Z4900006Transceiver for Heating Control

- 6 - Fig. 1 Fig. 2 Zip-tie to be cut. Installing the Transceiver Transceiver must be installed before the heater is secured to a wall. 1. Using a pair of ‘cutter’ pliers cut the zip-tie to release the transceiver cable. 2. Re-route the transceiver cable as shown by the arrow down towards the rectangular hole in the base of the heater. Making sure that the transceiver cable is on the outside of all other cables. - 7 - 3. Pull the transceiver cable through the rectangular hole in the base of the heater. 4. Plug the transceiver cable into the socket of the transceiver housing. Fig. 3 Fig. 4 - 8 - 5. Hook the transceiver housing through the oval shaped slots in the base of the heater. 6. Check that the location hooks of the transceiver housing are located as shown in the picture. Fig. 5 Fig. 6 Location Hooks - 9 - Fig. 7 7. Using the supplied screws securely screw the transceiver housing into place. 8. On Quantum Size 100 Heater the leg must be attached using the ‘X’ screw holes to allow the transceiver housing to be accessible for maintenance. Fig. 8  12  !3 -$%%  !4  #55  &   %  6   7 ! !   (8912            8/912          2               4 :       #%;&   %     #   #  4;#    : # #    2 (89;           8/9;   ;         :  <   =     ;       >0&?(%  @   # 2  2        2  ;   <  1 &%(    @      @ &   %      @  !

Manufacturer control of unit once in the field: The units that these modules are to be installed on are not able to be modified by the end user. Installers will receive training from a representative of the Dimplex North America team assisted by a member of staff from the group R&D facility in Ireland. Product details: This product shall be limited to use within Dimplex product ranges. Only an approved installer can add these modules to the products: Quantum Storage Range(QTM070‐QTM150) Quantum Water range(ECSd175‐580) Type of Modulation: GFSK. Number of Channels: 1(one). Label location: On Module: Note a label must be fitted to the outside of the appliance when the module is installed Refer to “Appliance label 11868.pdf”

Dimplex NA compliance statement for Modular Transmitters (in Blue below) § 15.212 Modular transmitters. (a) Single modular transmitters consist of a completely self-contained radiofrequency transmitter device that is typically incorporated into another product, host or device. Split modular transmitters consist of two components: a radio front end with antenna (or radio devices) and a transmitter control element (or specific hardware on which the software that controls the radio operation resides). All single or split modular transmitters are approved with an antenna. All of the following requirements apply, except as provided in paragraph (b) of this section. (1) Single modular transmitters must meet the following requirements to obtain a modular transmitter approval. (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Shielding not present ->Non Comply (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. Comply (iii) The modular transmitter must have its own power supply regulation. Comply (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Antenna is pcb track ->Comply (v) The modular transmitter must be tested in a stand-alone configuration, i.e. , the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). Comply (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. Permanently affixed label fitted -> Comply (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Comply (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. Electronic Display for FCC ID not used ->N/A (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Comply (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Comply (2) Split modular transmitters must meet the requirements in paragraph (a)(1) of this section, excluding paragraphs (a)(1)(i) and (a)(1)(v), and the following additional requirements to obtain a modular transmitter approval. Not split module -> N/A (i) Only the radio front end must be shielded. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The interface between the split sections of the modular system must be digital with a minimum signaling amplitude of 150 mV peak-to- peak. Not split module -> N/A (ii) Control information and other data may be exchanged between the transmitter control elements and radio front end. Not split module -> N/A iii) The sections of a split modular transmitter must be tested installed in a host device(s) similar to that which is representative of the platform(s) intended for use. Not split module -> N/A (iv) Manufacturers must ensure that only transmitter control elements and radio fron…

Text truncated - open the document above for the full version.

THIS MUST BE SIGNED BY THE APPLICANT AND SHOULD BE PLACED ON APPLICANTS LETTERHEAD ONLY IF AGENT IS SUBMITTING APPLICATION 022311 – 6 Authority to Act as Agent Date: July 23, 2013 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: COMPLIANCE ENGINEERING IRELAND is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: April 24, 2014 By: Kelly Stinson Signature Print name Title: Manager of R&D On behalf of: DIMPLEX NORTH AMERICA LTD. Telephone: 519-650-3630 x310 THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD 022311 – 6 Request for Confidentiality Date: July 23, 2013 Subject: Confidentiality Request for: FCC ID: Z49-00005, Z49-00006 IC: 6592A-00005, 6592A-00006 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual DIMPLEX NORTH AMERICA LTD. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Kelly Stinson Manager or R&D Print name

DIMPLEX Model No.:11123622 FCC ID: Z4900006 IC: 6592A-0006 Notes: 1. Material: PE85 Gloss polyethylene film with print friendly top coating. 2. Finish: Gloss finish with black indelible ink. 3. Dimensions to outside edges unless otherwise specified. 4. Font: True type font - Arial Bold 5. Font point size: first line 14pt / other lines 10pt 6. All dimensions in mm. 7. Label temperature rating Minimum application temperature +5C Service temperature range -20C/+100C Material: PE85 Gloss polyethylene film Title : Transceiver label Rev : 01 Finish : Transparent with black ink Drn by : L Knowles Date : 15th July 2013 Drawing No : 11866 Sheet : 1 of 1 Scale : 1:1 Chk'd by : D Shields Date : 15th July 2013 42.0 42.0 Seagoe TechnologiesLimited

DIMPLEX This product contains transmitter module FCC ID: Z4900006 IC: 6592A-0006 Notes: 1. Material: PE85 Gloss polyethylene film with print friendly top coating. 2. Finish: Gloss finish with black indelible ink. 3. Dimensions to outside edges unless otherwise specified. 4. Font: True type font - Arial Bold 5. Font point size: first line 14pt / other lines 10pt 6. All dimensions in mm. 7. Label temperature rating Minimum application temperature +5C Service temperature range -20C/+100C Material: PE85 Gloss polyethylene film Title : Appliance label Rev : 01 Finish : Transparent with black ink Drn by : L Knowles Date : 15th July 2013 Drawing No : 11868 Sheet : 1 of 1 Scale : 1:1 Chk'd by : D Shields Date : 15th July 2013 42.0 42.0 Seagoe TechnologiesLimited

Report Ref: 13E4506-2b Page 1 of 3 Project Number: 13E4506-2b Prepared for: Dimplex North America Ltd By Compliance Engineering Ireland Ltd Clonross Lane Derrockstown Dunshaughlin Co. Meath FCC Site Registration: 92592 Industry Canada Assigned Site Code: 8517A-2 FCC ID: Z4900006 IC: 6592A-00006 Date 20 June 2013 FCC EQUIPMENT AUTHORISATION Test Report EUT Description Radio Hub for heater control. Authorised : John McAuley THIS REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF COMPLIANCE ENGINEERING IRELAND LTD Compliance Engineering Ireland Ltd Clonross Lane, Derrockstown, Dunshaughlin, Co. Meath Tel: +353 1 8256722 Fax: +353 1 8256733 Report Ref: 13E4506-2b Page 2 of 3 RF Exposure Exhibit– Technical Report Applicant Name and Address The system covered under this authorisation report was designed, manufactured and assembled by Dimplex North America. The company's full name and mailing address is given below: Dimplex North America 1367 Industrial Road, Cambridge, Ontario N1R 7G8 Canada Model Name The model number for the EUT covered under this application report is: Z4900006 Report Ref: 13E4506-2b Page 3 of 3 1.0 Maximum Permissible Exposure Prediction of MPE limit at a given distance Equation from OET Bulletin 65 / RSS102 where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Note 10W/m^2 = 1mW/cm^2 Maximum peak output power at antenna input terminal: 3.8 dBm Maximum peak output power at antenna input terminal: 2399 uW Antenna gain(typical): 2.15 dBi Maximum antenna gain: 1.64 numeric Prediction distance: 20 cm Prediction frequency: 914.964 MHz MPE limit for uncontrolled exposure at prediction frequency: 0.61 mW/cm^2 Power density at prediction frequency: 0.000783 mW/cm^2 Power density at prediction frequency: 0.007829 W/m^2

Report Ref: 13E4506-3a-2 Page 1 of 24 Project Number: 13E4506-3a-2 Prepared for: Glen Dimplex Nordic By Compliance Engineering Ireland Ltd Clonross Lane Derrockstown Dunshaughlin Co. Meath FCC Site Registration: 92592 Industry Canada Assigned Site Code: 8517A-2 FCC ID: Z4900006 IC: 6592A-00006 Date 20 June 2013 FCC EQUIPMENT AUTHORISATION Test Report EUT Description Radio Transceiver for heater control. Authorised : John McAuley Compliance Engineering Ireland Ltd Clonross Lane, Derrockstown, Dunshaughlin, Co. Meath Tel: +353 1 8256722 Fax: +353 1 8256733 Report Ref: 13E4506-3a-2 Page 2 of 24 TEST SUMMARY The equipment complies with the requirements according to the following standards. FCC Part Section(s) RSS-210 Section TEST PARAMETERS Test Result 15.249(a) A.2.9(a) RADIATED EMISSIONS PASS 15.249(d) A.2.9(b) RADIATED EMISSIONS PASS 15.249(e) A.2.9(b) RADIATED EMISSIONS PASS 15.207(a) CONDUCTED EMISSIONS ON THE MAINS PASS THIS REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF COMPLIANCE ENGINEERING IRELAND LTD Report Ref: 13E4506-3a-2 Page 3 of 24 Exhibit A – Technical Report Table of Contents 1.0 EUT DESCRIPTION..............................................................................................................................4 1.1 EUT OPERATION..................................................................................................................................5 1.2 MODIFICATIONS...................................................................................................................................5 1.3 DATE OF TEST......................................................................................................................................5 1.4.1 MEASUREMENT UNCERTAINTY.......................................................................................................6 2.0 EMISSIONS MEASUREMENTS............................................................................................................7 2.1 CONDUCTED EMISSIONS MEASUREMENTS...................................................................................7 2.2 RADIATED EMISSIONS MEASUREMENTS.......................................................................................7 2.3 TEST CRITERIA.....................................................................................................................................9 3.0 MAXIMUM MODULATION PERCENTAGE (M%)..............................................................................10 4.0 FIELD STRENGTH OF SPURIOUS RADIATED EMISSIONS..........................................................14 5.0 LIST OF TEST EQUIPMENT...............................................................................................................19 Report Ref: 13E4506-3a-2 Page 4 of 24 1.0 EUT Description The EUT was a module using a short range 915 MHz band transceiver for heater control in buildings. Model: 11123622 Type: 915 MHz Radio Transceiver for heater control FCC ID: Z4900006 Company: Dimplex North America Contact Kelly Stinton Address: 1367 Industrial Road, Cambridge, ON N1R 7G8 Canada Phone: 519-650-3630 e-mail: [email protected] Test Standards: 47 CFR, Part 15.249(a,d,e) ; Type of radio: Stand-alone Transmitter Type: GPSK Operating Frequency Range(s): 915 MHz Number of Channels: 1 Antenna: Integral Transmitter power configuration: 5v dc Oper. Temp Range: 0° C to +40° C Classification: DXT Test Methodology: Measurements performed according to the procedures in ANSI C63.4-2003 Report Ref: 13E4506-3a-2 Page 5 of 24 1.1 1.2 EUT Operation Operating Conditions during Test: The equipment under test was operated during the measurement under the following conditions: The EUT was powered from a 5v dc mains adapter. The EUT was operated in CW mode for the Radiated power and Spurious Emissions tests. The EUT was operated in normal operation for the duty cycle test. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: +15 to +35 ° C Humidity: 20-75 % 1.3 Modifications No modifications were required in order to pass the test specifications. 1.4 Date of Test The tests were carried out on one sample of the EUT during the months of May and June 2013. 1.4 Electromagnetic Emissions Testing The guidelines of CISPR 16-4 were used for all uncertainty calculations, estimates and expressions thereof for EMC testing. A copy of Compliance Engineering Ireland Ltd.’s policy for EMC Measurement Uncertainty is available on request. RF Requirements: Spurious emissions in accordance with FCC CFR 15.107, 15.109 and 15.209. Tests were carried out to the requirements of CISPR 16-4 and ANSI C63.4-2009. Report Ref: 13E4506-3a-2 Page 6 of 24 1.4.1 Measurement Uncertainty The measurement uncertainty (with a 95% confidence level) for the conducted emissions test was ±3.5 dB. The measurement uncertainty (with a 95% confidence level) for the radiated emissions test was ±5.3 dB (from 30 to 100 MHz), ±4.7 dB (from 100 to 300 MHz), ±3.9 dB (from 300 to 1000 MHz) and ±3.8 dB (from 1 GHz to 40 GHz). Report Ref: 13E4506-3a-2 Page 7 of 24 2.0 Emissions Measurements 2.1 Conducted Emissions Measurements The EUT was powered from a mains to 5v dc adapter which was connected to the mains through a LISN and measurements were carried out using a Receiver over the frequency range 150KHz to 30MHz. 2.2 Radiated Emissions Measurements Radiated Power measurements were made at the Compliance Engineering Ireland Ltd anechoic chamber located in Dunshaughlin, Co. Meath, Ireland to determine the radio noise radiated from the EUT. A "Description of Measurement Facilities" has been submitted to the FCC and approved pursuant to Section 2.948 of CFR 47 of the FCC rules. The EUT was centred on a motorized turntable, which allows 360 degree rotation. A measurement antenna was positioned at a distance of 3 metres as measured from the closest point of the EUT. The radiated emissions were maximise…

Text truncated - open the document above for the full version.

Report Ref: 13E4506-5a Page 1 of 20 Project Number: 13E4506-5a Prepared for: Glen Dimplex Nordic By Compliance Engineering Ireland Ltd Clonross Lane Derrockstown Dunshaughlin Co. Meath FCC Site Registration: 92592 Industry Canada Assigned Site Code: 8517A-2 Date 11 Sept 2013 FCC EQUIPMENT AUTHORISATION Test Report EUT Description Storage Heater with Radio Transceiver for heater control. Authorised : John McAuley Compliance Engineering Ireland Ltd Clonross Lane, Derrockstown, Dunshaughlin, Co. Meath Tel: +353 1 8256722 Fax: +353 1 8256733 Report Ref: 13E4506-5a Page 2 of 20 TEST SUMMARY Emissions were assessed to the following standards: FCC CFR 47 Part 15 Federal Communications Commission: Part 15 Radio Frequency Devices The equipment complies with the requirements according to the following standards. FCC Part TEST PARAMETERS Test Result 15.109 RADIATED EMISSIONS PASS 15.107 CONDUCTED EMISSIONS ON THE MAINS PASS THIS REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF COMPLIANCE ENGINEERING IRELAND LTD Report Ref: 13E4506-5a Page 3 of 20 Exhibit A – Technical Report Table of Contents 1.0 EUT DESCRIPTION..............................................................................................................................4 1.1 EUT OPERATION..................................................................................................................................5 1.2 MODIFICATIONS...................................................................................................................................5 1.3 DATE OF TEST......................................................................................................................................5 1.4 EMISSIONS TESTING..........................................................................................................................5 1.4.1 MEASUREMENT UNCERTAINTY.......................................................................................................6 2.0 EMISSIONS MEASUREMENTS............................................................................................................7 2.1 CONDUCTED EMISSIONS MEASUREMENTS...................................................................................7 2.2 RADIATED EMISSIONS MEASUREMENTS.......................................................................................7 2.3 DUTY CYCLE.........................................................................................................................................8 3.0 SPURIOUS RADIATED EMISSIONS..................................................................................................11 4.0 RESULTS FOR SPURIOUS RADIATED EMISSIONS......................................................................11 4.3 RESULTS FOR CONDUCTED EMISSIONS......................................................................................11 Appendix 1 List of Test Equipment 15 Appendix 2 Test Configurations 17 Appendix 3 Test plots 20 Report Ref: 13E4506-5a Page 4 of 20 1.0 EUT Description The EUT was a Storage Heater which contained a transceiver module as below. The module used a short range 915 MHz band transceiver for heater control. Storage Heater Manufacturer: Glen Dimplex Make: Quantum Heater Model: QM 070 Module Model: 11123622 Type: 915 MHz Radio Transceiver for heater control FCC ID: Z4900006 IC ID: 6592A-00006 Report Ref: 13E4506-5a Page 5 of 20 1.1 EUT Operation Operating Conditions during Test: The equipment under test was operated during the measurement under the following conditions: The EUT was powered from the mains. The module was operated in CW mode for the Spurious Emissions tests. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: +15 to +35 ° C Humidity: 20-75 % 1.2 Modifications No modifications were required in order to pass the test specifications. 1.3 Date of Test The tests were carried out on one sample of the EUT on the 11 th September 2013. 1.4 Electromagnetic Emissions Testing The guidelines of CISPR 16-4 were used for all uncertainty calculations, estimates and expressions thereof for EMC testing. A copy of Compliance Engineering Ireland Ltd.’s policy for EMC Measurement Uncertainty is available on request. RF Requirements: Spurious emissions in accordance with FCC CFR 15.107, 15.109 and 15.209. Tests were carried out to the requirements of CISPR 16-4 and ANSI C63.4-2003. Report Ref: 13E4506-5a Page 6 of 20 1.4.1 Measurement Uncertainty The measurement uncertainty (with a 95% confidence level) for the conducted emissions test was ±3.5 dB. The measurement uncertainty (with a 95% confidence level) for the radiated emissions test was ±5.3 dB (from 30 to 100 MHz), ±4.7 dB (from 100 to 300 MHz), ±3.9 dB (from 300 to 1000 MHz) and ±3.8 dB (from 1 GHz to 40 GHz). Report Ref: 13E4506-5a Page 7 of 20 2.0 Emissions Measurements 2.1 Conducted Emissions Measurements The EUT was powered from the mains through a LISN and measurements were carried out using a Receiver over the frequency range 150 KHz to 30 MHz. 2.2 Radiated Emissions Measurements Radiated Power measurements were made at the Compliance Engineering Ireland Ltd anechoic chamber located in Dunshaughlin, Co. Meath, Ireland to determine the radio noise radiated from the EUT. A "Description of Measurement Facilities" has been submitted to the FCC and approved pursuant to Section 2.948 of CFR 47 of the FCC rules. The EUT was centred on a motorized turntable, which allows 360 degree rotation. A measurement antenna was positioned at a distance of 3 metres as measured from the closest point of the EUT. The radiated emissions were maximised by configuring the EUT, by rotating the EUT, and by raising and lowering the antenna from 1 to 4 meters. Emissions below 1GHz were measured using a bi-log antenna. In this case the resolution bandwidth was 100kHz. Emissions above 1GHz were measured using a horn antenna located at 3 metres dist…

Text truncated - open the document above for the full version.

Report Ref: 13E4506-5a Page 16 of 20 Appendix 2 Test Configurations Fig 1 Radiated Emissions - Fig 2 Radiated Emissions Fig 3 Radiated Emissions - Fig 4Transceiver fitted Fig 5 Conducted Emissions -

Report Ref: 13E4506-2a Page 1 of 1 Appendix B Test Set up Fig 1 Radiated Emissions Fig 2 Radiated Emissions Fig 3 Conducted Emissions
