Z7RBBALBLUETOOTH SPEAKER

QUICK START GUIDE BALANCE 2 3 Full manual and troubleshooting: braven.com/manuals ENG GET TO KNOW YOUR BRAVEN BATTERY INDICATOR LIGHTS POWER SWITCH BATTERY CHECK BUTTON PAIRING / ANSWER-END CALL / PAUSE-RESUME MUSIC POWER / PAIRING STATUS LIGHT BRAVEN CHARGING PORT VOLUME UP / SKIP TRACK (press and hold) EXTERNAL USB CHARGING PORT RESET BUTTON VOLUME DOWN / SKIP BACK (press and hold) 3.5 MM AUDIO-IN JACK 20% - 40% - 60% - 80% - 100% TURN ON & BLUETOOTH PAIRING 1. Press the Power button for 2-3 seconds to turn on your BRAVEN (BALANCE). Press the same button again for 2-3 seconds to turn your BRAVEN off. 2. Activate Bluetooth ® on the phone or device you are pairing with (see your device’s instruction manual for information on activating its Bluetooth ® settings). 3. Press and hold the Play Button on your BRAVEN until you hear the BRAVEN pairing sound. 4. Go to your phone or device’s Bluetooth ® settings and select “BRAVEN BALANCE” from the list. 5. If asked for a passcode enter “0000” Your BRAVEN will remember the last 8 devices it has paired with. NOTE: If your BRAVEN does not have an active Bluetooth ® connection and is left on, it will shut itself off after 30 minutes. To restart your BRAVEN you will need to press and hold the power button for 2-3 seconds. 4 5 Full manual and troubleshooting: braven.com/manuals ENG CHARGING YOUR BRAVEN • Before using your BRAVEN for the first time, charge the unit until all 5 Battery Capacity lights are solid (not flashing), indicating a full charge (typically 2 to 3 hours). • To charge your BRAVEN, plug the included USB-to-Micro-USB cable into a wall power adapter (not included) or into a powered USB port on a computer. Plug the Micro-USB connector end of the cable into the BRAVEN charging port. Your BRAVEN is designed to charge USB devices that draw from 0.3A - 1A (most cell phones & mp3 players – tablets and other 2A devices cannot be charged by your BALANCE) using the full-sized USB port located behind the cap. To use external charging: 1. Turn your BRAVEN on. 2. Plug the USB power cable that came with your phone, mp3 player, or other mobile device into the USB port on your BRAVEN. 3. Plug the other end of the cable into your mobile device, and it will immediately begin charging. CHARGING EXTERNAL DEVICES SPEAKERPHONE • Press the Answer-End button on your BRAVEN to answer the call over the speaker. Press the Answer-End button again to end the call. • The BALANCE is IPX7 Waterproof, and is designed to withstand rainfall, water jets, and water splashing. • IMPORTANT - To ensure your BRAVEN BALANCE speaker is prepared for use in a wet environment, remove all cable connections and tightly close the rear water cap. If the water cap is not properly closed, the BALANCE will not be water resistant. WATERPROOF FEATURES 6 7 Full manual and troubleshooting: braven.com/manuals ENG WARNINGS, CAUTIONS & LEGAL INFORMATION To reduce the risk of fire or electric shock, do not expose the BRAVEN to rain or moisture while charging. The BRAVEN should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on or near it while being charged or charging other devices. As with any electronic products, use care not to spill liquids into any part of the product. Liquids can cause a failure and/or a fire hazard. The power supply must be used indoors only. Make no modifications to the product or accessories. Unauthorized alterations may compromise safety, regulatory compliance, and system performance, and will void the warranty. Do not place any flame sources, such as lighted candles, on or near the BRAVEN. The BRAVEN contains small parts that may be a choking hazard and is not suitable for children under age 3. Do not continue charging the battery if it does not reach full charge within the specified charging time. Overcharging may cause the battery to become hot, rupture, or ignite. If you see any heat deformation or leakage, properly dispose of the battery. Do not attempt to charge the battery in temperatures outside the range of 32°-104°F (0°-40°C). If the battery begins to leak, do not allow the liquid to come in contact with your skin or eyes. If contact has been made, wash the affected area with plenty of water and seek medical attention immediately. Do not expose the product or battery to excessive heat, including direct sunlight or fire and storage or use inside cars in hot weather, where it can be exposed to temperatures in excess of 115°F (60°C). Doing so may cause the battery and power supply to generate heat, rupture, or ignite. Using the product in this manner also may result in a loss of performance and a shortened life expectancy. Extended exposure to direct sunlight may damage the external appearance and material qualities. Do not step on, throw, or drop batteries or the power supply or device, or expose them to a strong shock. Do not pierce, crush, dent, or deform the batteries or power supply in any way. If either becomes deformed, properly dispose of it. Do not short-circuit batteries. Do not attempt to service the BRAVEN yourself. Opening or removing covers may expose you to dangerous voltages or other hazards and will void the manufacturer’s warranty. To prevent risk of fire or electric shock, avoid overloading wall outlets, extension cords, or integral convenience receptacles. Your Bluetooth device (mobile phone, music player, tablet, laptop, etc.) must support the A2DP Bluetooth profile in order to work wirelessly with your new BRAVEN speaker. The A2DP profile is supported by most recent mobile products with built-in Bluetooth capability. Please refer to your device’s user manual for details and instruction regarding the Bluetooth profiles it supports. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interfer ence received, including interference that may ca…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 1 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Braven LC 2015-3-2 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Braven LC hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): BLUETOOTH SPEAKER, BALANCE FCC ID: Z7RBBAL Sincerely, signature Erik Sorenson/COO E-mail: [email protected] Phone: 801-669-5915 Fax: 949-250-4928 Address: 6001 Oak Canyon, Irvine, California92618, United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Braven LC 2015-3-2 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: Z7RBBAL We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature Erik Sorenson/COO E-mail: [email protected] Phone: 801-669-5915 Fax: 949-250-4928 Address: 6001 Oak Canyon, Irvine, California92618, United States

front Screen pri nt / Pad Print in cool grey 8 C on Black versions. BALANCE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B)/NMB-3(B) FCC ID: Z7RBBALIC: 10013A-BAL

Bluetooth module BluetoothAntenna

FCC ID: Z7RBBAL Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculated. Maximum measured transmitter power: Transmit Frequency (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune-up power(dBm) Result calculation 1-g SAR 2.402 GFSK -0.806 0±1 1 0.3902 3.00 2.441 GFSK -0.683 0±1 1 0.3933 3.00 2.480 GFSK -0.707 0±1 1 0.3965 3.00 2.402 π/4-DQPSK 0.349 0±1 1 0.3902 3.00 2.441 π/4-DQPSK 0.484 0±1 1 0.3934 3.00 2.480 π/4-DQPSK 0.452 0±1 1 0.3965 3.00 2.402 8-DPSK 0.835 0±1 1 0.3902 3.00 2.441 8-DPSK 0.930 0±1 1 0.3934 3.00 2.480 8-DPSK 0.842 0±1 1 0.3965 3.00 Conclusion: For the max result 0.3965≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Sincerely, Signature Company Name: SHENZHEN EMTEK CO., LTD. Address: Bldg 69, Majialong Industry Zone, NanshanDistrict, Shenzhen, China. David Lee/ Manager

TRF No.:FCC 15.247/A Page 1 of 67 Report No.: ES141230399E Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For BLUETOOTH SPEAKER MODEL No.: BALANCE FCC ID: Z7RBBAL BRAND NAME: N/A REPORT NO.: ES141230399E ISSUE DATE: March 31, 2015 Prepared for BRAVEN LC. 6001 Oak Canyon, Irvine, California92618, United States Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 67 Report No.: ES141230399E Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION .......................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................................ 4 3 SUMMARY OF TEST RESULT ............................................................................................................................. 6 4 TEST METHODOLOGY ........................................................................................................................................ 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................................... 7 4.2 MEASUREMENT EQUIPMENT USED ..................................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ............................................................................................................. 7 5 FACILITIES AND ACCREDITATIONS ................................................................................................................. 9 5.1 FACILITIES ................................................................................................................................................. 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS .............................................................................. 9 6 TEST SYSTEM UNCERTAINTY ......................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................................. 11 7.1 RADIO FREQUENCY TEST SETUP 1 ..................................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ..................................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................................. 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ................................................................. 13 7.5 SUPPORT EQUIPMENT ........................................................................................................................... 13 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ..................................................................................... 14 8.1 STA N D A R D APPLICABLE .............................................................................................................................. 14 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ........................................................................... 14 8.3 EQUAL HOPPING FREQUENCY USE .............................................................................................................. 15 8.4 FREQUENCY HOPPING SYSTEM .................................................................................................................... 15 9 TEST REQUIREMENTS ...................................................................................................................................... 16 9.1 20DB BANDWIDTH ................................................................................................................................. 16 9.2 CARRIER FREQUENCY SEPARATION .................................................................................................. 22 9.3 NUMBER OF HOPPING FREQUENCIES ............................................................................................... 28 9.4 AV E R A G E TIME OF OCCUPANCY (DWELL TIME) ............................................................................. 30 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................................ 33 9.6 CONDUCTED SUPRIOUS EMISSION .................................................................................................... 39 9.7 RADIATED SPURIOUS EMISSION ......................................................................................................... 46 9.8 CONDUCTED EMISSION TEST .............................................................................................................. 62 9.9 ANTENNA APPLICATION ....................................................................................................................... 67 TRF No.:FCC 15.247/A Page 3 of 67 Report No.: ES141230399E Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: BRAVEN LC. 6001 Oak Canyon, Irvine, California92618, United States Manufacturer: SHENZHEN FENDA TECHNOLOGY CO., LTD. Fenda Hi-Tech Park, Zhoushi Road, Shiyan Town, Baoan District, Shenzhen City, Guangdong, China Product Description: BLUETOOTH SPEAKER Model Number: BALANCE File Number: ES141230399E Date of Test: January 4, 2015 to January 26, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by th…
