YJW-10470PGMagnetic Wireless Car Charger

Magnetic Wireless Car Charger 23 ENGLISH Specs Magnetic Wireless Car Charger •USB-C ™ Input: 5V/2A, 9V/2.22A, 12V/1.67A •Output: Up to 15W Qualcomm ® Quick Charge ™ 3.0 Car Charger •Output: 3.6‒6V/3A; 6‒9V/2A; 9‒12V/1.5A Caution DO NOT place any credit cards or other types of magnetic material near the charging pad. Do not attempt to disassemble the wireless charging pad as it may short circuit or damage the product. Keep at least 8” (20cm) distance between implantable medical devices such as pacemakers, cochlear implants, etc. Keep this product in a dry and ventilated space. Do not place in direct heat or use in high humidity environments. Do not use organic solvents to clean surface. 45 ENGLISH ENGLISH Instructions Attaching the VENT MOUNT: 1. Unscrew the large socket nut and push vent clip ball joint into the hole until it snaps into place. 2. Screw the socket nut back on until tight – this locks the vent clip onto the wireless charging pad and holds the adjustable support base in place. Attaching the SUCTION MOUNT: 1. Unscrew the large socket nut and push vent clip ball joint into the hole until it snaps into place. 2. Screw the socket nut back on until tight – this locks the vent clip onto the wireless charging pad and holds the adjustable support base in place. Instructions Using your Magnetic Wireless Car Charger : 1. Connect the USB-A to USB-C cable to the USB-C port of the Magnetic Wireless Car Charger. 2. Connect the USB-A connector into the included car charger and plug it in. 3. Place the back of your Apple iPhone ® MagSafe ® device against the Magnetic Wireless Car Charger until it automatically aligns and snaps into place. *‡ Charging will begin automatically. * Works with MagSafe cases. Non-MagSafe cases must be removed before charging. ‡ If you prefer to strengthen the Magnetic Wireless Car Charger, use the enclosed ring sticker; however, it is not necessary. 67 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator & your body. FCC Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. ENGLISH ENGLISH Instructions Placing the Metal Ring Sticker on older iPhones and Androids without magnetic functionality built-in: Place the metal sticker in the middle of the back of your phone. To find the middle of the phone: 1. Ensure your Magnetic Wireless Car Charger is plugged in. 2. Place the metal sticker on the magnetic Magnetic Wireless Car Charger, with the adhesive side facing up and away from the charger. 3. Peel off the protective liner from the adhesive. 4. Make sure the phone’s volume is turned on high. Hold the back of your phone (or your phone with a case) close to the metal sticker but don’t let them touch, and line up the wireless charging position of the phone and the charger until the phone makes a sound and starts charging. 5. Close the gap between your phone and the Magnetic Wireless Car Charger and let the metal sticker attach to your phone or your case. 6. Firmly press on the sticker to adhere to your phone or case. For best results, let the metal ring sticker set for 30 minutes or longer before use. 89 FCC Interference Statement (cont.) This equipment generates, uses and can radiate radio frequency energy; if not installed and used in accordance with the instructions, maybe cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into and outlet on a circuit different form that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. IC Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference; (2) This device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 10cm between the radiator & your body. ENGLISH ENGLISH 10 Chargeur magnetique sans fils pour voiture Lifetime Warranty This product is fully warranted against defects in materials and workmanship for the lifetime of the product, so long as the manufacturer continues to make this product. If a product fails due to a manufacturing defect, we will replace it upon proper proof of purchase by the original purchaser. Replacement product will be subject to shipping and handling charges. Damages through normal wear and tear, alteration, misuse, neglect, accident, service by anyone other than the authorized service center, or act of God, are not covered by this warranty.…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Superior communications. FRN: 0019944727 Contact Name: George Chen Address: 5027 Irwindale Ave.Suite Irwindale Ave California United States. Telephone No: 818-636-4985 Email: [email protected] Applicant: Company name: Superior communications. Product Description: Magnetic Wireless Car Charger Grantee code: YJW FCC ID: YJW-10470PG Contact Name: George Chen Address: 5027 Irwindale Ave.Suite Irwindale Ave California United States. Telephone No: 818-636-4985 Email: [email protected] [Superior communications.] certifies that, as of the date of this filing of the application with the TCB, [Superior communications.] is our designated US agent for service of process for the above referenced FCC ID. [Superior communications.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Superior communications.] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 7.04.2023 Applicant’s Name: George Chen US Agent’s Name: George Chen Title: VP Product Development Title: VP Product Development Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Superior communications. Grantee code: YJW FCC ID: YJW-10470PG Contact Name: George Chen Address: 5027 Irwindale Ave.Suite Irwindale Ave California United States. Telephone No: 818-636-4985 Fax No: 626-608-9043 Email: [email protected] i. [Superior communications.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Superior communications.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Superior communications. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 7.04.2023 Applicant’s Name: George Chen Title: VP Product Development Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Superior communications. Address: 5027 Irwindale Ave.Suite Irwindale Ave California United States. Product Name: Magnetic Wireless Car Charger Model Number: 10470PG FCC Identifier: YJW-10470PG We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: George Chen Date: 7/4/2023 Title: VP Product Development Signature of applicant:

C5266091_X10_Ed.1 1/1 Superior communications. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 7/4/2023 Subject: Request for Confidentiality FCC ID: YJW-10470PG To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: George Chen Date: 7/4/2023 Title: VP Product Development

Page 1 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: 10470PG Page 2 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 5 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

/ 2023.5.24 底壳 冷灰7C 1:1 LC32 1.0 SR03

Page 1 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: 10470PG Coli Page 2 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 3 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 We b : www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230525022-01E2 Date of issue: 2023-06-07 Applicant: Superior Communications. Product: Magnetic Wireless Car Charger Model(s): 10470PG FCC ID: YJW-10470PG Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 13 Report No.: MTi230525022-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 13 Report No.: MTi230525022-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Description of support units ................................................................................................................................ 6 2 Measurement uncertainty ............................................................................................................... 6 3 Test facilities and accreditations .................................................................................................... 7 3.1 Test laboratory .................................................................................................................................................... 7 4 List of test equipment ..................................................................................................................... 8 5 Test result ........................................................................................................................................ 9 5.2 Test setup ......................................................................................................................................................... 10 5.3 Test Procedures ................................................................................................................................................ 10 5.4 Equipment Approval Considerations item 5 b) of KDB 680106 D01 v03r01 .................................................... 11 5.5 Test results ....................................................................................................................................................... 12 Photographs of the Test Setup ............................................................................................................ 13 Photographs of the EUT....................................................................................................................... 13 Page 4 of 13 Report No.: MTi230525022-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Superior Communications. Address: 5027 Irwindale Ave.Suite Irwindale Ave California United States Manufacturer: Shenzhen Powerqi Technology Co., Ltd. Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China Product description Product name: Magnetic Wireless Car Charger Trademark: PUREGEAR Model name: 10470PG Series Model: N/A Standards: FCC CFR 47 PART 1, § 1.1310 Test method: KDB 680106 v03r01 Date of Test Date of test: 2023-06-01 ~ 2023-06-07 Te s t result: Pass Test Engineer : (Yanice Xie) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) Page 5 of 13 Report No.: MTi230525022-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: Magnetic Wireless Car Charger Model name: 10470PG Series Model: N/A Model difference: N/A Electrical rating: Input: 5V/2A; 9V/2.22A; 12/1.67A Wireless Output: 5W,7.5W,10W,15W Accessories: 1. Cable: USB-A TO TYPE-C cable 1.4M 2. Car charge*1 3. Suction cup*1 4. Air outlet rack*1 5. Sheet iron*1 Hardware version: V10 Software version: V10 RF specification: Operation frequency: 115 kHz – 205 kHz Modulation type: ASK Antenna type: Coil Antenna 1.2 Description of test modes All the test modes were carried out with the EUT in normal operation, the final test mode of the EUT was the worst test mode for emission test, which was shown in this report and defined as: No. Emission test modes Mode 1 Wireless Output(5W) Mode 2 Wireless Output(7.5W) Mode 3 Wireless Output(10W) Mode 4 Wireless Output(15W) Mode 5 Standby The test data only show wo…

Text truncated - open the document above for the full version.

Page1of4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address: 东莞市石碣镇西沙路 2 号 Tel ： 86-076986018114Fax ： 86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 东莞市金赞智能科技有限公司 产品规格书 PRODUCTSPECIFICATION 拟制 PREPAREDBY 跟单员 MERCHANDISER 工程审核 ENGINEER CHECKEDBY 制程审核 PRODUCTION CHECKDEDBY 批准 APPROVEDBY 王云帆 客户：深圳市倍力奇科技有限公司 CUSTOMER:____________________________________________________________________ 客户料号：3-122DX01010AA-023 CUSTP/N:____________________________________________________________________ 金赞料号：单线圈 KCP/N:____________________________________________________________________ 产品型号：20.5*38*0.08*24P*2P*10TS*12MM DESE: 日期：2023.5.30 DATE:____________________________________________________________________ 版本：A.0 VERSION:____________________________________________________________________ （客户承认受领印）ACCEPTANCESTAMP Pageof4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-023 20.5*38*0.08*24P*2P*10TS*12MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 2 版本 Rev. 变更前 BeforeChange 变更后内容 DESCRIPTION(ContentOrReasonForChanged) 日期 Date 修订者 Revisor A.0--新发行（InitialRelease）2023/5/30王云帆 Pageof4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-023 20.5*38*0.08*24P*2P*10TS*12MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 3 1.产品外形尺寸（OVERALLDIMENSIONSOFPRODUCTS): 单位(Unit):毫米(mm) PS:1.（F）为磁外引线长度；2.（H）包含进线，不包含离型纸；3.引线间距：5mm胶布 圈数 Turn s 线径 WireDia. 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 线圈正/反贴 Coil Positive/AntiPaste 10TS 0.08*24P*2P热风绞线 （Strandedwire） 密绕（Close） 逆时针 （Anticlockwise） 是（Yes）反贴（Anti/-Paste） ABCDEFGHI 5.3±0.520.5±0.538±140±13±112±10.55±0.052.0MAX7±2 Pageof4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-023 20.5*38*0.08*24P*2P*10TS*12MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 4 所有材料要求合格ROHS标准 2.电气特性（ELECTRICALCHARACTERISTICS): 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±10% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1INDS-F 线圈加磁片：6.3uH±10% 1kHz/VLCZMETER1062 3.材料清单（BILLOFMATERIAIS): 序号 NO. 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 厂商代码 Vendorcode 1 线材0.08*24P*2P热风绞线 JX-2U-F-0009 ZY 2 铁氧体 40±1*5.3*0.8±0.1H（带孔，带U型直槽） GCP-T-0088LX 3 双面胶38.5*5.3*0.08H（带孔，带手撕） SMJ-00056 NR 4 金手指胶布5mm 高温胶纸5MMJRM 5 胶水JS-E7202（加稠）白胶 E7202WHZY 6 锡条环保无铅焊锡条 无铅高温锡条XC 7 热缩套管（黑色）ø0.8*10MM RS-TG-30-006KK

Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230525022-01E1 Date of issue: 2023-06-07 Applicant: Superior Communications. Product: Magnetic Wireless Car Charger Model(s): 10470PG FCC ID: YJW-10470PG Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 20 Report No.: MTi230525022-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 20 Report No.: MTi230525022-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 6 1.3 Description of support units ................................................................................................................................ 6 1.4 Environmental conditions ................................................................................................................................... 6 2 Measurement uncertainty ............................................................................................................... 7 3 Test laboratory ................................................................................................................................. 7 4 Summary of Test Result .................................................................................................................. 8 5 List of test equipment ..................................................................................................................... 9 6 Test Results ................................................................................................................................... 10 6.1 Standard requirement ....................................................................................................................................... 10 Description of the EUT antenna ............................................................................................................................. 10 6.2 AC power line Conducted emissions ................................................................................................................ 11 6.3 Radiated emissions .......................................................................................................................................... 12 6.4 Occupied bandwidth test .................................................................................................................................. 19 Photographs of the test setup ............................................................................................................. 20 Photographs of the EUT....................................................................................................................... 20 Page 4 of 20 Report No.: MTi230525022-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Superior Communications. Address: 5027 Irwindale Ave.Suite Irwindale Ave California United States Manufacturer: Shenzhen Powerqi Technology Co., Ltd. Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China Product description Product name: Magnetic Wireless Car Charger Trademark: PUREGEAR Model name: 10470PG Series Model: N/A Standards: FCC 47 CFR Part 15 Subpart C Test method: ANSI C63.10-2013 Date of Test Date of test: 2023-06-01 ~ 2023-06-07 Test result: Pass Test Engineer : (Yanice Xie) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) Page 5 of 20 Report No.: MTi230525022-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: Magnetic Wireless Car Charger Model name: 10470PG Series Model: N/A Model difference: N/A Electrical rating: Input: 5V/2A; 9V/2.22A; 12/1.67A Wireless Output: 5W,7.5W,10W,15W Accessories: 1. Cable: USB-A TO TYPE-C cable 1.4M 2. Car charge*1 3. Suction cup*1 4. Air outlet rack*1 5. Sheet iron*1 Hardware version: V10 Software version: V10 Test sample(s) number: MTi230525022-01S1001 RF specification: Operation frequency: 115 kHz – 205 kHz Modulation type: ASK Antenna type: Coil Antenna Page 6 of 20 Report No.: MTi230525022-01E1 Address: 101, N…

Text truncated - open the document above for the full version.

Page 1 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - Test Setup Photos Model: 10470PG Radiated emissions – Below 30 MHz Radiated emissions –Below 1 GHz Page 2 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] MPE ----End of Report----
