Z4RT10Transmitter

ColorMaker, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 02, 2011
Application Purpose: Original Equipment
Date of Application: Nov 02, 2011
Equipment Note: Transmitter
Frequency Range: 916.50000000 - 916.50000000
Company: ColorMaker, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Introduction The PX-T10 is the most advanced wireless LED controller on the market today. The PX-T10 design is an accumulation of years of research and development by ColorMaker inc. The PX-T10 is a microprocessor based system that can be updated by the user as new software is developed. The hardware was designed with more memory and features we could ever use so we are only limited by our imagination. This manual was written by the PX-T10 software developers at ColorMaker. We have tried to explain the numerous features the PX-T10 has to offer in the simplest terms possible. We understand the user will not think like a software developer and understand our technical language so we have 9am to 9pm technical support for the confused user. We have take thousands of technical calls and have a good understanding where users are most confused and have tried to explain less technical terms in this manual. All we ask is that you take the time to read and the rest will fall into place with a few phone calls. The PX-T10 basic functions can be learned in a just a few easy steps and will cover lessons in this manual. The more complicated features can be mastered is just under an hour. As always we have 9am to 9pm technical support (407) 862-3363 and 24/7 email support [email protected]. The lessons in this manual have been written to provide the user with start up information to get up and running is just a few minutes. We will then take you into the fi xture color editing with the various functions and discuss how each function will work. This will be followed by scene control and we will teach you how to record and play scenes. The fi nal lesson will be using the ColorRoll features and how it will senselessly integrate into the controls. Below is a list of new features that will be covered in detail in this manual 1) Group Control 2) Master Dimmer Controls 3) Full ON/OFF Buttons 4) 10 Color Presets 5) ColorRoll STOP 6) F Save 7) SFCP (Single Fixture Color Programming) 8) Display in Percent or DMX 9) Battery Level Monitor Keypad buttons and Functions The PX-T10 has 30 buttons to control up to 90 individual fi xtures. Each button was graphically designed to represent a function. Some button functions will change when used with multi button press such as the shift button. All these functions will be covered in detail later in this manual and followed by lessons and procedures. Master control This is the UP and Down control of the master dimmer. When pressed all fi xtures on the remote network address will be dimmed by the setting from 0 to 100%. When dimmer is not at 100% (Full ON) the LED indicator marked Master will light. RGB controls This is the UP and Down control for the RGB (Red, Green and Blue) color settings. These will also be used when a ColorRoll is active to adjust the Roll, Rate and Flash controls of the ColorRoll Full Button This is a one of the multi button controls. When pressed with the RGB controls the current color will advance to full on or full off. Preset Button This is another multi button control. When pressed with the Q1 through Q10 buttons the color in the circle will be the preset color that will be sent to the controls. Fixture Select buttons are multi function buttons. The will be used to select a fi xture, Change networks and select a color preset. ColorRoll Select buttons. These will also be used to make changes to the PX-T10 function controls. ColorRoll Stop will be used to terminate a ColorRoll and a single channel. This is also a control button to set the LED display to read out in Decimal (DMX) or Percentage 0%-100%. Go Button used to execute a group control feature. This will also be used to display PX-T10 battery power level. Play Button use to play a scene Record Button used to record a scene. This will also be used to command all fi xtures to store its current color into memory. SFCP (Single Fixture ColorRoll Programming) This is a multi button control. When pressed along with the Q1 through Q10 this will also the user to program ColorRolls using a single fi xture. This will also be used to restore the PX-T10 to default factory settings. Shift Button used to select multi function controls Blackout used to turn all fi xtures OFF 1 2 Display Features The PX-T10 has 4 LED indicators, 3 digit display and an RGB color simulator to assist the user in remote navigation. These indicators will be explained in more details in this manual as we guild you through each of the features. The 4 LED indicators each with a single word to illustrate what they will identify during programming. Here is a brief description: Master indicator will light when master value is below 100%. ColorRoll indicator will light when the RGB Up and DN buttons are for editing the ColorRoll Rate, Follow and Flash values. ALL indicator will light when Q10 (ALL) button was pressed to target all fi xtures on the current network. Group indicator will light when the user has preselected a group of fi xtures for editing. RGB Color Simulator is the larger LED just to the left of the 3 digit display. This will emit the same color as the current fi xture that is being edited. This is useful during programming and allow the user to make changes to fi xture color without needing a fi xture to visually see the colors. 3 Digit LED Display is a numeric display that will also show alpha characters to guild the user in programming. Display Power Down is a battery save feature that will turn off the display after 10 minutes of non use. By pressing any button the display will activate. 3 4 PX-T10 Fade, Beep, Display Setup The PX-T10 can be setup to each users needs with custom cross fade and dimmer speed controls. These custom options are programed through the keypad with just a few simple steps. Once programmed the options setting are saved to memory and are recalled each time the PX-T10 is turned on. The options can also be set back to factory defaults if needed. Below is a table of the custom settings and a des…

Text truncated - open the document above for the full version.

Attestation Statements

p.2 Oct 07 ' 1 09:2 Ll .. (~olorMaker inc 980 SWlsrune lane ste T A,1tamonte Springs FL 32714 (407) 862-3363 :.0/06/2011 CETCB j 14 Olinda Drive Brea, CA 92823 Cientlemen: This is a letter of aUJ.horization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for ColorMaker inc 980 ~:unshine laneSte T Altamonte Springs FL 32714 for a period of one year, to sign applications before the COl11llllssion on our behalf, to make representations to you on our t-ehalf, and to receive and exchange data between our company and the Commission in (onnection with certification ofthe following ColorMaker inc product: (Generic description oftype ofproducts) Remote Control LED Lighting, Transmitters and Receivers under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 1:) ofFCC Rules and Regulations. flease also accept this letter as an attestation that neither ColorMaker inc nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti [Irug-Abuse act of 1988,21 V.S.c. 853(a). In addition, ColorMakerinc will notify the Federal Communications Commission if, at any time, the situation changes causing ( olorMaker inc to be derned federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 407-862-3363 . Sincerely, ,i t:rrv M b' . 1 -a le S~AY

Cover Letter(s)

p.1 Oct 07·1 09:2h • CoJorMaker Inc 980 Sunshine Lane ste T Altamonte Springs FL 32714 (407) 862-3363 10/06/2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, ColorMaker fnc, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Ruies. This request is made under the provisions of Section 0 .457 (d) ofthe Commission's Rules, and Section 552 (b)(4) ofthe Freedom of1nformation Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law jf retained by the person submitting them, and materials which would not customarily be released to the publ ic by that person. If you have any questions, please do not hesitate to contact us at (407) 862·-3363 Sincerely, ~

Cover Letter(s)

Correspondence by Project Project Number: Correspondence Number Memo Z4RT10-1 1) Please describe the type of modulation used by the device. Response: The EUT uses FSK modulation. 2) The external photos show a port on the back of the device that was not terminated during testing. Please explain why the port wasn’t terminated during the testing. Response: The port is used for in house programming. When a connection is made the transmitter and receiver parts of the device are disabled.

ID Label/Location Info

Model S/N 0000001 PX-T10 2.10" 3.20" PX-T10 back label design This device complies with part15 of Operation is subject (1) this device may not cause harmful and (2) this device must received ,that may cause undesired the FCC rules. to the following two conditions: interference, accept any interference including interference operation FCC ID: Z4RT10

Test Report

Report Number: B11018D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PX-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for TRANSMITTER MODEL: PX-T10 Prepared for COLORMAKER, INC. 980 SUNSHINE LANE, SUITE T ALTAMONTE SPRINGS, FLORIDA 32714 Prepared by:_____________________ ALEX BENITEZ Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: OCTOBER 19, 2011 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 13 10 45 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B11018D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PX-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B11018D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PX-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos Test Setup Diagram Antenna and Amplifier Factors Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURETITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site – 3 Meters Report Number: B11018D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PX-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Transmitter Model: PX-T10 S/N: N/A Product Description: See Expository Statement Modifications: Please refer to Appendix B for details. Customer: ColorMaker, Inc 980 Sunshine Lane, Suite T Altamonte Springs, Florida 32714 Test Date(s): October 17 and 18, 2011 Test Specifications:Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, sections 15.205,15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TESTDESCRIPTIONRESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power only. 2 Radiated RF Emissions 10 kHz – 10,000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B11018D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PX-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Transmitter, Model: PX-T10. The emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B for the digital and receiver portion; and the limits defined in Subpart C, secti…

Text truncated - open the document above for the full version.

Test Setup Photos
