Z3K-BYOCRSE10.1 inches Full HD entertainment system for rear-seat

T CN ES TW RU PL JA IT FR CS EN DE Quick Start Guide Rear seat entertainment This quick start guide explains the operating elements and the most important functions of your BYOC RSE SYSTEM. You can obtain more detailed information by calling up the integrated online help screens. Read and observe the enclosed safety instructions in all cases to ensure that the device can be used in a safe manner. 。 Overview of functions • Playback of films, musics and images • Intuitive touchscreen user interface • Wireless network connection via Wi-Fi • Headset connection via wire or Bluetooth • Many different connecting Switching on and operating the device • Make sure the device is connected to the power source, the device will automatically turn on when the car starts. • After switching on for the first time, select the country-specific settings matching your requirements. • Briefy tap on the symbols of the screen in order to open the separate areas. • When the power is turned off, the device will automatically turn off. 1. Front side/start screen 2. Setting menu 3. Volume control 4. Wi-Fi connection 5. Source 6. Bluetooth connection 7. Screen off 8. Brightness control 9. User guide Using in the Vehicle Use the device in the vehicle only in the holder intended for this purpose. The device may only be installed and operated in such vehicles so that the driver cannot be distracted. When removing the BYOC RSE SYSTEM from the holder when traveling or when the engine is running, a warning message appears on the screen. Information on troubleshooting The device cannot be switched on Rechargeable battery is empty – Using the adjacent options specified, charge the rechargeable battery and switch on again. No volume The volume is at 0 – Increase the volume. Playing back has been interrupted – Continue playback or restart. ATTENTION! Children in the passenger compartment in reboard position: Remove the BYOC RSE SYSTEM as well as the corresponding holder from the backrest of the front seat – Risk of injoury. This document is protected by copyright. Any use and distribution, even excerpts is forbidden without the perssion of the owner. Films / photos / music files / applications are not displayed as expected The file format is not supported – The playback formats are specified in the online help. The data carrier cannot be read – Check correct connection and read again. Symbols have been deleted – Add the symbol (e.g., an App) back to the desired area. Please note that Apps can be loaded only for landscape mode. For questions arising, consult the online help or contact your dealer or local BYOC RSE SYSTEM Partner incase you cannot find a solution. Declaration FCC §15.105 statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC § 15.19 Labelling requirements "This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation." FCC § 15.21 Information to user "Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment."

Commercial Power of attorney for Type Approval in several countries We hereby authorize company “7layers GmbH” to act on our behalf to obtain “Radio Type Approval” for the following electronic components: Model: BYOC RSE SYSTEM manufactured by “JET Optoelectronics Co., Ltd.” Unless further correspondence form “JET Optoelectronics Co., Ltd.” please extend your full cooperation to “7layers GmbH” This document is valid until the end of the project. With kind regards To whom I may concern July 15, 2020 Taipei, Taiwan

SOP-RD-0001-A 䇰㛔5 !!܍ᇡ!!ਜ! APPROVAL SHEET ⭊㇞/⺈⓮⎵䧙 Customer/Vendor Name 烉 怑䓐㨇䧖 Model No 烉 復ẞ㖍㛇 Date 烉 ↙扛㕁嘇 JET P/N 烉ġ 䈑㕁婒㖶 Description 烉 䇰㛔 Ver. 烉 (八)娵䶐嘇 㟠ġD⮑ġ㟠㑼ġ䔞 ⎘⊿䷥℔⎠ ⎘⊿ⶪℏ㷾⋨春⃱埿300嘇3F 3F., NO.300, YANG GUANG ST., Neihu Dist.,Taipei City 11491, Taiwan, R.O.C Tel: (02) 5582-1818 Fax: (02) 5582-0098 ⣏映℔⎠ 㰇喯䚩喯ⶆⶪ⏛㰇䴻㾇攳䘤⋨忳㜙⣏忻1518嘇 No.1518,Yundong Avenue炻Wujiang Economic Development Zone, Suzhou City,JiangSu Province Tel: 86-512-63456325 R415500901P ANT,WNC,AUDI專用天線4,81XCBD15.G02 Black IJįı 2020/3/3 ŃŚŐńġ 啟碁科技股份有限公司 च ဃ 㻟 ഋ ࠶ ד ഋ Ш ৎ 3W-RD-03-1003 2 Index 1. Antenna Introduction.........................3 2. Antenna Specification.........................5 3. Antenna Performance........................6 4. Package.......................................7 5. M aterial Data Sheet........................9 6. SGS report ....................................10 3 1. Antenna Introduction 1.1 Antenna Features Antenna Type: Dipole Antenna Operation Frequency: WIFI 2.4GHz Cable Length: 30±2 m 1.2Antenna Outline 5 2. Antenna Specification Item Description Frequency Range 2402MHz ~ 2480MHz Peak Gain 1dBi Return Loss -8dB Characteristics impedance 50 ohm Note: Antenna gain includes the connector and cable loss 6 3. Antenna Performance 3.1 Return Loss 3.2 Antenna Gain and Efficiency Test in BYOC case -8dB 7 3.3 Antenna radiation pattern Test in BYOC case 4. Package Wistron NeWeb Corporation 03-666-7799 81XCBD15.G02 R415500901P0.544012 No. Name of the partMaterial nameComponent weight(gram)100% in total product Materials analysis(element)CAS numberElement Mass(gram) Element Mass (% Weight) 1SOLDER WIRESOLDER WIRE5.26%Tin7440-31-50.028399899.30% Copper7440-50-80.00020020.70% 2DOUBLE SIDE TAPEAcrylic glue2.06%2-Propenoic acid, polymer with butyl 2-propenoate and ethenyl acetate25085-41-00.01122100.00% Tissue paper3.67%Paper-0.019965100.00% Release paper0.33%Polyethylene9002-88-40.001815100.00% 3 TUBE,TRANSPARENT CB-101EVA14.13%Ethylene-vinyl acetate copolymer24937-78-80.076868100.00% 4INTERNAL CONNECTOR Housing 1.12% Poly(oxy-1,4-butanediyloxycarbonyl-1,4-phenylenecarbonyl)24968-12-50.003629559.50% Glassfiber-0.0006110.00% Carbon black1333-86-40.00003050.50% Phosphorus Flame retardant and othersconfidential0.0018330.00% CONTACT/C5210R 2.40%Lead7439-92-10.00000030.00% Copper7440-50-80.012030792.13% Tin7440-31-50.00101077.74% Phosphorus7723-14-00.00001440.11% Iron7439-89-60.00000030.00% Zinc7440-66-60.00000130.01% CONTACT-Plating Au 0.02% Gold 7440-57-50.0000882100.00% CONTACT-Plating Ni 0.12%Nickel7440-02-00.0006541100.00% GROUND CONTACT/C5191R 7.02%Lead7439-92-10.00000040.00% Copper7440-50-80.035975494.14% Tin7440-31-50.00219735.75% Zinc7440-66-60.00000150.00% Phosphorus7723-14-00.00003820.10% Iron7439-89-60.00000080.00% CONTACT-Plating Au 0.01% Gold 7440-57-50.0000809100.00% CONTACT-Plating Ni 0.15%Nickel7440-02-00.0008055100.00% 5CABLE SILVER-COATED COPPER WIRE 1.88%Copper7440-50-80.009187290.00% Silver7440-22-40.001020810.00% FEP/NP-3180 4.45% 1-Propene, 1,1,2,3,3,3-hexafluoro-, polymer with tetrafluoroethene25067-11-20.024224100.00% TINNED COPPER WIRE 7.05%Copper7440-50-80.03795072399.00% Tin7440-31-50.000383361.00% Antimony7440-36-01.9168E-070.00% Arsenic7440-38-21.9168E-070.00% Iron7439-89-61.9168E-070.00% Nickel7440-02-01.9168E-070.00% Sulphur7704-34-93.8336E-070.00% Silver7440-22-47.6672E-070.00% FEP/NP-101 4.04% 1-Propene, 1,1,2,3,3,3-hexafluoro-, polymer with tetrafluoroethene25067-11-20.021984100.00% FEP Colormasterbatch 0.33% 1-Propene, 1,1,2,3,3,3-hexafluoro-, polymer with tetrafluoroethene25067-11-20.00156887.50% various heavy metal free organic and inorganic pigments, undangerous substanceconfidential0.00022412.50% 6PCB Copper 11.49%Copper7440-50-80.0625100.00% plank 32.17%Glass, oxide, chemicals65997-17-30.052530.00% Copper7440-50-80.0262515.00% Epoxy Resin-0.0962555.00% Surface treatment 0.46%Citric acid77-92-90.0025100.00% Solder resist ink 1.38% Novolac epoxy61788-97-40.00049.60% O-cresol novolac epoxy29690-82-20.00335.20% Acrylic ester29570-58-90.001516.40% Barium sulfate7727-43-70.001618.40% Defoaming63148-62-90.00024.20% Fumed silica60676-86-00.00024.20% Pigment1308-38-90.00011.00% High boiling point solvent95481-62-20.000511.00% Text ink 0.46%EPOXY RESIN29690-82-20.0014558.00% FILLING7727-43-70.0007530.00% THINNER111-76-20.000312.00% Note: Component derived from MSDS and material C of C from vendors; Composition weight based on assembly of generic parts. Material Data Sheet part No: Total package weight: Contact phone No: English Form is better Supplier company: Supplier part No: 9 Test Report. No. SHAEC1910973101 Date: 31 May 2019.Page 1 of 7. MAX JOY INTERNATIONAL INDUSTRIAL LIMITED. UNIT B ,23/F.,PHASE 1,KINGSFORD INDUSTRIAL BUILDING, 26-32 KWAI HEI STREET,KWAI . . The following sample(s) was/were submitted and identified on behalf of the clients as : HALOGEN FREE SOLDER WIRE. SGS Job No. :SP19-017009 - SH. Model No. :.FY-SnCu0.7. Material No. :.SnCu0.7. Date of Sample Received :. 27 May 2019. Testing Period :.27 May 2019 - 31 May 2019. Test Requested :.Selected test(s) as requested by client.. Please refer to next page(s).. Please refer to next page(s).. Test Method :. Test Results :. Conclusion :. Based on the performed tests on submitted sample(s), the results of Cadmium, Lead, Mercury, Hexavalent chromium, Polybrominated biphenyls (PBBs), Polybrominated diphenyl ethers (PBDEs) and Phthalates such as Bis(2-ethylhexyl) phthalate (DEHP), Butyl benzyl phthalate (BBP), Dibutyl phthalate (DBP) and Diisobutyl phthalate (DIBP) comply with the limits as set by RoHS Directive (EU) 2015/863 amending Annex II to Directive 2011/65/EU.. Dora Hu. Approved Signatory. Signed for and on behalf of SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd.. Test Report. No. SHAEC1910973101 Date: 31 May 2019.Page 2 of 7. Test Results :. Test Part Description :. Specimen No..SGS Sample ID.Description. SN1.SHA19-109731.001Silvery metal wire. Remarks :. (1) 1 mg/kg = 0.0001%. (2) MDL = Method Detection Limit.…

Text truncated - open the document above for the full version.

FCC, Request for non-disclosure Date: 21-Nov-2018 RF_501, Issue 8 Page 1 of 1 Company Name: JET Optoelectronics Co., Ltd. Address: 3F., No. 300, Yangguang St., Neihu Dist. City: Taipei City 11491 Country: Taiwan To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: Z3K-BYOCRSE Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby request non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: These documents contain detailed system and equipment description and related information. This information should never get into the possession of competitors, which would be harmful for our business. Date: 11/08/2021 Name and signature of applicant: Melanie Anastassiou Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should stated in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

1.BYOC-Bentley 2.BYOC-Audi 3.BYOC-Porsche 4.BYOC-Lamborghini 5.BYOC-Audi China

49 Manufactured by JET Optoelectronics Co., Ltd. VW AG Model No. / 型号 / 型號 : BYOC RSE SYSTEM Power Input / 输入 / 輸入 : 12Vdc/3.5A Output / 端口输出 / 端口輸出 : 5Vdc1.5A MADE IN CHINA HVIN: BYOC RSE SYSTEM PMN: BYOC RSE SYSTEM Bentley Rear Seat Entertainment / 宾利后座娱乐系统 / 賓利後座娛樂系統 Part No.: 36A.919.607.E IC: 9930A-BYOCRSE FCC ID: Z3K-BYOCRSE TA No: AA 000081 OMAN-TRA X/NNNN/YY Dyynnnn TRA REGISTERED No: XXXXXXXXXXXX DEALER No: XXXXXXXXX TA-XXXX/XXXX XXXXX-XX-XXXXX XXXXXXXXXXXX IFT: XXXXXXXXX-XXXX NR: XXXX-XX-X-XXXX R-C/R-ABC- XXXXXXXXXX RXXXXX RoHS XXX-XXXXXX X JJ-5NNN AAA E 49 AA B - CC DDDDD XX-XXXXX CMIIT ID: XXXXXXXXXX FCC ID: Z3K-BYOCRSE IME: XXXXXXXXXXXXXXX IC: 9930A-BYOCRSE Approved by PTA (2019) Pakistan Telecom Authority XXXXXXXXXXXXXXXXXX RoHSXXXXXXXXXXXXXX Manufactured by JET Optoelectronics Co., Ltd. Power Input / 输入 / 輸入 : 12Vdc/3.5A Output / 端口输出 / 端口輸出 : 5Vdc1.5A MADE IN CHINA HVIN: BYOC RSE SYSTEM PMN: BYOC RSE SYSTEM Audi Rear Seat Entertainment / 奥迪后座娱乐系统 / 奧迪後座娛樂系統 VW AG Model No. / 型号 / 型號 : BYOC RSE SYSTEM Part No.: 4N1.919.607 159mm 42mm

Item2 label location Brand Label location Bentley FCC statement added Audi Porsche FCC statement added Lamborghini Audi China Item3 the difference Brand front frame back cover Bentley Silver color front frame Black back cover Audi Black front frame Silver back cover Porsche Black front frame Black back cover Lamborghini Silver color front frame Black back cover Audi China Silver color front frame Black back cover

1.BYOC-Bentley 2.BYOC-Audi 3.Main BoardForBentley、Porsche、Lamborghini、Audi-China 4.Main Board For Audi 5.Touch Board 6.PHONE JACK Board

1 Copyright © Verkotan 2020 Document ID: FCC ISED SAR report_Rear Seat Entertainment_ID4408_08092020 SAR Compliance Test Report Date of Report 8/09/2020 Client’s Contact person: Angie Kang Number of pages: 32 Responsible Test engineer: Ilari Kinnunen Testing laboratory: Verkotan Oy Elektroniikkatie 17 90590 Oulu Finland Client: JET Optoelectronics Co., Ltd. 3F., No. 300, Yangguang St., Neihu Dist. 11491 Taipei City Taiwan Tested device Rear Seat Entertainment Related reports: - Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC published RF exposure KDB procedures IEEE 1528 - 2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique RSS-102, Issue 5, 2015 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signatures: 08.09.2020 Laboratory Manager 2 Copyright © Verkotan 2020 Document ID: FCC ISED SAR report_Rear Seat Entertainment_ID4408_08092020 TABLE OF CONTENTS 1. SUMMARY OF SAR TEST REPORT .................................................................................................................................. 3 1.1 TEST DETAILS ......................................................................................................................................................................3 1.2 MAXIMUM RESULTS ..........................................................................................................................................................3 Standalone SAR.......................................................................................................................................................................................... 3 Simultaneous Transmission SAR ......................................................................................................................................................... 4 Maximum Drift ........................................................................................................................................................................................... 4 Measurement Uncertainty .................................................................................................................................................................... 4 2. DESCRIPTION OF THE DEVICE UNDER TEST (DUT) ...................................................................................................... 5 2.1 SUPPORTED FREQUENCY BANDS AND OPERATIONAL MODES .................................................................................5 2.2 TEST EXCLUSIONS..............................................................................................................................................................5 2.3 SIMULTANEOUS TRANSMISSION ....................................................................................................................................5 3. OUTPUT POWER ............................................................................................................................................................... 6 3.1 MAXIMUM SPECIFIED CONDUCTED OUTPUT POWER .................................................................................................6 3.2 TESTED CONDUCTED POWER ..........................................................................................................................................6 4. TEST EQUIPMENT ............................................................................................................................................................. 7 4.1 TEST EQUIPMENT LIST ......................................................................................................................................................8 Isotropic E-field Probe Type EX3DV4................................................................................................................................................ 8 4.2 PHANTOMS ........................................................................................................................................................................8 4.3 TISSUE SIMULANTS ...........................................................................................................................................................9 4.4 SYSTEM VALIDATION STATUS .........................................................................................................................................9 4.5 SYSTEM CHECK ..................................................................................................................................................................9 Tissue Simulant Verification ................................................................................................................................................................ 10 5. TEST PROCEDURE .......................................................................................................................................................... 11 5.1 TEST POSITIONS .............................................................................................................................................................. 11 Body-worn Configuration, 120mm separation distance ................................................................................................... 11 Extremity Configuration, 0mm separation distance ............................................................................................................ 11 5.2 SCA…

Text truncated - open the document above for the full version.

Test Laboratory: 7layers GmbH Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7layers GmbH Geschäftsführer/ Borsigstraße 11 Managing Directors: Registergericht/registered: a Bureau Veritas 40880 Ratingen, Germany Frank Spiller Düsseldorf HRB 75554 Group Company T +49 (0) 2102 749 0 Bernhard Retka USt-Id.-Nr./VAT-No. DE203159652 F +49 (0) 2102 749 350 Alexandre Norré-Oudard Steuer-Nr./TAX-No. 147/5869/0385 www.7layers.com Commerzbank AG Account No. 303 016 000 Bank Code 300 400 00 IBAN DE81 3004 0000 0303 0160 00 Swift Code COBADEFF FCC Measurement/Technical Report on Rear Seat Entertainment System BYOC RSE SYSTEM FCC ID: Z3K-BYOCRSE IC: 9930A-BYOCRSE Test Report Reference: MDE_JET_1905_FCC_02 TEST REPORT REFERENCE: MDE_JET_1905_FCC_02 Page 2 of 70 Table of Contents 1 Applied Standards and Test Summary 3 1.1 Applied Standards 3 1.2 FCC-IC Correlation Table 4 1.3 Measurement Summary 5 2 Revision History / Signatures 9 3 Administrative Data 10 3.1 Testing Laboratory 10 3.2 Project Data 10 3.3 Applicant Data 10 3.4 Manufacturer Data 10 4 Test object Data 11 4.1 General EUT Description 11 4.2 EUT Main components 11 4.3 Ancillary Equipment 12 4.4 Auxiliary Equipment 12 4.5 EUT Setups 12 4.6 Operating Modes / Test Channels 13 4.7 Product labelling 13 5 Test Results 14 5.1 Occupied Bandwidth (6 dB) 14 5.2 Occupied Bandwidth (99%) 18 5.3 Peak Power Output 22 5.4 Spurious RF Conducted Emissions 27 5.5 Transmitter Spurious Radiated Emissions 32 5.6 Band Edge Compliance Conducted 39 5.7 Band Edge Compliance Radiated 46 5.8 Power Density 52 6 Test Equipment 57 7 Antenna Factors, Cable Loss and Sample Calculations 62 7.1 LISN R&S ESH3-Z5 (150 kHz – 30 MHz) 62 7.2 Antenna R&S HFH2-Z2 (9 kHz – 30 MHz) 63 7.3 Antenna R&S HL562 (30 MHz – 1 GHz) 64 7.4 Antenna R&S HF907 (1 GHz – 18 GHz) 65 7.5 Antenna EMCO 3160-09 (18 GHz – 26.5 GHz) 66 7.6 Antenna EMCO 3160-10 (26.5 GHz – 40 GHz) 67 8 Setup Drawings 68 9 Measurement Uncertainties 69 10 Photo Report 70 TEST REPORT REFERENCE: MDE_JET_1905_FCC_02 Page 3 of 70 1 APPLIED STANDARDS AND TEST SUMMARY 1.1 APPLIED STANDARDS Type of Authorization Certification for an Intentional Radiator. Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 and 15 (10-1-19 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.201 Equipment authorization requirement § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements § 15.247 Operation within the bands 902-928 MHz, 2400-2483.5 MHz Note: The tests were selected and performed with reference to the FCC Public Notice “Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of the FCC Rules, 558074 D01 15.247 Meas Guidance v05r02, 2019-04-02”. ANSI C63.10–2013 is applied. TEST REPORT REFERENCE: MDE_JET_1905_FCC_02 Page 4 of 70 1.2 FCC-IC CORRELATION TABLE Correlation of measurement requirements for DTS (e.g. WLAN 2.4 GHz, BT LE) equipment from FCC and IC DTS equipment Measurement FCC reference IC reference Conducted emissions on AC Mains § 15.207 RSS-Gen Issue 5: 8.8 Occupied bandwidth § 15.247 (a) (2) RSS-247 Issue 2: 5.2 (a) Peak conducted output power § 15.247 (b) (3), (4) RSS-247 Issue 2: 5.4 (d) Transmitter spurious RF conducted emissions § 15.247 (d) RSS-Gen Issue 5: 6.13 / 8.9/8.10; RSS-247 Issue 2: 5.5 Transmitter spurious radiated emissions § 15.247 (d); § 15.209 (a) RSS-Gen Issue 5: 6.13 / 8.9/8.10; RSS-247 Issue 2: 5.5 Band edge compliance § 15.247 (d) RSS-247 Issue 2: 5.5 Power density § 15.247 (e) RSS-247 Issue 2: 5.2 (b) Antenna requirement § 15.203 / 15.204 RSS-Gen Issue 5: 8.3 Receiver spurious emissions – – TEST REPORT REFERENCE: MDE_JET_1905_FCC_02 Page 5 of 70 1.3 MEASUREMENT SUMMARY 47 CFR CHAPTER I FCC PART 15 Subpart C §15.247 § 15.247 (a) (2) Occupied Bandwidth (6 dB) The measurement was performed according to ANSI C63.10 Final Result OP-Mode Radio Technology, Operating Frequency Setup Date FCC IC Bluetooth LE 1 Mbps, Module0 high S01_AE01 2020-07-27 Passed Passed Bluetooth LE 1 Mbps, Module0 low S01_AE01 2020-07-27 Passed Passed Bluetooth LE 1 Mbps, Module0 mid S01_AE01 2020-07-27 Passed Passed WLAN b, Module0 high S01_AF01 2020-08-18 Passed Passed WLAN b, Module0 low S01_AF01 2020-08-18 Passed Passed WLAN b, Module0 mid S01_AF01 2020-08-18 Passed Passed WLAN g, Module0 high S01_AF01 2020-08-18 Passed Passed WLAN g, Module0 low S01_AF01 2020-08-18 Passed Passed WLAN g, Module0 mid S01_AF01 2020-08-18 Passed Passed WLAN n 20 MHz, Module0 high S01_AF01 2020-08-18 Passed Passed WLAN n 20 MHz, Module0 low S01_AF01 2020-08-18 Passed Passed WLAN n 20 MHz, Module0 mid S01_AF01 2020-08-18 Passed Passed 47 CFR CHAPTER I FCC PART 15 Subpart C §15.247 IC RSS-Gen & IC TRC-43; Ch. 6.7 & Ch. 8 Occupied Bandwidth (99%) The measurement was performed according to ANSI C63.10 Final Result OP-Mode Radio Technology, Operating Frequency Setup Date FCC IC Bluetooth LE 1 Mbps, Module0 high S01_AF01 2020-08-18 N/A Performed Bluetooth LE 1 Mbps, Module0 low S01_AF01 2020-08-18 N/A Performed Bluetooth LE 1 Mbps, Module0 mid S01_AF01 2020-08-18 N/A Performed WLAN b, Module0 high S01_AF01 2020-08-18 N/A Performed WLAN b, Module0 low S01_AF01 2020-08-18 N/A Performed WLAN b, Module0 mid S01_AF01 2020-08-18 N/A Performed 47 CFR CHAPTER I FCC PART 15 Subpart C §15.247 § 15.247 (b) (3) Peak Power Output The measurement was performed according to ANSI C63.10 Final Result OP-Mode Radio Technology, Operating Frequency, Measurement method Setup Date FCC IC Bluetooth LE 1 Mbps, Module0 high, conducted S01_AE01 2020-07-…

Text truncated - open the document above for the full version.

Test Laboratory: 7layers GmbH Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7layers GmbH Geschäftsführer/ Borsigstraße 11 Managing Directors: Registergericht/registered: a Bureau Veritas 40880 Ratingen, Germany Frank Spiller Düsseldorf HRB 75554 Group Company T +49 (0) 2102 749 0 Bernhard Retka USt-Id.-Nr./VAT-No. DE203159652 F +49 (0) 2102 749 350 Alexandre Norré-Oudard Steuer-Nr./TAX-No. 147/5869/0385 www.7layers.com Commerzbank AG Account No. 303 016 000 Bank Code 300 400 00 IBAN DE81 3004 0000 0303 0160 00 Swift Code COBADEFF FCC Measurement/Technical Report on Rear Seat Entertainment System BYOC RSE SYSTEM FCC ID: Z3K-BYOCRSE IC: 9930A-BYOCRSE Test Report Reference: MDE_JET_1905_FCC_04 TEST REPORT REFERENCE: MDE_JET_1905_FCC_04 Page 2 of 45 Table of Contents 1 Applied Standards and Test Summary 3 1.1 Applied Standards 3 1.2 FCC-IC Correlation Table 4 1.3 Measurement Summary 5 2 Revision History / Signatures 6 3 Administrative Data 7 3.1 Testing Laboratory 7 3.2 Project Data 7 3.3 Applicant Data 7 3.4 Manufacturer Data 7 4 Test object Data 8 4.1 General EUT Description 8 4.2 EUT Main components 8 4.3 Ancillary Equipment 9 4.4 Auxiliary Equipment 9 4.5 EUT Setups 9 4.6 9 4.7 Operating Modes / Test Channels 9 4.8 Product labelling 9 5 Test Results 10 5.1 Transmitter Spurious Radiated Emissions 10 5.2 Band Edge Compliance Radiated 26 6 Test Equipment 33 7 Antenna Factors, Cable Loss and Sample Calculations 37 7.1 LISN R&S ESH3-Z5 (150 kHz – 30 MHz) 37 7.2 Antenna R&S HFH2-Z2 (9 kHz – 30 MHz) 38 7.3 Antenna R&S HL562 (30 MHz – 1 GHz) 39 7.4 Antenna R&S HF907 (1 GHz – 18 GHz) 40 7.5 Antenna EMCO 3160-09 (18 GHz – 26.5 GHz) 41 7.6 Antenna EMCO 3160-10 (26.5 GHz – 40 GHz) 42 8 Setup Drawings 43 9 Measurement Uncertainties 44 10 Photo Report 45 TEST REPORT REFERENCE: MDE_JET_1905_FCC_04 Page 3 of 45 1 APPLIED STANDARDS AND TEST SUMMARY 1.1 APPLIED STANDARDS Type of Authorization Certification for an Intentional Radiator. Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 and 15 (10-1-19 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.201 Equipment authorization requirement § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements § 15.247 Operation within the bands 902-928 MHz, 2400-2483.5 MHz Note: The tests were selected and performed with reference to the FCC Public Notice “Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of the FCC Rules, 558074 D01 15.247 Meas Guidance v05r02, 2019-04-02”. ANSI C63.10–2013 is applied. TEST REPORT REFERENCE: MDE_JET_1905_FCC_04 Page 4 of 45 1.2 FCC-IC CORRELATION TABLE Correlation of measurement requ…

Text truncated - open the document above for the full version.
