535iFR, 535iRXT, 535iRX ENOperator's manual2-30 Contents Introduction.....................................................................2 Safety..............................................................................4 Assembly...................................................................... 12 Operation......................................................................18 Maintenance................................................................. 24 Troubleshooting............................................................27 Transportation, storage and disposal........................... 27 Technical data.............................................................. 28 Accessories.................................................................. 29 Introduction Intended use Use the product with a saw blade, a grass blade or a trimmer head to cut different types of vegetation. Do not use the product for other tasks than grass trimming, grass clearing and forestry clearing. Use a saw blade to cut fibrous types of wood. Use a grass blade or trimmer head to cut grass. Note: National or local regulations can regulate the use. Comply to given regulations. Only use the product with accessories that are approved by the manufacturer. Refer to Accessories on page 29. Product overview 7 4 5 iFR/iRX iRXT 35 16 22 2324 13 21 30 27 26 32 2 28 28 18 25 28 1 30 29 31 6 3 20 19 36 15 17 33 13 9 10 8 11 11 12 12 13 34 14 14 10 6 7 23 15 23 29 1. Grass blade 2. Saw blade (535iFR) 3. Shaft 4. Balance 55 Harness (535iFR, 535iRX) 5. Balance XB Harness (535iRXT) 6. Knob 7. Handlebar 8. Power trigger 9. Power trigger lockout 10. Add-on weight (accessory) 11. ErgoFeed button (535iRXT) 12. Handle 13. Warning indicator (LED) 14. Speed mode button 2609 - 001 - 15. Start/Stop button 16. Charger 17. Charger cable 18. Power on and Warning indicator (LED) 19. Combination wrench 20. Locking pin 21. Battery release buttons 22. Battery 23. State of charge 24. Battery indicator button 25. Grass blade guard 26. Trimmer guard 27. Saw blade guard (535iFR) 28. Drive disc 29. Washer 30. Locknut 31. Support cup 32. Trimmer head 33. Transport guard 34. Harness support hook 35. Battery carrier (accessory) 36. Operator's manual Symbols on the product WARNING! This product can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. It is extremely important that you read and understand the contents of the operator's manual. Please read the operator’s manual carefully and make sure you understand the instructions before the product is used. Use a protective helmet in locations where objects can fall on you. Use approved hearing protection. Use approved eye protection. Maximum speed of the output shaft. The product can cause objects to eject, which can cause injury. Keep a minimum distance of 15 m to persons and animals during operation of the product. Risk of blade thrust if the cutting equipment touches an object that it does not immediately cut. The product can cut off body parts. Keep a minimum of 15 m distance to persons and animals during operation of the product. Use approved protective gloves. Use heavy-duty slip-resistant boots. Only use a flexible cutting wire. Do not use metal cutting elements. Protected against splashing water. Direct current. Keep all parts of your body away from the hot surfaces. This product features Bluetooth ® wireless technology. refer to Husqvarna Connect on page 18. yyyywwxxxxxThe rating plate shows the serial number. yyyy is the production year, ww is the production week and xxxxx is the sequential number. Note: Other symbols/decals on the product refer to certification requirements for other commercial areas. California Proposition 65 Manufacturer Husqvarna AB Drottninggatan 2, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500 609 - 001 - 3 Safety Safety definitions Warnings, cautions and notes are used to point out specially important parts of the manual. WARNING: Used if there is a risk of injury or death for the operator or bystanders if the instructions in the manual are not obeyed. CAUTION: Used if there is a risk of damage to the product, other materials or the adjacent area if the instructions in the manual are not obeyed. Note: Used to give more information that is necessary in a given situation. IMPORTANT SAFETY INSTRUCTIONS General power tool safety warnings WARNING: Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Note: Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool. Work area safety • Keep work area clean and well lit. Cluttered or dark areas invite accidents. • Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. • Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. Product liability As referred to in the product liability laws, we are not liable for damages that our product causes if: • the product is incorrectly repaired. • the product is repaired with parts that are not from the manufacturer or not approved by the manufacturer. • the product has an accessory that is not from the manufacturer or not approved by the manufacturer. • the product is not repaired at an approved service center or by an approved authority. Electrical safety • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. • Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerat…
Text truncated - open the document above for the full version.
Installation Manual HMI Bluetooth® Modules 1 (2) UI Medium (ZAS-HQ-HH-001) UI Small (ZAS-HQ-HH-002) In addition to technical implementation specifications, the following instructions shall be followed when implementing the HMI modules incorporating Bluetooth® functionality, i.e. the UI Medium and UI Small, for the below mentioned certifications to be valid. 1 - Compliance This device complies with Part 15 of the FCC Rules and with Industry Canada licensee exempt RSS standard(s). Operation is subject to the following two conditions: • this device may not cause harmful interference, and • this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: • l'appareil ne doit pas produire de brouillage, et • l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Changes or modifications made to this equipment not expressly approved by Husqvarna may void the FCC authorization to operate this equipment. Installation Manual HMI Bluetooth® Modules 2 (2) 2 - Modular Approval (FCC Part 15) Both UI Medium (ZAS-HQ-HH-001) and UI Small (ZAS-HQ-HH-002) is of the type Limited single-modular transmitter. Due to lack of shielding on the module itself, each product using the module need to be measured to comply with FCC Part 15. 3– Product Labeling For products using the modules UI Medium (ZAS-HQ-HH-001) and UI Small (ZAS-HQ-HH- 002) the host product need to be labeled accordingly to comply. For UI Medium (ZAS HQ-HH-001): Marking with the wording “THIS PRODUCT CONTAINS” followed by and on a separate line “FCC ID: ZAS-HQ-HH-001” and . again on a separate line “IC: 23307-HQHH001”. For UI Small (ZAS HQ-HH-002): Marking with the wording “THIS PRODUCT CONTAINS” followed by and on a separate line “FCC ID: ZAS-HQ-HH-002” and . again on a separate line “IC: 23307-HQHH002”.
Applicant/Grantee Husqvarna AB FCC ID: ZAS-HQ-HH-001 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Module will be tested in host product. No 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Yes 3 The modular transmitter must have its own power supply regulation. Yes 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Yes 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Yes equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. Yes 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Yes 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Yes A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.
2019-08-30 Request for Confidentiality of Exhibits addressed to FCC Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: ZAS-HQ-HH-001 T o Whom It May Concern: Pursuant to the provisions o f Sections 0.457 and 0.459 of the Commission's rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block D iagram Theory of Operation Antenna Specification Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. tel Husqvama Group I t is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards (HJ Husqvama Group Therese Berg Electrical Compliance Specialist Phone +46 36 36 42 75 Mobile +46 739 17 59 32 [email protected] Husqvarna AB (publ) 56182 Huskvarna, Sweden Visiting address: Drottninggatan 2 www.husqvamagroup.com 2 (21
FCC Part 1 Subpart I FCC Part 2 Subpart J ISED CANADA RSS 102 ISSUE 5 RF EXPOSURE REPORT FOR BLE MODULE MODEL NUMBER: HQ-HH-001 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 REPORT NUMBER: R12368801-E8 ISSUE DATE: 12 March 2020 Prepared for Husqvarna AB EM-FHR Huskvarna, SE-561 82 Sweden Prepared by UL LLC 12 LABORATORY DR. RESEARCH TRIANGLE PARK, NC 27709 USA TEL: (919) 549-1400 REPORT NO: R12368801-E8 DATE: 2020-03-12 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 2 of 12 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. Revision History Ver. Issue Date Revisions Revised By 1 2018-09-11 Initial Issue Brian T. Kiewra 2 2020-02-04 Updated model number Lariah Ijames 3 2020-03-12 Corrected Average power Lariah Ijames REPORT NO: R12368801-E8 DATE: 2020-03-12 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 3 of 12 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................4 2. TEST METHODOLOGY ......................................................................................................5 3. REFERENCES ....................................................................................................................5 4. FACILITIES AND ACCREDITATION ..................................................................................5 5. MAXIMUM PERMISSIBLE RF EXPOSURE ........................................................................6 5.1. FCC RULES .................................................................................................................6 5.2. IC RULES .....................................................................................................................7 5.3. EQUATIONS .................................................................................................................8 5.4. LIMITS AND IC EXEMPTION .....................................................................................10 6. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS .........................................11 6.1. FCC ............................................................................................................................11 6.2. INDUSTRY CANADA ..................................................................................................12 END OF TEST REPORT ..........................................................................................................12 REPORT NO: R12368801-E8 DATE: 2020-03-12 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 4 of 12 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Husqvarna AB EM-FHR Huskvarna, SE-561 82 Sweden EUT DESCRIPTION: BLE Module MODEL: HQ-HH-001 SERIAL NUMBER: C1 DATE TESTED: NA APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Compliant ISED CANADA RSS 102 ISSUE 5 Compliant UL LLC tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL LLC based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL LLC and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL LLC will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Approved & Released For UL LLC By: Prepared By: Jeffrey Moser Brian T. Kiewra Operations Leader Project Engineer UL – Consumer Technology Division UL – Consumer Technology Division REPORT NO: R12368801-E8 DATE: 2020-03-12 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 5 of 12 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 2. TEST METHODOLOGY All calculations were made in accordance with FCC Parts 2.1091, 2.1093 and KDB 447498 D01 v06 and IC Safety Code 6, RSS 102 Issue 5. 3. REFERENCES All measurements were made as documented in test report UL LLC Documents R12368801-E1 for operation in the 2.4 GHz band. Output power, Duty cycle and Antenna gain data is excerpted from product documentation provided by the applicant. 4. FACILITIES AND ACCREDITATION The test sites and measurement facilities used to collect data are located at 12 Laboratory Dr., Research Triangle Park, NC 27709, USA and 2800 Perimeter Park Drive, Suite B, Morrisville, NC 27560. UL LLC (RTP) is accredited by NVLAP, Laboratory Code 200246-0. The full scope of accreditation can be viewed at http://www.nist.gov/nvlap/ REPORT NO: R12368801-E8 DATE: 2020-03-12 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 6 of 12 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., RTP, NC 27709 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 5. MAXIMUM PERMISSIBLE RF EXPOSURE 5.1. FCC RULES §1.1310 The criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as s…
Text truncated - open the document above for the full version.
NVLAP Lab code: 200246-0 CERTIFICATION TEST REPORT Report Number : R12368801-E1 Applicant : Husqvarna AB EM-FHR Huskvarna, SE-561 82 Sweden Model : HQ-HH-001 FCC ID : ZAS-HQ-HH-001 IC : 23307-HQHH001 EUT Description : BLE Module Test Standard(s) : FCC 47 CFR PART 15 SUBPART C ISED RSS-247 ISSUE 2 ISED RSS-GEN ISSUE 5 Date Of Issue: 2020-02-10 Prepared by: UL LLC 12 Laboratory Dr. Research Triangle Park, NC 27709 U.S.A. TEL: (919) 549-1400 REPORT NO: R12368801-E1 DATE: 2020-02-10 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 2 of 41 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. REPORT REVISION HISTORY Rev. Issue Date Revisions Revised By 1 2018-08-09 Initial Issue Brian T. Kiewra 2 2020-02-04 Updated model name Lariah Ijames 3 2020-02-10 Revised measurement methods in Section 6 to ANSI C63.10-2013 references. Brian T. Kiewra REPORT NO: R12368801-E1 DATE: 2020-02-10 FCC ID: ZAS-HQ-HH-001 IC: 23307-HQHH001 Page 3 of 41 UL LLC 12 Laboratory Dr., RTP, NC 27709; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. TABLE OF CONTENTS REPORT REVISION HISTORY ..................................................................................................2 TABLE OF CONTENTS .............................................................................................................3 1. ATTESTATION OF TEST RESULTS ..................................................................................4 2. TEST METHODOLOGY ......................................................................................................5 3. FACILITIES AND ACCREDITATION ..................................................................................5 4. CALIBRATION AND UNCERTAINTY .................................................................................6 4.1. MEASURING INSTRUMENT CALIBRATION ...............................................................6 4.2. SAMPLE CALCULATION .............................................................................................6 4.3. MEASUREMENT UNCERTAINTY ................................................................................6 5. EQUIPMENT UNDER TEST ................................................................................................7 5.1. EUT DESCRIPTION .....................................................................................................7 5.2. MAXIMUM OUTPUT POWER .......................................................................................7 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ...............................................................7 5.4. SOFTWARE AND FIRMWARE .....................................................................................7 5.5. WORST-CASE CONFIGURATION AND MODE ...........................................................7 5.6. DESCRIPTION OF TEST SETUP .................................................................................8 6. MEASUREMENT METHOD.................................................................................................9 7. TEST AND MEASUREMENT EQUIPMENT ......................................................................10 8. ANTENNA PORT TEST RESULTS ...................................................................................12 8.1. ON TIME AND DUTY CYCLE .....................................................................................12 8.2. 99% BANDWIDTH ......................................................................................................13 8.2.1. BLE (1Mbps) ........................................................................................................13 8.3. 6 dB BANDWIDTH ......................................................................................................14 8.3.1. BLE (1Mbps) ........................................................................................................14 8.4. OUTPUT POWER .......................................................................................................16 8.5. AVERAGE POWER ....................................................................................................17 8.6. POWER SPECTRAL DENSITY ..................................................................................18 8.6.1. BLE (1Mbps) ........................................................................................................19 8.7. CONDUCTED SPURIOUS EMISSIONS .....................................................................20 8.7.1. BLE (1Mbps) ........................................................................................................21 9. RADIATED TEST RESULTS .............................................................................................22 9.1. LIMITS AND PROCEDURE ........................................................................................22 9.2. TRANSMITTER ABOVE 1 GHz ..................................................................................23 9.2.1. BLE (1Mbps) ........................................................................................................23 9.3. WORST CASE BELOW 1 GHz ...................................................................................33 9.4. WORST CASE 18-26 GHz ..........................................................................................36 10. AC POWER LINE CONDUCTED EMISSIONS ..................................................................38 10.1.1. AC Power Line Norm ........................................................................................39 11. SETUP PHOTOS ...............................................................................................................41 END OF REPORT ....................................................................................................................41 REPORT NO: R12368801-E1 DATE: 2020-02-10 FCC ID: ZAS-HQ-HH-001 …
Text truncated - open the document above for the full version.
REPORT Testing issued by an Accredited Testing Laboratory Contact person Date Reference Page Fredrik Isaksson 2019-12-16 9P08169 1 (38) Electronics +46 10 516 55 80 [email protected] Husqvarna AB Drottninggatan 2 561 82 HUSKVARNA Equipment Authorization measurements on 2402-2480 MHz Transceiver Unit Accred. No. 1002 Testing ISO/IEC 17025 RISE Research Institutes of Sweden AB Postal address Office location Phone / Fax / E-mail This report may not be reproduced other than in full, except with the prior written approval of the issuing laboratory. Box 857 SE-501 15 BORÅS Sweden Brinellgatan 4 SE-504 62 BORÅS +46 10 516 50 00 +46 33 13 55 02 [email protected] Test object Product name: Husqvarna Brushcutter 535iRXT with BLE User Interface Medium (UI-M) Article no: 967850601 Serial no: 08 Contains: FCC id: ZAS-HQ-HH-001 IC: 23307-HQHH001 RISE Research Institutes of Sweden AB Electronics - EMC Performed by Examined by __Signature_1 __Signature_2 Fredrik Isaksson Monika Fuller REPORT Date Reference Page 2019-12-16 9P08169 2 (38) RISE Research Institutes of Sweden AB Table of Content Summary ..................................................................................................................................... 3 Commission ................................................................................................................................ 4 Test object ................................................................................................................................... 4 Operational test mode ............................................................................................................. 6 Ancillary and/or support equipment .................................................................................... 6 References ........................................................................................................................... 7 Uncertainties ....................................................................................................................... 8 Test results .............................................................................................................................. 9 Restricted bands of operation measurements according to FCC 47 CFR part 15.247 (d) / RSS-247 5.5 ........................................................................................................................ 9 Band edge measurements according to 47CFR 2.1049 / RSS-247 5.5 ............................. 26 Photos ........................................................................................................................................ 32 REPORT Date Reference Page 2019-12-16 9P08169 3 (38) RISE Research Institutes of Sweden AB Summary Standard Compliant Remarks FCC 47 CFR Part 15 C 15.247 Operation within the band 2400-2483.5 MHz Note 1 ISED RSS-247 Issue 2, February 2017 Note 1 15.247 (d) / RSS-247 5.5 Unwanted emission Yes 2.1049 / RSS-247 5.5 Band Edge Yes Note 1: The test was performed to verify that the object complies with the Tx unwanted emissions according to 15.247 (d)/RSS-247 Issue 2, 5.5 (unwanted emission) when the pre-approved radio module is mounted in the final host. REPORT Date Reference Page 2019-12-16 9P08169 4 (38) RISE Research Institutes of Sweden AB Commission The tests …
Text truncated - open the document above for the full version.
