Z5YHS-BT01Bluetooth Wireless Stereo Headset

Bluetooth Wireless Stereo Headset Quick Start Guide HS-BT01 Product Picture FCC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Introduction Thanks for purchasing this Bluetooth Wireless Stereo Headset. The headset is ideal for your audio source such as notebook, PC, smart phone and other devices with Bluetooth. The ergonomic design and high quality materials make the headset comfortable for daily use. Headsets with DSP technology bring clear sound and amazing feeling. The package contents 1. One Bluetooth Wireless Stereo Headset 2. One 1M standard USB cable 3. Quick Start Guide CAUTION Read all safety and operating instructions below before this device is operated. 1. Stop using this product immediately if it causes discomfort or pain. When using this product, it is recommended that you limit volume to help avoid harm to your ears and danger resulting from being unable to hear what is going on around you. 2. Keep the device out of extreme heat and humidity. 3. Do not use the device near water, such as sinks, bathtubs, swimming pools, washing machines, tubs of water, etc. 4. Observe all signs and instructions that require an electrical device or radio product to be switched off in designated areas, such as petrol/refueling stations, hospitals, blasting areas, potentially explosive atmospheres or aircraft. 5. The headset has a wireless range of up to 10M, but wireless performance may be affected in different operating environment. 6. Barriers and other wireless devices may affect the performance of headset. 7. Power time may differ depending on personal habits. 8. Please do not rotate the headset until the head band is set / pushed to lowest position. PLEASE NOTE: the information in this quick start guide was correct at the time of publication, but some minor changes may have been made late in the product’s development. Structure of Headset (图片) A. Volume up/down button B. Blue LED (Power indication and pairing indication) C. Red LED (Battery charge indication and low-voltage indication) D. Ф6mm Omni-directional microphone E. Multifunction button (Answer call / Hang up / Play/pause / Power on/off / Pairing ) F. Mini USB jack G. Adjustable headband (用小图标标示) H. 1M standard USB cable I. Quick Start Guide Power On/Power Off （图示） A. Power On 1. If the headset had never been paired any Bluetooth device before, push the multifunction button about 8 seconds and the headset will automatically go to the pairing mode, and the blue LED will fast twinkle. 2. If the headset had ever been paired some Bluetooth device before, push the multifunction button about 5 seconds to power on and the blue LED will slowly twinkle. The headset will automatically search the last paired Bluetooth device for 3 minutes and it will shut down automatically without pairing. B. Power Off 1. Push the multifunction button about 5 seconds and the red LED will short flash and go off. Headset connection 1 Take the headset out of package, chose the suitable headband for you and press the multifunction button. 1.1 If the headset had ever paired some Bluetooth device before, push the multifunction button about 5 seconds and the headset will automatically search the last paired Bluetooth device. Besides, the blue LED will slowly twinkle（图示） 1.2 If the headset had never paired any Bluetooth device before, make sure the headset is power off and long press the multifunction button around 8 seconds until the blue LED flash rapidly to indicate pairing mode. （图示） 2. Activate the Bluetooth feature on the phone or other devices, then use their setting to add/search/discover new Bluetooth devices. （图示） 3. Select “HS-BT01” from the list of Bluetooth devices shown on the phones or other devices. If ask for a pass code, enter four zeros “0000”. Some phones also ask to confirm headset connection after pairing. （图示） 4. Blue LED will stop flashing but keep solid after the headset is successfully paired. （图示） 5. select “play through headset” in your smart phone if required 6. Adjust the headband to your favorite. （图示） Enjoying music 1. After connection, play the music and enjoy the on the headset. 2. Adjust the volume on headset or Bluetooth devices to your favorite level. 3. Pause or resume the song, please short press the multifunction button. 4. The music will automatically pause if answer or dial a call and resume the music after the call …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006

External of EUT

FCC ID Label FCC ID: Z5YHS-BT01 Model Number: HS-BT01 Made in China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Label Location Proposed Label Location on EUT

Internal of EUT Bluetooth module Antenna

FCC ID : Z5YHS-BT01 BT (Portable device) According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2402 2480 2441 25 Maximum measured transmitter power: Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 2.65 0 2.65 Threshold at which no SAR required is 25 mw. Maximum Tx power is 2.65mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A Sincerely, Signature Peter Pan / Product Specialist E-mail: : [email protected] Phone: 86-573-84681198 Fax: 86-573-84669785 Address : No.1555 Jiashan Avenue, Jiashan 314113, Zhejiang, China

SHENZHEN EMTEK CO., LTD. REPORT NO: ES110929157F FCC ID:Z5YHS-BT01 DATE:11/01/2011 Page 1 of 44 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPARTC REQUIREMENT OF Bluetooth Wireless Stereo Headset MODEL No.: HS-BT01 BRAND NAME: Compupal FCC ID: Z5YHS-BT01 REPORT NO: ES110929157F ISSUE DATE: November 1, 2011 Prepared for Compupal Group Corporation No.1555 Jiashan Avenue, Jiashan 314113, Zhejiang, China Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 SHENZHEN EMTEK CO., LTD. REPORT NO: ES110929157F FCC ID: Z5YHS-BT01 DATE: 11/01/2011 Page 2 of 44 VERIFICATION OF COMPLIANCE Applicant: Compupal Group Corporation No.1555 Jiashan Avenue, Jiashan 314113, Zhejiang, China Product Description: Bluetooth Wireless Stereo Headset Brand Name: Compupal Model Number: HS-BT01 Serial Number: N/A File Number: ES110929157F Date of Test: September 29, 2011 to October 13, 2011 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : September 29, 2011 to October 13, 2011 Prepared by : (Engineer) Reviewer : (Quality Manager) Approve & Authorized Signer : (Manager) SHENZHEN EMTEK CO., LTD. REPORT NO: ES110929157F FCC ID: Z5YHS-BT01 DATE: 11/01/2011 Page 3 of 44 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 P RODUCT DESCRIPTION.............................................................................................................. 5 1.2 R ELATED SUBMITTAL(S) / GRANT (S) ......................................................................................... 5 1.3 T EST METHODOLOGY................................................................................................................. 5 1.4 S PECIAL ACCESSORIES................................................................................................................ 5 1.5 E QUIPMENT MODIFICATIONS...................................................................................................... 5 1.6 T EST FACILITY............................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION................................................................................................................ 7 2.2 EUT EXERCISE........................................................................................................................... 7 2.3 T EST PROCEDURE....................................................................................................................... 7 2.4 L IMITATION................................................................................................................................7 2.5 C ONFIGURATION OF TESTED SYSTEM....................................................................................... 11 2.6 EQUIPMENT USED IN TESTED SYSTEM........................................................................................ 11 2.7 DESCRIPTION OF TEST MODES..................................................................................................... 12 3. SUMMARY OF TEST RESULTS ....................................................................................... 13 4. CONDUCTED EMISSIONS TEST ..................................................................................... 14 4.1 M EASUREMENT PROCEDURE:.................................................................................................... 14 4.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................ 14 4.3 M EASUREMENT EQUIPMENT USED: .......................................................................................... 14 4.4 CONDUCTED EMISSION LIMIT..................................................................................................... 14 4.5 M EASUREMENT RESULT: .......................................................................................................... 15 4.6 CONDUCTED MEASUREMENT PHOTOS: ....................................................................................... 16 5. RADIATED EMISSION TEST ............................................................................................ 17 5.1 M EASUREMENT PROCEDURE..................................................................................................... 17 5.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................ 18 5.3 M EASUREMENT EQUIPMENT USED: .......................................................................................... 19 5.4 M EASUREMENT RESULT........................................................................................................... 20 5.5 RADIATED MEASUREMENT PHOTOS: .......................................................................................... 26 6. CHANNEL SEPARATION TEST ....................................................................................... 28 6.1 M EASUREMENT PROCEDURE..................................................................................................... 28 6.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................ 28 6.3 M EASUREMENT EQUIPMENT USED: ..............................…

Text truncated - open the document above for the full version.

RADIATED EMISSION TEST CONDUCTED EMISSION TEST
