YWLLWMV140003Collects voltage and current readings from MVSS sensors

QinetiQ North America, Inc.
Collects voltage and current readings from MVSS sensors - FCC ID YWLLWMV140003 - QinetiQ North America, Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Oct 01, 2014
Application Purpose
Original Equipment
Date of Application
Oct 01, 2014
Equipment Note
Collects voltage and current readings from MVSS sensors
Frequency Range
2412.00000000 - 2462.00000000
Company
QinetiQ North America, Inc.
Country
United States

Documents & Files

Select a file to view

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

QNA Proprietary MEMO-1102190152 Page 1 of 1 QNATSG0346 Form Rev D This document is proprietary and its contents are the exclusive property of QinetiQ North America (QNA). This document may NOT be reproduced in any format without prior written permission from QNA. MEMORANDUM TO: MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 DATE: 2/11/14 FROM: QinetiQ North America, Inc. Technology Solutions Group 350 Second Avenue Waltham, MA 02451 NUMBER: MEMO-1102190152 CC: REVISED: 7/10/14 SUBJECT: CONFIDENTIALITY REQUEST FOR PRD-1102191005/YWLLWMV140003 FOR FCC CERTIFICATION ATTACHMENT: To Whom It May Concern: This letter serves as an official request for confidentiality for FCC certification under sections 0.457 and 0.459 of CFR 47. We have requested that all items identified by and pertaining to PRD-1102191005, including the schematics, block diagrams, user manual, operational description, and all parts lists of the device required to be submitted with this application be permanently withheld from public review, unless otherwise instructed by QNA. The above documents are QNA proprietary information, which contain intellectual property, and QNA requests that they not be shared with the public. Please contact me if there is any information you may need. Sincerely, Chuck DeLoid Systems Engineer
