MICROWAVE OVEN INSTRUCTION MANUAL C28PCS20-A90 IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE 2 Household use only SAVE THESE INSTRUCTIONS .IMPORTANT SAFEGUARDS............。。.................. ......... .. When using electrical appliances basic safety precautions should be followed, including the following: WARNING – To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" found on page ?. 3. This appliance must be grounded. Connect only to properly grounded outlet. See "GROUNDING INSTRUCTIONS" found on page ?. 4. Install or locate this appliance only in accordance with the provided installation instructions. 5. Some products such as whole eggs and sealed containers – for example, closed glass jars – are able to explode and should not be heated in this oven. 6. Use this appliance only for its intended use as described in the manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use. 7. As with any appliance, close supervision is necessary when used by children. 8. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. 3 9. This appliance should be serviced only by qualified service personnel. Contact nearest authorized service facility for examination, repair, or adjustment. 10. Do not cover or block any openings on the appliance. 11. Do not store this appliance outdoors. Do not use this product near water – for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations. 12. Do not immerse cord or plug in water. 13. Keep cord away from heated surfaces. 14. Do not let cord hang over edge of table or counter. 15. When cleaning surfaces of door and oven that comes together on closing the door, use only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth. 16. To reduce the risk of fire in the oven cavity: a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. b. Remove wire twist-ties from paper or plastic bags before placing bag in oven. c. If materials inside the oven ignite, keep oven door closed, turn oven off, and disconnect the power cord, or shut off power at the fuse or circuit breaker panel. d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use. 17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS 4 SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID. 18. Notice for extension cord: a. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. b. Longer cord sets or extension cords are available and may be used if care is exercised in their use. c. If a long cord or extension cord is used: 1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance; 2) The extension cord must be a grounding-type 3-wire cord; and 3) The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally. The following basic precautions should always be followed when using electrical appliance: 1. Read all instructions before using. 2. Make sure the voltage in your living area corresponding to the one shown on the rating label of the appliance. And the wall socket is properly grounded. 3. TO reduce the risk of fire in the oven cavity: a. DO not overcook the food. b. Remove wire twist -ties from paper or plastic bags before placing bags in the oven. c. Do not heat oil or fat for deep drying as the temperature 5 of oil cannot be controlled. d. After use wipe the waveguide cover with a damp cloth, followed by dry cloth to remove any food splashes and grease. Built -up grease may overheat and begin to cause smoke or catch fire. e. If materials inside the oven should smoke or ignite, keep oven door closed, turn oven off and disconnect the power supply. f. Close supervision is necessary when using disposable containers made from plastic, paper or other combustible material. 4. TO reduce the risk of explosion and sudden boiling: a. Do not place sealed containers in the oven. Baby bottles fitted with a screw cap or teat are considered to be sealed containers. b. When boiling liquid in the oven, use the wide -mouthed container and stand about 20 seconds at the end of cooking to avoid delayed eruptive boiling of liquids. c. Potatoes, sausage and chestnut should be peeled or pierced before cooking. Eggs in their shell, whole hard -boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended. d. The cooked liquid should not be removed out immediately. Several moments should be waited before removing. In order to avoid possible hazards caused by delayed eruptive boiling of 1iquids. e. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be checked before consumption, in order to avoid burns. 5. Never operate the oven further if the door or door seals is 6 damaged or the oven is malfunctioned or supply cord is damaged. Return the appliance to the nearest authorised service center for repair and maintenance. Never try to adjust or repair the oven yourself.…

Text truncated - open the document above for the full version.

Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. Address: Fusha Industrial Park, Fusha Town, Zhongshan, China Tel: 0760-22507145 Email: [email protected] Fax: 0760‐22507100‐1080 CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 2023-7-6 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: YI4DWC28PCS20 Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. certifies that the equipment for which authorization is sought, is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Print Name: Jianli Yang Title: Engineer

Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. Address: Fusha Industrial Park, Fusha Town, Zhongshan, China Tel: 0760-22507145 Email: [email protected] Fax: 0760‐22507100‐1080 CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 2023-7-6 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: YI4DWC28PCS20 Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Print Name: Jianli Yang Title: Engineer

U.S. AGENT LETTER OF ATTESTATION 2023-7-6 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: YI4DWC28PCS20 Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. certifies that, as of the date of the filing of the application, Emerson Radio Corp. is our designated U.S. agent for service of process for the above referenced FCC ID. Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Emerson Radio Corp. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Emerson Radio Corp. Company Address: 959 Route 46 East, Suite 210,2 nd Floor, Parsippany, NJ 07054 FRN: 0026321828 Tel.: +1(973)4282436 Email: [email protected] Signed by (printed name): Brian Leung Signature: Applicant: Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. Address: Fusha Industrial Park, Fusha Town, Zhongshan, China FRN: 0019939883 Tel: 0760-22507145 Email: [email protected] Signed by (printed name): Jianli Yang Signature:

Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. Address: Fusha Industrial Park, Fusha Town, Zhongshan, China Tel: 0760-22507145 Email: [email protected] Fax: 0760‐22507100‐1080 FCC Confidential Authorization 2023-7-6 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: YI4DWC28PCS20 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Zhongshan Donlim Weili Electrical Appliances Co., Ltd. hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Print Name: Jianli Yang Title: Engineer

Zhongshan Donlim Weili Electrical Appliances Co.,Ltd. Address: Fusha Industrial Park, Fusha Town, Zhongshan, China Tel: 0760-22507145 Email: [email protected] Fax: 0760‐22507100‐1080 Product Similarity Declaration Date: 2023-7-19 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, Zhongshan Donlim Weili Electrical Appliances Co.,Ltd., hereby declare that we have a product named as Microwave Oven, FCC ID: YI4DWC28PCS20 (model: C28PCS20-A90) was tested by Shenzhen Accurate Technology Co., Ltd. Meanwhile, for our marketing purpose, we would like to list a series models (C28PCS19-A90) on reports and certificate, all the models are identical in electrically. The main and series models are just different in appearance. Series model: C28PCS19-A90, Different from the test model in terms of front appearance, one is a sliding door, one is a press door, and all others are the same. Testing Products C28PCS20-A90, series models C28PCS19-A90 We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely Yours, Signature: Print Name: Jianli Yang Title: Engineer

Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM EXHIBITA-FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible tothe time purchase (Labeling requirements per 2.295)

Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 1 of 11 Internal Photos Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 2 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 3 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 4 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 5 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 6 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 7 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 8 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 9 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 10 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA230601-30977E-EM-01 Internal Photos Page 11 of 11

Shenzhen Accurate Technology Co., Ltd. Report No.: RA230601-30977E-EM-01 Version 27: 2023-01-30 Page 10 of 25 FCC-EMC FCC §18.313, §1.1310, §2.1091- MAXIMUM PERMISSIBLE EXPOSURE Applicable Standard According to subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; Measurement Environmental Conditions Temperature: 23 °C Relative Humidity: 52 % ATM Pressure: 101.0 kPa The testing was performed by Jason Liu on 2023-06-07. Radiation leakage was measured in the as-received condition with the oven door closed using a microwave leakage meter. A 275 mL water load was placed in the center of the oven and the oven was operated at maximum output power. There was no microwave leakage exceeding a power level of 0.1mW/cm 2 observed at any point 5 cm or more from the external surface of the oven. A maximum of 1.0 mW/cm 2 is allowed in accordance with the applicable Federal Standards. Hence, microwave leakage in the as-received condition with the oven door closed was below the maximum allowed.
