YHLBLUG33U92Smart Phone with GSM, WCDMA, LTE, WiFi and Bluetooth

G33 Quick Guide | Guía Rápida | Guía Rápido | Guide Rapide o For instructions or any questions pertaining to phone usage, please click on the BLU page by visiting the following address: http://www.bluproducts.com o Para obtener instrucciones o preguntas relacionadas con el uso del teléfo no, por favor haga clic en la página de BLU visitando la siguiente dirección: http://www.bluproducts.com o Para obter instruções ou perguntas relacionadas ao uso do telefone, por fa vor, clique na página da BLU visitando o seguinte endereço: http://www.bluproducts.com o Pour des instructions ou pour toutes questions sur l'utilisation du télép hone, veuillez cliquer sur à la page BLU en visitant l'adresse suivante: http://www.bluproducts.com ATTENTION ABOUT YOUR PHONE Transportation SafetyObserve all transportation laws and regulations. PLEASE DRIVE RESPONSIBLY - DO NOT TEXT & DRIVE Hospital SafetyFollow hospital rules and limitations and turn off your mobile phone when n ear medical instruments. Airport SafetyRemember to follow all airport and flight safety regulations.Water HazardYour phone is not waterproof. Keep your phone away from water or liquid to av oid damage. Emergency CallsMake sure your mobile phone is switched on and in a service area. On home scre en, tap the phone key and dial the emergency number.Battery UsageFor better performance and longer battery life, it is recommended that you charge the battery fully before using the mobile phone for the first time and that you initially complete tw o to three charge cycles. IMEI InformationTo check your IMEI, press *#06# KEY FUNCTIONS Front Camera Back Camera Recent Apps Volume Home Power On / Off Flash Rear Camera Power On / Off Used to power on/off the device and to lock the screen. » Long press the power button to power on » While powered on, long press the power off and the volume up key to power off Volume Adjusts the ringer volume, call v olume, and multimedia volume. Home The home button pauses any current action and returns to the home screen. Recent Apps Opens a list of recently opened applications that allows you to switch conv eniently between them. This option can also close any open applications by swiping to the side. Back Returns to the previous screen; Closes the keyboard, any open program, or a ny menu option. USB Port Charges the device and transfers data such as documents, music, and video b etween your device and a PC. Headset Port Connect earphones to this port for hands-free capabilities. You may also t o listen to music or FM radio. Front Camera A high-resolution front camera to tak e pictures and video. This option is i deal for self-portraits. Rear Camera A high-resolution rear camera to take pictures and video. Flash Provides light for pictures in low-light conditions. It also may be used as a flashlight. Camera Button Launches the phones camera. INTRODUCTION Installation of the SIM CardWarning: Please keep the SIM card out of the reach of children. The SIM card and its con tact are easily damaged due to scratching or bending. Please use caution when carrying, in stalling, or taking out the SIM card. Note: Please contact your cellular phone service provider directly to obtain yo ur SIM card. To insert SIM card:  Remove the rear cover. Insert the SIM card.  Insert the SD card (For additional storage capacity)  Insert the battery, replace the rear cover and power on the phone. SIM Card Slot DEVICE CONFIGURATION When you initially power on your phone, there will be a series of steps to set up basic features. INSERT SIMInsert your SIM card so the phone can register to the network.SELECT LANGUAGEWhile on the Welcome screen, please scroll to select your language. In this step, you also have the option to adjust Vision Settings such as magnification, font, and display size. Y ou have the ability to place an Emergency Call.CONNECT TO WI-FIThis step allows the device to connect to the internet. Click on the desired Wi-Fi network that the device that will be connected. Please note that any unsecured Wi-Fi networks can b e connected to without credentials and any secured Wi-Fi networks require a password for credent ials prior to connection. It is recommended that you connect to a Wi-Fi network to check for software updat es prior to startup to avoid any data overages.COPY APPS & DATAThis step allows you to select transfer options such as applications, pict ures, music and more from a previous device. You may also setup as new if you choose not to from a previou s device. ADD YOUR ACCOUNTSign in to your Google TM Account in order to keep accounts streamlined with Google services. Your a ccount will be used for Google programs such as Google Play TM , Google Drive, and Google Pay. If you do not have a Google account, click to create a new account. If the device is not recogni zed by your Google account, you will have to complete a security verification. GOOGLE SERVICESClick to add Google services that include Backup and Restore, Location Ser vices, Install Updates and Apps.DEVICE PROTECTIONClick to setup device protection such as a PIN or Password. This option can b edoneatalatertime. FINALIZE SETUPThe last step allows you to setup Google Assistant. You may also add another email address, control what information is visible through the phones lock screen, and lets you also re view any additional apps. You may skip this step and setup later. SOBRE SU TELÉFONO Google, Google Play, Google Maps, YouTube, Gmail, and other marks are trad emarks of Google LLC. Seguridad de TransporteSiga todas las leyes y regulaciones de transporte. MANEJE RESPONSABLEMENTE - NO USE MENSAJERIA DE TEXTO CUANDO CONDUCIENDO Seguridad de HospitalesSiga todas las leyes y regulaciones de hospital y apague su teléfono móvil c uando cerca de instrumentos médicos.Seguridad de AeropuertosPor favor, siga todas las normas de seguridad de vuelo y de aeropuerto.Prueba de AguaEl teléfono móvil no es impermeable. Manténgalo alejado de agua o líquidos para evitar daño. Ll…

Text truncated - open the document above for the full version.

BLU Products, Inc. To: Federal Communications CommissionDate: 2023/07/10 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section2.911(d)(5)(i)andSection2.911(d)(5)(ii) (KDB986446D01CoveredEquipment) Section2.911(d)(5)(i) BLU Products, Inc.certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section2.911(d)(5)(ii) BLU Products, Inc.certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as anentity producing “covered” equipment. Type of Equipment subject to FCCCertification:Smart Phone FCC ID:YHLBLUG33U92 If you have any questions, please feel free to contact me Contact Person:Zeng Wei Position in the Company: Senior Manager Date of Signature:2023-07-10 ___________________________ Signatory (signature of the applicant)

BLU Products, Inc. Certification Designating a U.S. Agent for Service of Process Date: 2023-07-10 Ref: Section 2.911(d)(7) filing FCC ID: YHLBLUG33U92 FRN: 0019890946 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA BLU Products, Inc. as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC ID. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Contact Person: Zeng Wei Company Name: BLU Products, Inc. Company Address: 8600 NW 36th Street, Suite #200 Doral, FL 33166, USA Email: [email protected] Sincerely yours, Applicant Company (grantee) Contact Person: Zeng Wei Company Name: BLU Products, Inc. Company Address: 8600 NW 36th Street, Suite #200 Doral, FL 33166, USA Email: [email protected]

BLU Products, Inc. Date:2023/07/10 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The BLU Products, Inc., the undersigned, hereby authorizes Mrs. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the BLU Products, Inc. solely in matters relating to the application for an FCC equipment authorization for FCC ID: YHLBLUG33U92 including the signing of documents in connection with this Application. Necessary acts carried out Shenzhen Morlab Communications Technology Co., Ltd. on our behalf of the BLU Products, Inc. in connection with the Application shall have the same effect as acts of the BLU Products, Inc.. BLU Products, Inc. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name:Wei Zeng Title:Senior Manager Tel:3057157171 Email:[email protected] Company name: BLU Products, Inc.

BLU Products, Inc. Date: 2023/07/10 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality for FCC ID: YHLBLUG33U92 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules (CFR 47), and Section 552(b)(4) of the Freedom of Information Act, BLU Products, Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days from grant date as outlined in Public Notice DA04-1705. This provision will give BLU Products, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 BOM 5 Tune up procedure SHORT-TERM 6 External Photos 7 Internal Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory： Contact name:Wei Zeng Title:Senior Manager Tel:3057157171 Email:[email protected] Company name: BLU Products, Inc.

BLU Products, Inc. UNII Declaration Letter We have declared below featured for FCC equipment authorization, device FCC ID:YHLBLUG33U92 (1) DFS Device -- Master, Client with Radar detection capability , Client without radar detection capability, N/A (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 2412 – 2472 MHz Yes, No Yes, No Yes, No Yes, No 2422 – 2462 MHz Yes, No Yes, No Yes, No Yes, No 5745 – 5825 MHz Yes, No Yes, No Yes, No Yes, No 5755 – 5795 MHz Yes, No Yes, No Yes, No Yes, No 5180 – 5240 MHz Yes, No Yes, No Yes, No Yes, No 5190 – 5230 MHz Yes, No Yes, No Yes, No Yes, No 5260 – 5320 MHz Yes, No Yes, No Yes, No Yes, No 5270 – 5310 MHz Yes, No Yes, No Yes, No Yes, No 5500 – 5700 MHz Yes, No Yes, No Yes, No Yes, No 5510 – 5670 MHz Yes, No Yes, No Yes, No Yes, No (3) Country code selection ability - Yes , No If no, pls explain how was implemented : Country is selected as US by default and user can not change the country code. (4) Meet 15.202 requirement - Yes , No , pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply , No Apply , (If apply , pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) The device configuration can not be modified by user as program is not exposed to user by any means. Hardware does not allow USB connection for user which is must to change the configuration. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Printed Name : Zeng Wei Position : Senior Manager

FCC ID: YHLBLUG33U92 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

Label： Location：(Insidethebatterycompartment) BackView

FCC ID: YHLBLUG33U92 Internal Photos 1. EUT uncover view 2. Antenna view

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Annex C Plots of System Performance Check Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.9 System Check_750MHz_Head Communication System: UID 0, CW (0); Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750 Medium parameters used: f = 750 MHz; σ = 0.919 S/m; ε r = 42.139; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(10.45, 10.45, 10.45) @ 750 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) CW750/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.43 W/kg CW750/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 51.31 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 3.41 W/kg SAR(1 g) = 2.17 W/kg; SAR(10 g) = 1.45 W/kg Maximum value of SAR (measured) = 2.43 W/kg 0 dB = 2.43 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.11 System Check_900MHz_Head Communication System: UID 0, CW (0); Frequency: 900 MHz;Duty Cycle: 1:1 Medium: HSL_900 Medium parameters used: f = 900 MHz; σ = 0.992 S/m; ε r = 42.096; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(10, 10, 10) @ 900 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) CW900/Area Scan (71x71x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 1.80 W/kg CW900/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 43.63 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 2.46 W/kg SAR(1 g) = 2.87 W/kg; SAR(10 g) = 1.9 W/kg Maximum value of SAR (measured) = 1.76 W/kg 0 dB = 1.76 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.14 System Check_1800MHz_Head Communication System: UID 0, CW (0); Frequency: 1800 MHz;Duty Cycle: 1:1 Medium: HSL_1800 Medium parameters used: f = 1800 MHz; σ = 1.401 S/m; ε r = 39.03; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(8.4, 8.4, 8.4) @ 1800 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) CW1800/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 7.73 W/kg CW1800/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 72.68 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 12.4 W/kg SAR(1 g) = 10.02 W/kg; SAR(10 g) = 5.26 W/kg Maximum value of SAR (measured) = 7.50 W/kg 0 dB = 7.50 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.17 System Check_2000MHz_Head Communication System: UID 0, CW (0); Frequency: 2000 MHz;Duty Cycle: 1:1 Medium: HSL_2000 Medium parameters used: f = 2000 MHz; σ = 1.423 S/m; ε r = 39.631; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.2 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(8.13, 8.13, 8.13) @ 2000 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) CW2000/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 7.97 W/kg CW2000/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 75.51 V/m; Power Drift = -0.18 dB Peak SAR (extrapolated) = 13.3 W/kg SAR(1 g) = 10.53 W/kg; SAR(10 g) = 5.33 W/kg Maximum value of SAR (measured) = 7.89 W/kg 0 dB = 7.89 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.20 System Check_2450MHz_Head Communication System: UID 0, CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL_2450 Medium …

Text truncated - open the document above for the full version.

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Annex D Plots of Maximum SAR Test Results Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.11 GSM850_GPRS(4 TX slots)_Right Cheek_Ch189 Communication System: UID 0, GSM850(class 12) (0); Frequency: 836.4 MHz;Duty Cycle: 1:2.08 Medium: HSL_900 Medium parameters used: f = 836.4 MHz; σ = 0.924 S/m; ε r = 42.368; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(10.45, 10.45, 10.45) @ 836.4 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Ch189/Area Scan (71x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.213 W/kg Ch189/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.933 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 0.235 W/kg SAR(1 g) = 0.184 W/kg; SAR(10 g) = 0.142 W/kg Maximum value of SAR (measured) = 0.213 W/kg 0 dB = 0.213 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.14 GSM1900_GPRS(4 TX slots)_Right Cheek_Ch661 Communication System: UID 0, PCS1900(class 12) (0); Frequency: 1880 MHz;Duty Cycle: 1:2.08 Medium: HSL_1900 Medium parameters used: f = 1880 MHz; σ = 1.455 S/m; ε r = 40.159; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(8.11, 8.11, 8.11) @ 1880 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Ch661/Area Scan (71x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.370 W/kg Ch661/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 7.705 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 0.462 W/kg SAR(1 g) = 0.253 W/kg; SAR(10 g) = 0.147 W/kg Maximum value of SAR (measured) = 0.344 W/kg 0 dB = 0.344 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.14 WCDMA Band II_RMC 12.2Kbps_Right Cheek_Ch9262 Communication System: UID 0, UMTS-FDD (0); Frequency: 1852.4 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1852.4 MHz; σ = 1.429 S/m; ε r = 40.061; ρ = 1000 kg/m 3 Ambient T emperature： 23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(8.11, 8.11, 8.11) @ 1852.4 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Ch9262/Area Scan (71x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 1.01 W/kg Ch9262/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 12.35 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 1.23 W/kg SAR(1 g) = 0.667 W/kg; SAR(10 g) = 0.384 W/kg Maximum value of SAR (measured) = 0.908 W/kg 0 dB = 0.908 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.6.14 WCDMA Band IV_RMC 12.2Kbps_Right Cheek_Ch1413 Communication System: UID 0, UMTS-FDD (0); Frequency: 1732.6 MHz;Duty Cycle: 1:1 Medium: HSL_1800 Medium parameters used: f = 1733 MHz; σ = 1.38 S/m; ε r = 41.367; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7608; ConvF(8.4, 8.4, 8.4) @ 1733 MHz; Calibrated: 2023.3.15 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1643; Calibrated: 2023.2.22 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Ch1413/Area Scan (71x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.858 W/kg Ch1413/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 12.17 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 1.07 W/kg SAR(1 g) = 0.578 W/kg; SAR(10 g) = 0.329 W/kg Maximum value of SAR (measured) = 0.758 W/kg 0 dB = 0.758 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Test Laboratory: Shenzhen Morlab Communic…

Text truncated - open the document above for the full version.

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 Annex E Conducted Power Note: Conducted power unit: dBm The target power was recorded in the manufacture document. 128189251128189251 824.2836.4848.8824.2836.4848.8 31.9031.9531.8833.0022.9022.9522.8824.00 31.9331.9731.9033.0022.9322.9722.9024.00 31.2131.0731.1832.0025.2125.0725.1826.000.14 29.7229.5229.5230.5025.4625.2625.2626.240.20 28.4728.5428.3229.5025.4725.5425.3226.500.22 28.0128.0727.9529.0019.0119.0718.9520.000.12 26.8927.0326.9328.0020.8921.0320.9322.000.14 24.6124.6524.5825.5020.3520.3920.3221.240.07 23.6823.7523.7124.5020.6820.7520.7121.500.07 Max.31.97Max.25.54 512661810512661810 1850.218801909.81850.218801909.8 30.0730.1130.0231.0021.0721.1121.0222.00 30.1130.1530.0531.0021.1121.1521.0522.00 29.5029.5229.4530.5023.5023.5223.4524.500.07 27.7127.8127.7628.5023.4523.5523.5024.240.10 26.5426.6826.5527.5023.5423.6823.5524.500.14 24.7424.9324.9026.0015.7415.9315.9017.000.19 23.6523.8423.7424.5017.6517.8417.7418.500.19 21.4621.5421.5022.5017.2017.2817.2418.240.08 20.3320.5120.4821.5017.3317.5117.4818.500.18 Max.30.15Max.23.68 926294009538131214131513413241824233 966298009938153716381738435744074458 1852.418801907.61712.41732.61752.6826.4836.4846.6 3GPP Rel 99RMC 12.2Kbps23.3823.4223.3224.5023.3523.4023.3424.5023.0723.1323.1024.00 3GPP Rel 5HSDPA Subtest-120.4420.1620.2021.0022.4722.5722.4023.5020.4720.3720.3421.50 3GPP Rel 5HSDPA Subtest-219.0118.9618.9320.0020.9320.7420.8022.0019.6419.7219.5120.50 3GPP Rel 5HSDPA Subtest-317.5917.4717.3618.5019.1419.3919.6220.0018.1218.1418.3219.00 3GPP Rel 5HSDPA Subtest-417.1917.3417.2918.5019.3919.1419.1220.0017.4017.5117.5318.50 3GPP Rel 6HSUPA Subtest-118.3718.1118.1520.0018.3118.4218.2120.0018.4818.3918.3319.50 3GPP Rel 6HSUPA Subtest-218.3618.1318.1720.0018.2918.4218.2319.0018.4518.3918.3519.50 3GPP Rel 6HSUPA Subtest-319.4019.1219.1420.0019.2619.3619.1820.0019.4119.3619.3020.50 3GPP Rel 6HSUPA Subtest-417.9217.6717.6818.0017.8217.9517.7118.0017.9717.8717.8719.00 3GPP Rel 6HSUPA Subtest-519.4219.1619.1620.0019.2319.3719.1720.0019.4119.5119.4720.50 3GPP Rel 7HSPA+ (16QAM) Subtest-121.5021.5221.5622.5021.4121.5621.4622.5021.3821.4321.3222.50 Cable Loss0.8Cable Loss0.8Cable Loss0.6 Max.23.42Max.23.40Max.23.13 Tune-up Limit (dBm) Mode Attenuator Tune-up Limit (dBm) Tune-up Limit (dBm) Tune-up Limit (dBm) BandWCDMA Band II (dBm)WCDMA Band IV (dBm)WCDMA Band V (dBm) TX Channel Rx Channel Frequency (MHz) Mode AttenuatorCable Loss : 0.8 EDGE 4 Tx slots EDGE 1 Tx slot EDGE 2 Tx slots EDGE 3 Tx slots GPRS 2 Tx slots GPRS 3 Tx slots GPRS 4 Tx slots GSM1900Burst Average Power (dBm)Frame-Average Power (dBm) TX Channel Frequency (MHz) GSM 1 Tx slot GPRS 1 Tx slot Tune-up Limit (dBm) Ch Delta > 0.5 0.13 Mode AttenuatorCable Loss : 0.6 EDGE 2 Tx slots EDGE 3 Tx slots EDGE 4 Tx slots GPRS 3 Tx slots GPRS 4 Tx slots EDGE 1 Tx slot Frequency (MHz) GSM 1 Tx slot GPRS 1 Tx slot GPRS 2 Tx slots Tune-up Limit (dBm) Tune-up Limit (dBm) Ch Delta > 0.5 0.09 GSM850 Burst Average Power (dBm)Frame-Average Power (dBm) TX Channel Full Power MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ23060021S01 BW [MHz]ModulationRB SizeRB Offset Low Channel Middle Channel High Channel BW [MHz] ModulationRB SizeRB Offset Low Channel Middle Channel High Channel 187001890019100200502017520300 18601880190017201732.51745 20QPSK1023.3223.3523.2620QPSK1023.2823.3523.30 20QPSK14923.5223.5723.5020QPSK14923.5623.6223.58 20QPSK19923.2823.3123.2520QPSK19923.3323.3423.24 20QPSK50022.5422.6122.5820QPSK50022.6822.7522.72 20QPSK502422.5022.5722.5320QPSK502422.6622.6822.60 20QPSK505022.5422.5522.5020QPSK505022.6…
