 11 9.4.TEST RESULT .................................................................................................................................. 12 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ............................................................................................ 15 APPENDIX 2 EXTERNAL PHOTOGRAPHS OF PRODUCT ............................................................................ 16 APPENDIX 3 INTERNAL PHOTOGRAPHS OF PRODUCT ............................................................................. 17 N/A means not applicable. Report No. : EED32H000971 Page 3 of 19 1. CERTIFICATION INFORMATION The above equipment was tested by Centre Testing International (Shenzhen) Corporation for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart C and the measurement procedure according to ANSI C63.4:2014 and ANSI C63.10:2013. 2. TEST SUMMARY No. Test Item Rule Result 1 Operation characteristics FCC Part15.231(a) PASS 2 Radiated Emission FCC Part15.231(b) PASS 3 20dB bandwidth FCC Part15.231 & PASS 4 AC Conducted Emission FCC PART15.207 N/A 5 Antenna requirements FCC PART15.203 PASS (See Note 1) Note: 1. According to Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The EUT has a built in the PCB; this is permanently attached antenna and meets the requirements of this section. 2. New battery is used during all the test. Applicant: American Technology Components Inc. 2905 LaVanture Place, Elkhart, IN 46514, United States Manufacturer: Wuxi Contact Electronics Co., Ltd. No.8 Chunxing Industrial Park Youyi Road, Dongting Town, Xishan District, Wuxi City FCC ID: YGN-RF2BTN001U Product: G3 Model/Type reference: G3-E, G3-H Trade Name: Genesis 3 Serial Number: N/A Report Number: EED32H000971 Sample Received Date: Aug. 01, 2015 Sample tested Date: Aug. 01, 2015 to Aug. 12, 2015 Report No. : EED32H000971 Page 4 of 19 3. MEASUREMENT UNCERTAINTY Where relevant, the following test uncertainty levels have been estimated for tests performed on the product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a co…
