YHLBOLDM6Smart Phone (LTE/WCDMA/GSM/BT/WIFI)

-1- Content FCC ID:YHLBOLDM6 1 General Information..................................................................................................................................................... 4 1.1 Profile ............................................................................................................................................................................... 4 1.2 Safety warning and Attentions ......................................................................................................................................... 4 2 Your phone .................................................................................................................................................................... 7 2.1 Phone overview ................................................................................................................................................................ 7 2.2 Functions of Keys............................................................................................................................................................. 7 2.3 Functions of icons ............................................................................................................................................................ 8 3 Getting started .............................................................................................................................................................. 9 3.1 Installing the SIM Card and the Battery ........................................................................................................................... 9 3.2 Charging the Battery ...................................................................................................................................................... 10 3.3 Linking to the Networks and devices .............................................................................................................................. 11 3.4 Using the touch screen ................................................................................................................................................... 13 3.5 Using the onscreen keypad ............................................................................................................................................. 14 3.6 Dialing Calls ................................................................................................................................................................... 14 4 Using the Menus.......................................................................................................................................................... 15 -2- 4.1 Backup Restore .............................................................................................................................................................. 16 4.2 Browser .......................................................................................................................................................................... 16 4.3 Calculator ....................................................................................................................................................................... 18 4.4 Calendar ......................................................................................................................................................................... 19 4.5 Call History .................................................................................................................................................................... 20 4.6 Camera ........................................................................................................................................................................... 20 4.7 Clock .............................................................................................................................................................................. 20 4.8 Downloads ...................................................................................................................................................................... 21 4.9 Email .............................................................................................................................................................................. 21 4.10 Facebook ...................................................................................................................................................................... 22 4.11 File manager ................................................................................................................................................................. 22 4.12 FlashLight .................................................................................................................................................................... 22 4.13 Flipkart ......................................................................................................................................................................... 22 4.14 FM Radio ..................................................................................................................................................................... 22 4.15 Gallery .......................................................................................................................................................................... 23 4.16 Gmail ............................................................................................................................................................................ 23 4.17 Google .......................................................................................................................................................................... 23 4.18 Google settings ..........................................................................................................................…

Text truncated - open the document above for the full version.

BLU Products, Inc. Date: 2020/03/30 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To whom it may concern, The BLU Products, Inc., the undersigned, hereby authorizes Miss. Catherine Chen from Shenzhen Moriah Communications Technology Co., Ltd., to act on the behalf of the BLU Products, Inc. solely in matters relating to the application for an FCC equipment authorization for FCC ID: YHLBOLDM6 including the signing of documents in connection with this Application. Necessary acts carried out Shenzhen Moriah Communications Technology Co., Ltd. on our behalf of the BLU Products, Inc. in connection with the Application shall have the same effect as acts of the BLU Products, Inc .. BLU Products, Inc. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name: Wei Zeng Ti tle: Senior Manager Tel: 3057157171 Email: [email protected] Company name: BLU Products, Inc.

BLU Products, Inc. Date:2020/03/30 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality for FCC ID: YHLBOLDM6 To whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission's Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act, BLU Products, Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA04-1705. This provision will give BLU Products, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Ooerational Description PERMANENT 3 Schematics 4 SOM 5 Tune up procedure 6 External Photos SHORT-TERM 7 Internal Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Yours Sincerely, Signatory: Contact name: Wei Zeng Title: Senior Manager Tel: 3057157171 Email: 双[email protected] Company name: BLU Products, Inc.

FCC ID:YHLBOLDM6 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Ports and slots supported by this device 8. Accessories

BLU Products, Inc. Label Label Location On exterior

FCC ID:YHLBOLDM6 Internal Photos 1. EUT uncover view 2. Antenna view BT/WIFI Antenna WWAN Antenna WWAN DRX Antenna

REPORT No.：SZ20010065S01 Annex C Plots of System Performance Check MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Te l : 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.16 System Check_835MHz_Head Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835 Medium parameters used: f = 835 MHz; σ = 0.912 S/m; ε r = 41.366; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(9.3, 9.3, 9.3); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW835/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.67 W/kg CW835/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 54.18 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 3.77 W/kg SAR(1 g) = 2.31 W/kg; SAR(10 g) = 1.52 W/kg Maximum value of SAR (measured) = 2.67 W/kg 0 dB = 2.67 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.20 System Check_1750MHz_Head Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL_1750 Medium parameters used: f = 1750 MHz; σ = 1.381 S/m; ε r = 40.097; ρ = 1000 kg/m 3 Ambient Temperature：23.1 °C; Liquid Temperature：22.4 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.99, 7.99, 7.99); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW1750/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 11.27 W/kg CW1750/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 77.62 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 14.3 W/kg SAR(1 g) = 9.18 W/kg; SAR(10 g) = 4.97 W/kg Maximum value of SAR (measured) = 11.27 W/kg 0 dB = 11.27 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.18 System Check_1900MHz_Head Communication System: UID 0, CW (0); Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1900 MHz; σ = 1.397 S/m; ε r = 40.033; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW1900/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 11.19 W/kg CW1900/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 88.14 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 17.72 W/kg SAR(1 g) = 9.82 W/kg; SAR(10 g) = 5.21 W/kg Maximum value of SAR (measured) = 12.19 W/kg 0 dB = 12.19 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.19 System Check_2450MHz_Head Communication System: UID 0, CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL_2450 Medium parameters used: f = 2450 MHz; σ = 1.828 S/m; ε r = 39.588; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.4 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.3, 7.3, 7.3); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW2450/Area Scan (101x101x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 14.77 W/kg CW2450/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 90.37 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 30.82 W/kg SAR(1 g) = 13.09 W/kg; SAR(10 g) = 6.11 W/kg Maximum value of SAR (measured) = 14.77 W/kg 0 dB = 14.77 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.17 System Check_2600MHz_Head Communication System: UID 0, CW (0); Frequency: 2600 MHz;Duty Cycle: 1:1 Medium: HSL_2600 Medium parameters used: f = 2600 MHz; σ = 1.986 S/m; ε r = 39.149; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：22.2 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7, 7, 7); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) CW2600/Area Scan (101x101x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 16.15 W/kg CW2600/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 84.79 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 30.62 W/kg SAR(1 g) = 13.49 W/kg; SAR(10 g) = 6.22 W/kg Maximum value of SAR (measured) = 16.15 W/kg 0 dB = 16.15 W/kg

REPORT No.：SZ20010065S01 Annex D Plots of Maximum SAR Test Results MORLAB SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Te l : 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.16 GSM850_GPRS(2 TX slots)_Right Cheek_Ch189 Communication System: UID 0, GSM850(class 10) (0); Frequency: 836.4 MHz;Duty Cycle: 1:4.15 Medium: HSL_835 Medium parameters used: f = 836.4 MHz; σ = 0.904 S/m; ε r = 41.033; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(9.3, 9.3, 9.3); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch189/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.308 W/kg Ch189/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.180 V/m; Power Drift = 0.15 dB Peak SAR (extrapolated) = 0.358 W/kg SAR(1 g) = 0.291 W/kg; SAR(10 g) = 0.226 W/kg Maximum value of SAR (measured) = 0.305 W/kg 0 dB = 0.305 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.18 GSM1900_GPRS(3 TX slots)_Right Cheek_Ch661 Communication System: UID 0, PCS1900(class 11) (0); Frequency: 1880 MHz;Duty Cycle: 1:2.77 Medium: HSL_1900 Medium parameters used: f = 1880 MHz; σ = 1.321 S/m; ε r = 41.384; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch661/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.555 W/kg Ch661/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 1.536 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 0.830 W/kg SAR(1 g) = 0.052 W/kg; SAR(10 g) = 0.031 W/kg Maximum value of SAR (measured) = 0.551 W/kg 0 dB = 0.551 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.18 WCDMA Band II_RMC 12.2Kbps_Right Cheek_Ch9400 Communication System: UID 0, UMTS-FDD (0); Frequency: 1880 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1880 MHz; σ = 1.321 S/m; ε r = 41.384; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch9400/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.532 W/kg Ch9400/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 1.918 V/m; Power Drift = 0.08 dB Peak SAR (extrapolated) = 0.790 W/kg SAR(1 g) = 0.051 W/kg; SAR(10 g) = 0.031 W/kg Maximum value of SAR (measured) = 0.549 W/kg 0 dB = 0.532 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.16 WCDMA Band V_RMC 12.2Kbps_Right Cheek_Ch4183 Communication System: UID 0, UMTS-FDD (0); Frequency: 836.6 MHz;Duty Cycle: 1:1 Medium: HSL_835 Medium parameters used: f = 837 MHz; σ = 0.905 S/m; ε r = 40.944; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(9.3, 9.3, 9.3); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 2; Type: QD000P40CC; Serial: TP:1464 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch4183/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.164 W/kg Ch4183/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.755 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 0.187 W/kg SAR(1 g) = 0.156 W/kg; SAR(10 g) = 0.124 W/kg Maximum value of SAR (measured) = 0.163 W/kg 0 dB = 0.163 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.18 LTE Band 2_20MHz_QPSK_1RB_0Offset_Right Cheek_Ch18900 Communication System: UID 0, LTE (0); Frequency: 1880 MHz;Duty Cycle: 1:1 Medium: HSL_1900 Medium parameters used: f = 1880 MHz; σ = 1.321 S/m; ε r = 41.384; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.74, 7.74, 7.74); Calibrated: 2020.01.03; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2019.04.11 - Phantom: SAM 1; Type: QD000P40CC; Serial: TP:1471 - Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Ch18900/Area Scan (71x91x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.702 W/kg Ch18900/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 2.770 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.101 W/kg SAR(1 g) = 0.063 W/kg; SAR(10 g) = 0.038 W/kg Maximum value of SAR (measured) = 0.658 W/kg 0 dB = 0.658 W/kg Test Laboratory: SAR Lab. of Shenzhen Morlab Communications Technology Co., Ltd. Date: 2020.03.20 LTE Band 4_20MHz_QPSK_1RB_0Offset_Left Cheek_Ch20175 C…
