YHLBLUSTX5Mobile Phone

-1- Content 1 General Information ...................................................................................................................................................... 3 1.1 Profile ................................................................................................................................................................................ 3 1.2 Safety warning and Attentions .......................................................................................................................................... 3 2 Your phone ..................................................................................................................................................................... 6 2.1 Phone overview ................................................................................................................................................................. 6 2.2 Functions of Keys ............................................................................................................................................................. 7 2.3 Functions of icons ............................................................................................................................................................. 7 3 Getting started ............................................................................................................................................................... 8 3.1 Installing the SIM Card and the Battery ........................................................................................................................... 8 3.2 Charging the Battery ......................................................................................................................................................... 9 3.3 Linking to the Networks and devices .............................................................................................................................. 10 3.4 Using the touch screen .................................................................................................................................................... 12 3.5 Using the onscreen keypad ............................................................................................................................................. 13 3.6 Dialing Calls ................................................................................................................................................................... 13 4 Using the Menus........................................................................................................................................................... 14 -2- 4.1 Browser ........................................................................................................................................................................... 15 4.2 Calculator ........................................................................................................................................................................ 15 4.3 Calendar .......................................................................................................................................................................... 15 4.4 Call History ..................................................................................................................................................................... 16 4.5 CallFireWall .................................................................................................................................................................... 17 4.6 Camera ............................................................................................................................................................................ 17 4.7 Clock ............................................................................................................................................................................... 17 4.8 Contacts .......................................................................................................................................................................... 17 4.9 Downloads ...................................................................................................................................................................... 18 4.10 Email ............................................................................................................................................................................. 18 4.11 File Explorer ................................................................................................................................................................. 19 4.12 FM Radio ...................................................................................................................................................................... 19 4.13 Gallery .......................................................................................................................................................................... 19 4.14 Messaging ..................................................................................................................................................................... 20 4.15 Music ............................................................................................................................................................................ 20 4.16 Note ............................................................................................................................................................................... 22 4.17 Phone ............................................................................................................................................................................ 22 4.18 Search .....................................................................................................................…

Text truncated - open the document above for the full version.

BLU Products, Inc. Agent Authorization Company: BLU Products, Inc. Address: 10814 NW 33rd St # 100 Doral, FL 33172, USA Product Name: Mobile Phone Model Number(s): STUDIO X5 Product Description: Mobile Phone FCC ID: YHLBLUSTX5 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022.03.31 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

BLU Products, Inc. Authorization Letter We, (the approval holder) Company name BLU Products, Inc. Addresss 10814 NW 33rd St # 100 Doral, FL 33172, USA declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Micom Labs for product certification below Product Description Mobile Phone Type or Model(s) STUDIO X5 Tradename or Brand(s) BLU Attestation: City: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Shenzhen 2022.03.31 Jiankuai Li PM

BLU Products, Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022.03.31 Subject; Request for Confidentiality FCC ID: YHLBLUSTX5 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Shenzhen STS Test Services Co., Ltd. Title: PM

Page 1 of 4 Report No.: STS2201225 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 4 Report No.: STS2201225 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2201225 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2201225 Photo 7

FCC Label Mobile Phone Model name: STUDIO X5 FCC ID: YHLBLUSTX5 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 50mm 40mm

Page 1 of 7 Report No.: STS2201225 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 LTE RX Antenna BT/WIFI/GPS Antenna GSM/WCDMA/LTE Antenna Page 2 of 7 Report No.: STS2201225 Photo 3 Photo 4 Page 3 of 7 Report No.: STS2201225 Photo 5 Photo 6 Page 4 of 7 Report No.: STS2201225 Photo 7 Photo 8 Page 5 of 7 Report No.: STS2201225 Photo 9 Photo 10 Page 6 of 7 Report No.: STS2201225 Photo 11 Photo 12 Page 7 of 7 Report No.: STS2201225 Photo 13

Ref : ACR.262.4.20.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING 2, ZHUOKE SCIENCE PARK,No.190, CHONGQING ROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONG,CHINA MVG COMOSAR REFERENCE DIPOLE FREQUENCY: 750 MHZ SERIAL NO.: SN 30/14 DIP0G750-331 SAR Reference Dipole Calibration Report Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise - 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 07/14/2020 Summary: This document presents the method and results from an accredited SAR reference dipole calibration performed in MVG. using the CALIPROBE test bench. for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units(SI). Page: 1/11 SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.4.20.MVGB.A Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Name Function Date Signature Prepared by : Jérôme LUC Technical Manager 7/28/2020 Checked by : Jérôme LUC Technical Manager 7/28/2020 Approved by : Yann Toutain Laboratory Director 7/28/2020 Issue Date Modifications A 7/28/2020Initial release Name Jérôme LUC Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.4. TABLE OF CONTENTS 1 Introduction ................................................................................................................ 4 2 Device Under Test ..................................................................................................... 4 3 Product Description ................................................................................................... 4 3.1 General Information _______________________________________________________ 4 4 Measurement Method ................................................................................................ 5 4.1 Return Loss Requirements __________________________________________________ 5 4.2 Mechanical Requirements ___________________________________________________ 5 5 Measurement Uncertainty .......................................................................................... 5 5.1 Return Loss ______________________________________________________________ 5 5.2 Dimension Measurement ___________________________________________________ 5 5.3 Validation Measurement ____________________________________________________ 5 6 Calibration Measurement Results .............................................................................. 6 6.1 Return Loss and Impedance In Head Liquid ____________________________________ 6 6.2 Return Loss and Impedance In Body Liquid ____________________________________ 6 6.3 Mechanical Dimensions ____________________________________________________ 6 7 Validation measurement ............................................................................................ 7 7.1 Head Liquid Measurement __________________________________________________ 7 7.2 SAR Measurement Result With Head Liquid ____________________________________ 8 7.3 Body Liquid Measurement __________________________________________________ 9 7.4 SAR Measurement Result With Body Liquid __________________________________ 10 8 List of Equipment .................................................................................................... 11 Page: 3/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. MVGB.A 20. Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.4.20.MVGB.A 1 INTRODUCTION This document contains a summary of the requirements set forth by the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards for reference dipoles used for SAR measurement system validations and the measurements that were performed to verify that the product complies with the fore mentioned standards. 2 DEVICE UNDER TEST Device Under Test Device Type COMOSAR 750 MHz REFERENCE DIPOLE Manufacturer MVG Model SID750 Serial Number SN 30/14 DIP0G750-331 Product Condition (new / used) Used A yearly calibration interval is recommended. 3 PRODUCT DESCRIPTION 3.1 GENERAL INFORMATION MVG’s COMOSAR Validation Dipoles are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. The product is designed for use with the COMOSAR test bench only. Figure 1 – MVG COMOSAR Validation Dipole Page: 4/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262.4.20.MVGB.A 4 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards provide requirements for reference dipoles used for system validation measurements. The following measurements were performed to verify that the product complies with the fore mentioned standards. 4.1 RETURN LOSS REQUIREMENTS The dipole used for SAR system validation measurements and checks must have a return loss of -20 dB or better. The return loss measurement shall be performed against a liquid filled flat phantom, with the phantom constucted as outlined in the fore mentioned standards. 4.2 MECHANICAL REQUIREMENTS The IEEE Std. 1528 and CEI/IEC 62209 standards specify the mechanical components and dimensions of the validation dipoles, with the dimensions frequency an…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2201225H01 Issued for BLU Products, Inc. 10814 NW 33rd St # 100 Doral, FL 33172, USA Product Name: Mobile Phone Brand Name: BLU Model Name: STUDIO X5 Series Model: N/A FCC ID: YHLBLUSTX5 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Head: 0.925 W/kg Body: 1.327 W/kg S T L A B S Page 2 of 126 Report No.: STS2201225H01 Test Report Certification Applicant’s name ................. : BLU Products, Inc. Address ................................. : 10814 NW 33rd St # 100 Doral, FL 33172, USA Manufacturer's Name .......... : BLU Products, Inc. Address ................................. : 10814 NW 33rd St # 100 Doral, FL 33172, USA Product description Product name ........................ : Mobile Phone Brand name ......................... : BLU Model name ......................... : STUDIO X5 Series Model .......................... : N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ............................................ : Date (s) of performance of tests ............. : 14 Feb. 2022 ~ 28 Feb. 2022 Date of Issue ........................................... : 29 Mar. 2022 Test Result ............................................... : Pass Testing Engineer : (Shifan. Long) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 126 Report No.: STS2201225H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 15 5.1 Validation System 15 5.2 Validation Result 15 6. SAR Evaluation Procedures 16 7. EUT Antenna Location Sketch 17 7.1 SAR test exclusion consider table 18 8. EUT Test Position 24 8.1 Define Two Imaginary Lines on the Handset 24 8.2 Hotspot mode exposure position condition 25 9. Uncertainty 26 9.1 Measurement Uncertainty 26 10. Conducted Power Measurement 27 10.1 Test Result 27 11. EUT and Test Setup Photo 49 11.1 EUT Photo 49 11.2 Setup Photo 52 12. SAR Result Summary 58 12.1 Head SAR 58 12.2 Body-worn and Hotspot SAR 62 12.3 repeated SAR measurement 69 13. Equipment List 73 Appendix A. System Validation Plots 74 Appendix B. SAR Test Plots 92 Appendix C. Probe Calibration and Dipole Calibration Report 126 Page 4 of 126 Report No.: STS2201225H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 29 Mar. 2022 STS2201225H01 ALL Initial Issue Page 5 of 126 Report No.: STS2201225H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Mobile Phone Brand Name BLU Model Name STUDIO X5 Series Model N/A Model Difference N/A Battery Rated Voltage:3.7V Charge Limit Voltage:4.2V Capacity: 2000mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled IMEI IMEI 1: 359588046382896/78 IMEI 2: 359588046382900/78 Hardware Version HCT-M896MB-A2 Software Version Bom3-cts-go-Blu-Latin_V1_S01_20220105_user_20220105_temp Frequency Range GSM 850: 824 MHz ~ 849 MHz PCS1900: 1850 MHz ~ 1910 MHz WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band IV:1710 MHz ~ 1755 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 7:2500 MHz ~ 2570 MHz LTE Band 12: 699 MHz ~ 716 MHz LTE Band 17: 704 MHz ~ 716 MHz LTE Band 66: 1710 MHz ~ 1780 MHz WLAN802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40: 5150 ~ 5250 MHz WLAN 802.11a/n20/n40: 5250 ~ 5350 MHz WLAN 802.11a/n20/n40: 5470 ~ 5725 MHz WLAN 802.11a/n20/n40: 5725 ~ 5850 MHz Bluetooth: 2402 MHz to 2480 MHz Page 6 of 126 Report No.: STS2201225H01 Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode Head (W/kg) Body Worn and Hotspot(W/kg) PCE GSM 850 0.925 1.084 PCE GSM 1900 0.753 0.905 PCE WCDMA Band II 0.514 0.895 PCE WCDMA Band IV 0.664 1.285 PCE WCDMA Band V 0.476 0.584 PCE LTE Band 2 0.563 0.756 PCE LTE Band 4 0.616 1.327 PCE LTE Band 5 0.476 0.611 PCE LTE Band 7 0.858 0.821 PCE LTE Band 12 0.434 0.567 PCE LTE Band 17 0.371 0.580 PCE LTE Band 66 0.619 1.263 DTS 2.4G WLAN 0.025 0.018 DSS BT 0.070 0.185 NII 5.3G WLAN 0.252 0.179 NII 5.6G WLAN 0.296 0.109 NII 5.8G WLAN 0.139 0.062 1-g Sum SAR 1.221 1.512 FCC Equipment Class Licensed Portable Transmitter Held to Ear (PCE) Part 15 Spread Spectrum Transmitter (DSS) Digital Transmission System (DTS) Unlicensed National Information Infrastructure TX(NII) Operating Mode: GSM: GSM Voice; GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM WLAN: 802.11 a/b/g/n20/n40 Bluetooth: GFSK +π/4DQPSK+8DPSK BLE: GFSK Antenna Specification: GSM/WCDMA/…
