YNIJAZWARES15295BSTAR WARS - Mouse

2408-2474 MHz 2.4G Filter/match Key ENCODER Crystal X1 12.000MHz MA4302 EEPROM U2 XX24C02 SENSOR PAN3204 Battery

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT - Front View EUT - Rear View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Battery off View EUT – Cover off View EUT – Main Board Top View EUT – Main Board Bottom View EUT – RF Module Top View EUT – RF Module Bottom View Antenna

Circuit Description 1. CPU, MA4302 have an 8-bit microprocessor with low-power and high-speed CMOS technology. Operation frequency is needs an external 12MHz crystal for reference frequency. 2. E2PROM, 24C02, 2048 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 256 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power operation is essential. 3. Fully programmable PLL (2.4GHz) Built-in Channel filter Data Rate up to 1MHz 4. OPTICAL SENSOR, with DSP integration chip that serves as a non-mechanical motion estimation engine for implementing a computer wireless mouse. 5. ANTENNA, The antenna is typically fed from the end of the monopole section by a plated through-hole via which is in turn connected to the RF output on the 2.4 GHz band.

1 2 3 4 ABCD 4 3 2 1 D CBA V1.0 1 1 2012/03/30 Osan Revision Date: Drawn By: sheet of CPI+ Key define 1200cpi 1600cpi 800cpi CPI+ C120.1uF R15 15K R9 4.7K C2056pF C19 1.8nF C114.7uF C10 0.1uF 3.0V L122nH C7 C17 *1pF C6 *47pF C14 0.1uF + C410uF 1.8V 1.8V X1 12MHz C26*27pF C25*27pF R16 1M C13 0.1uF 1.8V 3.0V C5 100uF/220uF C2968pF 3.0V GNDZ1Z2 SW_ZENCODER K03 K02 K01 K00 P01P02P03 MISO MOSI/SDIO SCLK E_SCLE_SDA C9 0.1uF C8 0.1uF C15 1nF 3.0V K00 11 K01 10 P05/I2CSDA 28 P06 27 P07 26 P10/SPI0DI 25 P13/SPI0RDY 34 P20/PWM0 41 P21/PWM1 42 P22/FOUT 43 P23/NRZCLK 44 P11/SPI0DO 24 P12/SPI0CK 23 XRESET 5 K02 9 VCO_Guard/REG_VCO 62 VSS_Guard/_LOGIC 64 XCLKI 4 XCLKO 3 K03 8 K04 7 K05 6 VSS/VSS18 14 XOSCI 13 XOSCO 12 VBAT 22 P00/XA 33 P01/XB 32 P02/YA 31 P03/YB 30 P04/I2CSCL 29 IOVDD0 35 P14/SPI1DI 37 P15/SPI1DO 38 P16/SPI1CK 39 P17/SPI1RDY 40 V_CAP 47 OP_OUT 48 RSSI_OUT_90_N 49 RSSI_OUT_90 50 RSSI_DC 53 VOSN 51 VOSP 52 CP_OUT 61 VSS_VCO_G 60 ANT_PA1 58 ANT_PA0 59 VSS_ANT_AC 57 VSS_ANT_DC 56 REG_LNA 55 REG_BASE 54 REG_LOGIC 1 VCO_TUNE 63 IOVDD1 36 VPP 45 VSS_BASE 46 VDD 17 VDD18/Ldo_Out 15 AVDD18 2 VDD18_FT 16 VD2_DC 18 VL_DC 19 VSS_DC 20 VD1_DC 21 U2 A0 1 A1 2 A2 3 VSS 4 SDA 5 SCL 6 WP 7 VCC 8 U424LC02 C27 0.1uF R2210K 3.0V E_SCLE_SDA 0(PAN-S) +90(PAN-S) 180(PAN-S) -90(PAN-S) JR1=NC JR1=0R JR2=0RJR2=NC Sensor PAN3204 **Angle select ANTENNA 2408MHz---2474MHz P01 3.0v GND Z1Z2 SW_Z ENCODER _+ BT1 SW1Power SW P03 1.8V K01 SCLK K00 3.0v MOSI/SDIO K02 C21 100uF 8 7 9 6 10 54321 11121314 A?DIP-2-14 LED1 0RNC PAN3204 Sensor Select PAN3204VLPAN3204LPAN3204LL U1 JR5 0RNC R136K36KNCNC MA4302 1 2 3 4 ABCD 4 3 2 1 D CBA V1.0 1 1 2012/03/30 Osan Revision Date: Drawn By: sheet of LED2 C10.1uF 3.0V LED 5 VDD 7 1 MOTSWK 2 SDIO 3 SCK 4 VDDA 8 VSS 6 U1 MOSI/SDIOSCLK SW_RBUT SW_LBUT K01 K00 K02 SW_BBUT SW_FBUT P03P01 SW_DPI+ * P01 ~ P03 K00 ~ K03:Key scan   SW_MBUT VBAT IN R11 P01 3.0V GND Z1Z2 SW_Z ENCODER _+ BT1 SW1Power SW P03 1.8V K01 SCLK K00 3.0V MOSI/SDIO K02 C21 100uF 8 7 9 6 10 54321 11121314 A?DIP-2-14 LED1 0(PAN-S) +90(PAN-S) 180(PAN-S) -90(PAN-S) JR1=NC JR1=0R JR2=0RJR2=NC Sensor PAN3204 **Angle select C2 22uF PAN3204TJDB

Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Shenzhen). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, or any agency of the Federal Government. * This report contains data that are not covered by the NVLAP accreditation and are marked with an asterisk “★” (Rev.2) FCC PART 15.249 TEST REPORT For Jazwares Inc 1067 Shotgun Road, Sunrise, FL 33326, USA FCC ID: YNIJAZWARES15295B Report Type: Original Report Product Type: STAR WARS - Mouse Test Engineer: Brown Lu Report Number: RSZ120420813-00 Report Date: 2012-04-28 Reviewed By: Alvin Huang EMC Engineer Test Laboratory: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ120420813-00 FCC Part 15.249 Page 2 of 14 TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .....................................................................................3 OBJECTIVE...................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................3 TEST METHODOLOGY..................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................3 SYSTEM TEST CONFIGURATION ..........................................................................................................................5 JUSTIFICATION.............................................................................................................................................................5 EQUIPMENT MODIFICATIONS.......................................................................................................................................5 CONFIGURATION OF TEST SETUP.................................................................................................................................5 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................5 SUMMARY OF TEST RESULTS...............................................................................................................................6 FCC§15.203 - ANTENNA REQUIREMENT..............................................................................................................7 APPLICABLE STANDARD..............................................................................................................................................7 ANTENNA CONNECTOR CONSTRUCTION......................................................................................................................7 FCC§15.205, §15.209&§15.249- RADIATED EMISSIONS ......................................................................................8 APPLICABLE STANDARD..............................................................................................................................................8 MEASUREMENT UNCERTAINTY....................................................................................................................................8 TEST EQUIPMENT SETUP..............................................................................................................................................8 EUT SETUP..................................................................................................................................................................9 TEST PROCEDURE........................................................................................................................................................9 CORRECTED AMPLITUDE & MARGIN CALCULATION...................................................................................................9 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................10 TEST RESULTS SUMMARY..........................................................................................................................................10 TEST DATA................................................................................................................................................................10 FCC§15.249(D) - OUT OF BAND EMISSION (50DB ATTENUATION) .............................................................13 APPLICABLE STANDARD............................................................................................................................................13 TEST PROCEDURE......................................................................................................................................................13 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................13 TEST DATA................................................................................................................................................................13 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ120420813-00 FCC Part 15.249 Page 3 of …

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emissions View (30 MHz - 1GHz) Radiated Emissions View (Above 1GHz)
