Impact Sensor The Impact Sensor, only offered with the WellAWARE™ Systems, is placed on the floor and detects vibrations through the floor. It can detect disabling falls in a fifteen foot radius. The Data Manager uses this data in tandem with the motion sensors to infer whether a fall has happened in the apartment. The Impact Sensor can differentiate between a solid object falling and a person falling hard. Installation: The batteries (4AA-cell) are installed by unscrewing the retainer screw on one side of the detector. Pull the battery compartment open. The battery pack comes out of the box. After the batteries are replaced and reconnected to the box carefully place the battery pack in the box as shown. The top can then be screwed back on. First the floor type needs to be determined. There are 8 settings: These are set by the rotary switch near the bottom of the detector. This switch can be changed carefully by simply rotating the knob. The settings from 0 to 7 go from least sensitive to most sensitive. A wooden floor will need a less sensitive setting because the vibrations being detected will show up easily. A concrete slab floor will need a much more sensitive setting since vibrations don’t travel as well through it. Less Sensitive ... More Sensitive Wood Mezzanine Noisy Slab Slab “ 0“ “ 7“ Make sure the switch is clicked in place. If it is in between settings the sensor will behave unpredictably. Set the floor to the one that best describes the where it will be placed, i.e. if it is a 2 nd floor of concrete in a building where there is industrial equipment nearby this would be considered noisy mezzanine. The more solid the floor is (concrete etc) the more sensitive the setting will need to be. If the floor is less solid (a 2 nd story wood floor) it will need to be set to the less sensitive side. When the Impact Sensor is in place out of the way it can be tested. Test it by walking near it. The LED shouldn’t light up. If this is not the case you should use a less sensitive setting. Then stomp three times near it. The LED should light up. If this is not the case try using a more sensitive setting. Considerations: This sensor does not detect falls. It detects impacts associated with hard falls within a fifteen foot radius. If the sensor is placed near a wall its range may be limited. However load bearing walls have more of a limiting effect than partitions. In some cases you may be able to place a sensor close to a wall and increase the sensitivity a notch to compensate for the dampening effect of the wall. The sensor must be placed out of the way and preferably out of sight. If it is in plain sight it may be tampered with resulting in faulty data. Good examples for placement are: under the bed, between a partition and a table etc. FCC COMPLIANCE
