Z4RCUETransmitter

ColorMaker, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 08, 2011
Application Purpose: Original Equipment
Date of Application: Dec 08, 2011
Equipment Note: Transmitter
Frequency Range: 916.50000000 - 916.50000000
Company: ColorMaker, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ColorCue-PX User’s Manual www.ColorMaker.net Introduction ColorCue is a wireless control for ColorMaker wireless LED fixtures designed for both beginners and advanced users. Fully programmable for advanced users and ready to command out of the box for beginners. The ColorCue can command 8 individual fixtures to control RGB with 16 programmable presets or create custom colors with RGB Up / Down controls. ColorCue has 1 ColorRoll and 1 Scene button for easy event setup. ColorCue Controls A- Status indicator B- Power ON-OFF switch C- RGB Up / Down controls. Also used for ColorRoll timing. D- Power up function keys. Used to set ColorCue network and restore factory defaults. E- ColorRoll and Scene activation controls F- Fade / Snap controls. G- 8 fixture select buttons H- 16 programmable color presets I - Blackout button J- Save button used for ColorRoll, Scene and 16 Presets Status Indicator identifies the remotes status during operation. Red indicated the maximum intensity has been reached when using the RGB Up buttons. Green indicates the remote is currently updating a scene. During this time the RGB Up/Down buttons are disabled. Yellow blink identifies the remote has entered Network address edit. Power switch. This one should be obvious, it turns the remote ON and OFF. RGB Up / Down used to set the color of the fixture by adjusting the red, green and blue intensity levels. When the maximum level of the current key has been reached the indicator will turn red. The RGB controls also used to set the roll rate of the ColorRoll which will be covered later during ColorRoll programming. Fade / Snap controls. These 2 keys set the ColorCue color transition fade time. When set to Snap the selected color changes the fixture instantly hence the word Snap. When set to Fade the colors transition is slow approximately 4 seconds depending on the colors. Then Fade and Snap also sets the fade time for the 1 scene button control. To set the Snap control press the Snap button to set the Fade press the fade button. Fixture Select Buttons. Buttons marked with Q1 through Q8 selects the fixture. After each fixture is selected the user can set the color by using the RGB UP/DN buttons or press 1 of the 16 presets. The ColorCue stores the color of each fixture so users can edit all 8 colors. 16 Programmable Color Presets keys are used to set the fixture to a programmable preset. The keys are color representation of the colors that are factory programmed. The presets can be edited and saved for custom colors. Blackout buttons turns all fixtures off and terminates all ColorRolls. Save button is a Press and Hold button to save color presets, Scene and ColorRoll colors. Play and Save Scene and ColorRoll Scene and ColorRoll patterns are played and saved in the same way. A scene stores all 8 fixture colors and a ColorRoll stores all 8 fixture colors but stores them in a pattern which is then sent to a single fixture. The fixture then rolls through all the 8 colors continuous loop until the user stops the ColorRoll. Lets start with scene Record and Playback. Scene Record Set all 8 fixture to a desired color by using the RGB Up/Dn keys or 1 of the presets. After all 8 fixtures are set PRESS and HOLD the Save key then press the Scene button. Now released both buttons. The scene is now saved. Scene is stored in memory, turning off the remote or changing batteries will not affect the stored data. Scene Play To play the scene just press the scene button and all 8 fixtures will transition to the previously stored scene. If the ColorCue is set to Snap the fixtures will instantly turn to the saved scene. The indicator will turn green during the color transition and the RGB UP/DN buttons will be disabled. When a scene has been sent to the fixtures the colors of each of the fixtures can be edited by using the RGB UP/DN buttons or 1 of the 16 presets. www.ColorMaker.net Q1Q2Q3Q4Q5Q6Q7Q8 Example 1: ColorRoll setting that starts with Red then fades through all 10 colors then repeats. Example 2: ColorRoll process that starts with Red the fades to Green then fades to Blue then repeats. Q1Q2Q3Q4Q5Q6Q7Q8 www.ColorMaker.net (407) 862-3363 Record and Play ColorRoll Record ColorRoll A ColorRoll is a set of 8 colors that are programmed using Q1 through Q8 on the remote. Once all 8 colors are programmed set PRESS and HOLD the Save key then press the ColorRoll button. Now released both buttons. The ColorRoll is now saved. ColorRoll pattern is stored in memory, turning off the remote or changing batteries will not affect the stored data. ColorRoll Patterns Below are 2 examples of ColorRoll patterns. Example 1 shows a complete set of 8 colors. The fixture will roll through all 8 colors then repeat until user presses the blackout key or adjust the fixture RGB levels to 0. Example 2 show a ColorRoll with 3 colors Red, Green and Blue. Note that Q4 through Q8 are set to blue. This will keep the fixture from rolling to OFF before repeating. This technique applies to all patterns regardless of how many color are in the pattern. Play ColoRoll To play a ColorRoll select a fixture Q1 through Q8 then press the ColorRoll button. The fixture will then start rolling through the colors stored in the pattern. Roll rate can then be adjusted using the Red (Fade rate) Green (Follow rate) Blue (Fade / Flash). * Follow rate only applies to fixtures with Enhanced ColorRoll technology see fixtures user’s manual for details. Red (Fade rate) Green (Follow rate) Blue (Fade / Flash) can only be edited after the ColorRoll button has been pressed. One any of the Q buttons are pressed the Red (Fade rate) Green (Follow rate) Blue (Fade / Flash) are disabled. Once the ColorRoll rate has been edited the value is stored and the new rates will be used when the ColorRoll is pressed again. 16 Programmable Color Presets The ColorCue has 16 programmable preset which can be edited and saved for custom presets. The presets are factory set to the button color which span the color range …

Text truncated - open the document above for the full version.

Attestation Statements

p.2 Oct 07 ' 1 09:2 Ll .. (~olorMaker inc 980 SWlsrune lane ste T A,1tamonte Springs FL 32714 (407) 862-3363 :.0/06/2011 CETCB j 14 Olinda Drive Brea, CA 92823 Cientlemen: This is a letter of aUJ.horization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for ColorMaker inc 980 ~:unshine laneSte T Altamonte Springs FL 32714 for a period of one year, to sign applications before the COl11llllssion on our behalf, to make representations to you on our t-ehalf, and to receive and exchange data between our company and the Commission in (onnection with certification ofthe following ColorMaker inc product: (Generic description oftype ofproducts) Remote Control LED Lighting, Transmitters and Receivers under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 1:) ofFCC Rules and Regulations. flease also accept this letter as an attestation that neither ColorMaker inc nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti [Irug-Abuse act of 1988,21 V.S.c. 853(a). In addition, ColorMakerinc will notify the Federal Communications Commission if, at any time, the situation changes causing ( olorMaker inc to be derned federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 407-862-3363 . Sincerely, ,i t:rrv M b' . 1 -a le S~AY

Cover Letter(s)

p.1 Oct 07·1 09:2h • CoJorMaker Inc 980 Sunshine Lane ste T Altamonte Springs FL 32714 (407) 862-3363 10/06/2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, ColorMaker fnc, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Ruies. This request is made under the provisions of Section 0 .457 (d) ofthe Commission's Rules, and Section 552 (b)(4) ofthe Freedom of1nformation Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law jf retained by the person submitting them, and materials which would not customarily be released to the publ ic by that person. If you have any questions, please do not hesitate to contact us at (407) 862·-3363 Sincerely, ~

Cover Letter(s)

Correspondence by Project Project Number: Correspondence NumberMemo Z4RCUE-1 1) Please provide additional information regarding the type of modulation that is used by the device. Response: The devices uses FSK modulation

ID Label/Location Info

This device complies with part15 of Operation is subject (1) this device may not cause harmful and (2) this device must received ,that may cause undesired the FCC rules. to the following two conditions: interference, accept any interference including interference operation Model S/N 00001 ColorCue www.colormaker.net ColorRoll TM Function Keys Power ON Reset Save ColorRoll (Save + ColorRoll) Save Scene (Save + Scene) Set default Colors (Q7 [ Colors]) Set Network (Q6 [Network]) Beep control (Q5 [Beep]) Version 100 FCC ID: Z4RCUE
