Z87ABBAM115MOBILE PHONE

1 User’s Manual of M115 Mobile Phone 2 TABLE OF CONTENT 1. BASIC INFORMATION....................8 1.1. BRIEF INTRODUCTION........................................... 8 1.2. SAFETY NOTICE.................................................... 9 1.3. SAFETY ALERT AND CAUTIONS........................... 10 1.3.1. General Cautions......................................... 10 1.3.2. Cautions of Using the Phone....................... 12 1.3.3. Cautions of Using the Battery..................... 14 1.3.4. Cautions of Using the Charger.................... 16 1.3.5. Cleaning and Maintenance.......................... 18 2. BEFORE USE....................................18 2.1. NAME AND EXPLANATION OF EACH PART........... 18 2.1.1. Technical Parameters ..错误 错误错误 错误！ ！！ ！未定义书签 未定义书签未定义书签 未定义书签。 。。 。 2.1.2. Appearance Sketch Map (the picture is only for your reference) .................................................... 18 2.1.3. Description of the Standby Pictures (the 3 picture is only for your reference) ............................ 19 2.1.4. Description of Keys .................................... 23 2.2. INSTALL SIM CARD AND MEMORY CARD........... 24 2.2.1. SIM Card..................................................... 24 2.2.2. Inserting and Taking out SIM Card ............ 25 2.2.3. Memory Card .............................................. 26 2.3. BATTERY............................................................ 26 2.3.1. Install the Battery........................................ 26 2.3.2. Charging...................................................... 27 2.4. SECURITY PASSWORD......................................... 28 3. QUICK USER GUIDE.....................29 3.1. FEATURE FUNCTIONS............................................. 29 3.2. FUNCTION HOT KEY............................................... 32 3.3. DIAL A CALL....................................................... 32 3.4. REJECT A CALL...................................................33 3.5. RECEIVE A CALL................................................. 33 3.6. END A CALL........................................................ 34 3.7. EMERGENCY SERVICES....................................... 34 3.8. EXTENSION SPEED DIAL..................................... 34 3.9. DIALED CALLS/MISSED CALLS/RECEIVED CALLS/REJECTED CALLS.............................................. 34 4 3.10. CALL FORWARD.................................................. 35 3.11. CALL WAITING...................................................35 3.12. CALL BARRING...................................................35 3.13. POWER OFF THE PHONE...................................... 35 4. FUNCTION MENU..........................36 4.1. STRUCTURE OF FUNCTION MENU....................... 36 4.2 CALL LOGS........................................................ 39 4.2.1 Dialed calls ................................................. 39 4.2.2 Received calls ............................................. 40 4.2.3 Missed calls................................................. 40 4.2.4 Rejected calls .............................................. 41 4.2.5 Delete All: ................................................... 41 4.2.6 Call timer .................................................... 41 4.2.7 Call costs ..................................................... 41 4.2.8 GPRS counter.............................................. 42 4.3 CONTACTS............................................................ 42 4.3.1 New............................................................. 43 4.3.2 Search ......................................................... 43 4.3.3 Write Message .............................................. 43 4.3.4. Call ................................................................. 43 4.3.5. Delete.............................................................. 44 5 4.3.76 Mark .............................................................. 44 4.3.7. Copy ............................................................... 44 4.3.8. Others ............................................................. 44 4.4 INTERNET........................................................... 45 4.4.1 open .......................................................... 46 4.4.2 Current page................................................ 46 4.4.3 send connection ............................................ 47 4.4.4 Bookmarks.................................................... 47 4.4.5 History......................................................... 47 4.4.6 Offline pages ............................................... 48 4.4.7 Tools ........................................................... 48 4.4.8 Eixt ............................................................... 49 4.5 MULTIMEDIA..................................................... 50 4.5.1 TV............................................................. 50 4.5.2 Audio Player ............................................... 50 4.5.3 Video Player................................................ 52 4.5.4 FM radio...................................................... 52 4.5.5 Digital video................................................ 53 4.5.6 Recorder ...................................................... 54 4.5 MESSAGE............................................................ 54 4.5.2 Write Message ............................................ 54 4.5.3 Inbox ........................................................... 57 4.5.4 Outbox......................................................... 58 6 4.5.5 Sentbox ....................................................... 59 4.5.6 Templates .................................................... 60 4.5.7 Voice Mail server........................................ 60 4.5.8 Message Settings......................................... 61 4.5.9 Message capacity ........................................ 65 4.6 TOOLS................................................................ 65 4.6.2 Alarm .............................…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 ABBA INNOVATION S.A.S (2012/9/29) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ABBA INNOVATION S.A.S hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Mobile Phone Trade name: GIGO yaddas rewell Sumtech Model name: M115,H100, m115,s20 and k55 FCC ID:Z87ABBAM115 We affirm that between SIEMIC and ABBA INNOVATION S.A.S, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Printed name/title: Ernesto .Sequera /General manager Tel: 57-5-3608855 Fax: 57-5-3608855 Address: CALLE 76 N52-40, Local , Alto Prado,1BARRANQUILLACITY, COLOMBIA

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 ABBA INNOVATION S.A.S (2012/9/29) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: Z87ABBAM115 We hereby request confidential treatment of information accompanying this application as outlined below: - 1.Block Diagram - 2. Schematics - 3. Operational Description - 4. Tune up Procedure - 5.BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Printed name/title: Ernesto .Sequera /General manager Tel: 57-5-3608855 Fax: 57-5-3608855 Address: CALLE 76 N52-40, Local , Alto Prado,1BARRANQUILLACITY, COLOMBIA

ABBA INNOVATION S.A.S To：SIEMIC , 775 Montague Expressway , Milpitas, CA 95035 USA Declaration letter Dear Sir， For our business issue and marketing requirement, we would like to list different models numbers on the FCC certificates and reports, as following: Model No.: M115, H100, m115,s20 and k55 We declare that there is no electrical change has been made to the equipment that alters the compliance characteristics. The difference of these different models is for different Color. Please kindly handle on the project. Thank you! Signature: Printed name: Ernesto. Sequera

Annex B. EUT External Photo EUT all Package - Front View EUT - Front View EUT - Rear View EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

LABEL LOCATION

Annex B. EUT Internal Photo Cover Off - Bottom View Cover Off - Top View LCD - Top View LCD - Bottom View Uncover - Top View Uncover - Bottom View Uncover without LCD - Top View Uncover Without Shielding - Top View GSM Antenna - Top View BT Antenna - Top View GSM Antenna BT Antenna

ABBA INNOVATION S.A.S Mobile Phone Model: M115 Serial Model: H100, m115, s20, k55 Sep 28 th , 2012 Report No.: 12070198-FCC-H (This report supersedes NONE) This Test Report is Issued Under the Authority of: Chris You Test Engineer Alex Liu Technical Manager Modifications made to the product : None This test report may be reproduced in full only. All Test Data Presented in this report is only applicable to presented Test sample. Title: RF Test Report of Mobile Phone Model : M115 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C, IEC62209-2 & RSS-102 Issue 4 and Safety Code 6 Serial# 12070198-FCC-H Issue Date Sep 28th, 2012 Page 2 of 99 www.siemic.com Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB, NIST EMC,RF,Safety,Telecom Title: RF Test Report of Mobile Phone Model : M115 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C, IEC62209-2 & RSS-102 Issue 4 and Safety Code 6 Serial# 12070198-FCC-H Issue Date Sep 28th, 2012 Page 3 of 99 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Mobile Phone Model : M115 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C, IEC62209-2 & RSS-102 Issue 4 and Safety Code 6 Serial# 12070198-FCC-H Issue Date Sep 28th, 2012 Page 4 of 99 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .............................................................................................................. 6 2 TECHNICAL DETAILS ................................................................................................................................................... 7 3 INTRODUCTION ........................................................................................................................................................... 8 4 SAR MEASUREMENT SETUP ....................................................................................................................................... 9 5 ANSI/IEEE C95.1 – 1999 RF EXPOSURE LIMIT ............................................................................................................ 20 6 SYSTEM AND LIQUID VALIDATION ............................................................................................................................ 21 7 UNCERTAINTY ASSESSMENT .................................................................................................................................... 28 8 OUTPUT POWER VERIFICATION ................................................................................................................................ 30 9 SAR TEST RESULTS .................................................................................................................................................. 32 10 SAR MEASUREMENT REFERENCES .......................................................................................................................... 35 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................................ 60 ANNEX B CALIBRATION REPORTS .................................................................................................................................. 61 ANNEX C SAR SYSTEM PHOTOGRAPHS .......................................................................................................................... 94 ANNEX D SETUP PHOTOGRAPHS .................................................................................................................................... 95 Title: RF Test Report of Mobile Phone Model : M115 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C, IEC62209-2 & RSS-102 Issue 4 and Safety Code 6 Serial# 12070198-FCC-H Issue Date Sep 28th, 2012 Page 5 of 99 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Mobile Phone Model : M115 To C95.1, IEEE 1528, OET Bulletin 65 Supplement C, IEC62209-2 & RSS-102 Issue 4 and Safety Code 6 Serial# 12070198-FCC-H Issue Date Sep 28th, 2012 Page 6 of 99 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programmed was to demonstrate compliance of the ABBA INNOVATION S.A.S. Model: M115 against the current Stipulated Standards. The Mobile Phone have demonstrated compliance with the C95.1, IEEE 1528, OET Bulletin 65 Supplement C , IEC62209-2, RSS-102 Issue 4 and Safety Code 6. The test has demonstrated that this unit complies with stipulated standards. EUT Information EUT Description : Mobile Phone Model No : M115, H100, m115,s20, k55 Input Power : Li-ion Battery Charging Voltage:3.7V 800mAh Charge Cut-off Voltage: 4.2 V Maximum Output Power to Antenna : Cellular 850(Class 4) : 1.614 W (32.08dBm) PCS1900 (Class 1) : 0.752 W …

Text truncated - open the document above for the full version.

ABBA INNOVATION S.A.S Mobile Phone Main Model: M115 Serial Model: H100, m115, s20, k55 25th Sep, 2012 Report No.: 12070198-FCC-R1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Back Huang Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for Mobile Phone Main Model: M115 Serial Model: H100, m115, s20, k55 To: FCC Part 22(H) & FCC Part 24(E): 2011 Report No: 12070198-FCC-R1 Issue Date: 25th Sep, 2012 Page: 2 of 37 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Test Report for Mobile Phone Main Model: M115 Serial Model: H100, m115, s20, k55 To: FCC Part 22(H) & FCC Part 24(E): 2011 Report No: 12070198-FCC-R1 Issue Date: 25th Sep, 2012 Page: 3 of 37 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for Mobile Phone Main Model: M115 Serial Model: H100, m115, s20, k55 To: FCC Part 22(H) & FCC Part 24(E): 2011 Report No: 12070198-FCC-R1 Issue Date: 25th Sep, 2012 Page: 4 of 37 www.siemic.com.cn CONTENTS 1. EXECUTIVE SUMMARY & EUT INFORMATION ........................................................................................... 5 2. TECHNICAL DETAILS .......................................................................................................................................... 6 3. MODIFICATION ..................................................................................................................................................... 7 4. TEST SUMMARY .................................................................................................................................................... 8 5. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ................................................................... 9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................ 29 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 32 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 33 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................ 36 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 37 Title: RF Test Report for Mobile Phone Main Model: M115 Serial Model: H100, m115, s20, k55 To: FCC Part 22(H) & FCC Part 24(E): 2011 Report No: 12070198-FCC-R1 Issue Date: 25th Sep, 2012 Page: 5 of 37 www.siemic.com.cn 1. EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programmed was to demonstrate compliance of the ABBA INNOVATION S.A.S Mobile Phone and model: M115 against the current Stipulated Standards.The Mobile Phone has demonstrated compliance with the FCC Part 22(H) & FCC Part 24(E): 2011. EUT Information EUT Description : Mobile Phone Main Model : M115 Serial Model : H100, m115, s20, k55 Antenna Gain : GSM850: 1 dBi PCS1900: 1 dBi Bluetooth: 1 dBi Input Power : Power Adapter: Model: JDB0507 Input: AC100-240V 50/60Hz 0.15A Output: DC5.0V-700mA Li-ion Rechargeable Battery Model : BL-4B Charging Voltage:3.7V 2800 mAh Maximum Conducted Peak Power to Antenna : GSM850: 32.08 dBm PCS1900: 28.76 dBm Maximum Radiated ERP/EIRP : GSM850: 30.08 dBm / ERP PCS1900: 27.02 dBm / EIRP Classification Per Stipulated Test Standard : FCC Part 22(H) & FCC Part 24(E): 2011 Note1: In this report, we have chosen the main model M115 for testing. Note2: The differences between main model M115 and series model H100, m115, s20, k55 in this report is the appearance of color. Title: RF Test Report for Mobile Phone Main Model: M115 Serial Model: H100, m115, s20, k55 To: FCC Part 22(H) & FCC Part 24(E): 2011 Report No: 12070198-FCC-R1 Issue Date: 25th Sep, 2012 Page: 6 of 37 www.siemic.com.cn 2. TECHNICAL DETAILS Purpose Compliance testing of Mobile Phone with stipulated standard Applicant / Client ABBA INNOVATION S.A.S Calle 76 NO. 52-40 Local 1, Alto Prado, Barranquilla, Colombia Manufacturer sumtech industry development co limited Room521 Sanjiu Hotel,No.1001 Shennan East Road,Luohu District,Shenzhen,China Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China T…

Text truncated - open the document above for the full version.

Annex B. Test Setup Photo Radiated Emissions Test Setup Below 1GHz - Front View Radiated Emissions Test Setup Above 1GHz - Front View
