YHLBLUDJPLUSGSM mobile

-1- Content 1 Getting started ........................................................................................................................................................... 3 1.1 Installing the SIM Cards and the Battery ........................................................................................................ 3 1.2 Charging the Battery ....................................................................................................................................... 3 1.3 Linking to the Network ................................................................................................................................... 5 2 Input method ............................................................................................................................................................. 5 2.1 To Shift Entry Methods ................................................................................................................................... 5 2.2 Numeric and English Input ............................................................................................................................. 5 2.3 Inserting a Symbol .......................................................................................................................................... 6 3 Using the Menus ........................................................................................................................................................ 6 3.1 Phonebook.................................................................................................................. 錯誤 錯誤錯誤 錯誤! 尚未定義書籤 尚未定義書籤尚未定義書籤 尚未定義書籤。 。。 。 3.2 Multimedia ...................................................................................................................................................... 6 3.3 Messages ...................................................................................................................... 錯誤 錯誤錯誤 錯誤! 尚未定義書籤 尚未定義書籤尚未定義書籤 尚未定義書籤。 。。 。 3.4 Call History ..................................................................................................................................................... 9 3.5 Profiles ............................................................................................................................................................ 9 3.6 Organizer ......................................................................................................................................................... 9 -2- 3.7 Settings .......................................................................................................................................................... 10 3.8 Games.............................................................................................................................................................13 3.9 File manager.......................................................................................................................................................13 Phone Specifications Dimensions (H×W×D): 102.8*44.5*15.2MM Weight: 66.3g Camera: 0.08Mpixel Lithium battery -3- Rated capacity: 3.7V 600mAh Continuous standby duration: (Relates to network status) 96-144 hours Continuous conversation duration: (Relates to network status) 3 hours Please refer to their labels for other data related to the battery and the charger. 1 11 1 Getting started Getting startedGetting started Getting started 1.1 Installing the SIM Cards and the Battery An SIM card carries useful information, including your mobile phone number, PIN (Personal Identification Number), PUK (PIN Unlocking Key), IMSI (International Mobile Subscriber Identity), network information, contacts data, and short messages data. 1.2 Charging the Battery The lithium battery delivered with the mobile phone can be put into use immediately after being unpacked. Your mobile phone can monitor and display the battery state.
Normally the remaining energy of the battery is indicated by the battery level icon at the upper right corner of the display screen.
When the battery energy is insufficient, the mobile phone prompts "Battery low". If you have set an alert tone, an alert tone will be given off when the battery level is too low. -4-
A charging animation appears when the battery is being charged. When the charging is complete, the animation disappears.
It is normal of the battery to become hot during the charging period.
The battery icon does no longer flicker when the charging process ends.
Use only the battery provided by the vendor. Otherwise, damages or even injuries could be caused during the charging.
Power off the mobile phone before removing the battery.
The charging process lasts a longer time for a new battery or a battery not in use for a long time. If the battery voltage is too low to enable the mobile phone to be powered on, charge the battery for a longer time.
During the charging, ensure the battery is placed in a room temperature environment or in an environment close to room temperature. Immediately stop using the battery if the battery produces odor, overheats, cracks, distorts or has other damage, or if the electrolyte leaks.
The battery wears out with use. A longer charging time is required as the battery is put into use for a long time. Warning: (1) There may be the risk of explosion if the battery is replaced by the wrong type. (2)Dispose of used batteries according to the guidelines. (3)The socket-outlet shall be installed near the equipment and shall be easily accessible. -5- Provides charging temperature range -5 °C to 55 °C, over this range, please do not use the charging equipment. And be sure to use the charger provided by the supplier. Use of an unapproved charger may be dangerous and breach of warranty of the equipment approval and terms. 1.3 Linking to the Network After the SIM card and the mobile phone are successfully unlocked, the mobile phone automatically searches for an …
