YHLBLUB170DSmart Phone with GSM, WCDMA, LTE, WiFi and Bluetooth

BLU Products, Inc.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Nov 30, 2023
Application Purpose: Original Equipment
Date of Application: Nov 29, 2023
Equipment Note: Smart Phone with GSM, WCDMA, LTE, WiFi and Bluetooth
Frequency Range: 5745.00000000 - 5825.00000000
Company: BLU Products, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

VIEW 5 PRO B170D User Guide 2 Contents Safety information .............................................................................................. 4 Getting to know your phone .............................................................................. 6 Setting up your phone ....................................................................................... 9 Phone ................................................................................................................ 11 Contacts ............................................................................................................ 13 Messages .......................................................................................................... 14 Email .................................................................................................................. 15 Chrome browser .............................................................................................. 16 Bluetooth ........................................................................................................... 17 Wi-Fi ................................................................................................................... 19 Camera .............................................................................................................. 20 Photos ............................................................................................................... 22 Calendar ............................................................................................................ 23 3 Calculator .......................................................................................................... 24 Clock .................................................................................................................. 25 Google Maps .................................................................................................... 26 Google Play Store ........................................................................................... 27 Settings ............................................................................................................. 28 Troubleshooting ................................................................................................ 43 Regulatory Information .................................................................................... 47 4 Safety information Please carefully read the items bellow: Use Safely Do not use the phone in situations where it might cause danger. Transportation Safety Please observe all transportation laws and regulations. Please drive with both hands on the wheel. DO NOT TEXT AND DRIVE Hospitals Please follow limitations. Please turn off your mobile phone when near medical instruments. Airports Remember to follow all airport and flight safety regulations. Please do not use your phone during flight. 5 Toxic Chemicals Do not use your mobile phone around fuels or chemicals. Hazard Do not use in hazardous areas where explosions may occur. Accessories and Batteries Use only Blu authorized batteries and accessories. Backup Remember to keep a written record of all important information. Water Your phone is not waterproof. Keep it away from water and liquids. SOS Emergency Calls Make sure your mobile phone is switched on and in a service area. In home screen, tap the phone key and dial 911 and send. 6 Getting to know your phone 7 Power key • Long press the power button to power on. • While the phone is powered on, press power button and volume up button at the same time to access the phone options screen or click to lock the screen. Volume keys Adjust the volume for ringtones, media, notifications, and system sounds. Home The home button pauses any current action and returns to the home screen. Recent Apps Open a list of recently opened applications that allows you to switch conveniently between them. This option can also close any open applications by swiping to the side. Back Return to the previous screen; Closes the keyboard, any open program, or any menu option. USB port Charge the device and transfers data such as documents, music, and video between your device and a PC. 8 Headset port Connect earphones to this port for hands-free capabilities. You may also to listen to music or FM radio. Mic Mobile phone can receive your voice during calling, taping, record video and voice assistant Status bar Provide phone and service status information on the right side and notification alerts on the left. Front Camera A high-resolution front camera to take pictures and video. This option is ideal for self-portraits. Rear Camera A high-resolution rear camera to take pictures and video. Flash Provide light for pictures in low-light conditions. It also may be used as a flashlight. 9 Setting up your phone Install a Nano SIM/microSD card Note: Please contact your cellular phone service provider directly to obtain your SIM card if your card is not preinstalled. 1. Open the SIM and memory card tray: push the tray opener pin in the tray hole and side the tray out. 2. Put the nano-SIM in the SIM slot on the tray with the contact area face down. 3. If you have a memory card, put it in the memory card slot. 4. Slide the tray back in. 10 Warning: Please keep the SIM card out of the reach of children. The SIM card and its contact are easily damaged due to scratching or bending. Use caution when carrying, installing, or taking out the SIM card. Charge the battery 1. Connect one end of the data cable to the USB port located on the bottom of your phone. 2. Connect the other end to the power adapter. 3. Connect the power adapter to an electrical outlet to fully charge your phone. Power On and Off Long press the Power key to switch on the phone. To turn off the phone, long press the Power key and volume up key tap Power Off on the screen that displayed. 11 Phone Make a call 1. To make a call, tap Phone from the Home screen. 2. Tap Dialer to access the keypad, or sele…

Text truncated - open the document above for the full version.

Cover Letter(s)

BLUProducts,Inc. PHOENIXTESTLABGmbHDate:23November2023 ProductCertification Königswinkel10 D32825Blomberg RE:LETTEROFAGENCYAUTHORIZATION ToWhomItMayConcern: We,BLU,theundersigned,herebyauthorizeCTTL,TelecommunicationTechnologyLabs,CAICTtoact onourbehalfinallmattersrelatingtoapplicationforequipmentauthorization,includingthesigning ofalldocumentsrelatingtothesematters. Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits,pursuant toSection5301oftheAnti-DrugAbuseACTof1988,U.S.C.862.Further,noparty,asdefinedin47 CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits,thatincludesFCCbenefits. ThisagreementisvaliduntilApirl-01-2024. Ifyouhaveanyquestions,pleasefeelfreetocontactme Yourssincerely, Signatory PrintedName ： Zengwei Position：SeniorManager

ID Label/Location Info

Label Label

RF Exposure Info

No. 23T04Z80263-19 ©Copyright. All rights reserved by CTTL. Page 1 of 84 SAR TEST REPORT No. 23T04Z80263-19 For BLU Products, Inc. Smart Phone Model Name: B170D with Hardware Version: V1.0 Software Version: BLU_B170D_V14.0.01.05.01.01_FSec FCC ID: YHLBLUB170D Issued Date: 2023-11-28 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No. 23T04Z80263-19 ©Copyright. All rights reserved by CTTL. Page 2 of 84 REPORT HISTORY Report Number Revision Issue Date Description 23T04Z80263-19 Rev.0 2023-11-22 Initial creation of test report 23T04Z80263-19 Rev.1 2023-11-28 1. Revise Graph Results for LTE B26 body on page19 of ANNEX. 2. Revise the maximum SAR results of LTE B41 PC2 body on page70. 3. Revise SAR results for BT on page75. 4. Revise tune up power for WIFI5G on page60. No. 23T04Z80263-19 ©Copyright. All rights reserved by CTTL. Page 3 of 84 TABLE OF CONTENT 1 TEST LABORATORY ................................................................................................................. 5 1.1 INTRODUCTION & ACCREDITATION ................................................................................................................ 5 1.2 TESTING LOCATION ........................................................................................................................................ 5 1.3 TESTING ENVIRONMENT ................................................................................................................................. 6 1.4 PROJECT DATA ............................................................................................................................................... 6 1.5 SIGNATURE ..................................................................................................................................................... 6 2 STATEMENT OF COMPLIANCE ................................................................................................ 7 3 CLIENT INFORMATION.............................................................................................................. 9 3.1 APPLICANT INFORMATION .............................................................................................................................. 9 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 9 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) .............................. 10 4.1 ABOUT EUT ................................................................................................................................................. 10 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ........................................................................ 11 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST .......................................................................... 11 5 TEST METHODOLOGY ............................................................................................................ 12 5.1 APPLICABLE LIMIT REGULATIONS ................................................................................................................ 12 5.2 APPLICABLE MEASUREMENT STANDARDS ................................................................................................... 12 6 SPECIFIC ABSORPTION RATE (SAR) .................................................................................... 13 6.1 INTRODUCTION ............................................................................................................................................. 13 6.2 SAR DEFINITION .......................................................................................................................................... 13 7 TISSUE SIMULATING LIQUIDS ............................................................................................... 14 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 14 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 14 8 SYSTEM VERIFICATION .......................................................................................................... 16 8.1 SYSTEM SETUP ............................................................................................................................................. 16 8.2 SYSTEM VERIFICATION ................................................................................................................................. 17 9 MEASUREMENT PROCEDURES ............................................................................................ 18 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 18 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 20 9.3 WCDMA MEASUREMENT PROCEDURES FOR SAR ...................................................................................... 21 9.4 SAR MEASUREMENT FOR LTE ..................................................................................................................... 22 9.5 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR .................................................................... 24 9.6 POWER DRIFT ............................................................................................................................................... 24 10 AREA SCA…

Text truncated - open the document above for the full version.

RF Exposure Info

©Copyright. All rights reserved by CTTL. ANNEX of No. 23T04Z80263-19 For BLU Products, Inc. Smart Phone Model Name: B170D with Hardware Version: V1.0 Software Version: BLU_B170D_V14.0.01.05.01.01_FSec FCC ID: YHLBLUB170D Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn . GSM850 Head Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Duty Cycle Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity LeftHead, HSL CHEEK, 0.00 GSM 850 1:4 836.600, 190 10.31 0.959 41.352 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2114 HBBL-600-10000 EX3DV4 - SN7727, 2023-06-05 DAE4 Sn1807, 2023-05-15 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid N/A Yes Grading Ratio N/A 1.5 MAIA Y Y Surface Detection Unknown method VMS + 6p Scan Method Measured Measured Measurement Results Area Scan Zoom Scan Date 2023-10-19 2023-10-19 psSAR1g [W/kg] 0.001 0.008 psSAR10g [W/kg] 0 0.002 Power Drift [dB] 0.07 0.01 Power Scaling Disabled Disabled Scaling Factor [dB] TSL Correction No correction No correction M2/M1 [%] 79.4 Dist 3dB Peak [mm] 2.7 . GSM850 Body Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Duty Cycle Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL BACK, 10.00 GSM 850 1:4 848.800, 251 10.31 0.964 41.36 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2114 HBBL-600-10000 EX3DV4 - SN7727, 2023-06-05 DAE4 Sn1807, 2023-05-15 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid N/A Yes Grading Ratio N/A 1.5 MAIA Y Y Surface Detection VMS + 6p VMS + 6p Scan Method Measured Measured Measurement Results Area Scan Zoom Scan Date 2023-10-19 2023-10-19 psSAR1g [W/kg] 0.089 0.094 psSAR10g [W/kg] 0.053 0.047 Power Drift [dB] 0.08 0.01 Power Scaling Disabled Disabled Scaling Factor [dB] TSL Correction No correction No correction M2/M1 [%] 77.0 Dist 3dB Peak [mm] 8.5 . GSM1900 Head Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Duty Cycle Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity RightHead, HSL CHEEK, 0.00 PCS 1900 1:4 1850.200, 512 8.47 1.376 39.619 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2114 HBBL-600-10000 EX3DV4 - SN7727, 2023-06-05 DAE4 Sn1807, 2023-05-15 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid N/A Yes Grading Ratio N/A 1.5 MAIA N/A N/A Surface Detection VMS + 6p VMS + 6p Scan Method Measured Measured Measurement Results Area Scan Zoom Scan Date 2023-10-24 2023-10-24 psSAR1g [W/kg] 0.256 0.267 psSAR10g [W/kg] 0.150 0.168 Power Drift [dB] -0.05 0.19 Power Scaling Disabled Disabled Scaling Factor [dB] TSL Correction No correction No correction M2/M1 [%] 88.1 Dist 3dB Peak [mm] 15.1 . GSM1900 Body Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Duty Cycle Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL BACK, 10.00 PCS 1900 1:2 1850.200, 512 8.47 1.376 39.619 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2114 HBBL-600-10000 EX3DV4 - SN7727, 2023-06-05 DAE4 Sn1807, 2023-05-15 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid N/A Yes Grading Ratio N/A 1.5 MAIA N/A N/A Surface Detection All points All points Scan Method Measured Measured Measurement Results Area Scan Zoom Scan Date 2023-10-24 2023-10-24 psSAR1g [W/kg] 0.590 0.628 psSAR10g [W/kg] 0.321 0.325 Power Drift [dB] -0.15 -0.04 Power Scaling Disabled Disabled Scaling Factor [dB] TSL Correction No correction No correction M2/M1 [%] 81.4 Dist 3dB Peak [mm] 10.3 . WCDMA1900 Head Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Duty Cycle Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity RightHead, HSL CHEEK, 0.00 Band 2 1:1 1852.400, 9262 8.47 1.376 39.619 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2114 HBBL-600-10000 EX3DV4 - SN7727, 2023-06-05 DAE4 Sn1807, 2023-05-15 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid N/A Yes Grading Ratio N/A 1.5 MAIA N/A N/A Surface Detection VMS + 6p VMS + 6p Scan Method Measured Measured Measurement Results Area Scan Zoom Scan Date 2023-10-24 2023-10-24 psSAR1g [W/kg] 0.388 0.399 psSAR10g [W/kg] 0.228 0.254 Power Drift [dB] -0.16 0.02 Power Scaling Disabled Disabled Scaling Factor [dB] TSL Correction No correction No correction M2/M1 [%] 89.1 Dist 3dB Peak [mm] 16.5 . WCDMA1900 Body Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Duty Cycle Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL BACK, 10.00 Band 2 1:1 1907.600, 9538 8.47 1.416 39.513 Hardware Setup P…

Text truncated - open the document above for the full version.

RF Exposure Info

©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ANNEX H Dipole Calibration Certificate 750 MHz Dipole Calibration Certificate ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL.

RF Exposure Info

©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. 835 MHz Dipole Calibration Certificate ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. 1800 MHz Dipole Calibration Certificate ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. 1900 MHz Dipole Calibration Certificate ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. 2450 MHz Dipole Calibration Certificate

RF Exposure Info

©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. 2600 MHz Dipole Calibration Certificate ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. 5 GHz Dipole Calibration Certificate ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL. ©Copyright. All rights reserved by CTTL.

RF Exposure Info

Test Report

禾苗集团深圳禾苗通信科技有限公司 DCC#: 发行日期: 物料分类样品承认书表单编号：SPC-JL-QM-51-21-V1.4 天线–承认书 Check List 一 . 厂商应填写基本数据 : 二 . 厂商应填写产品数据 : 1. 天线类型 : a. 拉杆材料类型及规格 ______________________________ b.金属冲压材料类型及规格______________________________弹片化金厚度：____________ c.FPC 基材类型及规格 ___PI 半对半基材 ___ 金手指金厚度： ___ ≥ 0.075um___ 镍厚度 :__3-8um__ FPC 背胶材料 ( 指定 3M9471LE, 特殊请备注说明 ) ______3M467 厚度 0.05mm_________ 三 . 厂商应在承认书附下面相关文件 ; 文件电子档 (pdf) 发邮件到禾苗。 ◆ 1. 标准的 2D 图纸及全（重点）尺寸测量报告◆ 2. 材质证明书◆ 3. 包装方式 ◆ 4. 天线性能测试报告（如 TRP, TIS, SAR, 频率和相位误差等数据） ◆ 5. 可靠性测试报告 ◆6 ROHS 声明书四.确认栏供应商签核并盖公司章禾苗签核并盖受控章业务客户经理硬件测试研发结构工程 DQE 品质项目经理料号： 15.01.1961 承认书版本：V1.0 项目名称： PD6703TF_GPS/WIFI/BT 天线合作厂商：惠州硕贝德无线科技股份有限公司零件名称： PD6703TF_GPS/WIFI/BT： GPS:1575； BT/WIFI:2400-2484、 5150-5850 地址：广东省惠州市仲恺高新区东江高新科技产业园惠泽大道138号天线丝印型号： PD6703TF-DIV-V1.0 禾苗集团深圳禾苗通信科技有限公司 DCC#: 发行日期: 物料分类样品承认书表单编号：SPC-JL-QM-51-21-V1.4 说明：1、样品承认书一式五份，共需提供5-10个样品； 2 、批量交货前供应商一定要收到双方签字并经禾苗 DCC 受控发行的样品承认书； 3 、供应商批量交的货，必须符合样品和承认书，有问题需提前沟通确认，否则一律批退 . 4、所有质量标准依据禾苗质量要求为准，如有特殊缺陷（无法达到质量标准），供应商需在承认封样时将不良现象特别标示出，并在承认书内容中予以陈述。五.变更记录栏编制/变更日期变更理由变更内容版本 PI半对半 ◆符合我司《产品中有毒有害物质管理标准》 ◇客户环保标准____________ 技术要求尺寸材料金手指工艺表面处理包装质量要求环保要求铜材:◆电解铜厚度 _无胶单面 ◇电镀 ◆化学镀 __沉金_镍厚 3-8um _ 金厚_≥0.075um_ ◆半切 ◇单PCS袋装 ◇托盘包装 ◆符合我司《FPC检验标准》和可靠性标准 ◇AOI全检 ◇AOI抽检 ◇电阻___ ◆盐雾 48 小时 ◇附加说明____________ 3M467 厚度 0.05mm ◇原装离型纸_ ◇离型纸颜色_ 未注尺寸公差表硅胶模切五金塑胶 ≤ > ±0.10±0.10±0.05±0.05 30 ±0.10±0.10±0.05±0.07 63 ±0.15±0.15±0.10±0.10 306 ±0.25±0.25±0.15±0.15 12030 ±0.30±0.30±0.20±0.20 120 未注角度公差 ±0.5 △ 1 日期日期日期版本批准审核设计单位比例材质料号机种名称 FIT Huizhou speed wireless technology co.,ltd. MM 签名备注日期更改内容处数标记 5678 D 2341 SCT/QRF 7.3-48-001/A.1 C B D A 12345678 B C A 惠州硕贝德无线科技股份有限公司 PD6703-分集天线 PD6703 F-2A-T5-4584-000-K0 张娜 2023.10.12 T13 半切 PI补强含胶0.25mm厚黑色亮光丝印区域 6-*1.60±0.30 *83.70±0.15 *29.10±0.15 6-*2.50±0.30 01 02 03 04 6-Ø1.20±0.10 2-Ø1.00±0.10 05 06 07 Ø1.90±0.10 PD6703TF-DIV-V1.0 231012 Ø0.80±0.10 08 15.87±0.15 18.95±0.15 24.91±0.15 2.26±0.15 7.28±0.15 9.51±0.15 2.16±0.15 11.07±0.15 20.22±0.15 30.30±0.15 36.19±0.15 36.28±0.15 12 13 14 15 16 17 091011 18 1920 C C 惠州硕贝德无线科技股份有限公司 Huizhou speed wireless technology co.,ltd. 尺寸检测报告项目名称:PD6703-分集天线料号：F-2A-T5-4584-000-K0测量穴数:5 版本：T17 测量员：何绿魁审核：胡小群测量日期：2023/11/8 尺寸编号规格测量值判定超差值标称值上公差下公差12345测量工具 183.70 0.15 -0.15 83.736 83.723 83.680 83.686 83.667 二次元OKOKOKOKOK 229.10 0.15 -0.15 29.084 29.089 29.066 29.104 29.110 二次元OKOKOKOKOK 31.60 0.30 -0.30 1.6031.6151.6341.6211.61二次元OKOKOKOKOK 31.60 0.30 -0.30 1.615 1.621 1.583 1.621 1.626 二次元OKOKOKOKOK 31.60 0.30 -0.30 1.639 1.639 1.646 1.632 1.638 二次元OKOKOKOKOK 31.60 0.30 -0.30 1.585 1.592 1.701 1.677 1.658 二次元OKOKOKOKOK 31.60 0.30 -0.30 1.610 1.611 1.586 1.616 1.603 二次元OKOKOKOKOK 31.60 0.30 -0.30 1.631 1.639 1.645 1.651 1.652 二次元OKOKOKOKOK 42.50 0.30 -0.30 2.495 2.495 2.629 2.592 2.599 二次元OKOKOKOKOK 42.50 0.30 -0.30 2.489 2.495 2.622 2.611 2.579 二次元OKOKOKOKOK 42.50 0.30 -0.30 2.538 2.538 2.550 2.538 2.544 二次元OKOKOKOKOK 42.50 0.30 -0.30 2.533 2.533 2.552 2.533 2.546 二次元OKOKOKOKOK 42.50 0.30 -0.30 2.523 2.506 2.524 2.511 2.511 二次元OKOKOKOKOK 42.50 0.30 -0.30 2.506 2.506 2.494 2.506 2.519 二次元OKOKOKOKOK 51.90 0.10 -0.10 1.924 1.941 1.925 1.934 1.928 二次元OKOKOKOKOK 61.00 0.10 -0.10 1.031 1.024 1.035 1.026 1.037 二次元OKOKOKOKOK 61.00 0.10 -0.10 1.035 1.038 1.024 1.035 1.037 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.229 1.244 1.221 1.215 1.221 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.234 1.231 1.222 1.230 1.220 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.230 1.226 1.228 1.189 1.199 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.211 1.204 1.230 1.223 1.222 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.229 1.231 1.228 1.228 1.228 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.243 1.233 1.217 1.220 1.222 二次元OKOKOKOKOK 71.20 0.10 -0.10 1.228 1.216 1.223 1.231 1.225 二次元OKOKOKOKOK 80.80 0.10 -0.10 0.830 0.813 0.830 0.819 0.825 二次元OKOKOKOKOK 915.87 0.15 -0.15 15.841 15.866 15.870 15.856 15.867 二次元OKOKOKOKOK 1018.95 0.15 -0.15 18.937 18.950 18.962 18.956 18.933 二次元OKOKOKOKOK 1124.91 0.15 -0.15 24.897 24.912 24.891 24.924 24.899 二次元OKOKOKOKOK 122.16 0.15 -0.15 2.175 2.168 2.203 2.174 2.177 二次元OKOKOKOKOK 1311.07 0.15 -0.15 11.076 11.077 11.085 11.104 11.103 二次元OKOKOKOKOK 1420.22 0.15 -0.15 20.228 20.223 20.220 20.248 20.242 二次元OKOKOKOKOK 1530.30 0.15 -0.15 30.303 30.321 30.323 30.311 30.327 二次元OKOKOKOKOK 1636.19 0.15 -0.15 36.190 36.210 36.221 36.201 36.219 二次元OKOKOKOKOK 1736.28 0.15 -0.15 36.276 36.305 36.290 36.270 36.295 二次元OKOKOKOKOK 182.26 0.15 -0.15 2.260 2.259 2.271 2.269 2.282 二次元OKOKOKOKOK 197.28 0.15 -0.15 7.277 7.306 7.283 7.272 7.272 二次元OKOKOKOKOK 209.51 0.15 -0.15 9.507 9.538 9.521 9.523 9.536 二次元OKOKOKOKOK 第 1 页 CPK Report Part Number( 料号 ) F-2A-T5-4584-000-K0 Vendor( 供应商 ) SPEED Description( 零件名称 ) PD6703- 分集天线 spected( 确认者 ) Tool Number( 模号 )/MM( 英寸 / 毫米 ) mm Cavity(穴号) Name(材质名称) PI半对半 Material Code( 材质牌号 ) Revision( 版本 )Date( 日期 ) 2023/11/8 . Designator( 尺寸序号 ) 12 Nominal( 公称尺寸 ) 83.700 29.100 + Tolerance(正公差) 0.150 0.150 - Tolerance( 负公差 ) -0.150 -0.150 Upper Limit( 规格上限 ) 83.850 29.250 Lower Limit( 规格下限 ) 83.550 28.950 183.736 29.084 2 83.723 29.089 3 83.680 29.066 4 83.686 29.104 5 83.667 29.110 683.735 29.112 7 83.750 29.095 8 83.679 29.065 9 83.703 29.112 10 83.692 29.104 1183.740 29.109 12 83.738 29.119 13 83.710 29.078 14 83.687 29.097 15 83.698 29.118 1683.732 29.112 17 83.723 29.088 18 83.712 29.060 19 83.688 29.130 20 83.691 29.133 2183.753 29.085 22 83.733 29.113 23 83.711 29.074 24 83.682 29.105 25 83.678 29.121 2683.763 29.079 27 83.745 29.105 28 83.739 29.089 29 83.735 29.101 30 83.694 29.060 3183.717 29.122 32 83.698 29.117 MAX.83.7629.13 MIN.83.6729.06 AVERAGE83.7129.10 STDEV0.030.02 CP1.902.46 Cpk1.742.44 TOOLING( 测量工具 ) 二次元二次元审核：胡小群制作：何绿魁 Packing （ FPC ）一般要求： 1.说明客户名，项目名称，型号， 2. 图片说明内外箱，出货时包装方式，层数，单层数量等 3. 备注栏内填写包装所用材料名称，数量等 4.质量部主管签字，日期产品料号： F-2A-T5-4584-000-K0 产品名称： PD6703TF-分集天线产品版本：包装方式： PE袋或夹板 + 外箱图1：做成版;图2：约每40版为1PE袋或夹板内箱层数：20 外箱内箱数量约20000 备注：外箱材料：A=A双坑量产以实际包装数量为准。图3：10PE袋/箱图4：包装箱的堆放形式。图5：外箱标签。图6：外包装箱外形制作：陈和睿日期：2023.11.08 一、无源测试报告 1 、 The r…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Wei Zeng(Senior Manager)

[email protected]3057157171Fax: 3054368819

Test Firm

Telecommunication Technology Labs, CAICTJiyang Zhu

[email protected]008601062305048

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
4	15E	5.75 GHz - 5.83 GHz	60.50 mW

Confidentiality

Long Term

Grant Notes

Output power is maximum average conducted. This device supports IEEE 802.11 a/n/ac 20, 40 and 80 MHz channel bandwidths. This device has integrated DSS, DTS, NII and PCE transmitters certified under the same FCC ID. This device supports WIFI 802.11 b/g/n20 and 40 MHz channel bandwidth. SAR compliance for body-worn operating configurations is limited to the belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 15 mm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for head, body-worn accessory, hotspot and simultaneous transmission use conditions are 0.38 W/kg, 0.25 W/kg, 0.25 W/kg and 1.01 W/kg, respectively. <br> The HAC Rating is M4T4-2011.
