Mango Datasheet Mango Data Sheet Mango system on module (SOM) is based on IPQ6010 SoC from Qualcomm, which incorporates a powerful quad-core ARM Cortex A53 processor with NEON SIMD DSP extension for each core, ideal for Routers, Gateways and Access Points. It comes with a high-power dual-band concurrent radio supporting WIFI 6 (802.11ax) technology 2x2 MIMO. Two Ethernet SerDes to connect to external multi-GbE PHYs. Advanced power management for low active standby power consumption. SOM supports one USB3.0, USB2.0, PCIe 3.0, miscellaneous interfaces, which can be configured as general-purpose I/O pins and other. SoC has hardware NAT engine and high-end security features like crypto engine and others. The module is in a surface mountable form. Commercial temperature range: 0-65°C, industrial temperature range: -40-85°C. Quick specs •Wi-Fi 6 (802.11a/n/ac/ax) 5GHz with 2x2 MU-MiMo, 1201Mbps data-rate •Wi-Fi 6 (802.11b/g/n/ac/ax) 2.4GHz with 2x2 MU-MiMo, 573,5Mbps data-rate •MIPI DBI v2.0 type B display interface •CPU – IPQ6010 (1.8GHz) •OpenWRT Linux flash image •22 dBm per chain RF output power •Size – 38,3 by 61,7 mm •Available interfaces: 50 GPIOs, 1 x PCIe 3.0, 1 x USB3.0, 1 x USB2.0, 6 x BLSP ports for UART, 2C and SPI interfaces, 4 x PWM, 1 x JTAG, 2 x multi-GbE ethernet SedDes, dual SDIO for eMMC and SD card, PTA QPIC for parallel NAND device and LCD support. Mango Datasheet 3 Features Features TABLE 1-1. MANGO FEATURES Feature list MAN_100 Mango Integrated core Core type IPQ-6010 ARM Cortex-A53 Core clock frequency 1.8GHz Cache 512kB L2 Memory DRAM DDR3L 512MB (up to 2GB) NOR FLASH 32MB WIFI IEEE 802.11 b/g/n/ac/ax 2x2 MU-MIMO 2.4GHz 20/40 MHz 1024 QAM 2412-2462MHz IEEE 802.11 a/n/ac/ax 2x2 MU-MIMO 5GHz 20/40/80 MHz 1024 QAM 5150-5250MHz,5725-5850MHz RF pin RF signal is fed to 2 external module pins 2 Display LCD controller 1 Peripherals PCIe PCIe 3.0 1 USB USB 3.0 1 USB 2.0 1 BLSP SPI/UART/I 2 C configuration ports 6 GPIO IN/OUT/INT 64 PWM Audio Pulse Width Modulation interface 4 Parallel For parallel NAND flash memory 1 Ethernet SerDes supports 6.25/5/3.125/1.25 Gbps Ethernet 5*1/4*1/2.5/1 GbE PHYs. PSGMII, QSGMII, SGMII/+ 1 Reset Reset controlled via voltage monitor 1 SDIO3.0/eMMC Secure Digital Input Output / Embedded Multi Media Card 1 Mango Datasheet 4 B1 B76 Module pinout and Pin description FIGURE 3-1. PIN ASSIGNMENTS A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24 A25 A26 A27 A28 A29 A30 A31 A32 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24 B25 B26 B27 B28 B29 B30 B75 B74 B73 B72 B71 B70 B69 B68 B67 B66 B65 B64 B63 B62 B61 B60 B59 B58 B57 B56 B55 B54 B53 B52 B51 B50 B49 B48 B47 A83 A82 A81 A80 A79 A78 A77 A76 A75 A74 A73 A72 A71 A70 A69 A68 A67 A66 A65 A64 A63 A62 A61 A60 A59 A58 A57 A56 A55 A54 A53 A52 A51 A84 A85 A50 B77 B46 A86 A49 B78 B45 A87 A48 B79 B44 A88 A47 B80 B43 A89 A46 B81 B42 A90 A45 B82 B41 A91 A44 B83 B40 A92 A43 B84 B39 A93 A42 B85 B38 A94 A41 B86 B37 A95 A40 B87 B36 A96 A39 B88 B35 A97 A38 B89 B34 A98 A37 B90 B33 A99 A36 B91 B32 A100 A35 B92 B31 A101 A34 A102 A33 Mango Datasheet 5 TABLE 3-1. I/O DESCRIPTION (PAD TYPE) PARAMETERS Symbol Description AI Analog input AO Analog output GND Ground RF In/Out RF input/output I Digital input signal O Digital output signal IO Digital bidirectional signal Z High-impedance TABLE 3-2. POWER, GROUND AND RESET Pin ID Pin name Type Description A83, A84, A85,B76,B77 3V3 I 3.3V digital power A36,A39,A45,A49, B33, B36, B42, B45 3V3_RF I 3.3V digital power for RF A1, A2, A12, A24, A32, A34, A35, A37, A38, A40, A41, A42, A43, A44, A46, A47, A48, A50, A52, A76, A79, A82, A86, A87, A88, A97, A100, A102, B1, B18, B20, B30, B31, B32, B34, B35, B37, B38, B39, B40, B41, B43, B44, B46, B47, B55, B56, B58, B59, B60, B61, B62, B63, B64, B65, B66, B67, B68, B69, B72, B75, B78, B79, B90 GND GND Ground A81 PBIN_N I Power off/on the device B10 RESET_OUT_N O Reset output A20 PMIC_RST_O O Hardware reset TABLE 3-3. RADIO Pin ID Pin name Type Description A51 TX0 RF In/Out Signal line for antenna A33 TX1 RF In/Out Signal line for antenna TABLE 3-4. USB 3.0 Pin ID Pin name Type Description B70 USB_0_D_P AI, AO USB HS data positive A75 USB_0_D_N AI, AO USB HS data negative B73 USB_0_SS_RX_P AI USB SS receive data positive A78 USB_0_SS_RX_N AI USB SS receive data negative A77 USB_0_SS_TX_P AO USB SS transmit data positive B71 USB_0_SS_TX_N AO USB SS transmit data negative Mango Datasheet 6 TABLE 3-5. USB 2.0 Pin ID Pin name Type Description A80 USB_1_D_P AI, AO USB HS data positive B74 USB_1_D_N AI, AO USB HS data negative TABLE 3-6. PCIE GEN3 Pin ID Pin name Type Description A95 PCIE_W_DISABLE IO B87 PCIE_CLK_REQn IO PCIe clock request A96 PCIE_RSTn I PCIe reset B88 PCIE_WAKE I PCIe wake B89 PCIE_TX_N AO PCIe transmitter differential signal A98 PCIE_TX_P AO A99 PCIE_RX_P AI PCIe receiver differential signal B91 PCIE_RX_N AI B92 PCIE_REFCLK_N AO Reference clock A101 PCIE_REFCLK_P AO TABLE 3-7. ETHERNET Pin ID Pin name Type Description A74 CLK_50M_NAPA_P AO 50 MHz differential output clock A73 CLK_50M_NAPA_N AO A72 USXGMII0_TX_P O Transmitter differential signal A71 USXGMII0_TX_N O A70 USXGMII0_RX_P I Receiver differential signal A69 USXGMII0_RX_N I A68 CLK_50M_NAPA2_P AO 50 MHz differential output clock A67 CLK_50M_NAPA2_N AO A66 MDC AO MDIO interface clock A65 MDIO IO Management data input/output A64 USXGMII1_RX_N I Receiver differential signal A63 USXGMII1_RX_P I B57 CLK_25M_OUT AO 25 MHz output clock A62 USXGMII1_TX_N O Transmitter differential signal A61 USXGMII1_TX_P O Mango Datasheet 7 TABLE 3-8. NAND Pin ID Pin name Type Description B23 NAND_FLASH_ALE IO NAND controller ALE A25 NAND_DATA_0 IO NAND/Display controller data B24 NAND_DATA_3 IO NAND/Display controller data A26 NAND_DATA_2 IO NAND/Display controller data B25 NAND_DATA_1 IO NAND/Display controller data A27 NAND_FLASH_CS IO NAND controller select B26 NAND_FLASH_CLE IO NAND controller CLE. Boot up interface…

Text truncated - open the document above for the full version.

8devices Add: Antakalnio 17 - 6 Vilnius Lithuania Tel: +37052001014 Email: [email protected] Date: 2022-11-01 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, 8devices, hereby authorize China Certification ICT Co., Ltd (Dongguan). to act as a laboratory for testing and test report generation for the following project(s): (Product description:Mango, Model name:Mango, FCC ID:Z9WMAN) The chipset IPQ6010 supports 2.4G Wi-Fi and 5G Wi-Fi functions, but for this device, only supports 2.4G Wi-Fi and 5G Wi-Fi(5150-5250MHz,5725-5850MHz) bands. The other 5G Wi-Fi (5250-5350MHz, 5470-5725MHz)bands was disable by software. Sincerely, Signature: Printed Name: Jonas Sabaliauskas Title: Director

QA-FR-170-B 8devices Add: Antakalnio 17 - 6 Vilnius Lithuania Tel: +37052001014 Email: [email protected] FCC Authorization Date: 2022-11-01 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , 8devices, Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed Name: Jonas Sabaliauskas Title: Director

Device Security Declaration QA-FR-172-A 8devices Add: Antakalnio 17 - 6 Vilnius Lithuania Tel: +37052001014 Email: [email protected] FCC Confidential Authorization Date: 2022-11-01 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:Z9WMAN In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, 8devices hereby requests long- term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description As well as short-term (secrecy cycle: 180 days) confidential treatment of information accompanying this application as outlined below:  Internal Photos  User’s Manual  External Photos  Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature Printed Name: Jonas Sabaliauskas Title: Director 

8devices Add: Antakalnio 17 - 6 Vilnius Lithuania Tel: +37052001014 Email: [email protected] Modular Approval Letter Date:2022-11-01 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, 8devices, hereby request Modular Approval for Product: Mango (Model number: Mango, FCC ID: Z9WMAN).The EUT meets all the requirement for modular approval as detailed in FCC 15.212. the requirements is described below: 1. The modular has RF shielding, please refer to the EUT photo. 2. The modular transmitter has buffered modulation/data inputs, Buffered data inputs stage has been integrated in chip (Model:IPQ6010). 3. The modular transmitter has its own power supply regulation. Please refer to the Schematics. 4. Comply with the antenna requirements of Section 15.203 and 15.204(c), The module have two antenna types, one is chip antenna, another is whip antenna. For chip antenna, it must be permanently attached to the unit, the antenna gain is 2.09 dBi/2.4~2.5GHz,4.32dBi/5.15~5.85 GHz; For whip antenna, it must use a u nique type of connector to attach to the EUT, the antenna gain is 4.0dBi/2.4~2.5GHz, 4.5dBi/5.15~5.25GHz,5.0dBi/5.725~5.85GHz. 5. The EUT was tested in a stand-alone configuration, please refer to setup photos exhibit for details. 6. The module labeled with its own FCC ID. 7. Comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The necessary explanation to be complied with this requirement is contained in the user manual, please refers to the User Manual. 8. Comply with FCC §15.247 (i) & §15.407 (i) & §1.1310 & §2.1091 RF exposure requirements in its final configuration. Sincerely, Signature: Printed Name: Jonas Sabaliauskas Title: Director

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Test Fiture and Antenna Whip Antenna Chain 1 Antenna Connector Whip Antenna Chain 0 Chip Antenna Chain 0 Chip Antenna Chain 1

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS

China Certification ICT Co., Ltd (Dongguan) Report No.: CR22010029-00A Page 113 of 114 5. RF EXPOSURE EVALUATION 5.1 MAXIMUM PERMISSIBLE EXPOSURE (MPE) 5.1.1 Applicable Standard FCC §15.247 (i) & §1.1310 & §2.1091 Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See §1.1307(b)(1) of this chapter. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. 5.1.2 Procedure Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); 5.1.3 Calculated Result Operation Bands Frequency (MHz) Antenna Gain Conducted output power including Tune- up Tolerance Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) 2.4GHz 2412-2462 4 2.51 30 1000.00 20.00 0.50 1.0 5.2GHz 5150-5250 4.5 2.82 18.5 70.79 20.00 0.04 1.0 5.8GHz 5725-5850 5 3.16 18.5 70.79 20.00 0.04 1.0 Note: Non simultaneously transmission in the band 2.4GHz, 5.2GHz or 5.8GHz. Result: The device meet FCC MPE at 20 cm distance.

Description: 5320 2.4G&5GHz Chip Antenna PART NUMBER: ANT5320LL04R2455A In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. For more information: Pulse Worldwide Headquarters Pulse/Larsen Antennas Europe Headquarters Pulse (Suzhou) Wireless Products Co, Inc. 15255 Innovation Drive #100 Pulse GmbH & Do, KG 99 Huo Ju Road(#29 Bldg,4 th Phase San Diego, CA 92128 Vancouver, WA 98683 Zeppelinstrasse 15 Suzhou New District USA USA Herrenberg, Germany Jiangsu Province, Suzhou 215009 PR China Tel:1-858-674-8100 Tel: 1-360-944-7551 - Tel: 49 7032 7806 0 Tel: 86 512 6807 9998 18110 SE 34 th St Bldg 2 Suite 250 Features: Applications: •Size : 5.3x2.0x1.4 mm •Omni-directional Radiation •Dual-band design •Tape & reel automatic mounting •Reflow process compatible •RoHS compliant •2.4&5GHz WiFi device •ISM band equipment 1 In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 5320 2.4G&5GHz Chip Antenna PART NUMBER: ANT5320LL04R2455A 2 ELECTRICAL SPECIFICATIONS MECHANICAL DRAWING Working Frequency 2.45 G / 5.5GHz Bandwidth 150M / 900MHz(Typ.) Return Loss 6.5 dB Min Polarization Linear Azimuth Beamwidth Omni-directional Peak Gain 2.09 / 4.32 dBi(Typ.) Impedance 50 Ω Operating Temperature - 40~105 °C Maximum Power 1 W Termination Ni / Sn (Environmentally-Friendly Leadless) Resistance to Soldering Heats 260 °C , 10sec. NOTE 1. The specification is defined on Pulse evaluation board Dimension L (mm) 5.30 ± 0.20 W (mm) 2.00 ± 0.20 T (mm) 1.40 ± 0.30 A(mm) 0.40 ± 0.20 Terminal name Function S1 Feeding Point S2 Soldering Point TOP BOTTOM In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 5320 2.4G&5GHz Chip Antenna PART NUMBER: ANT5320LL04R2455A 3 REFERENCE DESIGN OF EVALUATION BOARD Outlook and dimension of evaluation board Details of soldering Pad In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 5320 2.4G&5GHz Chip Antenna PART NUMBER: ANT5320LL04R2455A 4 ELECTRICAL PERFORMANCES Return loss Radiation pattern Frequency= 2.45 GHz Max gain = 2.09 dBi, at (60, 150) MEG (mean effective gain)= -1.18 dBi Directivity (dB) = 3.58 Efficiency = -1.49 dB, 71.01 % Evaluation board and XYZ direction Marker data 1. 2.37GHz , -6.5dB 2. 2.45GHz , -7.6dB 3. 2.52GHz , -6.5dB 4. 5.05GHz , -6.5dB 5. 50GHz , -11.9dB 6. 95GHz , -6.5dB In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 5320 2.4G&5GHz Chip Antenna PART NUMBER: ANT5320LL04R2455A 5 ELECTRICAL PERFORMANCES Radiation pattern Frequency= 5.5 GHz Max gain = 4.32 dBi, at (90, 60) MEG (mean effective gain)= -2.57 dBi Directivity (dB) = 6.36 Efficiency = -2.04 dB, 62.52 % Evaluation board and XYZ direction In the effort to improve our products, we reserve the right to make changes judged to be necessary. CONFIDENTIAL AND PROPRIETARY INFORMATION This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 5320 2.4G&5GHz Chip Antenna PART NUMBER: ANT5320LL04R2455A 6 REVISION HISTORY Revision Date Description Version 1 Oct. 13, 2020 - New issue Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Deli…

Text truncated - open the document above for the full version.

                

TEST REPORT Applicant: 8devices Address: FCC:Antakalnio 17 - 6 Vilnius Lithuania IC: Antakalnio g. 17-6 Vilnius Vilnius County LT-10312 Lithuania FCC ID: Z9WMAN IC: 11468A-MAN HVIN: Mango Product Name: Mango Standard(s): 47 CFR Part 15, Subpart C(15.247) RSS-247 Issue 2, February 2017 RSS-Gen, Issue 5, February 2021 Amendment 2 ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR22010029-00A Date Of Issue: 2022-12-26 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR22010029-00A Page 2 of 114 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR22010029-00A Page 3 of 114 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.2 Support Equipment List and Details .............................................................................................................. 8 1.2.3 Support Cable List and Details ...................................................................................................................... 8 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 9 1.3 MEASUREMENT UNCERTAINTY ........................................................................................................ 10 2. SUMMARY OF TEST RESULTS .......................................................................................... 11 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 12 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 12 3.1.1 Applicable Standard ..................................................................................................................................... 12 3.1.2 EUT Setup.................................................................................................................................................... 14 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 14 3.1.4 Test Procedure ............................................................................................................................................. 15 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 16 3.2.1 Applicable Standard ..................................................................................................................................... 16 3.2.2 EUT Setup.................................................................................................................................................... 16 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 17 3.2.4 Test Procedure ............................................................................................................................................. 17 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 18 3.3 6 DB EMISSION BANDWIDTH: ............................................................................................................ 19 3.3.1 Applicable Standard ..................................................................................................................................... 19 3.3.2 EUT Setup................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View-Chip Antenna Conducted Emissions Side View-Chip Antenna Radiated Emissions Below 1G-Chip Antenna Radiated Emissions Below 1G-Whip Antenna Radiated Emissions Above 1G-Chip Antenna Radiated Emissions Above 1G -Whip Antenna
