Z5YMG-LBTS01IRBluetooth Light Speaker

Bluetooth Light Speaker Quick Start Guide Introduction This Bluetooth Light Speaker is a perfect combination of LED lamp and Bluetooth Speaker. It’s equipped with infrared remote control for easier use. You will be surprised to match it well with your desk lamp. Enjoy it! The Package Contents 1x Bluetooth Light Speaker 1x Infrared remote control 1x Quick Start Guide Caution 1. Please read and follow all instructions before operating this product. 2. Heed all warnings on the product and in the operation instructions. 3. Please cut power off before install or uninstall the product. 4. When LED lamp on, suggest not touch the product surface in case being burned. 5. To get better remote control performance, please do not place light proof obstacle on front of the product. 6. Suggest not use metal lampshade in case the wireless signal suffers from attenuation. 7. With LED lamp on, if not plan to listen music, suggest to turn Bluetooth off by pressing Bluetooth power button on remote control. It can save power, extend Bluetooth lifetime and reduce interference to lamp from Bluetooth. 8. With LED lamp on and brightness not reaching 100%, there maybe some slight background noise which is normal. 9. External dimmer does not work for the product. You can adjust lamp brightness by using remote control. 10. Do not open the product to avoid electronic shock. Repair has to be performed by a qualified technician. 11. Cut power off if not to use the product for a long period of time. 12. The product has a wireless transmission distance up to 33ft, but wireless performance may be affected in different operating environment. 13. Keep the product out of extreme heat and humidity. Do not install it near heaters, stoves or any other source of heat. 14. Do not use the product during lightning storms. Turn the power off to prevent damage to the product due to lightning and power-line surges. 15. Please do not stare at the light source for a long time to protect your eyes. 16. If cleaning is required, use a soft dry cloth. Before cleaning, unplug the device from the electrical source. Product Installation 1. Take the Bluetooth Light Speaker, Remote control, Quick start guide out of your package. 2. Pull out the insulation sheet on the remote control to make it work. 3. Before installing the Light Speaker into your lamp system, make sure the power is off. 4. Screw Light Speaker into E26 socket. 5. Turn the power on, white LED will be lit and speaker will enter Bluetooth pairing status with indication LED blinking fast in blue. You can use remote control to reduce white LED brightness to observe indication LED status. LED lamp function 1. LED lamp brightness has 5 levels: 0%, 25%, 50%, 75% and 100%. 2. You can short press button on remote control to adjust LED lamp brightness. Speaker function 1. Make sure Bluetooth Speaker is at pairing status (indication LED blinking fast in blue) 2. Make sure Bluetooth device (smart phone, pad etc) has open Bluetooth. 3. Enter Bluetooth interface to search for new device and select “MG-LBTS01IR” for paring. During pairing, some Bluetooth devices require to enter password. Just type four zeros “0000”. 4. Indication LED will stop blinking and keep solid in blue after Bluetooth connected. 5. Open music player to play the music you like. 6. You can use your Bluetooth device (smart phone, pad etc) or remote control to do play/pause, volume up/down, last track, next track, mute operation and so on. Note 1. If your Bluetooth device (smart phone, pad etc) has ever connected this Bluetooth Light Speaker, it supports Bluetooth automatically reconnect without pairing. 2. There is a Bi-color (red/blue) LED for Bluetooth, volume control and mute indication: - Bluetooth pairing: blinking fast in blue; - Bluetooth reconnecting: blinking slowly in blue; - Bluetooth connected: blue color on in solid; - Mute status: red color on in solid; - Volume control: blue color on in solid and red color blinking with every volume adjusting operation. Remote control function: No Button Function description 1 Bluetooth power Short press to open Bluetooth. Indication LED on. Short press to close Bluetooth. Indication LED off. 2 Mute Short press to mute. Short press to unmute. 3 Play/Pause Short press to play music. Short press to pause music. 4 Volume down Short press to decrease volume. Long press to decreasing volume continually. 5 Volume up Short press to increase volume. Long press to increasing volume continually. 6 Last track Short press to enter last track (If music has been played for a Note: Some function on remote control may not be supported by some Bluetooth devices. You can control directly through the Bluetooth device. Product Specification Product name: Bluetooth Light Speaker Model: MG-LBTS01IR Driver unit: 1.5’’ full range driver Rated lamp power: 7W Rated speaker power: 3W with 1% THD Rated voltage: 100-240V Socket: E26 Power factor (PFC) ≥0.68 Standby power consumption ≤0.5W Rated useful luminous flux: 300lm Color temperature: 3000K Color rendering index ≥80 Product dimension (W X D X H): 2.7X2.7X3.9 in. (68X68X98mm) Remote control dimension (W X D X H): 1.6X3.4X0.3 in. (40X86X7mm) FCC Part 15 Statement 1. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC ID: Z5YMG-LBTS01IR while, it will back to beginning of the music). Long press to fast backward. 7 Next track Short press to enter next track. Long press to fast forward. 8 LED lamp Short press to adjust LED lamp brightness. Brightness has 5 levels: 0%, 25%, 50%, 75% and 100%. 9 Bluetooth pairing Short press to cut the Bluetooth connection with current Bluetooth device. Bl…
