Z9O-92053073HHCM915 Badge Configuration POD

© 2020 Ecolab USA Inc. All rights reserved. All trademarks are the property of their respective owners. Ecolab ® Hand Hygiene Program Compliance Monitoring System Badge Configuration POD & Badge Programming Software, Directions for Use (9205-3073) 1 Table of Contents 1. The Ecolab Badge Programming POD and Badge Programming POD Application Software ......................................... 2 2. Ecolab Badge Programming POD and Badge Programming POD Software Installation ................................................ 2 2.1 Host PC Requirements ........................................................................................................................................................................................ 2 2.2 Badge POD Application Software Installation ......................................................................................................................................... 2 3. Description of Badge Programming POD Main Screen ........................................................................................................................ 3 Figure 1. Main Screen ................................................................................................................................................................................................. 3 3.1 Menu Option (refer to Figure 1) .................................................................................................................................................................. 3 3.2 POD Controls ........................................................................................................................................................................................................ 4 Figure 2. Main POD Controls ................................................................................................................................................................................... 4 3.3 Scanned Badges ................................................................................................................................................................................................. 4 Figure 3. Scanned Badges Display Window ................................................................................................................................................... 5 3.4 Badge Settings ..................................................................................................................................................................................................... 5 Figure 4. Badge Settings: “Custom” Versus Pre-Set Views .................................................................................................................... 5 4. How to Use the Badge Programming Pod .................................................................................................................................................... 7 4.1 Connecting the POD to the PC ................................................................................................................................................................... 7 4.2 Scanning for Badges ........................................................................................................................................................................................ 7 4.3 Changing the Badge Settings ...................................................................................................................................................................... 7 Figure 6. Error Message Prompting Change to Grace Periods to Comply with Priority Rules ......................................... 10 4.9 Changing the POD’s Range ...................................................................................................................................................................... 10 4.10 Changing Badge Revision Level Supported .................................................................................................................................. 10 5. Troubleshooting ....................................................................................................................................................................................................... 10 5.1 The Badge Programming POD Displays a Red “X” on the Connect Button .................................................................... 10 5.2 The Badge Programming POD Application will not Communicate with the Dashboard ........................................... 10 6. Cleaning the Badge Programming POD ..................................................................................................................................................... 11 Appendix A – Certification and Safety Approvals ........................................................................................................................................ 12 2 1. The Ecolab Badge Programming POD and Badge Programming POD Application Software The Ecolab Hand Hygiene Compliance Monitoring System (HHCM System) Badge Programming POD and Badge Programming POD Application Software, together with the Dashboard Badge Settings page, allow hospital staff to quickly and efficiently manage administration of healthcare worker (HCW) Badges, for new staff members, staff members who may have lost or broken their badge, or for staff members who are no longer employed at the facility. The POD connects directly to the host PC’s USB port via an A-A male-male USB cable (supplied with the POD). The POD is powered by the USB port and does not require an external power source. The Application is used exclusively with the Ecolab Badge Programming POD. 2. Ecolab Badge Programming POD and Badge Programming POD Software Installation The Badge Programming POD (9205-3073) is used with the Windows PC based Ecolab Badge Programming POD Application Software (2.0) to communicate with the HHCM Badge (9205-3066). 2.1 Host PC Requirements …

Text truncated - open the document above for the full version.

Figure 1: Front View Figure 2: Back View Figure 3: Top View Figure 4: Bottom View Figure 5: Right Side View Figure 6: Left Side View

Figure 1: Sample Label Figure 2: Label Location

Figure 1: Top View Figure 2: Bottom View

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD Certification Exhibit FCC ID: Z9O-92053073 FCC Rule Part: 47 CFR Part 2.1091 TÜV SÜD Project Number: 72156787 Manufacturer: Ecolab Inc. Model: 92053073 RF Exposure Model: 92053073 FCC ID: Z9O-92053073 Project: 72156787 TÜV SÜD America Inc. Page 2 General Information: Applicant: Ecolab Inc. Device Category: Mobile Environment: General Population/Uncontrolled Exposure Technical Information: Antenna Type: Ceramic Chip Antenna Antenna Gain: -2.5 dBi Maximum Transmitter Conducted Power: -7.91 dBm, 0.1618 mW Maximum System EIRP: -10.41 dBm, 0.0910 mW Exposure Conditions: 20 centimeters or greater MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG π Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Table 1: MPE Calculation Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/Cm2) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Distance (cm) Power Density (mW/cm^2) 917 -7.91 0.61 0.16 -2.5 0.562 20 0.000

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD RESPONSIBLE FOR NAME DATE SIGNATURE Authorized Signatory Peter Walsh 2020 -March-16 Testing Thierry Jean-Charles 2020-March-16 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD America, Inc. document control rules. FCC Accreditation Designation Number US1063 Tampa, FL Test Laboratory Innovation, Science, and Economic Development Canada Accreditation Site Number 2087A-2 Tampa, FL Test Laboratory EXECUTIVE SUMMARY Samples of this product were tested and found to be in compliance with FCC Part 15.249. and ISED Canada’s RSS-210. A2LA Cert. No. 2955.15 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD America with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD America. No part of this document may be reproduced without the prior written approval of TÜV SÜD America. © TÜV SÜD. DISCLAIMER AND COPYRIGHT Our A2LA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our A2LA Accreditation. Results of test not covered by our A2LA Accreditation Schedule are marked NUA (Not A2LA Accredited). FCC and ISED Canada Testing of the Ecolab Inc. 92053073 In accordance with FCC 47 CFR Part 15.249 & ISED Canada’s Radio Standards Specifications RSS-210 Prepared for: Ecolab Inc. 1201 Jupiter Park Drive Jupiter, FL 33458 FCC ID: Z9O-92053073 IC: 10060A-92053073 COMMERCIAL-IN-CONFIDENCE Document Number: TP72156787.202| Version Number: 03 Document Number: TP72156787.202 | Version Number: 03 COMMERCIAL-IN-CONFIDENCE Page 2 of 30 Contents 1Report Summary .........................................................................................................................3 1.1Report Modification Record ...........................................................................................................3 1.2Introduction ....................................................................................................................................3 1.3Brief Summary of Results .............................................................................................................5 1.4Product Information .......................................................................................................................6 1.5Deviations from the Standard ........................................................................................................8 1.6EUT Modification Record ..............................................................................................................8 1.7Test Location .................................................................................................................................9 2Test Details ............................................................................................................................... 10 2.1Antenna Requirements............................................................................................................... 10 2.220 dB Bandwidth ........................................................................................................................ 11 2.399% Bandwidth .......................................................................................................................... 13 2.4Field Strength of Fundamental and Spurious Emissions ........................................................... 15 2.5Power Line Conducted Emissions ............................................................................................. 22 3Test Equipment Information ................................................................................................... 26 4Diagram of Test Set-ups .......................................................................................................... 27 5Measurement Uncertainty ....................................................................................................... 29 6Accreditation, Disclaimers and Copyright............................................................................. 30 Document Number: TP72156787.202 | Version Number: 03 COMMERCIAL-IN-CONFIDENCE Page 3 of 30 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 2020-February-27 2 Corrected typo on Grantee Code 2020-March-05 3 Corrected Model Number 2020-March-16 1.2 Introduction The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations Section 15.249 and Innovation Science and Economic Development Canada’s Radio Standards Specification RSS-210 for the tests documented herein. Document Number: TP72156787.202 | Version Number: 03 COMMERCIAL-IN-CONFIDENCE Page 4 of 30 Applicant Ecolab Inc. Manufacturer Ecolab Inc. Applicant’s Email Address [email protected] Model Number(s) 92053073 Serial Number(s) N/A FCC ID Z9O-92053073 ISED Certification Number 10060A-92053073 Hardware Version(s) 1 Software Version(s) 1.00 Number of Samples Tested 1 Test Specification/Issue/Date US Code of Federal Regulations (CFR): Title 47, Part 15, Subpart C: Radio Frequency Devices, Intentional Radiators, 2019 Innovation, Science and Economic Development Canada Radio Standards Specification: RSS-210 — Licence-Exempt Radio Apparatus: Category I Equipment, Issue 10, December 2019 Test Plan/Issue/Date 2020-January-15 Order Number 72156787 Date 2020-January-26 Date of Receipt of EUT 2020-February-13 Start of Test 2020-February-17 Finish of Test 2020-February-24 Name of Engineer(s) Thierry Jean-Charles, Jean N. Rene Related Document(s) ANSI C63.10-2013: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices Document Number: TP72156787.202 | Ver…

Text truncated - open the document above for the full version.

TÜV SÜD America 5610 West Sligh Ave., Suite 100 Tampa, FL 33634 Phone: 813-284-2715 www.tuv-sud-america.com TÜV SÜD Certification Exhibit FCC ID: Z9O-92053073 IC: 10060A-92053073 FCC Rule Part: 15 Subpart C ISED Canada’s Radio Standards Specification: RSS-210 Project: 72156787 Manufacturer: Ecolab Inc. Model: 92053073 Test Setup Photos Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 2 Figure 1: Radiated Spurious Emissions – Front View – below 1 GHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 3 Figure 2: Radiated Spurious Emissions – Back View – 9 kHz -30 MHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 4 Figure 3: Radiated Spurious Emissions – Back View – 30 MHz – 1 GHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 5 Figure 4: Radiated Spurious Emissions – Front View – above 1 GHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 6 Figure 5: Radiated Spurious Emissions – Back View – above 1 GHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 7 Figure 6: RF Conducted Emissions – TX = 917 MHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 8 Figure 7: Bandwidth Measurements – TX = 125 kHz Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 9 Figure 8: Power Line Conducted Emissions Model: 92053073 FCC ID: Z9O-92053073 IC: 10060A-92053073 Project: 72156787 TÜV SÜD America, Inc. Page 10 Figure 9: Power Line Conducted Emissions
