YHLBLUN3USmart Phone

N3 Quick Guide | Guía Rápida | Guía Rápido | Guide Rapide o For instructions or any questions pertaining to phone usage, please click on the BLU page by visiting the following address: https://boldphone.com o Para obtener instrucciones o preguntas relacionadas con el uso del teléfono, por favor haga clic en la página de BLU visitando la siguiente dirección: https://boldphone.com o Para obter instruções ou perguntas relacionadas ao uso do telefone, por favor, clique na página de BLU visitando o seguinte endereço: https://boldphone.com o Pour des instructions ou pour toutes questions sur l'utilisation du téléphone, veuillez cliquer sur à la page BLU en visitant l'adresse suivante: https://boldphone.com ATTENTION ABOUT YOUR PHONE Transportation Safety Observe all transportation laws and regulations. PLEASE DRIVE RESPONSIBLY - DO NOT TEXT & DRIVE Hospital Safety Follow hospital rules and limitations and turn off your mobile phone when near medical instruments. Airport Safety Remember to follow all airport and flight safety regulations. Water Hazard Your phone is not waterproof. Keep your phone away from water or liquid to avoid damage. Emergency Calls Make sure your mobile phone is switched on and in a service area. On home screen, tap the phone key and dial the emergency number. Battery Usage For better performance and longer battery life, it is recommended that you charge the battery fully before using the mobile phone for the first time and that you initially complete two to three charge cycles. IMEI Information To check your IMEI, press *#06#. KEY FUNCTIONS Volume Power On / Off Back Home Recent Apps Front Camera Fingerprint Sensor (On Touch panel) Rear Camera (Multiple Sensors) Flash Power On / Off Used to power on/off the device and to lock the screen. » Long press the power button to power on » While the phone is powered on, long press to access the power off menu or click to lock the screen Volume Adjusts the ringer volume, call volume, and multimedia volume. Home The home button pauses any current action and returns to the home screen. Recent Apps Opens a list of recently opened applications that allows you to switch conveniently between them. This option can also close any open applications by swiping to the side. Back Returns to the previous screen; Closes the keyboard, any open program, or any menu option. USB Port Charges the device and transfers data such as documents, music, and video between your device and a PC. Headset Port Connect earphones to this port for hands-free capabilities. You may also to listen to music or FM radio. Front Camera A high-resolution front camera to take pictures and video. This option is ideal for self-portraits. Rear Camera A high-resolution rear camera to take pictures and video. Flash Fingerprint Sensor Provides light for pictures in low-light conditions. It also may be used as a flashlight (Rear). Security measure that unlocks your device with the User’s fingerprints. INTRODUCTION Installation of the SIM Card Warning: Please keep the SIM card out of the reach of children. The SIM card and its contact are easily damaged due to scratching or bending. Please use caution when carrying, installing, or taking out the SIM card. Note: Please contact your cellular phone service provider directly to obtain your SIM card. To insert SIM card:  Remove the SIM card tray (with tool). Insert the SIM card.  Replace the SIM card tray and power on the phone. DEVICE CONFIGURATION When you initially power on your phone, there will be a series of steps to set up basic features. INSERT SIM Insert your SIM card so the phone can register to the network. SELECT LANGUAGE While on the Welcome screen, please scroll to select your language. In this step, you also have the option to adjust Vision Settings such as magnification, font, and display size. You have the ability to place an Emergency Call. SELECT WI-FI This step allows the device to connect to the internet. Click on the desired Wi-Fi network that the device that will be connected. Please note that any unsecured Wi-Fi networks can be connected to without credentials and any secured Wi-Fi networks require a password for credentials prior to connection. It is recommended that you connect to a Wi-Fi network to check for software updates prior to startup to avoid any data overages. COPY APPS & DATA This step allows you to select transfer options such as applications, pictures, music and more from a previous device. You may also setup as new if you choose not to from a previous device. ADD YOUR ACCOUNT Sign in to your Google TM Account in order to keep accounts streamlined with Google services. Your account will be used for Google programs such as Google Play, Google Drive, and Google Pay. If you do not have a Google account, click to create a new account. If the device is not recognized by your Google account, you will have to complete a security verification. GOOGLE SERVICES Click to add or remove Google services that include Backup and Restore, Location Service, Install Updates and Apps. SET DEVICE SECURITY Setup your fingerprint to unlock your phone and for authorization on certain applications. There will be three options to setup fingerprint security: with PIN, Password or Pattern. In this step, you will have the ability to setup a PIN at startup as an extra layer of security. You also have the option of skipping the fingerprint setup and completing it at a later time. You can also setup face unlock during this process. FINALIZE SETUP The last step allows you to set up Google Assistant. It also allows you to add another email address. You can also control what information is visible through the phones lock screen and lets you also review any additional apps. You may skip this step and setup later. SOBRE SU TELÉFONO Google, Google Play, Google Maps, YouTube, Gmail, and other marks are trademarks of Google LLC. Seguridad de Transporte Siga todas las leyes y regulaciones de transporte. MANEJE RESPONSABLEMENTE - NO US…

Text truncated - open the document above for the full version.

BLU Products, Inc. 8600 NW 36th Street, Suite #200 Doral, FL 33166, United States Date: 2023-06-29 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d) (5) (i) Filing SUBJECT: FCC Application for FCC ID: YHLBLUN3U To Whom It May Concern: BLU Products, Inc. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signatory [Wei Zeng, Senior Manager]

BLU Products, Inc. 8600 NW 36th Street, Suite #200 Doral, FL 33166, United States Date: 2023-06-29 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d) (5) (ii) Filing SUBJECT: FCC Application for FCC ID: YHLBLUN3U To Whom It May Concern: BLU Products, Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signatory [Wei Zeng, Senior Manager]

BLU Products, Inc. 8600 NW 36th Street, Suite #200 Doral, FL 33166, United States Rev 1/26/2023 Date: 2023-06-29 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d) (7) Filing Grantee Code: YHL BLU Products, Inc. certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. BLU Products, Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Designated U.S. Agent Information: Name: BLU Products, Inc. FRN: 0019890946 Address: 8600 NW 36th Street, Suite #200 Doral, FL 33166, United States Contact Person: Wei Zeng Tel.: 3057157171 Email: [email protected] Sincerely, Signatory [Wei Zeng, Senior Manager]

BLU Products, Inc. 8600 NW 36th Street, Suite #200 Doral, FL 33166, United States Date: 2023-06-29 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: YHLBLUN3U Confidentiality Request To whom it may concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. ☒ Block Diagram ☒ Tune-Up Information ☒ Operational Description ☒ Security Information ☒ Schematics ☐ Software Defined Radio (SDR) Information ☒ Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ User Manual ☐ For 45 days, pursuant to Public Notice DA 04-1705. or ☐ For 180 days pursuant to KDB 726920 D01. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signatory [Wei Zeng, Senior Manager]

BLU Products, Inc. 8600 NW 36th Street, Suite #200 Doral, FL 33166, United States Date: 2023-06-29 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: YHLBLUN3U POWER OF ATTORNEY To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, BLU Products, Inc. are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Signatory [Wei Zeng, Senior Manager]

Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 2 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 3 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 4 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 5 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7

Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 1 of 13 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 6 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 7 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 8 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 9 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 5 Solder Board-Component View 6 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 10 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 7 Solder Board-Component View 8 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 11 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 9 Antenna View 1 Reference No.: WTX23X05095991W001/002/003/004/005/006/007/008/009/010/011 Page 12 of 15 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View 2

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 36 TEST REPORT Reference No. .................... : WTX23X05095991W012 FCC ID ................................ : YHLBLUN3U Applicant ........................... : BLU Products, Inc. Address ............................. : 8600 NW 36th Street, Suite #200,Doral, FL 33166,USA Manufacturer ..................... : The same as Applicant Address ............................. : The same as Applicant Product Name ................... : Smart Phone Model No. ........................... : N3 Standards .......................... : FCC PART15 SUBPART B Date of Receipt sample .... : 2023-05-05 Date of Test........................ : 2023-05-05 to 2023-06-14 Date of Issue ..................... : 2023-06-15 Test Report Form No. ....... : WTX_FCC PART15B_001 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jason Su Silin Chen Reference No.: WTX23X05095991W012 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 36 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................... 5 1.3 TEST METHODOLOGY ............................................................................................................................................. 5 1.4 TEST FACILITY ....................................................................................................................................................... 5 1.5 EUT SETUP AND OPERATION MODE ...................................................................................................................... 6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 1.7 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 10 3. CONDUCTED EMISSIONS .................................................................................................................................. 11 3.1 TEST PROCEDURE ................................................................................................................................................. 11 3.2 BASIC TEST SETUP BLOCK DIAGRAM ................................................................................................................... 11 3.3 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 11 3.4 SUMMARY OF TEST RESULTS ............................................................................................................................... 11 4. RADIATED EMISSION ......................................................................................................................................... 14 4.1 TEST PROCEDURE ................................................................................................................................................. 14 4.2 BLOCK DIAGRAM OF TEST SETUP ........................................................................................................................ 14 4.3 TEST RECEIVER SETUP ......................................................................................................................................... 15 4.4 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................................ 15 4.5 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 15 4.6 SUMMARY OF TEST RESULTS ............................................................................................................................... 15 APPENDIX PHOTOGRAPHS ................................................................................................................................... 36 Reference No.: WTX23X05095991W012 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 36 Report version Version No. Date of issue Description Rev.00 2023-06-15 Original / / / Reference No.: WTX23X05095991W012 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 36 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) General Description of EUT Product Name: Smart Phone Trade Name: BLU Model No.: N3 Adding Model(s): / Note: The test data is gathered from a production sample, provided by the manufacturer. Technical Characteristics of EUT Rated Voltage: DC3.87V Rated Current: / Rated Power: / Adapter Model: US-KB-PD66W01 Input:AC100-240v~50/60Hz 1.5A Output:DC5V3A;DC9V3A;DC12V3A;DC15V3A;DC20V3.25A; DC11V6A Lowest Internal Frequency: 26MHz Highest Internal Frequency: 5825MHz Classification of ITE: Class B Reference No.: WTX23X05095991W012 Waltek …

Text truncated - open the document above for the full version.

Reference No.: WTX23X05095991W012 Page 11 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test View (30MHz to 1GHz) Reference No.: WTX23X05095991W012 Page 12 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test View (Above 1GHz) ***** END OF REPORT *****
