Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
2011/11 A.06506-009-001 REV Awww.stryker.com Power-PRO™ XT Model 6506 Operations/Maintenance Manual For parts or technical assistance: USA: 1-800-327-0770 www.stryker.com6506-009-001 REV A3 Table of Contents Symbols and Definitions....................................................................6 Symbols ............................................................................6 Warning/Caution/Note Definition...........................................................7 Introduction .............................................................................8 Product Description....................................................................8 Intended Use of Product.................................................................8 Specifications ........................................................................9 Contact Information...................................................................11 Serial Number Location ................................................................11 Product Illustration....................................................................12 Summary of Safety Precautions .............................................................13 Pinch Points ........................................................................18 Setup Procedures........................................................................19 Setting Cot Load Height and “Jog” Function .................................................20 Product Inspection .......................................................................21 Cot Fastener Installation...................................................................23 Installing the In-Fastener Shut-Off ........................................................25 Vehicle Safety Hook Selection ..............................................................26 Vehicle Safety Hook Installation .............................................................27 Vehicle Configuration..................................................................27 Required Hardware for Installation of the Safety Hook (Not Supplied) ..............................27 Front to Back Positioning of the Safety Hook ................................................28 Side to Side Positioning of the Safety Hook .................................................29 Installing the Safety Hook...............................................................29 Operation Guide.........................................................................30 Operating Guidelines..................................................................30 Proper Lifting Techniques...............................................................30 Transferring the Patient to the Cot ........................................................31 Rolling the Cot.......................................................................31 Adjusting The Height of the Cot with Two Operators ...........................................32 Loading the Cot into a Vehicle with Two Operators - Powered Method..............................33 Loading the Cot into a Vehicle with Two Operators at the Foot End - Powered Method..................34 High Speed Retract/Extend .............................................................34 Loading an Empty Cot into a Vehicle with One Operator - Powered Method..........................35 Unloading the Cot from a Vehicle with Two Operators - Powered Method ...........................36 Unloading an Empty Cot from a Vehicle with One Operator - Powered Method.......................37 Using the Manual Override..............................................................38 Loading the Cot into a Vehicle with Two Operators - Manual Method...............................39 Unloading the Cot from a Vehicle with Two Operators - Manual Method............................40 Unloading an Empty Cot from a Vehicle with One Operator - Manual Method........................41 Using Additional Assistance.............................................................42 Removing and Replacing a SMRT Pak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 Using the Battery Power Indicator.........................................................44 Using the Hour Meter..................................................................45 46506-009-001 REV Awww.stryker.com Table of Contents Using Restraint Straps.................................................................46 Using the Optional Restraint Belt Extension .................................................48 Operating the Siderails.................................................................49 Operating the Backrest ................................................................49 Operating the Retractable Head Section....................................................50 Adjusting the Footrest .................................................................51 Raising and Lowering the Optional Gatch...................................................52 Operating the Optional Wheel Lock(s) .....................................................53 Operating the Optional 2-Stage I.V. Pole....................................................54 Operating the Optional 3-Stage I.V. Pole ...................................................55 Optional Accessories .....................................................................56 Using the Equipment Hook..............................................................57 Using the Retractable Head Section Oxygen Bottle Holder ......................................58 Using the Kickstand for Dialysis Scale .....................................................59 Attaching the Pedi-Mate® Infant Restraint System ............................................60 Using the Transfer Flat.................................................................62 Installing the Backrest Storage Pouch......................................................…
Text truncated - open the document above for the full version.
Medical Michael Hayes 3800 E. Centre Ave. Portage, Michigan 49002 t:(269)389-6754 [email protected] Attention: Application Examiner Re: Request for confidentiality Applicant: Stryker medical FCC ID: Z7A-6506 To whom it may concern, Permanent Confidentiality Request is hereby submitted by Stryker Medical to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts list • Internal photos (Boards are potted) Rationale for request for confidentiality: Stryker Medical has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.
Medical Michael Hayes 3800 E. Centre Ave. Portage, Michigan 49002 t:(269)389-6754 [email protected] Attention: Application Examiner Re: Authorized Representatives Applicant: Stryker medical FCC ID: Z7A-6506 To whom it may concern, Authorized Representatives I here authorize the following Stryker Medical Employees to act as a representative in the FCC filing for the following products FCC ID: Z7A-6390 FCC ID: Z7A-6506 FCC ID: Z7A-6516 Peter Schultz Senior Approvals Engineer Stryker EMS Equipment Kristin Dudek, MS, CLSSGB Regulatory Affairs Representative Business Unit Support - EMS Stryker Medical 3800 E. Centre Ave. Portage, MI 49002 t: 269.389.6927 c: 269.519.9818 [email protected]
UL 2 MIL 3M 3690-10 WHITE W/ PERMANENT ADHESIVE 1 MIL CLEAR POLYESTER, 3M FM011 SEE BASE MATERIAL 1.88 X 2.50 LABEL, FCC 6506-001-101 A.0 3.LABEL MATERIAL AND ADHESIVE SHALL BE UL RECOGNIZED (), RATED FOR 60C MINIMUM, AND ACCEPTABLE FOR APPLICATION TO STRYKER MEDICAL PRODUCT SURFACE. VENDOR SHALL AFFIX THEIR UL CONTROL NUMBER ON EACH ROLL OR PACKAGE OF LABELS DELIVERED TO STRYKER MEDICAL. XXXXX XXX 4.ALL TEXT TO BE NOT LESS THAN 1.6MM (.063 INCH) HIGH IN UPPER CASE EXCEPT THE SIGNAL WORD (WARNING, CAUTION, ETC) WHICH SHALL BE NO LESS THAN 2.8MM (.109 INCH) HIGH BOLD IN UPPER CASE LETTERS. 5.ALL TEXT TO BE NOT LESS THAN 2.4MM (.094 INCH) HIGH IN UPPER CASE EXCEPT THE SIGNAL WORD (WARNING, CAUTION, ETC) WHICH SHALL BE NO LESS THAN 2.8MM (.109 INCH) HIGH BOLD IN UPPER CASE LETTERS. NOTES: 1.GRAPHICS NOT DIMENSIONED ARE DEFINED BY THE ASSOCIATED ELECTRONIC DATA. 2.LABEL MAY BE SUPPLIED IN EITHER TAB OR ROLL FORM BUT MUST BE IDENTIFIED WITH THE STRYKER PART NUMBER AND CURRENT REVISION LEVEL. IF SUPPLIED AS AN INDIVIDUAL COMPONENT THE PART NUMBER MAY BE PRINTED ON EITHER A QUICK DETACH TAB, OR THE SCRAP AREA OF THE LABEL. THE LOCATION OF THE TAB AROUND THE PERIMETER OF THE LABEL IS AT THE SUPPLIERS DISCRETION. FOR ROLL SUPPLIED LABELS THE PART NUMBER AND REVISION MAY BE PRINTED ON THE ROLL CORE. REVISION LEVEL MUST BE UPDATED ON THE TAB, CORE, OR SCRAP AREA WITH EACH REVISION CHANGE. BLACK WHITE GRAY PANTONE 423C GREEN PANTONE 348C RED PANTONE 1797U PANTONE COOL GRAY 3U WHITE PER ES-0526 BLUE PANTONE 653C BLUE PANTONE 7462C @ 50% YELLOW PANTONE 116C COOL GRAY 11U GRAY PANTONE 430C OPAL CLEAR WHITE RED PANTONE 185 BLACK YELLOW PANTONE 116C 0.00 - X DESCRIPTION - X DESCRIPTION - X DESCRIPTION XX-XX-XX XXX - X DESCRIPTION XX-XX-XX XXX - X DESCRIPTION XX-XX-XX XXX 8765432I 8765432I D C B A D C B A 3800 E. Centre Ave. Portage, MI 49002 TITLE BASE MATERIAL: OVERLAMINATION: DO NOT SCALE FROM DRAWING REV. LABEL SPECIFICATIONS ADHESIVE: OVERALL SIZE: COLORS: DRAWING BASED ON ASME Y14.5M- 1994 KEY PRODUCT CHARACTERISTIC MINOR KPC MAJOR KPC CRITICAL KPC TOLERANCES X.XX - ± .03 X.XXX - ± .010 ANGLE - ± 1° THIRD ANGLE PROJECTION REQUIREMENTS FOR FINISHED PART UNLESS OTHERWISE SPECIFIED - DIMENSIONS SHOWN ARE IN INCHES AND ARE FOR INSPECTION PURPOSES ONLY. THIS DRAWING CONTAINS CONFIDENTIAL INFORMATION AND IS ISSUED IN CONFIDENCE ON CONDITION THAT IT WILL BE RETURNED ON DEMAND AND NOT COPIED, REPRODUCED, DISCLOSED TO OTHERS OR USED IN THE MANUFACTURE OF THE SUBJECT MATTER THEREOF WITHOUT THE WRITTEN CONSENT OF THE STRYKER CORPORATION. PART NUMBER: SHEET: 1 OF 1 SIZE ZONE REVDESCRIPTION DATE BY REVISION HISTORY B F M - 6 0 2 R e v . B MEDICAL COLOR PALETTE THE STRYKER LOGO MAY ONLY BE FILLED IN BLACK, WHITE, OR PMS 423 GRAY. R LOGOS AND ICONS CAUTION SINGLE USE MANUFACTURER DATE OF MANUFACTURE RECYCLE SERIAL NUMBER CATALOGUE NUMBER CE MARK INSTRUCTIONS FOR USE BATCH CODE AUTHORIZED EUROPEAN REP USE BY SHOCK HAZARD MAX WEIGHT ON A SURFACE MAX WEIGHT UL MARK IPX 4 MARK IPX 5 MARK TEMPERATURE LIMITATION HUMIDITY LIMITATION REGISTERED COMPONENT MADE IN THE USA STRYKER LOGOSTRYKER LOGO WITH “R” REVISION HISTORY DIMENSIONS AND LEADERS NOTES OXYGEN WARNING STANDARD WARNING FLAG UL MATERIAL AND ADHESIVE CALLOUT - A INITIAL RELEASE 10-27-11 BDN BLUE PANTONE 654C EMS COLOR PALETTE 5 ECREP 0% 100% LOT 2 R 104 F o (40 C) o -4 F o (-20 C) o Made in the U.S.A. R Model 6506 IC: 4919E-6506 FCC ID: Z7A-6506 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 3.SUPPLIER TO PROVIDE CERTIFICATION THAT PART IS REACH COMPLIANT PER ES-0604 WITH FIRST ARTICLE SUBMISSION. 4. SUPPLIER TO PROVIDE CERTIFICATION THAT PART IS ROHS COMPLIANT PER ES-0520 WITH FIRST ARTICLE SUBMISSION.
This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Emissions Report for Stryker Medical on the POWER-LOAD System Page 1 of 41 EMISSIONS TEST REPORT Report Number: 100514149BOX-002c Project Number: G100514149 Report Issue Date: 10/14/2011 Product Designation: Cot Transmitter and Receiver in POWER-LOAD System Standards: CFR47 FCC Part 15:2011 Subpart C Section 15.225, Industry Canada RSS-210 Issue 8 December 2010, Annex 2 (A2.6) Industry Canada RSS-Gen Issue 3 December 2010 Tested by: Client: Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 Stryker Medical 3800 E. Centre Avenue Portage, MI 49002 Report prepared by Report reviewed by Kouma Sinn / Senior Project Engineer Michael F. Murphy / EMC Staff Engineer Intertek Report Number: 100514149BOX-002c Issued: 10/14/2011 Emissions Report for Stryker Medical on the POWER-LOAD System Page 2 of 41 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 3.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. 2 Test Summary Section Test full name Result 3 Client Information -- 4 Description of Equipment Under Test -- 5 System Setup and Method -- 6 Fundamental Radiated Emissions FCC Part 15:2011 Subpart C 15.225(a), (b), (c), (d) IC RSS-210 Issue 8 December 2010 A2.6 (a), (b), (c), (d) Pass 7 Transmitter Spurious Emissions Below 30MHz FCC Part 15:2011 Subpart C 15.209, 15.225(d), IC RSS-210 Issue 8 December 2010 A2.6(d) Pass 8 Transmitter Spurious Emissions Above 30MHz FCC Part 15:2011 Subpart C 15.209, 15.225(d), IC RSS-210 Issue 8 December 2010 A2.6(d) Pass -- Receiver Spurious Emissions Below 30MHz FCC Part 15:2011 Subpart B 15.109, IC RSS-Gen Issue 3 December 2010: Section 6.0 N/A* 9 Receiver Spurious Emissions Above 30MHz FCC Part 15:2011 Subpart B 15.109, IC RSS-Gen Issue 3 December 2010: Section 6.0 Pass 10 20dB Bandwidth FCC Part 15:2011 Subpart C 15.215 IC RSS-Gen Issue 3 December 2010 Section 4.6 Pass 11 Frequency Stability FCC Part 15:2011 Subpart C 15.225(e), IC RSS-Gen Issue 3 December 2010 Section 4.7 IC RSS-210 December 2010 A2.6 Pass 12 Revision History -- * - no limits below 30 MHz Intertek Report Number: 100514149BOX-002c Issued: 10/14/2011 Emissions Report for Stryker Medical on the POWER-LOAD System Page 3 of 41 3 Client Information This EUT was tested at the request of: Company: Stryker Medical 3800 E. Centre Avenue Portage, MI 49002 Contact: Mr. Peter Schultz Telephone: (269) 488-6415 Fax: (269) 329-2260 Email: [email protected] 4 Description of Equipment Under Test Equipment Under Test Description Manufacturer Model Number Serial Number Cot (Transmitter) Stryker Medical 6506 45305031 Cot (Receiver) Stryker Medical 6506 45305229 Cot (Un-modulated) Stryker Medical 6506 45305067 Receive Date: 10/03/2011 Received Condition: Good Type: Production Description of Equipment Under Test (provided by client) The Power-LOAD ambulance cot fastener is a new product designed to reduce EMT workload by eliminating the need to lift a cot into the back of the ambulance. The EUT consists of the Power-Pro XT(cot), Model 6506. The cot is a gurney which contains a 13.56 MHz transceiver for communication to the Load portion of the Power-Load System. The antenna is integral. Equipment Under Test Power Configuration Rated Voltage Rated Current Rated Frequency Number of Phases 24VDC (Internal Battery) 78A DC DC Operating modes of the EUT: No. Descriptions of EUT Exercising 1 During testing, the 13.56 MHz transmitter was operating as near to continuously as possible, except in receive mode where the transmitter was idle and waiting for messages. A modulated carrier was used, except for frequency stability testing where an un-modulated carrier generated by a standalone comm. board was used. Intertek Report Number: 100514149BOX-002c Issued: 10/14/2011 Emissions Report for Stryker Medical on the POWER-LOAD System Page 4 of 41 5 System Setup and Method Cables ID Description Length (m) Shielding Ferrites Termination None Support Equipment Description Manufacturer Model Number Serial Number None 5.1 Method: Configuration as required by ANSI C63.4-2003 5.2 EUT Block Diagram: Intertek Report Number: 100514149BOX-002c Issued: 10/14/2011 Emissions Report for Stryker Medical on the POWER-LOAD System Page 5 of 41 6 Fundamental Frequency Radiated Emissions 6.1 Method Tests are performed in accordance with FCC Part 15:2011 Subpart C 15.225(a), (b), (c), (d), IC RSS-210 Issue 8 December 2010 A2.6 (a), (b), (c), (d), ANSI C63.4-2003. TEST SITE: 10m ALSE The 10m ALSE is 13m (Length) x 21m (Depth) …
Text truncated - open the document above for the full version.
Intertek Report Number: 100514149BOX-002c Issued: 10/14/2011 Emissions Report for Stryker Medical on the POWER-LOAD System Page 8 of 41 6.4 Setup Photographs: Fundamental and Offset Frequencies Test Setup Photo # 1 Intertek Report Number: 100514149BOX-002c Issued: 10/14/2011 Emissions Report for Stryker Medical on the POWER-LOAD System Page 9 of 41 Fundamental and Offset Frequencies Test Setup Photo # 2
3800 E. Centre Avenue · Portage, Michigan · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 13.56 MHz - 13.56 MHz | - |

AMS-R2X
Equipment Class
DTS - Digital Transmission SystemPower-PRO IT
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
Power-LOAD
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
