YUYSSRC002RF REMOTE CONTROL

Brushless DC Tubular Motor Operation Manual Tubular Motor Type： SS40E Remote Control Type： ZEN16SA、ZEN16DA - 2 - Table of Content Before Using Safety recautions 3 Name of Each Part 4 Installation 7 Settings Switch Setting Mode / User Mode 11 Switch blind system 13 Set Connection Between Motor and Remote Control 14 Cancel the Connection 15 Switch Between Forward and Reverse Rotations 16 Set Upper and Lower limits 17 Set Group Control 19 Duplicate Remote Control 21 Cancel『Other』Remote Control 22 Set \ Cancel Preferred Position 23 Operate Preferred Position 24 Quick Command Guide 25 Miscellaneous Troubleshooting 27 Illustration of Wiring 28 Appendix 29 - 3 -  Before using th is product , please read the manual carefully.  After reading , please keep this manual properly for future reference.  In this manual, the precautions indicated as Warnings and Cautions. Please observe the following precautions to ensure safety. Warning This indicates " Possible death or serious injury may occur ". Caution This indicates " Possible injury or material damage may occur". Warning  The appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.  Children being supervised not to play with the appliance.  Important safety instructions. Follow all instructions, since incorrect installation can lead to severe injury.  Do not allow children to play with fixed controls. Keep remote controls away from children  Frequently examine the installation for imbalance and signs of wear or damage to cables and springs. Do not use if repair or adjustment is necessary.  Full all-pole disconnection from the supply mains must be provided in the fixed wiring in accordance with the wiring rules. Caution To reduce the fire risk of electric shock or product damage:  Do not expose the equipment to rain, moist, water dripping or water splashing environment; and do not place objects fully filled with water next to the equipment.  Do not disassemble this equipment.  Do not use any power supply with a voltage not complying with the rated voltage of the equipment.  If there is any abnormal condition or when it needs repair, please contact your distributor or the original dealer. If you find any errors in this manual, or if you are not clear about the description in this manual, please contact the distributor. Thank you! Safety Precautions ！ ！ ！ ！ - 4 -  SS40E series Tubular Motor 1. Driving Wheel：  It connects the tubular motor to the aluminum tube so that the motor may drive the aluminum tube to rotate. 2. Code Button：  It is for setting the communication code between the remote control unit and the tubular motor. 3. Crown 4. Antenna：  It is for receiving instructions from the remote control unit. 5. AC Power Cord Name of Each Part 1 2 3 4 5 - 5 -  ZEN16SA remote control  Front side details 1. LCD Screen： A. Group channel : 4 group control channels available from G1 to G4. B. Window channel: 16 window channels available from 1 to 16. C. All: to control all channels at the same time. D. Battery: appears only low battery. E. OK: a confirm key during group control settings. F. Window number frame selection: the currently promoted window number. 2. Channel selection buttons「」、「」、「<」、「>」:  To select window channel or group channel or All. 3. ENTER :：  To confirm channel selected. 4. UP :：  To lift blinds upward. 5. STOP：  To stop blinds movement, or move blinds to preferred position, or switch between forward and backward rotations. 6. DOWN：  To move blinds downward. 1 4 5 6 2 3 2 A D B C E LCD Screen detail F - 6 -  Reverse side details 1. Duplicate button： 2. To duplicate or cancel the remote control 3. Mode switch：  To switch between USER MODE and SETTING MODE。 4. Battery cover ※Notice: About the remote control:  Please do not install the socket at a location that may be exposed to direct sunlight.  If the Remote Control activates other electronic appliances, please contact the distributor. Caution:  FCC ID: YUYSSRC002  This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.  Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 2 1 3 - 7 - 1. Select a suitable aluminum tube 2. Insert the tubular motor into tube Installation  Installation of motorized blinds： Cylindrical Aluminum Tube Inside diameterφ40 Slot size 13㎜ 5㎜ Molded Aluminum Tube AT D 4 6 Molded Aluminum Tube AT D 5 0 A "plastic ring for ATD50" is required Molded Aluminum Tube AT D 5 1 A " ring for ATD51" is required Molded Aluminum Tube AT O 4 3 Specified tube for venetian blinds - 8 - 3. Position the Crown pin into the slot. 4. Fasten the tube at the motor end with screws (not a necessity, may skip this step) 5. Inset the idler wheel onto tube. Cylindrical Aluminum Tube Molded Aluminum Tube Position for inserting the Positioning Pin of the Crown Positions for mounting the screws - 9 - 6. Fasten the tube at the idler wheel end with screws (not a necessity, may skip this step ). 7. Install the brackets: Measure a suitable distance for installing the brackets to the target position (in the curtain box or on the wall). 8. Install the motorized blinds: Install the motorized blinds onto the brackets. 9. Connect to the electric power: Connect power cord to AC power before setting and operation. 。 Positions for mounting the screws Notice！The positioning slot should be firmly fixed into the bracket. - 10 -  Screen display sequences after installing battery  Battery installation 1 3 2 1. Open the battery cover 2. Insert the battery (notice the polarity ○ ＋ /○ － ) 3. Close the battery cover 4. Battery speci…
