Remote Control (L6N5A-AW) Company : Loong Yee Product Name : Remote Control Loong Yee Part Number : L6N5A-AW Operation Frequency : 2.409 GHz Modulation Type: FSK Number Of Channel 1 Antenna Type: PCB Power Source: Suppplied from Battery Power Rating: DC 3V Front View : 2.409 GHz Field strength Operating Step: 1. Connet Loong‐Yee Touch Switch. 2. Press Remote control Box “1” 5 Sec, the Red LED is flash. 3. Press Switch, then the Red LED is off. 4. Push remote control “1’” , the Switch “1” can be Turn ON or OFF. 5. The Button “2” , “3” , “4” , “5”, “6” same procedure. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! 1. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Indoor use only

CERTIFICATEOF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the BTL EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Touch Switch Model Name LR7A-M12, LR7A-M13 , LR3A-M13, L6N5A-AW Brand Name Loong Yee Applicant LoongYee Industry Co.,Ltd Address No.14, Lane 103, Sec.2,Zhongxing Rd, Wu Gu Dist,24873 New Taipei City, Taiwan, R.O.C. Standard(s) FCC Part 15, Subpart B: 2014 ANSI C63.4-2014 CISPR 22: 2008 Report(s) BTL-FCCE-1-1507004 The test data, data evaluation, and equipment configuration contained in our test report(s) above was (were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory BTL INC. B1, No. 37, Lane 365, Yang-Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL:+886-2-2657-3299 FAX:+886-2-2657-3331

Project No.: 1507004 Page 2 of 1 0 L6N5A-AW Project No.: 1507004 Page 3 of 1 0

Project No.: 1507004 Page 4 of 1 0 Project No.: 1507004 Page 6 of 1 0 Project No.: 1507004 Page 7 of 1 0 Project No.: 1507004 Page 8 of 1 0 Project No.: 1507004 Page 9 of 1 0 Project No.: 1507004 Page 10 of 10

Report No.: BTL-FCCP-2-1507004 Page 1 of 37 FCC Radio Test Report FCC ID: Z5N-RMC06 This report concerns (check one): Original Grant Class II Change Project No. : 1507004 Equipment : Touch Switch Model Name : L6N5A-AW Applicant : LoongYee Industry Co.,Ltd Address : No.14, Lane 103, Sec.2,Zhongxing Rd, Wu Gu Dist,24873 New Taipei City, Taiwan, R.O.C. Date of Receipt : Jul. 01, 2015 Date of Test : Jul. 01, 2015~Oct. 13, 2015 Issued Date : Oct. 14, 2015 Tested by : BTL Inc. Testing Engineer : (Josh Lin) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) BTL INC. B1, No.37, Lane 365, Yang Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Report No.: BTL-FCCP-2-1507004 Page 2 of 37 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement b y NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-2-1507004 Page 3 of 37 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 9 3 .GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 11 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION 13 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 14 4.1.5 EUT OPERATING CONDITIONS 14 4.1.6 EUT TEST CONDITIONS 14 4.1.7 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 RADIATED EMISSION LIMITS 15 4.2.2 TESTPROCEDURE 16 4.2.3 DEVIATION FROM TEST STANDARD 16 4.2.4 TESTSETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 4.2.6 EUT TEST CONDITIONS 18 4.2.7 TEST RESULTS (9KHZ 30MHZ) 18 4.2.8 TEST RESULTS (30MHZ to 1000 MHZ) 18 4.2.9 TEST RESULTS (ABOVE1000 MHZ) 19 5 . BANDWIDTH TEST 20 5.1 TEST PROCEDURE 20 5.2 DEVIATION FROM STANDARD 20 5.3 TEST SETUP 20 5.4 EUT OPERATION CONDITIONS 20 5.5 EUT TEST CONDITIONS 20 5.6 TEST RESULTS 20 6 . MEASUREMENT INSTRUMENTS LIST AND SETTING 21 7 . EUT TEST PHOTO 22 Report No.: BTL-FCCP-2-1507004 Page 4 of 37 Table of Contents Page ATTACHMENT A - CONDUCTED EMISSION 25 ATTACHMENT B -RADIATED EMISSION (9KHZ to 30MHZ) 26 ATTACHMENT C -RADIATED EMISSION (30MHZ TO 1000MHZ) 28 ATTACHMENT D -RADIATED EMISSION (ABOVE 1000MHZ) 31 ATTACHMENT E - BANDWIDTH 36 Report No.: BTL-FCCP-2-1507004 Page 5 of 37 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-2-1507004 Original Issue. Oct. 14, 2015 Report No.: BTL-FCCP-2-1507004 Page 6 of 37 1. CERTIFICATION Equipment : Touch Switch Brand Name : Loong Yee Model Name : L6N5A-AW Applicant : LoongYee Industry Co.,Ltd Manufacturer : LoongYee Industry Co.,Ltd Address : No.14, Lane 103, Sec.2,Zhongxing Rd, Wu Gu Dist,24873 New Taipei City, Taiwan, R.O.C. Factory : LoongYee Industry Co.,Ltd Address : No.14, Lane 103, Sec.2,Zhongxing Rd, Wu Gu Dist,24873 New Taipei City, Taiwan, R.O.C. Date of Test : Jul. 01, 2015~Oct. 13, 2015 Test Sample : Engineering Sample Standard(s) : FCC Part15, Subpart C :2014 (15.249)/ ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc.. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-2-1507004) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-2-1507004 Page 7 of 37 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark FCC 15.207(a) Conducted Emission N/A Note（1） 15.205 Restricted Band of Operation PASS 15.209 15.249(a) Radiated Emissions PASS 15.215(c) 20dB Bandwidth Test PASS NOTE: (1)”N/A” denotes test is not applicable to this device. Report No.: BTL-FCCP-2-1507004 Page 8 of 37 2.1 TEST FACILITY Radiated emission Test (Below 1 GHz): CB08: (FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Radiated emission Test (Above 1 GHz): CB08: (FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Report No.: BTL-FCCP-2-1507004 Page 9 of 37 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2. The BTL measurement uncertainty is less tha…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-1507004 Page 22 of 37 7. EUT TEST PHOTO Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-2-1507004 Page 23 of 37 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FCCP-2-1507004 Page 24 of 37 Radiated Measurement Photos Above 1000MHz
