Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
10W Fast Wireless Charging Stand 23 Specs Wireless Charging Pad, Dual Coil: • Input: 5VDC/2A; 9VDC/1.67A • Output: Up to 10W (Fast Charge) * Charging time may vary based on device AC Adapter: • Input: 110–240V ~ 50/60Hz 0.6A • Output: 3.6–6V 3A; 6.2–9V 2A; 9.2–12V 1.5A CAUTION: DO NOT place any credit cards or other types of magnetic material near the charging pad. This product can ONLY be charged using the provided adapters and cables. Do not attempt to disassemble the wireless charging pad as it may short circuit or damage the product. Keep this product in a dry and ventilated space. Do not place in direct heat or use in high humidity environments. Do not use organic solvents to clean surface. ENGLISH 45 Using your Fast Wireless Charging Pad 1. Connect the charge/sync cable to the Micro-USB port on your Fast Wireless Charging Pad. 2. Plug the USB connector into the wall charger. 3. Plug in the wall charger. 4. Place your Qi-enabled device on the Fast Wireless Charging Pad with the screen facing up. The LED is white when your device is charging. Charging Indicator Light Status: RED LIGHT: Device is not charging properly. Please reposition your device until you see the white light come on. WHITE LIGHT: Device is charging. ENGLISH One Year Limited Warranty This product is covered by a limited warranty to the original purchaser only in that this product is free from defects in workmanship and materials for ONE YEAR from the date of purchase (damages through normal wear and tear, alteration, misuse, neglect, accident, service by anyone other than the authorized service center, or act of God not included). During the warranty period and upon verification of defects, this wireless product will be replaced when returned with proper proof of purchase. This limited warranty is in lieu of all other warranties, express or implied, including, but not limited to, implied warranty of merchantability or fitness for a particular use. The ‘Qi’ symbol is a trademark of the Wireless Power Consortium. ENGLISH 67 FCC Interference Statement (cont.) instructions, maybe cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into and outlet on a circuit different form that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. ENGLISH FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 8 inches between the radiator & your body. FCC Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the ENGLISH 8 10 W Support de charge rapide sans fil ENGLISH IC Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 101110 Caractéristiques Socle de charge sans fil, double bobines : • Entrée : 5 V c.c. / 2 A; 9 V c.c. / 1.67 A • Sortie : jusqu’à 10 W (charge rapide) * Temps de recharge peuvent varier en fonction d'appareil Adaptateur C.A. : • Entrée : 110–240 V ~ 50/60 Hz 0,6 A • Sortie : 3,6–6V 3A; 6,2–9V 2A; 9,2–12V 1,5A MISE EN GARDE : NE placez PAS de carte de crédit ou tout autre type de matériau magnétique près du socle de charge. Ce produit peut être chargé UNIQUEMENT au moyen des câbles et adaptateurs fournis. N’essayez pas de démonter le socle de charge sans fil car vous risqueriez de provoquer un court-circuit ou d’endommager le produit. Gardez ce produit dans un endroit sec et bien ventilé. Ne le placez pas près d’une source de chaleur directe ou dans des endroits soumis à l'humidité élevée. N’utilisez pas de solvants organiques pour nettoyer la surface. Utilisation de votre socle de charge sans fil 1. Branchez le câble de charge/synchronisation sur le port Micro-USB de votre socle de charge sans fil. 2. Branchez le connecteur USB sur l’adaptateur de courant. 3. Branchez l'adaptateur de courant sur la prise de courant. 4. Placez votre appareil répondant à la norme Qi sur le socle de charge sans fil en ayant soin d’orienter l’écran vers le haut. Le voyant s’allume en blanc lorsque l’appareil est en cours de charge. Indicateurs d’état de la charge : VOYANT ROUGE : L’appareil ne se charge pas correctement. VOYANT BLANC : En cours de charge. FRANÇAIS FR…
Text truncated - open the document above for the full version.
DATE : 2020.1.9 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: YJW-08755PG Product Name: Wireless Charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: George Chen Title: VP Product Development Company: Superior communications.
Date:2020.1.9 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Tony Tang Title: EMC Engineer Company: EST Technology Co., Ltd.
DATE : 2020.1.10 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint EST Technology Co., Ltd. Address: Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Superior communications. Address: 5027 Irwindale Ave.Suite 900, Irwindale, California 91706, United States (Applicant Name and address) <Signature> Name: George Chen Title: VP Product Development Company: Superior communications.
Superior communications. 2020.1.9 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: YJW-08755PG To Whom It May Concern: This letter is to ascertain that Superior communications.Product Wireless Charger, Model: 08755PG, has been the units used for conducting FCC compliance testing, and it meets KDB 680106 D01 RF Exposure Wireless Charging App v03 Clause 5(b) 6 conditions. 1Powertransferfrequencyislessthat1MHz YES.Thedeviceoperatedinthefrequencyrangefrom110.5-205KHz. 2Outputpowerfromeachprimarycoilislessthanorequalto15watts. YES.Themaximumoutputpoweroftheprimarycoilis10W. 3 The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detectandallowcouplingonlybetweenindividualpairsofcoils. YES. 4Clientdeviceisplaceddirectlyincontactwiththetransmitter. YES.Clientdeviceisplaceddirectlyincontactwiththetransmitter. 5 Mobile exposure conditions only (portable exposure conditions are not covered by thisexclusion). YES. 6 The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50%oftheMPElimit. YES. The EUT field strength levels are 50% x MPE limts. <Signature> Name: George Chen Title: VP Product Development Company: Superior communications.
External photos External photos External photos External photos External photos
08755PG 08755PG 9CHA 银色 TYPC C位置 IC :21802-08755PG 08755PG 08755PG 9CHA IC :21802-08755PG
Internal photos External photos External photos External photos Coil
FCC ID: YJW-08755PG EST Technology Co., Ltd Report No. ESTE-R2001009 Page 1 of 11 RF EXPOSURE REPORT FOR CERTIFICATION On Behalf of Superior communications. Wireless Charger Model Number: 08755PG FCC ID: YJW-08755PG Prepared for: Superior communications. 5027 Irwindale Ave.Suite,California,91706,United States Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2001009 Date of Test: Dec. 27, 2019~Jan. 03, 2020 Date of Report: Jan. 06, 2020 FCC ID: YJW-08755PG EST Technology Co., Ltd Report No. ESTE-R2001009 Page 2 of 11 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION......................................................................................................................... 3 1. SUMMARY OF TEST ......................................................................................................................... 4 1.1. Summary of test result ...................................................................................................................... 4 1.2. Test Mode ......................................................................................................................................... 4 1.3. Test Equipment List ......................................................................................................................... 4 2. MAXIMUM PERMISSIBLE EXPOSURE ............................................................................................... 5 2.1. Limit ................................................................................................................................................. 5 2.2. Test Setup ......................................................................................................................................... 5 2.3. Test Procedure .................................................................................................................................. 6 2.4. Equipment Approval Considerations ............................................................................................... 7 2.5. Test Result ........................................................................................................................................ 8 3. TEST SETUP PHOTO ................................................................................................................... 9 FCC ID: YJW-08755PG EST Technology Co., Ltd Report No. ESTE-R2001009 Page 4 of 11 1. SUMMARY OF TEST 1.1. Summary of test result Report Section Description of Test Item FCC Standard Section Results 3 Maximum Permissible Exposure Part 1.1307(b)&1.1310 PASS 1.2. Test Mode 1.3. Test Equipment List Equipment ManufacturerModel No. Serial No.Last Cal. Next Cal. Exposure Level Tester Narda ELT-400 EST-E105 Aug. 21,19 1 Year B-Field Probe Narda ELT Probe EST-E106 Aug. 30,19 1 Year Test Item Test Mode Maximum Permissible Exposure Wireless Charging with Empty Load Wireless Charging with Half Load Wireless Charging with Full Load FCC ID: YJW-08755PG EST Technology Co., Ltd Report No. ESTE-R2001009 Page 5 of 11 2. MAXIMUM PERMISSIBLE EXPOSURE 2.1. Limit Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm2) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300-1,500 f/300 6 1,500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 Note: 1. f = frequency in MHz * = Plane-wave equivalent power density. 2. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of 15 cm. E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63 A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. 2.2. Test Setup FCC ID: YJW-08755PG EST Technology Co., Ltd Report No. ESTE-R2001009 Page 6 of 11 2.3. Test Procedure a. The test was performed on turn table in anechoic chamber with a dummy load. b. The dummy load must be placed horizontal of the EUT at the top (Parallel to the coil). c. The probe was placed at 15 cm surrounding the device and 20 cm above the top of the charger and the geometric centre of the probe. d. The highest emission level was recorded and compared with limit as soon as measurement of each point; A, B, C, D, E were completed. FCC ID: YJW-08755PG EST Technology Co., Ltd Report No. ESTE-R2001009 Page 7 of 11 2.4. Equipment Approval Considerations Inductive wireless power transfer applications with supporting field strength results and meeting all of the following requirements are not required to submit a KDB inquiry for devices approved using SDoC or a PAG for equipment approved using certification to address RF exposure compliance. 1 Power transfer frequency is less that 1 MHz YES; the device operated in the frequency range from 110.5-205KHz. 2 Output power from each primary coil is less than or equal to 15 watts. YES. The maximum output power of the primary coil is 10W. 3 The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. YES. 4 Client device is placed directly in contact with the transmitter. YES; Client device is placed directly i…
Text truncated - open the document above for the full version.
FCC ID: YJW-08755PG EST Technology Co., Ltd Report No.ESTE-R2001008 Page 1 of 56 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Superior communications. Wireless Charger Model Number: 08755PG FCC ID: YJW-08755PG Prepared for: Superior communications. 5027 Irwindale Ave. Suite 900, Irwindale, California 91706 United Sates Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2001008 Date of Test: Dec. 27, 2019~Jan. 03, 2020 Date of Report: Jan. 06, 2020 FCC ID: YJW-08755PG EST Technology Co., Ltd Report No.ESTE-R2001008 Page 2 of 56 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION ........................................................................................................................ 3 1. GENERAL INFORMATION ................................................................................................................. 4 1.1. Description of Device (EUT) ........................................................................................................... 4 2. SUMMARY OF TEST ......................................................................................................................... 5 2.1. Summary of test result ...................................................................................................................... 5 2.2. Test Facilities .................................................................................................................................... 6 2.3. Measurement uncertainty ................................................................................................................. 7 2.4. Assistant equipment used for test ..................................................................................................... 7 2.5. Block Diagram .................................................................................................................................. 7 2.6. Test Mode ......................................................................................................................................... 8 2.7. Test Equipment List ......................................................................................................................... 8 3. RADIATED EMISSION ...................................................................................................................... 9 3.1. Limit ................................................................................................................................................. 9 3.2. Test Setup ....................................................................................................................................... 10 3.3. Spectrum Analyzer Setting ............................................................................................................. 11 3.4. Test Procedure ................................................................................................................................ 11 3.5. Test Result ...................................................................................................................................... 12 4. AC POWER LINE CONDUCTED EMISSIONS .................................................................................... 30 4.1. Limit ............................................................................................................................................... 30 4.2. Test Setup ....................................................................................................................................... 30 4.3. Spectrum Analyzer Setting ............................................................................................................. 30 4.4. Test Procedure ................................................................................................................................ 30 4.5. Test Result ...................................................................................................................................... 31 5. ANTENNA REQUIREMENTS ............................................................................................................ 43 5.1. Limit ............................................................................................................................................... 43 5.2. Test Result ...................................................................................................................................... 43 6. TEST SETUP PHOTO ................................................................................................................. 44 7. EUT PHOTO ............................................................................................................................... 47 FCC ID: YJW-08755PG EST Technology Co., Ltd Report No.ESTE-R2001008 Page 4 of 56 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Note: For a more detailed features description, please refer to the manufacturer’s specifications or the user's manual. Product Name : Wireless Charger Model Number : 08755PG Operation Frequency : 110.5kHz-205kHz Max Charge Power : 10W Max Field Strength of Fundamental : 82.50 dBμV/m Modulation Type : MSK Antenna Type : Induction coil Sample Type : Prototype production FCC ID: YJW-08755PG EST Technology Co., Ltd Report No.ESTE-R2001008 Page 5 of 56 2. SUMMARY OF TEST 2.1. Summary of test result Report Section Description of Test Item FCC Standard Section Results 3 Radiated Emission 15.205 15.209 PASS 4 AC Power Line Conducted Emissions 15.207 PASS 5 Antenna Requirement 15.203 PASS Note: 1. “N/A” denotes test is not applicable in this test report FCC ID: YJW-08755PG EST Technology Co., Ltd Report No.ESTE-R2001008 Page 6 of 56 2.2. Test Facilities EMC Lab : Certificated by CNAS, CHINA Registration No.: L5288 Date of registration: November 13, 2017 Certificated by FCC, USA Designation Number: CN1215 Test Firm Registration …
Text truncated - open the document above for the full version.
Radiated test: 9k-30MHz Radiated test: 30M-1GMHz Conducted test:
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 0.1105 MHz - 0.205 MHz | - |
