Z8VF-208AFM Transmitter

DAZA Electronics Company
FM Transmitter - FCC ID Z8VF-208A - DAZA Electronics Company
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Nov 07, 2013
Application Purpose
Original Equipment
Date of Application
Nov 07, 2013
Equipment Note
FM Transmitter
Frequency Range
88.10000000 - 107.90000000
Company
DAZA Electronics Company
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

ID Label/Location Info

↗
↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

88.1 107.9 12V 88.1-107.9MHz 88.1-107.9MHz FCC STATEMENT 1.This device complies with Part 15 or the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 or the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --- Reorient or relocate the receiving antenna. --- Increase the separation between the equipment and receiver. --- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --- Consult the dealer or an experienced radio/ TV technician for help.

Cover Letter(s)

DAZA Electronics Company October 29, 2013 To: SIEMIC, INC. 775 Montague Expressway Milpitas , CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ DAZA Electronics Company ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: Fm transmitter Model name: F-208A(MSF11) FCC ID: Z8VF-208A We affirm that between SIEMIC and __ DAZA Electronics Company ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title: Yu Zhou / Engineer Contact information / address: Bldg G, Xinmusheng Low Carbon Industrial Park, NO.6 Xinmu Road Pinghu, Shenzhen, China

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 DAZA Electronics Company October 29, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: Z8VF-208A We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title: Yu Zhou / Engineer Contact information / address: Bldg G, Xinmusheng Low Carbon Industrial Park, NO.6 Xinmu Road Pinghu, Shenzhen, China

Cover Letter(s)

Accurate Technology Co., Ltd. Address: F1, Bldg. A&D, Changyuan New Material Port, Keyuan Rd., Science & Industry Park, Nanshan District, Shenzhen 518057 , P. R. China Tel: +86-755-26503290 Fax: +86-755-26503396 E-mail: [email protected] Http://www.atc-lab.com FCC ID: Z8VF-208A Model No.: F-208A(MSF11) 1) How does this device operate? This device is a FM stereo transmitting configuration, which radiates FM wave on the air by modulating the any required signal to the carrier signal. The transmission frequency is set from 88.1 to 107.9MHz (step freq.:0.2MHz) This product can be powered by an DC to DC regulator within the cigarette-lighter adapter. 2) Provide information on the device and its antenna. This product is designed to transmits audio signal from iPod and USB memory disk. external audio player to car stereo. The transmitter utilizes dipole antenna. The antenna was soldered to PCB. 3) How is it installed? The transmitter is powered from 12V in car. It can be connected to the car power socket outlet only 4) What test procedure was used? Operating condition is according to ANSI C63.4-2009 5) If tested in a car, how was it configured/tested? Not tested in a car, it was tested in a chamber. 6) Was the tuning range properly verified? The test lab should indicate in the report that the tuning controls were manually adjusted to verify maximum tuning range. EUT was adjusted to work at the selected channels: 88.1 MHz, 98.1 MHz, and 107.9 MHz. The EUT will not allow operation below 88.1 MHz and will not allow operation above 107.9 MHz. Press the “frequency +/- button” key to select the transmission frequency. We have indicated the testing in the test report, see clause 7. 7) Was the bandwidth properly tested with maximum audio input? The test was performed with playing typical audio signal with a 2.5 kHz tone at a level 16 dB higher than that required to produce a frequency deviation of 75 kHz. We have indicated the operating condition in the test report, see clause 6.3. 8) Provide the test report. Test Report Submitted. signature : name :Sean Liu Title: Manager Telephone: 008675526503290 Email:[email protected] Date: 2013-3-15

ID Label/Location Info

FCC Certification label Sample FCC ID: Z8VF-208A DAZA Electronics Company MODEL NO.: F-208A(MSF11) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

ID Label/Location Info

FCC Certification Label Location Sample Label location

Internal Photos

Antenna

Test Report

Page 1 of 82 FCC ID: Z8VF-208A ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20132273 FCC CERTIFICATION On Behalf of DAZA Electronics Company Fm transmitter Model No.: F-208A(MSF11) FCC ID: Z8VF-208A Prepared for : DAZA Electronics Company Address : Bldg G, Xinmusheng Low Carbon Industrial Park, NO.6 Xinmu Road Pinghu, Shenzhen, China Prepared by : Accurate Technology Co., Ltd. Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20132273 Date of Test : October 25, 2013 Date of Report : October 29, 2013 Page 2 of 82 FCC ID: Z8VF-208A ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20132273 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Accessory and Auxiliary Equipment ........................................................................................................4 1.3. Description of Test Facility ......................................................................................................................5 1.4. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. SUMMARY OF TEST RESULTS................................................................................................... 7 4. HARMONICS AND SPURIOUS RADIATED EMISSION AND BAND EDGE FOR FCC PART 15 SECTION 15.239(C) ................................................................................................................. 8 4.1. Block Diagram of Test Setup....................................................................................................................8 4.2. The Emission Limit for section 15.239(c) ................................................................................................9 4.3. Configuration of EUT on Measurement ...................................................................................................9 4.4. Operating Condition of EUT ..................................................................................................................10 4.5. Test Procedure ........................................................................................................................................10 4.6. The Field Strength of Radiation Emission Measurement Results ..........................................................11 5. FUNDAMENTAL RADIATED EMISSION FOR FCC PART 15 SECTION 15.239(B) ........ 20 5.1. Block Diagram of Test Setup..................................................................................................................20 5.2. The Emission Limit For Section 15.239(b) ............................................................................................20 5.3. EUT Configuration on Measurement .....................................................................................................21 5.4. Operating Condition of EUT ..................................................................................................................21 5.5. Test Procedure ........................................................................................................................................21 5.6. The Emission Measurement Result ........................................................................................................22 6. OCCUPIED BANDWIDTH FOR FCC PART 15 SECTION 15.239(A) ................................... 31 6.1. The Requirement For Section 15.239(a).................................................................................................31 6.2. EUT Configuration on Measurement .....................................................................................................31 6.3. Operating Condition of EUT ..................................................................................................................32 6.4. Test Procedure ........................................................................................................................................32 6.5. Test Result ..............................................................................................................................................33 7. TUNING RANGE ........................................................................................................................... 34 7.1. The Requirement For Section 15.239 .....................................................................................................34 7.2. EUT Configuration on Measurement .....................................................................................................34 7.3. Operating Condition of EUT ..................................................................................................................34 7.4. Test Procedure ........................................................................................................................................34 7.5. Test Result ..............................................................................................................................................35 8. ANTENNA REQUIREMENT........................................................................................................ 36 8.1. The Requirement ....................................................................................................................................36 8.2. Antenna Construction .............................................................................................................................36 Page 3 of 82 FC…

Text truncated - open the document above for the full version.

Test Setup Photos

Radiated emissions test

Contact Information

Applicant

Yu Zhou(Engineer)
[email protected]0755-36615522Fax: 0755-84528100

Test Firm

Accurate Technology Co., Ltd.Sean Liu
[email protected]86-755-26503291Fax: 86-755-26503396

Technical Specifications

#Rule PartsFrequency RangePower Output
115C88.1 MHz - 107.9 MHz-
