Z4RPSTTransmitter

ColorMaker, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 08, 2011
Application Purpose: Original Equipment
Date of Application: Dec 08, 2011
Equipment Note: Transmitter
Frequency Range: 916.50000000 - 916.50000000
Company: ColorMaker, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

PS-T10 Wireless Control for ColorMaker Series LED Fixtures with ColorRoll Technology User’s Manual Introduction PS-T10 This manual covers the PS-T10 If your remote is the Enhance version you will need to read the instruction for both models. The instruction for the enhanced version only covers new features. This manual is written to take you through each step required to complete a procedure it is recommend you follow each step in the sequence it is taught. There is a quick reference page to common question once you have finished covering all the key features. There is also a phone number and email address at the bottom of each page in case you need assistance. We have tried to keep the instructions as simple as possible to ease the learning curve. PS-T10 is an enhanced version of the PS-T10 transmitter. This enhanced version is compatible with all Color Maker series LED fixtures including our ColorRoll technology. All the functions found in the PS-T10 work the same in the Enhanced version. We have added a few key features for added control and to expand the number of fixture that can be controlled from a single handheld. Comparison chart FeaturesPS-T10PS-T10nhanced Addressable fixtures1090 Programmable Network Addresses09 Programmable Scenes1090 Programmable ColorRolls327 www.ColorMaker.net (407) 862-3363 Fixture Select buttons ------------------------------------------------------------------------------------1 Scene Select buttons --------------------------------------------------------------------------------------1 Recording a Scene ----------------------------------------------------------------------------------------1 Play a Scene -----------------------------------------------------------------------------------------------2 Lesson :Record and Play a Scene -----------------------------------------------------------------------2 Scene Cross Fade and Dimmer Speed -----------------------------------------------------------------3 Functions: Beep, Shift Q10, Shift UP -----------------------------------------------------------------4 What is ColorRoll ----------------------------------------------------------------------------------------5 Creating a ColorRoll -------------------------------------------------------------------------------------5 Lesson: Create a ColorRoll with 10 Colors -----------------------------------------------------------5 Lesson: Create a ColorRoll with 3 Colors -------------------------------------------------------------5 Removing a dead spot from a ColorRoll Pattern -----------------------------------------------------6 Controlling a ColorRoll Fade ----------------------------------------------------------------------------6 Lesson: Adjusting ColorRoll Fade Rate ---------------------------------------------------------------7 ColorRoll with Flash -------------------------------------------------------------------------------------7 ColorRoll Option on the DCR series Fixtures --------------------------------------------------------8 How Do I stop a ColorRoll in progress ----------------------------------------------------------------8 PS-T10 Keypad reference table -----------------------------------------------------------------9 PS-T10nhanced Instruction -------------------------------------------------------------------10 Why use Networking ? -----------------------------------------------------------------------------------10 Resetting Network Addresses (default) -----------------------------------------------------------------10 Fixture Address Vs Fixture Network Address ---------------------------------------------------------10 Network Address in detail --------------------------------------------------------------------------------11 Network Programming Display -------------------------------------------------------------------------11 Network address with Fixtures -------------------------------------------------------------------------12 Fixture Switch #8 -----------------------------------------------------------------------------------------12 Reset Network address in Fixtures ----------------------------------------------------------------------12 Programming the Remote with Network Addresses --------------------------------------------------13 Controlling fixtures using Network Addresses --------------------------------------------------------13 90 Fixture Buffer ( Memory) ----------------------------------------------------------------------------13 Function with Networking -------------------------------------------------------------------------------14 Fixture editing with Networking ------------------------------------------------------------------------14 Blackout ----------------------------------------------------------------------------------------------------14 Clearing Buffer --------------------------------------------------------------------------------------------14 Scene Control with Networking -------------------------------------------------------------------------15 New ColorRoll Features (enhanced version only) ----------------------------------------------------16 Programming ColorRoll using a Single Fixture -------------------------------------------------------17 PS-T10 Keypad reference table --------------------------------------------------------------18 Binary conversion Table ----------------------------------------------------------------------------------20 FirmWare Updates ----------------------------------------------------------------------------------------21 Table of Contents PS-T10 Keypad The PS-T10 has 24 keys some of which have multiple functions. These special functions are accessed by pressing the Shift Key first followed by the function key. For example the ColorRoll buttons 1 through 3 also function as Crossfade, Speed and Beep. To access these functions the Shift key must be pressed and held while the function key is pressed. Fixture select Buttons Fixture select buttons are marked Q1 through Q10 and have…

Text truncated - open the document above for the full version.

Attestation Statements

p.2 Oct 07 ' 1 09:2 Ll .. (~olorMaker inc 980 SWlsrune lane ste T A,1tamonte Springs FL 32714 (407) 862-3363 :.0/06/2011 CETCB j 14 Olinda Drive Brea, CA 92823 Cientlemen: This is a letter of aUJ.horization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for ColorMaker inc 980 ~:unshine laneSte T Altamonte Springs FL 32714 for a period of one year, to sign applications before the COl11llllssion on our behalf, to make representations to you on our t-ehalf, and to receive and exchange data between our company and the Commission in (onnection with certification ofthe following ColorMaker inc product: (Generic description oftype ofproducts) Remote Control LED Lighting, Transmitters and Receivers under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 1:) ofFCC Rules and Regulations. flease also accept this letter as an attestation that neither ColorMaker inc nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti [Irug-Abuse act of 1988,21 V.S.c. 853(a). In addition, ColorMakerinc will notify the Federal Communications Commission if, at any time, the situation changes causing ( olorMaker inc to be derned federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 407-862-3363 . Sincerely, ,i t:rrv M b' . 1 -a le S~AY

Cover Letter(s)

p.1 Oct 07·1 09:2h • CoJorMaker Inc 980 Sunshine Lane ste T Altamonte Springs FL 32714 (407) 862-3363 10/06/2011 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, ColorMaker fnc, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Ruies. This request is made under the provisions of Section 0 .457 (d) ofthe Commission's Rules, and Section 552 (b)(4) ofthe Freedom of1nformation Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law jf retained by the person submitting them, and materials which would not customarily be released to the publ ic by that person. If you have any questions, please do not hesitate to contact us at (407) 862·-3363 Sincerely, ~

Cover Letter(s)

Correspondence by Project Project Number: Correspondence NumberMemo Z4RPST-1 1) Please provide additional information regarding the type of modulation that is used by the device. Response: The device uses FSK modulation.

ID Label/Location Info

This device complies with part15 of Operation is subject (1) this device may not cause harmful and (2) this device must received , that may cause undesired the FCC rules. to the following two conditions: interference, accept any interference including interference operation Model S/N 0000001 PS-T10 www.colormaker.net ColorRoll TM Function Keys Shift + ColorROll1-FadeRate Shift + ColorRoll 2 - Speed Shift + ColorRoll 3 - Beep Shift + Q10 - All Fixture Select Shift + Q1-Q9 - Net Select FirmWare Version 208 FCCID: Z4RPST

Test Report

Report Number: B11102D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PS-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for TRANSMITTER MODEL: PS-T10 Prepared for COLORMAKER, INC. 980 SUNSHINE LANE, SUITE T ALTAMONTE SPRINGS, FLORIDA 32714 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: OCTOBER 19, 2011 REPORTAPPENDICESTOTAL BODYA B C D E PAGES 16 2 2 2 13 10 45 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B11102D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PS-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B11102D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PS-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos  Test Setup Diagram  Antenna and Amplifier Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site – 3 Meters Report Number: B11102D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PS-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Transmitter Model: PS-T10 S/N: N/A Product Description: See Expository Statement Modifications: Please refer to Appendix B for details. Customer: ColorMaker, Inc 980 Sunshine Lane, Suite T Altamonte Springs, Florida 32714 Test Date(s): November 1 and 2, 2011 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, sections 15.205,15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power only. 2 Radiated RF Emissions 10 kHz – 9.165 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B11102D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: PS-T10 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Transmitter, Model: PS-T10. The emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B for the digital portion; and the limits defined in Subpart C, sections 15.205, 15.209, and 15.249 for the transmitter portion. Re…

Text truncated - open the document above for the full version.

Test Setup Photos
