YNVZTRPT433Signal repeater

WellAWARE Systems Inc
Signal repeater - FCC ID YNVZTRPT433 - WellAWARE Systems Inc
Click to zoom

Application Details

Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Date of Grant
Aug 29, 2010
Application Purpose
Original Equipment
Date of Application
Aug 25, 2010
Equipment Note
Signal repeater
Frequency Range
433.92000000 - 433.92000000
Company
WellAWARE Systems Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ZT-RPT433 Repeater for WellAWARE Systems wireless sensors The repeater resends signals from any WellAWARE Systems sensor or PC attached radio (USB433). The repeater works on two layers, so it will resend a signal that has been send by another repeater, but not one that has been resent by two repeaters. On power on the RPT433 will send Heartbeat signal when you insert the AC adapter in the DC jack. The LED flashes when the repeater resends a signal. If the voltage is lower than 3.8V, the repeater will send “Low Voltage” Signal. Dimensions: 80 x 60 x 20 mm 3.15 x 2.36 x .79 in Software Protocol Info: Device Type: 0x Command Data 0x01 0x0000 HeartBeat (once every 4 hours) 0x02 0x8000 Normal Voltage 0x0000 Low Voltage 0x03 0x0000 Enrolled Signal 0xFE Tx' Address Acknowledgement Features • 100ft wireless range • 433MHz wireless radio Requirements • Line Power • Mounting Tape The "HearBeat" signal is transmitted every 4 hours when the sensor is in the idle mode. If ZT-RPT433 receives the RF signal, it will send the ACK signal. Then byte_1 of protocol will be increased “1” and re-send RF signal. Byte 1 bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0 RESERVE Repeater Bits If the repeater bits of byte 1 in a received signal are more than 2, the repeater will not retransmit the signal.

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

ID Label/Location Info

ZT-RPT-433規格貼紙 ZT-RPT-433FCC貼紙 ZT-RPT-433

Internal Photos

Page 3 Page 4 Page 5 Page 6 Page 7

Operational Description

FCC ID: YNVZTRPT433 Report No.: RF990628D12 Operational Description The transmitter of the EUT (Signal repeater) is powered by 5Vdc from adapter. The type of antenna is Monopole Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Test Report

Report No.: RF990628D12 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990628D12 MODEL NO.: ZT-RPT433 FCC ID: YNVZTRPT433 RECEIVED: June 28, 2010 TESTED: July 6, 2010 ISSUED: July 15, 2010 APPLICANT: WellAWARE Systems Inc. ADDRESS: 5500 Cox Rd, Glen Allen, VA23060 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan This test report consists of 31 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990628D12 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS..................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION..........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...........................10 3.4 DESCRIPTION OF SUPPORT UNITS......................................................10 4. TEST TYPES AND RESULTS....................................................................11 4.1 CONDUCTED EMISSION MEASUREMENT............................................11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................11 4.1.2 TEST INSTRUMENTS..............................................................................11 4.1.3 TEST PROCEDURES...............................................................................12 4.1.4 DEVIATION FROM TEST STANDARD.....................................................12 4.1.5 TEST SETUP............................................................................................13 4.1.6 EUT OPERATING CONDITIONS..............................................................13 4.1.7 TEST RESULTS........................................................................................14 4.2 RADIATED EMISSION MEASUREMENT.................................................16 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................16 4.2.2 TEST INSTRUMENTS..............................................................................18 4.2.3 TEST PROCEDURES...............................................................................19 4.2.4 DEVIATION FROM TEST STANDARD.....................................................19 4.2.5 TEST SETUP............................................................................................20 4.2.6 EUT OPERATING CONDITIONS..............................................................20 4.2.7 TEST RESULTS........................................................................................21 4.3 20dB OCCUPIED BANDWIDTH MEASUREMENT...................................24 4.3.1 LIMITS OF EMISSION BANDWIDTH MEASUREMENT...........................24 4.3.2 TEST INSTRUMENTS..............................................................................24 4.3.3 TEST PROCEDURE.................................................................................24 4.3.4 DEVIATION FROM TEST STANDARD.....................................................25 4.3.5 TEST SETUP............................................................................................25 4.3.6 TEST RESULTS........................................................................................26 4.4 DEACTIVATION TIME...............................................................................27 4.4.1 LIMITS OF DEACTIVATION TIME MEASUREMENT................................27 4.4.2 TEST INSTRUMENTS..............................................................................27 4.4.3 TEST PROCEDURES...............................................................................27 4.4.4 DEVIATION FROM TEST STANDARD.....................................................27 4.4.5 TEST SETUP............................................................................................27 4.4.6 TESE RESULTS........................................................................................28 Report No.: RF990628D12 3 Report Format Version 3.0.1 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................29 6. INFORMATION ON THE TESTING LABORATORIES...............................30 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................31 Report No.: RF990628D12 4 Report Format Version 3.0.1 1. CERTIFICATION PRODUCT: Signal repeater BRAND NAME: MODEL NO.: ZT-RPT433 APPLICANT: WellAWARE Systems Inc. TESTED: July 6, 2010 TEST SAMPLE: MASS-PRODUCTION STANDARDS: FCC Part 15, Subpart C (Section 15.231) ANSI C63.4-2003 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: July 15, 2010 ( Annie Chang / Senior Specialist ) TECHNICAL ACCEPTANCE : , DATE: July 15, 2010 Responsible for RF ( Jamison Chan / Supervisor )…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST

Contact Information

Applicant

Jeff Segal(CTO)
[email protected]804-249-2149Fax: 804-249-2158

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchKen Liu
[email protected]886-2-2605-2180

No. 47, 14 Ling, Chia Pau Tsuen, Lin Kou Hsiang, · Linkou, Taipei · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchWendy Liao
[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-3-3183232Fax: 886-3-2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
115.231433.92 MHz - 433.92 MHz-
