SMARTdiagnostics ® IoT HUB Product Guide v.1.0 Last Edited: 5/4/2020 IoT HUB Product Guide v.1.0 Lasted Edited: 05/04/2020 2 | Page Contents Revision History .......................................................................................................................................... 3 1 Product Overview ............................................................................................................................... 4 1.1 Introduction .................................................................................................................................. 4 1.2 How It Works ............................................................................................................................... 4 1.3 Applications ................................................................................................................................. 4 2 Product Specifications ....................................................................................................................... 5 2.1 IoT HUB ....................................................................................................................................... 5 2.1.1 Mechanical Specifications ..................................................................................................... 5 2.1.2 Electrical Specifications ......................................................................................................... 5 2.1.3 Environmental Specifications ............................................................................................... 6 2.1.4 Wireless Radio Specifications .............................................................................................. 6 2.1.5 Input Options ........................................................................................................................... 6 2.1.6 Part Numbers .......................................................................................................................... 7 2.2 Wired Vibration Sensor.............................................................................................................. 7 2.2.1 Mechanical Specifications ..................................................................................................... 7 2.2.2 Environmental Specifications ............................................................................................... 7 2.2.3 Acceleration ............................................................................................................................. 7 2.2.4 Temperature Sensor .............................................................................................................. 8 2.2.5 Part Numbers .......................................................................................................................... 8 3 Installation and Setup ........................................................................................................................ 9 3.1 Special Tools Needed ............................................................................................................... 9 3.2 Hardware Installation Procedures ............................................................................................ 9 3.3 Software Setup Procedures ...................................................................................................... 9 3.3.1 Adjusting HUB and Sensor Settings ................................................................................... 9 3.3.2 Collecting Long Burst Data ............................................................................................. 11 4 Product Support, Warranty, and Certification Information ......................................................... 11 4.1 KCF Contact Information ......................................................................................................... 11 4.2 Product Warranty and Return Policy ..................................................................................... 12 4.3 Certification Information .......................................................................................................... 14 IoT HUB Product Guide v.1.0 Lasted Edited: 05/04/2020 3 | Page Revision History Date Version Author Details 5/4/2020 1.0 R. Korte, E. Sankey Document Published IoT HUB Product Guide v.1.0 Lasted Edited: 05/04/2020 4 | Page 1 Product Overview 1.1 Introduction The HUB is the central part of a product system that is designed to meet the following needs in the industries we serve: • Fill the gap where deploying KCF’s wireless vibration sensors is not feasible due to access, size, environment, etc. • Update the KCF’s General Input Nodes’ capability to ingest standard, 3 rd -party transducer data into SMARTdiagnostics ® • Extend our monitoring capability with the ability to collect data at the same time across multiple sensors • Extend our monitoring capability with the ability to “trigger” data collection so that we can collect data when it matters- when a machine is running or at specific times during a machine’s cycle 1.2 How It Works The HUB controls up to seven (7) sensors that are connected to the HUB with a cable. In this way, the HUB can both power the sensors and control how and when those sensors collect data. When data is collected, it is transferred from the sensor to the HUB over-the-wire. The HUB subsequently transmits that data wirelessly to a base station or repeater (using DARTwireless™) which then sends it to SMARTdiagnostics ® software for analysis. While the sensors can be installed on multiple or single assets, the ability of the HUB to coordinate/synchronize data collection across multiple sensors on a single asset allows for fully understanding of the asset’s overall health. 1.3 Applications The HUB was designed to address several unique challenges. A few of these are discussed here. KCF’s Wireless Vibration Sensor has a wide operating temperature range that…

Text truncated - open the document above for the full version.

https://kcftech-my.sharepoint.com/personal/enoyes_kcftech_com/Documents/Organized files!/EA - Jeremy/BS&S/Hub FCC Docs/16-Z5IHB1 Agree.docx KCF Technologies, Inc. 336 South Fraser Street State College, PA 16801 Phone: (814) 867-4097 Fax: (814) 690-1579 www.kcftech.com ______________________________________________________________________ Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for Z5IHB1 To Whom It May Concern: We, the undersigned, hereby authorize Richard Reitz at Retlif Testing Laboratories on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Retlif Testing Laboratories on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Jeremy Frank CEO Date: May 4, 2020

KCF Technologies, Inc. 336 South Fraser Street State College, PA 16801 Phone: (814) 867-4097 Fax: (814) 690-1579 www.kcftech.com ______________________________________________________________________ Dear Sir or Madam, The application for FCC ID: Z5IHB1 will cover the following model numbers: SD- HUB- 1-MA Base model with magnets (for attachment) and with AC power module SD- HUB-1-MB Base model with magnets (for attachment) and with battery power module SD- HUB-1-XA Base model without magnets and with AC power module SD- HUB-1-XB Base model without magnets and with battery power module. The “base model” listed above for each variation is physically and electrically identical. Sincerely, Jeremy Frank CEO Date: May 4, 2020

KCF Technologies, Inc. 336 South Fraser Street State College, PA 16801 Phone: (814) 867-4097 Fax: (814) 690-1579 www.kcftech.com ______________________________________________________________________ Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: Z5IHB1. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematic Diagram Z5IHB1 Schem (CONFIDENTIAL).pdf Parts List Z5IHB1 PartsLst (CONFIDENTIAL).pdf Block Diagram Z5IHB1 BlkDia (CONFIDENTIAL).pdf Operational Description Z5IHB1 OpDes (CONFIDENTIAL).pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Jeremy Frank CEO Date: May 4, 2020

“HUB Top” without internal PCBs. Grid pattern is 5mm. “HUB Top” with all internal parts installed. Grid pattern is 5mm. Bottom of “HUB Base”. Grid pattern is 5mm. “AC Power Module” parts. Grid pattern is 5mm. Fully assembled HUB with Battery Power Module installed. Grid pattern is 5mm. Fully assembled HUB with AC Power Module installed. Grid pattern is 5mm.

SD–HUB–1–MA Serial number in Roman characters and machine- readable code Trade/Company Name/Logo Product Name Model/Part Number: SD-HUB-1-MA SD-HUB-1-XA SD-HUB-1-MB SD-HUB-1-XB FCC ID and IC numbers FCC Statement All markings permanently laser engraved into enclosure This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

SD–HUB–1–MA Serial number in Roman characters and machine- readable code Trade/Company Name/Logo Product Name Model/Part Number: SD-HUB-1-MA SD-HUB-1-XA SD-HUB-1-MB SD-HUB-1-XB FCC ID and IC numbers FCC Statement All markings permanently laser engraved into enclosure This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Top view of “Wireless PCB” prior to attaching to “HUB Main PCB”, without RF shield. Grid pattern is 5mm. Bottom view of “Wireless PCB.” Grid pattern is 5mm. Bottom view of “HUB Main PCB”. “Wireless PCB” is LGA’d to “HUB Main PCB” on the right. Power connector is on the left. Grid pattern is 5mm. Top view of “HUB Main PCB”. Grid pattern is 5mm. “HUB Base” and parts that are assembled into “HUB Base”. Grid pattern is 5mm. Fully assembled “HUB Base”. “Hub Base” is ready to be mated to fully assembled “HUB Top”. Grid pattern is 5mm. “HUB Top” and parts that are assembled into “HUB Top”. Grid pattern is 5mm. Fully assembled “HUB Top”. Grid pattern is 5mm. “HUB Main PCB” with antenna attached to “Wireless PCB”. Grid pattern is 5mm. Antenna and “Antenna Holder” that is installed into “HUB Top”. Antenna slides into “Antenna Holder”. Grid pattern is 5mm. “HUB Main PCB”, “Antenna Holder”, and antenna installed into “HUB Top”. “HUB Top” is ready to be mated to fully assembled “HUB Base”. Grid pattern is 5mm. Top: P0004-BRD-A Bottom: P0005-BRD-A sealed and mated to Tracopower supply Fully assembled “AC Power Module”. Fully assembled “Battery Power Module”. Grid pattern is 5mm. Enclosure and parts for the “Battery Power Module”. Grid pattern is 5mm.

FCC Part 15, Subpart C, Section 15.247 Test Report On IoT Sensor Hub FCC ID: Z5IHB1 Customer Name: KCF Technologies, Inc. Customer P.O: 04232020A Date of Report: September 17, 2020 Test Report No: R-3248P-1 Test Start Date: July 28, 2020 Test Finish Date: September 3, 2020 Test Technician: M. Nowak Approved By: D. Rybicki Report Prepared By: B. Bolton Our letters, procedures and reports are for the exclusive use of the customer to whom they are addressed and their communication or the use of the name of Retlif Testing Laboratories must receive our prior written approval. Our letters, procedures and reports apply only to the sample tested and are not necessarily indicative of the qualities of apparently identical or similar products. The letters, procedures and reports and the name of Retlif Testing Laboratories or insignia are not to be used under any circumstances in advertising to the general public. This test report shall not be reproduced, except in full, without the written approval of Retlif Testing Laboratories. Report No. R-3248P-1 Page 2 of 86 Retlif Testing Laboratories R Table of Contents Technical Information............................................................................................................ 3 Certification and Signatures .................................................................................................. 5 Requirements and Test Results ............................................................................................ 6 FCC Section 15.247(a)(2), Occupied Bandwidth .................................................................. 6 FCC Sections 15.247(b)(3), Power Output ........................................................................... 6 FCC Section 15.247(d), Antenna Port Conducted Emissions ............................................... 7 FCC Section 15.247(e), Antenna Port, Power Density ......................................................... 7 FCC Section 15.209(a), Radiated Emission Limits, General Requirements ......................... 8 FCC Section 15.207(a), Conducted Limits ............................................................................ 8 FCC Section 15.247 (i), RF Exposure Limits ...................................................................... 10 General Notes ..................................................................................................................... 11 Equipment List .................................................................................................................... 12 Test Data, Occupied Bandwidth, SD-HUB-1-MA .............................................. 13 Test Data, Occupied Bandwidth, SD-HUB-1-XA ............................................... 17 Test Data, Power Output, SD-HUB-1-MA ......................................................... 21 Test Data, Power Output, SD-HUB-1-MB ......................................................... 25 Test Data, Out of Band Emissions, SD-HUB-1-MA ........................................... 29 Test Data, Out of Band Emissions in Restricted Band, SD-HUB-1-MA ............ 40 Test Data, Out of Band Emissions, SD-HUB-1-XA ........................................... 49 Test Data, Out of Band Emissions in Restricted Band, SD-HUB-1-XA ............. 60 Test Data, Power Spectral Density, SD-HUB-1-MA .......................................... 69 Test Data, Power Spectral Density, SD-HUB-1-XA .......................................... 73 Test Data, Conducted Limits, SD-HUB-1-MA ................................................... 77 Test Data, Conducted Limits, SD-HUB-1-XA .................................................... 80 Test Data, Digital and Receiver Spurious Emissions, SD-HUB-1-MA ............... 83 Test Data, Digital and Receiver Spurious Emissions, SD-HUB-1-XA ............... 85 Report No. R-3248P-1 Page 3 of 86 Retlif Testing Laboratories R Technical Information Report Number: R-3248P-1 Customer: KCF Technologies, Inc. Address: 336 S. Fraser Street State College, PA 16801 Manufacturer: KCF Technologies, Inc. Manufacturer Address: 336 S. Fraser Street State College, PA 16801 Test Sample: IoT Sensor Hub Model Number: SD-HUB-1-MB SD-HUB-1-MA SD-HUB-1-XB SD-HUB-1-XA FCC ID: ZSIHB1 Type: 2.405 to 2.480 GHz Digital Spread Spectrum Transceiver Power Requirements: 120 VAC, 60 Hz (SD-HUB-1-MA and SD-HUB-1-XA) Power Requirements: 3.6 VDC internal battery derived from Li-SOCl 2 (SD-HUB-1-MB and SD-HUB-1-XB) Frequency of Operation: 2400 – 2483.5 MHz Equipment Class: DSS Equipment Use: Fixed Test Specification: FCC Rules and Regulations Part 15, Subpart C, Section 15.247 Test Procedure: ANSI C63.4:2014 ANSI C63.10:2013 Test Facility: Retlif Testing Laboratories 3131 Detwiler Road Harleysville, PA 19438 FCC Accreditation Designation Number: US2321 Report No. R-3248P-1 Page 4 of 86 Retlif Testing Laboratories R Tests Performed The test methods performed on the IoT Sensor Hub are shown in Table 1 below: Table 1 – Test Methods FCC Part 15, Subpart C Test Method 15.247(a)(2) Occupied Bandwidth 15.247(b)(3) Power Output 15.247(d) Antenna Port, Conducted Emissions 15.247(d) Out of Band / Band Edge Radiated Emissions, 9kHz to 25 GHz 15.247(e) Antenna Port, Power Density 15.207(a) Conducted Limits, 150 kHz to 30 MHz The equipment utilized to operate the EUT are shown in Table 2 below: Table 2 – Support Equipment Description Manufacturer Model Number Serial Number Test PC Dell Latitude 5490 GG1V7S2 Transceiver KCF Technologies SD-PRN-2 C00010D4 Vibration Sensor KCF Technologies SD-WVS-1 1000004E Vibration Sensor KCF Technologies SD-WVS-1 1000003C Vibration Sensor KCF Technologies SD-WVS-1 1000002D Vibration Sensor KCF Technologies SD-WVS-1 1000001F Vibration Sensor KCF Technologies SD-WVS-1 1000004B Vibration Sensor KCF Technologies SD-WVS-1 10000034 Vibration Sensor KCF Technologies SD-WVS-1 1000003A Report No. R-3248P-1 Page 5 of 86 Retlif Testing Laboratories R Certification and Signatures We certify that this report is a…
