YJW-06427Fast Wireless Charger

90*65mm 1:1 无线充电器说明书 LC06 / 128g哑粉纸 双面四色印刷 2020.10.23 3-608LC060602A0001 中性 DC5V 3A, DC9V 2.22A, DC12V 1.67A Φ63×10.5mm 57 DC5V 3A, DC9V 2.22A, DC12V 1.67A Φ63×10.5mm 57 注：20W适配器需另外购买，请根据适配器接口选择是否使用转接头。 充电板通电后白灯闪烁三次然后熄灭进入待机模式。 将带有磁吸无线充电功能的手机放置在充电板上，充电板会自动吸附 对位，指示灯白灯长亮30秒后熄灭，当有金属等异物放置在充电板上，指示 灯呈白灯闪烁。 本产品同时支持对不带磁吸功能的无线充电设备进行充电。 USB转接头 USB output port *20W PD wall charger need to buy separately, please use the connector adapter accordding to your wall charger USB output port. 快速无线充电器 The white LED light of charger will flash 3times when power on, then enter to standby mode. Put the magnetic wireless charging phone one the charger, they will align automaticly, white LED light will turn off after 30 seconds. The white LED light will flashing when FOD detected. The device also support wireless charging to other nonmagnatic wireless charging function device. FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. 警告语 此设备符合FCC规则的第15部分。 操作必须符合以下两个条件：（1）此设备 不会造成有害干扰，并且（2）此设备必须接受收到的任何干扰，包括可能导 致意外操作的干扰。 未经负责合规方明确批准的任何更改或修改，都可能使用户丧失操作设备的 权限。 注意：根据FCC规则第15部分的规定，本设备已经过测试，符合B类数字设备 的限制。 这些限制旨在为住宅安装中的有害干扰提供合理的保护。 本设备会 产生，使用并辐射射频能量，如果未按照说明进行安装和使用，可能会对无 线电通信造成有害干扰。 但是，不能保证在特定安装中不会发生干扰。 如果此设备确实对广播或电视接收造成有害干扰， 可以通过打开和关闭设备来确定，建议用户尝试以下一种或多种措施来纠正 干扰： - 重新调整或摆放接收天线。 - 增加设备和接收器之间的距离。 -将设备连接到与接收器不同电路的插座上。 -向经销商或有经验的无线电/电视技术人员咨询以获得帮助。 为了保持符合FCC的RF暴露准则，应在距您的身体辐射器20厘米的最小距离 内安装和操作此设备：仅使用提供的天线。 Fast Wireless Charger
