ASMB0911 MINI DUAL RF UHF MODULE SILABS HARDWARE INTEGRATION MANUAL © 2020 Wabtec Corporation. All rights reserved. The information contained in this publication is the property of Wabtec Corporation. This publication shall not be reproduced, redistributed, retransmitted, translated, abridged, adapted, condensed, revised or otherwise modified, in any form, in whole or in part, without the express written consent of Wabtec. By accessing this, you agree that the information contained herein does not purport to cover all details or variations in Wabtec products or to provide for every possible contingency with installation, operation or maintenance. Should further information b matter should be referred to Wabtec Corporation. Any applicable Federal, State or local regulations or company safety or operating rules must take precedence over any information or instructions given in the Technical Documentation. Wabtec has no obligation to keep the material up to date after the original publication. WABTEC CORPORATION EXPLICITLY DISCLAIMS ALL WARRANTIES OF ACCURACY, MERCHANTABILITY OR FITNESS FOR ANY PURPOSE IN CONNECTION WITH THIS PUBLICATION AND USE THEREOF.. Digital Mining Technology Page 2of 14 ASMB0911Hardware IntegrationManual Rev: B CONTENTS 1. MANUFACTURER INFORMATION.................................................................................................3 1.1. INTRODUCTION..............................................................................................................................3 1.2. SAFETY INFORMATION..................................................................................................................3 1.3. DISCLAIMER...................................................................................................................................3 1.4. COMPANY DETAILS........................................................................................................................4 2. OVERVIEW..................................................................................................................................5 2.1. GENERAL FEATURES.......................................................................................................................5 2.2. ABBREVIATIONS.............................................................................................................................5 2.3. SCOPE & SPECIFICATION................................................................................................................5 2.4. PIN CONFIGURATION AND FUNCTION..........................................................................................6 2.5. APPROVED ACCESSORIES LIST.......................................................................................................7 2.6. WARNINGS.....................................................................................................................................7 3. GENERAL INFORMATION.............................................................................................................8 3.1. INTEGRATION.................................................................................................................................8 3.2. MAINTENANCE...............................................................................................................................8 3.3. DECOMMISSION AND DISPOSAL...................................................................................................8 3.4. AUTHORIZED REPRESENTATIVES...................................................................................................9 4. PRODUCT APPROVALS AND REGULATORY INFORMATION.........................................................10 4.1. DECLARATION OF CONFORMITY 47 CFR § 2.1077 COMPLIANCE INFORMATION.......................10 4.2. MODULE STATEMENT, LABELLING & USER INSTRUCTIONS........................................................10 4.3. FCC INTERFERENCE STATEMENT FOR CLASS B DEVICES.............................................................11 4.4. FCC RADIATION EXPOSURE STATEMENT.....................................................................................12 4.5. INDUSTRY CANADA COMPLIANT.................................................................................................12 CONCERNING RADIO TRANSMITTERS.................................................................................12 INDUSTRY CANADA -RADIATION EXPOSURE STATEMENT.................................................12 INDUSTRIE CANADA ......................13 ..............................................................13 AU SUJET DES ÉMETTEURS RADIO.......................................................................................13 4.6. AUSTRALIAN RADIO COMMUNICATIONS EQUIPMENT RADIATION EXPOSURE STATEMENT..13 Page 3of 14 ASMB0911Hardware IntegrationManual Rev: B 1.MANUFACTURERINFORMATION 1.1.INTRODUCTION The product or product family described under scope of this document will be henceforth referred to as DEVICE. This manual provides the information on the DEVICE, its variants, specifications, operation, maintenance, decommission and disposal. 1.2.SAFETY INFORMATION The safety section includes safety precautions which must be observed when working on items that appear throughout the manual. Examples of safety precautions and labels are outlined below: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could result in minor or moderateinjury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury. Indicates a potential for equipment damage. 1.3. DISCLAIMER implied warranty of any kind. Wabtec makes no ANY EXPRESS OR IMPLIED WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER EXPRESS OR IMPLIED WARRANTY REGARDING ANY PRODUCTS DESCRIBED in these materials. To the max…

Text truncated - open the document above for the full version.

YIY-ASMB0911 Not Covered Entity Applicant Attestation Page 1 Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph No.: + 61 2 8863 4730 www.wabteccorp.com Doc Id: DMT/DEC/2024-010 July 4, 2024 CFR 47 §2.911 (d)(5)(ii) Attestation Statement - Not Covered Entity Applicant To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(ii) filing FCC ID: YIY-ASMB0911 Industrea Mining Technology Pty Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely yours, Applicant Signature Printed Name: Henro Van Wyk Title: Vice President & General Manager Industrea Mining Technology Pty Ltd T/A: Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph: +61 2 8863 4730 Email: [email protected]

YIY-ASMB0911 YIY-ASMB0911_Not Covered Equipment Attestation Page 1 Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph No.: + 61 2 8863 4730 www.wabteccorp.com Doc Id: DMT/DEC/2024-008 July 1, 2024 CFR 47 §2.911 (d)(5)(i) Attestation Statement - Not Covered Equipment To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) filing FCC ID: YIY-ASMB0911 Industrea Mining Technology Pty Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Henro Van Wyk Title: Vice President & General Manager Industrea Mining Technology Pty Ltd T/A: Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph: +61 2 8863 4730 Email: [email protected]

ASMB0911 FCC Agent Letter Page 1 Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph No.: + 61 2 8863 4730 www.wabteccorp.com Doc Id: DMT/DEC/2024-007 Date: July 1, 2024 U.S. Agent Designation for Service of Process Attention: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Regarding: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Wabtec US Rail, Inc Contact Name: Ehab Abbas Street Address: 500 West Monroe Street, Chicago, Illinois 60661-3671 Telephone No: +1 3122061735 Email: [email protected] FRN #: 0033574765 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: July 1, 2024 Signed by (Printed Name/Title): Ehab Abbas, Engineering Technical Leader The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Industrea Mining Technology Pty Ltd FRN #: 0019935618 FCC ID: YIY-ASMB0911 Contact Name: Henro Van Wyk Street Address: 3 Co-Wyn Close, Fountaindale NSW 2258, Australia City/Province/Zip: 2258 Telephone No: +61 2 8863 4730 Email: [email protected] Applicant Signature: Date: July 1, 2024 Signed by (Printed Name/Title): Henro Van Wyk, Vice President & General Manager

ASMB0911 FCC & ISED Authorization Letter Page 1 Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph No.: + 61 2 8863 4730 www.wabteccorp.com Doc Id: DMT/POA/2024-005 July 1, 2024 Authority to Act as Agent TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint Mr. Elliot Zhang of TÜV Rheinland (Shanghai) Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with Industrea Mining Technology Pty Ltd(Address: Co-Wyn Close, Fountaindale, NSW 2258, Australia). For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: July 1, 2024 Agreement is valid for 12 months from the above date. By: __________________________ Henro Van Wyk Vice President & General Manager On behalf of: Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph: +61 2 8863 4730 Email: [email protected]

ASMB0911 FCC Confidentiality Request Letter Page 1 Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph No.: + 61 2 8863 4730 www.wabteccorp.com Doc Id: DMT/DEC/2024-006 Date: June 28, 2024 To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Confidentiality Request for FCC ID: YIY-ASMB0911 Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term n/a External Photo Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Short Term Permanent Test Setup*** Short Term Permanent Tune-Up Procedure Short Term Permanent User’s Manual*** Short Term Permanent Part List/ Antenna Construction Industrea Mining Technology Pty Ltd has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** Exceptional case for Permanent Confidentiality for these Exhibits by PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, _____________________________ Henro Van Wyk Vice President & General Manager Industrea Mining Technology Pty Ltd Tel: +61 2 8863 4730 e-mail: [email protected]

Applicant/Grantee Industrea Mining Technology Pty Ltd FCC ID: YIY-ASMB0911 IC: 8903A-ASMB0911 Section 15.212 Modular Transmitters / Section 5 of RSP-100 ✓ Request for Modular Approval Request for Limited Modular Approval Requirements Device Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements must have the radio frequency circuitry must be shielded. Physical/discrete and tuning capacitors may be located external to the shield, but must be on the module assembly. The module has its own RF shielding.” Shield Can is employed on the board structure, please see exhibition External Photo, the emission measurement was conducted without further shielding added. Y 2 The module shall have buffered modulation/data input(s) (if such inputs are provided) to ensure that the module will comply with the requirements set out in the applicable RSS standard under conditions of excessive data rates or over-modulation. All modulation and data input(s) are buffered.” The EUT has buffered data inputs, it is integrated on chip - Digital packet radios (all internal to radio IC) – no direct access to modulators. Y 3 The module shall have its own power supply regulation on the module. This is to ensure that the module will comply with the requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module. Requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module. V2V module has an LDO that takes the input 3.3Vdc and regulates down to 3Vdc to power the internal RF circuits. Y 4 The module shall comply with the provisions for external power amplifiers and antennas detailed in this standard. The Equipment certification submission shall contain a detailed description of the configuration of all antennas that will be used with the module. The EUT meets the FCC antenna Requirements. There are no integral antennas on the module and are provided with MMCX ports for connecting external antenna. Y 5 The module shall be tested for compliance with the applicable standard in a stand- alone configuration, i.e. the module must not be inside another device during testing. The modular transmitter was tested in a stand-alone configuration via a Interface. Bare PCB, no enclosure, with micro to initialize and control the modules and basic power-supplies providing 3.3V & Vio Y 6 The module shall comply with the Category I equipment labelling requirements. In the exhibition OEM manual, there are Instructions given to the OEM on how to label the end product. Y 7 The modular transmitter complies with all specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer will provide adequate instructions along with the module to explain any such requirements. A copy of these instructions is included in this application for equipment authorization: Instructions in User Manual Y 8a Address compliance with the Commission's RF exposure limits in Sections 1.1310 and 2.1093. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4). Please refer the Maximum Permissible Exposure Information. Y 8b The module shall comply with applicable RSS-102 exposure requirements, which are based on the intended use/configurations. Please refer the Maximum Permissible Exposure Information. Y 9 Is the modular device for an Industry Canada licensed exempt service? Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured. _____________ Signature Henro Van Wyk Vice President & General Manager Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close, Fountaindale NSW 2258, Australia Ph: +61 2 8863 4730 Email: [email protected]

WABTEC CONTROLLED COPY ASMB0911 Mini Dual RF UHF Module Silabs Product Label ASMB0911 - Label & Labelling location.docx Revision: A Page 1 of 1 Module Model No. ASMB0911 – Label & Labelling location Label Image: Labelling Location:

MRT Technology (Suzhou) Co., Ltd Report No.: 2401RSU009-U2 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2024-08-07 Template Version:0.1 1 of 10 RF Exposure Evaluation Declaration FCC ID: YIY-ASMB0911 Applicant: Industrea Mining Technology Pty Ltd Product: Mini Dual RF UHF Module SiLabs Model No.: ASMB0911 Brand Name: Digital Mining Technology FCC Rule Part(s): FCC Part 2.1091 Result: Complies Evaluation Date: 2024-05-31 Reviewed By: Denise Zhou Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2401RSU009-U2 2 of 10 Revision History Report No. Version Description Issue Date Note 2401RSU009-U2 V01 Initial Report 2024-08-07 Valid Report No.: 2401RSU009-U2 3 of 10 CONTENTS Description Page 1. General Information ............................................................................................................................... 4 1.1. Applicant ........................................................................................................................................4 1.2. Manufacturer .................................................................................................................................4 1.3. Testing Facility ...............................................................................................................................4 1.4. Product Information .......................................................................................................................5 1.5. Antenna Details .............................................................................................................................5 1.6. Device Classification .....................................................................................................................5 1.7. Applied Standards .........................................................................................................................5 2. RF Exposure Evaluation ........................................................................................................................ 6 2.1. Limits .............................................................................................................................................6 2.2. MPE Exemptions ...........................................................................................................................7 2.3. Calculated Result ....................................................................................................................... 10 Report No.: 2401RSU009-U2 4 of 10 1. General Information 1.1. Applicant Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close Fountaindale NSW 2258 Australia 1.2. Manufacturer Industrea Mining Technology Pty Ltd T/A Digital Mining Technology 3 Co-Wyn Close Fountaindale NSW 2258 Australia 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025 G-20034 C-20020 T-20020 R-20141 G-20134 C-20103 T-20104 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2401RSU009-U2 5 of 10 1.4. Product Information Product Name Mini Dual RF UHF Module SiLabs Model No. ASMB0911 SRD Specification 902 ~ 928MHz Antenna Information Refer to Section 1.5 Module Voltage 3.3Vdc Test Fixture Voltage 6 ~ 18Vdc, nominal 12Vdc Operating Temperature -40 ~ 75°C Note: The information of EUT was provided by the manufacturer, and the accuracy of the information shall be the responsibility of the manufacturer. 1.5. Antenna Details Antenna Part No. Antenna Type Antenna Gain EA2-0287-N01SP-050 Omni-directional 8.0dBi PROD1196 Omni-directional 2.9dBi MISC1626 Monopole 2.0dBi Note: All antenna information is provided by the manufacturer. 1.6. Device Classification According to the user manual, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for mobile device exposure conditions subject to MPE limits. 1.7. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards:  FCC Part 2.1091 & KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: 2401RSU009-U2 6 of 10 2. RF Exposure Evaluation 2.1. Limits According to FCC §1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b) Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 0.3-3.0 614 1.63 *(100) ≤6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1,500 -- -- f/300 <6 1,500-100,000 -- -- 5 <6 (B) Limits for General Population/ Uncontrolled Exposures 0.3-1.34 614 1.63 *(100) <30 1.34-30 824/f 2.19/f *(180/f 2 ) <30 30-300 27.5 0.073 0.2 <30 300-1,500 -- -- f/1500 <30 1,500-100…

Text truncated - open the document above for the full version.

LLC ABRACON IS ISO9001-2015 CERTIFIED 5101 Hidden Creek Ln Spicewood TX 78669 Phone: 512-371-6159 | Fax: 512-351-8858 For terms and conditions of sales, please visit: www.abracon.com REVISED: 01.24.2019 LPWA/ISM External Antenna Pb 45.9 x 10.0 mm RoHS/RoHS II Compliant MSL = 1 AEACAC054010-S915 FeaturesApplications Electrical Characteristics ParametersMin.Typ.Max.UnitsNote Frequency Range915MHz VSWR3 PolarizationLinear Impedance50Ω Gain2dBiZenith Mechanical Characteristics ParametersDescription ConnectorSMA Male MountingConnector Environmental Characteristics ParametersDescription Operating temperature-40°C to +85°C Vibration10 to 55 Hz with 1.5 mm amplitude 2 hours • 915 MHz LPWA/ISM antenna • Linear polarization • Gain of 2 dBi • Compact, low profile whip antenna •LPWA/LoRa/SigFox applications •ISM applications •IoT •M2M •Remote technology/monitoring •Network devices •Smart buildings •Smart city •Agriculture/environment •Consumer tracking LLC ABRACON IS ISO9001-2015 CERTIFIED 5101 Hidden Creek Ln Spicewood TX 78669 Phone: 512-371-6159 | Fax: 512-351-8858 For terms and conditions of sales, please visit: www.abracon.com REVISED: 01.24.2019 LPWA/ISM External Antenna Pb 45.9 x 10.0 mm RoHS/RoHS II Compliant MSL = 1 AEACAC054010-S915 Dimensions Product Image LLC ABRACON IS ISO9001-2015 CERTIFIED 5101 Hidden Creek Ln Spicewood TX 78669 Phone: 512-371-6159 | Fax: 512-351-8858 For terms and conditions of sales, please visit: www.abracon.com REVISED: 01.24.2019 LPWA/ISM External Antenna Pb 45.9 x 10.0 mm RoHS/RoHS II Compliant MSL = 1 AEACAC054010-S915 VSWR ATTENTION: Abracon LLC’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applica- tions. Abracon’s products are not specifically designed for Military, Aviation, Aerospace, Life-dependent Medical applications or any application requiring high reliability where component failure could result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and authorization from Abracon LLC is required. Please contact Abracon LLC for more information. LLC ABRACON IS ISO9001-2015 CERTIFIED 5101 Hidden Creek Ln Spicewood TX 78669 Phone: 512-371-6159 | Fax: 512-351-8858 For terms and conditions of sales, please visit: www.abracon.com REVISED: 01.24.2019 LPWA/ISM External Antenna Pb 45.9 x 10.0 mm RoHS/RoHS II Compliant MSL = 1 AEACAC054010-S915 3D – Pattern Frequency (MHz)EfficiencyGain (dBi) 9150.662.2 Radiation Pattern: Horizontal Plane Vertical Plane 2D – Pattern Frequency: 915 MHz Frequency: 915 MHz Packaging A carton weighs about 8 Kg with 1,000 pieces each of dimension 37 x 36 x 17 cm. Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: ABRACON: AEACAC054010-S915

ShenzhenSuperbatElectronicsCo.,Ltd. Address:7FComprehensiveBuilding,JiangHaoIndustrialPark,JihuaRd, BantianLonggangDistrict,Shenzhen,Guangdong,China518129 TEL:+8675525614980 HotSalesOutdoorLora915mhzOmni8dBiFiberglassAntennaNMale Model:EA2-0287-N01SP-050 ShenzhenSuperbatElectronicsCo.,Ltd. Address:7FComprehensiveBuilding,JiangHaoIndustrialPark,JihuaRd, BantianLonggangDistrict,Shenzhen,Guangdong,China518129 TEL:+8675525614980 Specification: Frequency:860-930mhz Gain:8dBi AntennaConnectorType:N-typeMale AntennaLength:13.7inch/35cm VSWR:≤2 Polarization:vertical Impedance:50Ohm 【Application】-CompatiblewithNebraHNTOutdoorHotspotMiner,designedfor LoRaHeliumminer,Lowpowerradio:Sigfox,LPWA,LoRa,meshnetworks,IoT 【FrequencyRange】-Thisantennaworksperfectlyintherangeof902-928mhz 【IncreaseSignalStrength】-InnerCopperOscillator,8dBiGain,Omnidirectional, LongRange,LowerVSWR 【Durable】-Outdoorfulldayworking,anticorrosive,waterproof,easytoinstall ShenzhenSuperbatElectronicsCo.,Ltd. Address:7FComprehensiveBuilding,JiangHaoIndustrialPark,JihuaRd, BantianLonggangDistrict,Shenzhen,Guangdong,China518129 TEL:+8675525614980 【AluminumAlloyBase】-TheBaseisperfectlymadeofaluminumandfirmenough toagainststrongwind. Testdatasheet

1 1.Return Loss / VSWR 2.3D Radiation Pattern @865MHz @875MHz 2 @885MHz @905MHz @915MHz @922MHz @930MHz 3 3.Gain & Efficiency 0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 860880920940900 Frequency (MHz) Gain (dBi) 0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 860880920940900 Frequency (MHz) Efficiency (%) Frequency (MHz) 865 875 885 905 915 922 930 Gain (dBi) 1.9 2.3 2.5 2.9 2.8 2.6 2.5 Effieicney (%) 66.4 70.1 73.4 75.3 72.1 69.1 66.8

MRT Technology (Suzhou) Co., Ltd Report No.: 2401RSU009-U1 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2024-08-13 Template Version:0.0 1 of 67 RF MEASUREMENT REPORT FCC ID: YIY-ASMB0911 Applicant: Industrea Mi…
