YZP-VL3020Telematics Module

LG Innotek Co., Ltd.
Telematics Module - FCC ID YZP-VL3020 - LG Innotek Co., Ltd.
Click to zoom

Application Details

Equipment Class
PCB - PCS Licensed Transmitter
Date of Grant
Mar 01, 2021
Application Purpose
Original Equipment
Date of Application
Mar 01, 2021
Equipment Note
Telematics Module
Frequency Range
1720.00000000 - 1745.00000000
Company
LG Innotek Co., Ltd.
Country
South Korea

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Copyright ⓒ. 2020. All Rights Reserved. Data sheet for the LTD-VL3020 1.Overview 2.Major features 3.Interface 4.Electrical specifications 5.RF specifications 6.Mechanical specifications 7.General specifications 8.RFx information 9.Approbation FCC Table of Contents Product: LTE Wireless Modem Model name: LTD-VL3020 Copyright ⓒ. 2020. All Rights Reserved. The LTD-VL3020 is a personal mobile communication device that incorporates the latest compact radio technology, including smaller and lighter components and support LTE Band 2,4,5,13. This device acts as the vehicle’s telematics system and connects to LTE wireless networks and wireless modules to allow voice and data communication. Furthermore, this device can operate on land and water as well as other similar areas. In LTE mode (CAT4), the device provides uplink speeds of up to 50 Mbps and downlink speeds of up to 150 Mbps for seamless transfer of data such as movies and video calls. The device also supports the transfer of large amounts of data. The device communicates with the host system via a standard RS-232 or USB port, and AT commands and control commands can be used to send data. Voice calls are also possible. 1. Overview Copyright ⓒ. 2020. All Rights Reserved. Mechanical Dimensions 34.0 x 40.0 x 3.5 mm (L x W x T) (Tolerance – width, length: ±0.15 / height: ±0.2) Weight Max. 10.6 grams Interface USB, general purpose I/O pins Temperature* Operation: -20 °C - +70 °C Storage: -40 °C - +85 °C Technology Main chipset MDM9628 Memory 4Gb(NAND) / 2Gb(SDRAM) Standard LTE - DL Speed : 150 Mbps - UL Speed : 50 Mbps Band LTE B2, B4, B5, B13 Power LTE : Typ. 23dBm (Power Class 3) ETC DC power 4 V Functions Voice, data, SMS 2. Major features Copyright ⓒ. 2020. All Rights Reserved. 3. Interface 3.1 LGA Pad Layout (Top View) Figure 1. LGA Pin map GND GNDGNDGND GND GND 21 GND MAIN_ ANT GNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGND ANT_ DIV GND 20 GNDGND MAIN_ ANT_D TC_EN GNDGNDGNDGNDGNDGNDGNDGNDGND DIV_AN T_DTC_ EN GNDGND 19 GNDGNDADC1GNDGNDGNDGNDGNDGNDGNDGNDGNDGNDADC2GNDGND 18 GNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGND 17 VPH_P WR GNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGND GNSS_ ANT 16 VPH_P WR GNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGND 15 VPH_P WR GNDGNDGNDGNDGNDGNDGNDGNDGND 14 VPH_P WR GNDGNDGNDGNDGNDGNDGNDGNDGNDGND 13 GNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGNDGND 12 NCGNDGNDGNDGNDGNDGNDGNDGNDGNDGND 11 GNDGNDGNDGNDGNDGNDGNDGNDGND SGMII _RX_M SGMII _TX_P EPHY_ RST_N SGMII _CLK EPHY_ INT_N 10 GNDGNDGNDGNDGNDGNDGND SGMI I_RX_P SGMII _TX_M SGMII _DATA GND 9 VPH_P WR VREG_L 11_1P8 GNDNCNCGNDGNDGNDGNDGNDGNDGNDGND MDM_J TAG_SR ST_N 8 VPH_P WR VREG_L 11_1P8 GNDGNDGNDGNDGND MDM2 AP_INT _N AP2MD M_INT_ N[ MDM_J TAG_TC K MDM_J TAG_PS _HOLD 7 VPH_P WR VPH_P WR GNDNC SPI_LE VEL_SH IFT_EN GND COEX_ UART_R X GND MDM_J TAG_T MS MDM_J TAG_TR ST_N 6 GNDGNDGPIO1 ACC_P WR_ON GNDGPIO3GPIO4GND SPI_CS_ N SPI_CL K GND DSRC_ SLP_CL K COEX_ UART_T X MDM_J TAG_TD O MDM_J TAG_TD I 5 GNDNCGPIO2GNDBOOT_OK UART1_ TX UART2_ TX UART3_ TX SPI_INT ERRUPT SPI_MO SI SPI_MI SO GND WLAN_ 3V_ EN_DS GNDGNDGND 4 MDM_ RESOU T_N NCGNDMSGGND UART1_ RX UART2_ RX UART3_ RX GNDGNDGND RFCLK2 _QCA DSRC _PPS GND Eherne t_DC- DC_EN 3 PHONE _ON_N LGA_RE SIN_N GND 96H_E ND UIM1_P RESENT GNDGNDGND SDC_ DATA3 SDC_ DATA2 GND PCM_E N PCM_D IN WLAN_ E N_DSR GND VRG_L 5_UIM2 2 GNDGND VREG_L 6_UIM1 UIM1_C LK GNDUSB_ID USB_H S_DM GND SDC_ DATA1 SDC_ DATA0 GND PCM_C LK GND HSIC_ DATA NC 1 GNDGND UIM1_R ESET UIM1_ DATA GND USB_VB US USB_H S_DP GND SDC_ CMD SDC_ CLK GND PCM_S YNC PCM_D OUT GND HSIC _STB NC GND GND GND GNDGNDGND AEYZAAABACADSTUVWXMNOPQRGHIJKLABCDEF Copyright ⓒ. 2020. All Rights Reserved. 3. Interface 3.2 Pin description Table 1. Pin descriptions PAD. NAME DIRECTION DESCRIPTION Antenna Interface Pads C21 MAIN_ANT Input/Output RF Main Antenna AC21 DIV_ANT Input RF Diversity Antenna AE17 GNSS_ANT Input GNSS Antenna User Interface Pads H6 ACC_PWR_ON Input ACC_PWR_ON I5 BOOT_OK Output BOOT_OK H4 MSG Output MSG G3 168H_END Output Remote standby mode end F20 MAIN_ANT_DTC_EN Output Main ANT Detect Enable Z20 DIV_ANT_DTC_EN Output Diversity ANT Detect Enable I7 SPI_LEVEL_SHIFT_EN Output SPI LEVEL SHIFT Enable AD4 ETHERNET_DCDC_ENABLE Output Ethernet power enable F6 GPIO1 Input/Output (Do not use with External PU) General purpose I/O E5 GPIO2 General purpose I/O L6 GPIO3 Input/Output (Not support INTERR UPT) General purpose I/O N6 GPIO4 General purpose I/O ADC Interface Pads E19 ADC1 Input ADC Convertor input for main antenna detect AA19 ADC2 Input ADC Convertor input for diversity antenna detect PCM Interface Pads W3 PCM_EN Output PCM 3.3 Level Shifter Enable X2 PCM_CLK Input PCM Clock W1 PCM_SYNC Input PCM Frame Sync Y3 PCM_DIN Input PCM Data In Y1 PCM_DOUT Output PCM Data Out JTAG Pin Description AC7 MDM_JTAG_TMS Input/Output JTAG mode select input AD8 MDM_JTAG_PS_HOLD input JTAG PS HOLD detect AD6 MDM_JTAG_TDI Input JTAG data input AE7 MDM_JTAG_TRST_N Input JTAG reset for debug AB6 MDM_JTAG_TDO Output JTAG debugging AB8 MDM_JTAG_TCK Input JTAG clock input AE9 MDM_JTAG_SRST_N Input JTAG reset USB Interface Pads N2 USB_HS_DM Input/Output USB high speed data (minus) M1 USB_HS_DP Input/Output USB high speed data (plus) K1 USB_VBUS Input USB power L2 USB_ID Input USB ID SDIO Interface Pads S1 SDC_CLK Output Secure digital controller clock Q1 SDC_CMD Output Secure digital controller command T2 SDC_DATA0 Input/Output Secure digital controller data bit 0 R2 SDC_DATA1 Input/Output Secure digital controller data bit 1 S3 SDC_DATA2 Input/Output Secure digital controller data bit 2 Copyright ⓒ. 2020. All Rights Reserved. 3. Interface Table 1. Pin descriptions Q3 SDC_DATA3 Input/Output Secure digital controller data bit 3 SGMMI Interface Pads AA11 EPHY_RST_N or UIM2_RESET Output Ethernet PHY reset AE11 EPHY_INT_N or UIM2_DETECT Input Ethernet PHY interrupt AB10 SGMII_DATA or UIM2_CLK Input/Output SGMII input Output data AD10 GND Ground X10 SGMII_RX_P Input SGMII receive - plus W 11 SGMII_RX_M Input SGMII receive -minus…

Text truncated - open the document above for the full version.

Cover Letter(s)

Cover Letter-Modular Approval FCC ID: YZP-VL3020 Date: Feb. 15, 2021 Gentlemen: There’s a Telematics Module that would like to have your authorization as a modular approval. The specific product as below, Telematics Module with its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 by cross-reference list below. Company LG Innotek Co., Ltd. Model Name Telematics Module Model Number LTD-VL3020 FCC ID YZP-VL3020 Requirement of FCC KDB996369 Comply(Y/N) 1. The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, Please see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: YZP-VL3020” or “Contains FCC ID: YZP-VL3020” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific r ule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, By: ___________________ ___ Inchang Jeong_____ (Signature 1 ) (Print name) Title: Chief Research Engineer On behalf of: LG Innotek Co., Ltd. (Company Name) Telephone: +82-62-950-0332

Cover Letter(s)

LG Innotek Co., Ltd. 26, Hanamsandan 5beon-ro Gwangsan-gu Gwangju, 62229, Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER FOR AUTHORIZATION FCC ID : YZP-VL3020 To whom it may concern: I, the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; February 15, 2021 i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours Jeong Inchang Senior Research Engineer LG Innotek Co., Ltd. LG Innotek Co., Ltd. 26, Hanamsandan 5beon-ro Gwangsan-gu Gwangju, 62229, Korea

Cover Letter(s)

LG Innotek Co., Ltd. 26, Hanamsandan 5beon-ro Gwangsan-gu Gwangju, 62229, Korea Feburary 15, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST FOR CONFIDENTIALITY FCC ID : YZP-VL3020 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Innotek Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short‐Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04‐1705. This provision will give Samsung Electronics Co., Ltd temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics 4 Tune‐up Procedure / Part List Short‐ Term 5 External Photos 6 Internal Photos 7 Test Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours, Jeong Inchang Senior Research Engineer LG Innotek Co., Ltd.

Cover Letter(s)

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name LG Innotek Co., Ltd. Address 26, Hanamsandan 5beon-ro, Gwangsan-gu, Gwangju, 62229, South Korea Grantee Code YZP FCC ID YZP-VL3020 Authorized Contact Name Jeong, In-Chang Contact Email [email protected] Contact Phone 82-62-950-0332 I, t he undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accor dance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accept ing a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) l abeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if t he Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accor dance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accor dance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) t he Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the A pplicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link t o CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: February 15, 2021 Print Name: Jeong, In-Chang Title: Senior Research Engineer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

External Photos

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

ID Label/Location Info

Copyrightⓒ. 2017. All Rights Reserved. LTD-VL3020 Label 1. LGA Product Label 1.M/N : LTD-VL3020 5.FCC ID : YZP-VL3020 Copyrightⓒ. 2017. All Rights Reserved. Label location LTD-VL3020 Label LGA Module Label

Internal Photos

Internal photos of EUT Internal view of EUT Top view of Main PCB Bottom view of Main PCB

RF Exposure Info

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001669 Page: 1 of 6 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) TEST REPORT of FCC CFR 47 part 1, 1.1307(b), 1.1310 FCC ID: YZP-VL3020 Equipment Under Test : Telematics Module Model Name : LT D-VL3020 Variant Model Name(s) : - Applicant : LG Innotek Co., Ltd. Manufacturer : LG Innotek Co., Ltd. Date of Receipt : 2020.12.07 Date of Test(s) : 2020.12.07 ~ 2021.01.22 Date of Issue : 2021.02.09 In the configuration tested, the EUT complied with the standards specified above. This test report does not assure KOLAS accreditation. 1) The results of this test report are effective only to the items tested. 2) The SGS Korea is not responsible for the sampling, the results of this test report apply to the sample as received. 3) This test report cannot be reproduced, except in full, without prior written permission of the Company. Tested by: Technical Manager: SGS Korea Co., Ltd. Gunpo Laboratory SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001669 Page: 2 of 6 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents Page 1. General Information -------------------------------------------------------------------------------- 3 2. RF Exposure Evaluation -------------------------------------------------------------------------- 4 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001669 Page: 3 of 6 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil , Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone : +82 31 688 0901 FAX : +82 31 688 0921 1.2. Details of Applicant Applicant : LG Innotek Co., Ltd. Address : 26, Hanamsandan 5beon-ro, Gwangsan-gu, Gwangju, 62229, Korea Contact Person : Jeong, In-Chang Phone No. : +82 62 950 0332 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product Telematics Module Model Name LTD-VL3020 Serial Number ATML4VZH02.KM00 Power Supply DC 4.0 V Frequency Range LTE Band 2: 1 850 ㎒ ~ 1 910 ㎒ LTE Band 4: 1 710 ㎒ ~ 1 755 ㎒ LTE Band 5: 824 ㎒ ~ 849 ㎒ LTE Band 13: 777 ㎒ ~ 787 ㎒ Modulation Technique QPSK, 16QAM Antenna Type Dipole Antenna Antenna Gain 777 ㎒ ~ 787 ㎒: 4.5 ㏈i 824 ㎒ ~ 849 ㎒: 4.5 ㏈i 1 850 ㎒ ~ 1 910 ㎒: 2.0 ㏈i 1 710 ㎒ ~ 1 755 ㎒: 2.0 ㏈i H/W Version Rev A.2 S/ W Version 01C_DCUSKU1 1.5. Test Report Revision Revision Report Number Date of Issue Description 0 F690501-RF-RTL001669 2021.02.10 Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001669 Page: 4 of 6 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 2. RF Exposure Evaluation 2.1. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) 2.1.1. Friis transmission formula: Pd = (Pout*G)/(4*pi*R 2 ) Where Pd = power density in ㎽/㎠ Pout = output power to antenna in ㎽ G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in ㎝ Pd the limit of MPE, 1 ㎽/㎠. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Frequency Range (㎒) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (㎽/㎠) Average Time (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300-1 500 - - f/300 6 1 500-100 000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1 500 - - f/1500 30 1 500-100 000 - - 1.0 30 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001669 Page: 5 of 6 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 2.1.2. Test Result of RF Exposure Evaluation Test Item : RF Exposure Evaluation Data Test Mode : Normal Operation 2.1.3. Output Power into Antenna & RF Exposure Evaluation Distance LTE Band 2 - Maximum tune up tolerance Frequency Range (㎒) Output Average Power to Antenna (㏈m) Antenna Gain (㏈i) Power Density at 20㎝ (㎽/㎠) Limits (㎽/㎠) 1 850 ~ 1 910 25.7 2.0 0.117 146 1 LTE Band 4 - Maximum tune up tolerance Frequency Range (㎒) Output Average Power to Antenna (㏈m) Antenna Gain (㏈i) Power Density at 20㎝ (㎽/㎠) Limits (㎽/㎠) 1 710 ~ 1 755 25.7 2.0 0.117 146 1 LTE Band 5 - Maximum tune up tolerance Frequency Range (㎒) Output Average Power to Antenna (㏈m) Antenna Gain (㏈i) Power Density at 20㎝ (㎽/㎠) Limits (㎽/㎠) 824 ~ 849 25.7 4.5 0.208 319 0.549 333 LTE Band 13 - Maximum tune up tolerance Frequency Range (㎒) Output Average Power to Antenna (㏈m) Antenna Gain (㏈i) Power Density at 20㎝ (㎽/㎠) Limits (㎽/㎠) 777 ~ 787 25.7 4.5 0.208 319 0.518 000 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001669 Page: 6 of 6 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) Note; - The power density Pd (5th column) at a distance of 20 ㎝ calculated from the friis transmission formula is far…

Text truncated - open the document above for the full version.

Test Report

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001668-1 Page: 2 of 103 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) INDEX Table of Contents Page 1. General Information --------------------------------------------------------------------------------------- -3 2. RF Radiated Output Power & Spurious Radiated Emission ------------------------------------ -8 3. Conducted Output Power -------------------------------------------------------------------------------- -31 4. Occupied Bandwidth -------------------------------------------------------------------------------------- -39 5. Peak-Average Ratio --------------------------------------------------------------------------------------- 47 6. Spurious Emissions at Antenna Terminal ------------------------------------------------------------ 59 7. Band Edge --------------------------------------------------------------------------------------------------- -79 8. Frequency Stability ---------------------------------------------------------------------------------------- -99 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001668-1 Page: 3 of 103 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No. : +82 31 688 0901 Fax No. : +82 31 688 0921 1.2. Details of Applicant Applicant : LG Innotek Co., Ltd. Address : 26, Hanamsandan 5beon-ro, Gwangsan-gu, Gwangju, 62229, Korea Contact Person : Jeong, In-Chang Phone No. : +82 62 950 0332 1.3. Details of Manufacturer Company : Same as applicant Address : Same as applicant 1.4. Description of EUT Kind of Product Telematics Module Model Name LTD-VL3020 Serial Number ATML4VZH02.KM00 Power Supply DC 4.0 V Rated Power LTE Band 2, 4, 5, 13: 23 ㏈m Frequency Range LTE Band 2: 1 850 ㎒ ~ 1 910 ㎒ LTE Band 4: 1 710 ㎒ ~ 1 755 ㎒ LTE Band 5: 824 ㎒ ~ 849 ㎒ LTE Band 13: 777 ㎒ ~ 787 ㎒ Modulation Technique QPSK, 16QAM Antenna Type Dipole antenna Antenna Gain 777 ㎒ ~ 787 ㎒: 4.50 ㏈i 824 ㎒ ~ 849 ㎒: 4.50 ㏈i 1 710 ㎒ ~ 1 780 ㎒: 2.00 ㏈i 1 850 ㎒ ~ 1 910 ㎒: 2.00 ㏈i H/W Version Rev A.2 S/W Version 01C_DCUSKU1 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL001668-1 Page: 4 of 103 RTT7081-02(2020.10.05)(0) A4(210 mm * 297 mm) 1.5. Test Equipment List Equipment Manufacturer Model S/N Cal. Date Cal. Interval Cal. Due Signal Generator R&S SMR40 100272 Jun. 18, 2020 Annual Jun. 18, 2021 Signal Generator R&S SMBV100A 255834 Jun. 03, 2020 Annual Jun. 03, 2021 Spectrum Analyzer R&S FSV30 100768 Mar. 04, 2020 Annual Mar. 04, 2021 Mobile Test Unit R&S CMW500 144035 Feb. 17, 2020 Annual Feb. 17, 2021 Power Meter Anritsu ML2495A 1223004 Jun. 01, 2020 Annual Jun. 01, 2021 Power Sensor Anritsu MA2411B 1207272 Jun. 01, 2020 Annual Jun. 01, 2021 Temperature Chamber ESPEC CORP. PL-1J 15000796 Nov. 06, 2020 Annual Nov. 06, 2021 Low Pass Filter Mini-Circuits NLP-1200+ V9500401023-2 Jun. 01, 2020 Annual Jun. 01, 2021 High Pass Filter Wainwright Instrument GmbH WHKX10-900-1000-18000 -40SS 7 Mar. 04, 2020 Annual Mar. 04, 2021 High Pass Filter Wainwright Instrument GmbH WHKX1.5/15G-6SS 4 Jun. 11, 2020 Annual Jun. 11, 2021 High Pass Filter Wainwright Instrument GmbH WHKX2.2/12.75G-10SS8 Mar. 04, 2020 Annual Mar. 04, 2021 High Pass Filter Wainwright Instrument GmbH WHK3.0/18G-10SS 344 May 18, 2020 Annual May 18, 2021 High Pass Filter Wainwright Instrument GmbH WHK7.5/26.5G-6SS 15 Jun. 05, 2020 Annual Jun. 05, 2021 Directional Coupler KRYTAR 152613 122660 Jun. 11, 2020 Annual Jun. 11, 2021 DC Power Supply R&S HMP2020 019258024 Nov. 03, 2020 Annual Nov. 03, 2021 Preamplifier H.P. 8447F 2944A03909 Aug. 06, 2020 Annual Aug. 06, 2021 Preamplifier R&S SCU 18 10117 Jun. 10, 2020 Annual Jun. 10, 2021 Preamplifier MITEQ Inc. JS44-18004000-35-8P 1546891 May 08, 2020 Annual May 08, 2021 Test Receiver R&S ESU26 100109 Feb. 18, 2020 Annual Feb. 18, 2021 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 1519 1519-039 Aug. 22, 2019 Biennial Aug. 22, 2021 Bilog Antenna Schwarzbeck Mess-Elektronik VULB9163 396 Mar. 21, 2019 Biennial Mar. 21, 2021 Horn Antenna R&S HF906 100326 Feb. 14, 2020 Annual Feb. 14, 2021 Horn Antenna R&S HF907 102270 Feb. 14, 2020 Annual Feb. 14, 2021 Horn Antenna Schwarzbeck Mess-Elektronik BBHA9170 BBHA9170223 Sep. 16, 2020 Annual Sep. 16, 2021 Antenna Master Innco systems GmbH MM4000 N/A N.C.R. N/A N.C.R. Turn Table Innco systems GmbH DS 1200S N/A N.C.R. N/A N.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO3000/963/383 30516/L N.C.R. N/A N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.4 m) N/A N.C.R. N/A N.C.R. Coaxial Cable RFONE MWX221-NMSNMS (4 m) J1023142 Dec. 01, 2020 Semi- annual Jun. 01, 2021 Coaxial Cable RFONE PL520-NMNM-10M (10 m) 20200324001 Dec. 01, 2020 Semi- annual Jun. 01, 2021 Coaxial Cable Rosenberger LA1-C006-1500 131014 01/20 Aug. 21, 2020 Semi- annual Feb. 21, 2021 Coaxial Cable Rosenberger LA1-C006-1500 131014…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jeong Inchang(Senior Research Engineer)
[email protected]+82-62-950-0332Fax: +82-62-950-0368

Technical Contact

SGS Korea Co., LtdJulia Choi
[email protected]82-31-428-5853

4, LS-ro, 182 beon-gil · Gunpo-si, Gyeonggi-do · South Korea

Non-Technical Contact

SGS Korea Co., LtdYoungA Kum
[email protected]82-31-428-5887

Test Firm

SGS Korea Co., LtdHwang Gihee
[email protected]+82-31-688-0901Fax: +82-31-427-2370

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
36271.72 GHz - 1.75 GHz246.00 mW17M9D7D2.5 ppm
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Single Modular Approval. Output power is conducted. This device is to be used only for mobile and fixed application; and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter evaluation procedures as documented in this filing. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. OEM integrators must insure that the end user has no manual instructions to remove or install this module. For mobile and fixed operating configurations, the antenna gain, including cable loss, must not exceed 4.50 dBi at 1900 MHz; 2.00 dBi at 1700 MHz; 4.50 dBi at 800 MHz; 4.50 dBi at 700 MHz, as defined in 2.1091 for satisfying RF exposure compliance. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified in Parts 22, 24 and 27. The Grantee is responsible for providing the documentation required for modular use. This device has 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 2 and 4; 1.4 MHz, 3 MHz, 5 MHz and 10 MHz bandwidth modes for LTE Band 5; 5 MHz and 10 MHz bandwidth modes for LTE Band 13.
