  1. Home/
  2. Stratasys Ltd/
  3. YH6-ALARIS

YH6-ALARIS3D RAPID PRINTER

Stratasys Ltd
3D RAPID PRINTER - FCC ID YH6-ALARIS - Stratasys Ltd
Click to zoom

Application Details

Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant
Jul 11, 2010
Application Purpose
Original Equipment
Date of Application
Jul 11, 2010
Equipment Note
3D RAPID PRINTER
Frequency Range
0.12500000 - 0.12500000
Company
Stratasys Ltd
Country
Israel

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Guide English Alaris30 3-D Printer System DRAFT 4 - July 11, 2010 DRAFT 4 - July 11, 2010 DOC-24000 Rev. Aiii Copyright Copyright © 2010 Objet Geometries Ltd. All rights reserved. This documentation contains proprietary information of Objet Geometries Ltd. This information is supplied solely to assist authorized users of Alaris30 3‐D printing systems. No part of this document may be used for other purposes, and it may not be disclosed to ot her pa rties. The specifications on which this document is based are subject to change without notice. No part of this book may be reproduced in any form or by any means, nor stored in a database or retrieval system, without prior permission in writing from Objet Geometries Ltd. If this document is di stributed as a PDF fi le, you may print it for internal use. Trad em a r k s The following are registered trademarks of Objet Geometries Ltd.: Objet ® , FullCure ® . The following are trademarks of Objet Geometries Ltd.: Eden, Eden500V, Eden350V, Eden350, Eden330, Eden260, Eden260V, Eden250, Connex, Connex500, Connex350, Alaris, Alaris30, Alaris24, PolyJet, PolyJet Matrix, PolyLog, Objet Studio, Job Manager, SHR, TangoBlack, TangoGray, TangoPlus, VeroBlue, VeroGray, VeroWhite, VeroBlack, DurusWhite, RoseClear, Clear, Digital Materials. Microsoft and Microsoft XP are trademarks of Microsoft Co rporation. Al l names of products and services cited in this book are trademarks or registered trademarks of their respective companies. FCC Compliance The 3‐D printing systems referred to in this guide have been tested and found to comply with the limits for a Class A device pursuant to part 15 of the FCC rules. These limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. Objet 3‐D printi ng syst ems generate, use and can radiate radio frequency energy. If not installed and used in accordance with instructions in the relevan installation and user guides, these systems may cause harmful interference to radio communications. Operation of Objet 3‐D printing systems in residential areas may cause unacceptable interference to ra d io and TV reception, requiring the operator to take whatever steps are necessary to correct the interference. NOTE: Objet Geometries is not responsible for radio or TV interference caused by unauthorized modification to this equipment. Such modifications could void the user’s authority to operate the equipment. Equipment Recycling In the European Union, this symbol indicates that when the last user wishes to discard a product, it must be sent to appropriate facilities for recovery and recycling. For information about proper disposal, check your purchase contract, or contact the supplier of the equipment. Limitation of Liability The product, software or services are being provided on an “as is” and “as available” basis. Except as may be stated specifically in your contract, Objet Geometries Ltd. expressly disclaims all warranties of any kind, whether express or implied, including, but not limited to, any implied warranties of merchantability, fitness for a particular pu rp ose and non‐infringement. You understand and agree that Objet Geometries Ltd. shall not be liable for any direct, indirect, incidental, special, consequential or exemplary damages, including but not limited to, damages for loss of profits, goodwill, use, data or other intangible losses (even if Objet has been advised of th e possib ility of such damages), resulting from: (i) the use or the inability to use the product or software; (ii) the cost of procurement of substitute goods and services resulting from any products, goods, data, software, information or services purchased; (iii) unauthorized access to or alteration of your products, software or data ; (iv) statements or conduct of any third party; (v) any other matter relating to the product, software, or services. The text and drawings herein are for illustration and reference only. The specifications on which they are based are subject to change. Objet Geometries Ltd. may, at any time an d wi thout notice, make changes to this document. Objet Geometries Ltd., for itself and on behalf of its subsidiaries, assumes no liability for technical or editorial errors or omissions made herein, and shall not be liable for incidental, consequential, indirect, or special damages, including, without limitation, loss of use, loss or al teration of da ta, delays, or lost profits or savings arising from the use of this document. DRAFT 4 - July 11, 2010 iv DOC-24000 Rev. A Patents This product is covered by one or more of the following U.S. patents: 5,263,130 5,287,435 5,386,500 5,519,816 5,695,708 6,259,962 6,569,373 6,644,763 6,658,314 6,850,334 6,863,859 7,183,335 7,209,797 7,225,045 7,300,619 7,364,686 7,368,484 7,369,915 7,479,510 7,500,846 7,604,768 7,628,857 Objet Geometries Ltd. http://www.objet.com DOC‐24000 Revision A July 2010 DRAFT 4 - July 11, 2010 DOC-24000 Rev. Av 1About This Guide Using This Guide ............................................................................................................................... 1–2 For More Information........................................................................................................................ 1–2 Terms Used in This Guide................................................................................................................ 1–3 2 Safety Safety Features ................................................................................................................................... 2–2 Symbols and Warning Labels .......................................................................................................... 2–3 Safety Guidelines ............................................................................................................................... 2–4 Printer Installation.................................................................................…

Text truncated - open the document above for the full version.

Operational Description

Rev 1 Tel: 972-9-835-4848 Fax: 972-9-865-6262 2 Hamelacha St., Poleg Industrial Zone, Natanya ,P.O.B 8249, ZIP 42504 Israel LogiTag Systems LTD. www.logi-tag.com Page 1/1 Alaris 4 CHANNEL Reader 125KHz – theory of operation The system contains 3 main components: - Reader - 2 antennas - Transponders HITAG S The Reader has serial output which connects to control unit MCU or PC with software application that control the reader. The antennas connect to the output of the Reader: Connect the Reader to power supply and serial connection to MCU. The MCU send a command states to the Reader to identify transponders. At this situation the Reader is creating electromagnetic field emitting through the antenna. When placing a transponder near/on/above the antennas, at a distance which sufficient enough to create reaction at the transponder; a voltage generates at the transponder coil. The transponder is transmitting back to the antenna its ID and/or data from its memory according to the Reader's command. If the Reader identifies the transponder's encryption/data it is sending the transponder's ID/data to the control unit. At the same similar way the Reader can write info to the transponder memory, including verification process.

Test Report

DATE: 06 July 2010 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for Objet Geometries Ltd. Equipment under test: 3D Rapid Printer Alaris™30 V2.0, Alaris™24 Containing: Motion Controller Rev. 2.0; Vacuum Panel Rev. 2.0; Spartan With Lattice FPGA 10K* * See customer’s declaration on page 5. Written by: _____________________________ D. Shidlowsky, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E98115.00 Objet Geometries Ltd. Page 1 of 28 FCC ACC M Ver 1.1 05Mayl 2000 Test Report E98115.00 Objet Geometries Ltd. Page 2 of 28 FCC ACC M Ver 1.1 05Mayl 2000 Measurement/Technical Report for Objet Geometries Ltd. 3D Rapid Printer Alaris™30 V2.0, Alaris™24 Containing: Motion Controller Rev. 2.0; Vacuum Panel Rev. 2.0; Spartan With Lattice FPGA 10K FCC ID: YH6-ALARIS This report concerns: Original Grant: X Class I Change: Class II Change: Equipment type: Low Power Transmitter Below 1705 kHz Limits used: 47CFR15 Section 15.209 Measurement procedure used is ANSI C63.4-2003. Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Guy Menchik ITL (Product Testing) Ltd. Objet Geometries Ltd. Kfar Bin Nun 2 Holzman St. D.N. Shimshon 99780 Science Park Israel Rehovot 762124 e-mail [email protected] Israel Tel: +972- 8 - 931 - 4369 Fax: +972- 8 - 931 - 4969 e-mail: [email protected] TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information ................................................................................. 4 1.2 List of Accreditations ......................................................................................... 6 1.3 Product Description ........................................................................................... 7 1.4 Test Methodology .............................................................................................. 9 1.5 Test Facility ....................................................................................................... 9 1.6 Measurement Uncertainty ................................................................................. 9 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------10 2.1 Justification ...................................................................................................... 10 2.2 EUT Exercise Software ................................................................................... 10 2.3 Special Accessories ........................................................................................ 10 2.4 Equipment Modifications ................................................................................. 10 2.5 Configuration of Tested System ...................................................................... 11 3. TEST SETUP PHOTOGRAPHS ------------------------------------------------------------------------12 4. CONDUCTED EMISSION DATA -----------------------------------------------------------------------13 4.1 Test Specification ............................................................................................ 13 4.2 Test Procedure ................................................................................................ 13 4.3 Measured Data ................................................................................................ 13 4.4 Test Instrumentation Used, Conducted Measurement ................................... 18 5. FIELD STRENGTH OF FUNDAMENTAL ------------------------------------------------------------19 5.1 Test Specification ............................................................................................ 19 5.2 Test Procedure ................................................................................................ 19 5.3 Measured Data ................................................................................................ 19 5.4 Test Instrumentation Used, Field Strength of Fundamental ........................... 21 6. RADIATED EMISSION, 9 KHZ – 30 MHZ -----------------------------------------------------------22 6.1 Test Specification ............................................................................................ 22 6.2 Test Procedure ................................................................................................ 22 6.3 Measured Data ................................................................................................ 22 6.4 Test Instrumentation Used, Radiated Measurements .................................... 25 6.5 Field Strength Calculation ............................................................................... 25 7. APPENDIX B - CORRECTION FACTORS ----------------------------------------------------------26 7.1 Correction factors for CABLE ......................................................................... 26 7.2 Correction factors for CABLE ......................................................................... 27 7.3 Correction factors for ACTIVE LOOP ANTENNA ........................................... 28 Test Report E98115.00 Objet Geometries Ltd. Page 3 of 28 FCC ACC M Ver 1.1 05Mayl 2000 1. General Information 1.1 Administrative Information Manufacturer: Objet Geometries Ltd. Manufacturer's Address: 2 Holtzman St., Scientific Park, P.O.B. 2496, Rehovot, 76124 Israel Tel: +972 8 931 4314 Fax: +972 8 931 4315 Manufacturer's Representative: Moshik Antebi Equipment Under Test (E.U.T): 3D Rapid Printer Equipment Model No.: Alaris™30 V2.0, Alaris™24 Containing: Motion Controller Rev. 2.0; Vacuum Panel Rev. 2.0; Spartan With Lattice FPGA 10K Part No.: 7309 (See customer’s declaration on following p…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zohar Zosmanovich(Regulatory Affairs System Sr. Engineer)
[email protected]+972-74-7454447Fax: +972-74-7454315

Test Firm

Israel Testing LaboratoriesIIan Cohen
[email protected]972-3-5339022Fax: 972-3-5339019

Technical Specifications

#Rule PartsFrequency RangePower Output
115C0.125 MHz - 0.125 MHz-
Confidentiality
Long Term
