ZAZR7X1GSIndustrial Cellular Router

Beijing InHand Networks Technology Co,. Ltd.
Industrial Cellular Router - FCC ID ZAZR7X1GS - Beijing InHand Networks Technology Co,. Ltd.
Click to zoom

Application Details

Equipment Class
PCB - PCS Licensed Transmitter
Date of Grant
Dec 07, 2011
Application Purpose
Original Equipment
Date of Application
Dec 07, 2011
Equipment Note
Industrial Cellular Router
Frequency Range
1850.20000000 - 1909.80000000
Company
Beijing InHand Networks Technology Co,. Ltd.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Parts List/Tune Up Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

InRouter 700 Series User’s Manual www.inhandnetworks.com InRouter 7x1GS55 Series User’s Manual Fifth Edition, August, 2011 (For Firmware Version: 1.3.5.v2275) © 2011 InHand Networks, All rights reserved. Republication without permission is prohibited. InRouter 700 Series User’s Manual Copyright Notice Copyright © 2011 InHand Networks All rights reserved. Reproduction without permission is prohibited. Trademarks InHand is a registered trademark of InHand Networks. Other registered marks cited in this manual represented their respective companies. Disclaimer Information in this document is subject to change without notice and does not represent an obligation on the part of InHand Networks. This user manual may include intentional technical or typographical errors. Changes are periodically made to the manual to correct such errors, and these changes are not informed in new editions. Technical Support Contact Information InHand Networks, China Tel: +86-010-64391099 Fax: +86-010-64399872 Email: [email protected] InRouter 700 Series User’s Manual www.inhandnetworks.com 1 Release Notes 2011. 3. 24 th : Add description for functions: 1. WOL (Wakeup Over LAN) at “Networks”Æ”LAN”; 2. SMS control (reboot/show status) at “Service”Æ”SMS”; 3. “User+X.509” mode for OpenVPN client; Add Notice: 1. WAN/LAN settings: don’t set the WAN/LAN IP as 192.168.3.1 (the default IP of DMZ port); 2011.8.21 st : Add description for functions: 1. “Double Dialup”, set backup parameters for PPP dialup at “Networks”Æ”Dialup”; 2. “Double IPSec”, set backup IPSec tunnel at “VPN” Æ “IPSec Tunnels”; 3. “DHCP Relay” at “Service” Æ “DHCP Relay”; 4. “DNS Relay” at “Service” Æ “DNS Relay” 5. Enable “SSH configuration”; 6. Disable “Multi Manager” function at “System” Æ “Admin Access”; 7. “Loopback” at “Networks” Æ “Loopback”; 8. “Port Mirror” at “Networks” Æ “Port Mirror”; InRouter 700 Series User’s Manual www.inhandnetworks.com 2 Contents Contents ...................................................................................................................................................................................... 2 Introduction to InRouter 700 Series ........................................................................................................................................... 3 1.1 Overview ................................................................................................................................................................ 4 1.2 Package Checklist ................................................................................................................................................... 6 1.3 Product Features ..................................................................................................................................................... 7 1.3.1 Interfaces ........................................................................................................................................................... 7 1.3.2 Functions ........................................................................................................................................................... 8 1.3.3 Environmental Limits ........................................................................................................................................ 9 1.3.4 Power Requirements .......................................................................................................................................... 9 1.3.5 Physical Characteristics ..................................................................................................................................... 9 1.3.6 Advanced Industrial Features .......................................................................................................................... 10 1.3.7 Device Management Software ......................................................................................................................... 10 1.3.8 Warranty .......................................................................................................................................................... 10 1.4 Product Models ..................................................................................................................................................... 11 Quick Installation Guide ........................................................................................................................................................... 13 2.1 Typical Application ............................................................................................................................................... 14 2.2 Panel Layout ......................................................................................................................................................... 14 2.3 Quick Connection to Internet ............................................................................................................................... 16 2.3.1 Insert SIM Card ............................................................................................................................................... 16 2.3.2 Antenna Installation ......................................................................................................................................... 16 2.3.3 Power Supply ................................................................................................................................................... 16 2.3.4 Connect ............................................................................................................................................................ 16 2.3.5 First Connect InRouter with Your PC .............................................................................................................. 17 2.3.6 Start to configure your InRouter 700(Optional) .........................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Beijing InHand Networks Technology Co,.Ltd Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Beijing InHand Networks Technology Co,.Ltd FCC ID: ZAZR7X1GS FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Jason Hu Position Technology Engineer Company Name Beijing InHand Networks Technology Co,.Ltd Address WestWing 11 th Floor, Buiding G, Wangjing Science Park, Chaoyang District, Beijing. Tel / Fax (86) 10-64391099/(86) 10-64399872 E-Mail [email protected]

External Photos

CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 1 of 2 EXTERNAL PHOTOGRAPHS OF EUT CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 2 of 2

ID Label/Location Info

FCC ID Position: FCC ID

Internal Photos

CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 1 of 5 INTERNAL PHOTOGRAPHS OF EUT CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 2 of 5 CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 3 of 5 CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 4 of 5 GSM Module: CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 5 of 5

Parts List/Tune Up Info

CERPASS TECHNOLOGY CORP. ReportNo.:SEFI1111048 FCCID: ZAZR7X1GS Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 1 of 3 Radio frequency exposure LIMIT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1310 of this chapter. EUT Specification EUT Industrial Cellular Router Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.725GHz ~ 5.850GHz Bluetooth: 2.402GHz ~ 2.480 GHz Others:824MHz~849MHz 1850MHz~1910MHz Device category Portable (<20cm separation) Mobile (>20cm separation) Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (824MHz~849MHz :S=0.5576mW/cm 2 ) (1850MHz~1910MHz :S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power GPRS 850:33.19dBm GPRS 1900:29.67dBm Antenna gain (Max) 0.5 dBi (Numeric gain:1.122) Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum output power is 33.19 dBm (2084 mW) at 848.8 MHz (withnumeric 1.122 antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger. CERPASS TECHNOLOGY CORP. ReportNo.:SEFI1111048 FCCID: ZAZR7X1GS Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 2 of 3 TEST RESULTS No non-compliance noted. Calculation Given d GP E ×× = 30 & 3770 2 E S= Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S ×× = Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 2 2 0796.0 100/3770 1000/30 d GP d GP S × ×= × ×× = Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 CERPASS TECHNOLOGY CORP. ReportNo.:SEFI1111048 FCCID: ZAZR7X1GS Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 3 of 3 Maximum Permissible Exposure Modulation Mode Frequency band (MHz) Max. Conducted output power(dBm) Antenna gain (dBi) Distance (cm) Power density (mW/cm2) Limit (mW/cm2) GPRS850 824-849 33.19 0.5 20 0.465 0.5576 GPRS1900 1850-1910 29.67 0.5 20 0.207 1 NOTE: Total(Chain0+Chain1) , the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density

Test Report

CERPASS TECHNOLOGY CORP. Report No.:SEFI1111048 FCC ID:ZAZR7X1GS Cerpass Technology Corp. Issued Date : Nov 21,2011 Tel:86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 1 of 50 FCC TEST REPORT According to FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E Applicant : Beijing InHand Networks Technology Co., Ltd Address : WestWing 11 th Floor, Buiding G, Wangjing Science Park, Chaoyang District, Beijing. Manufacturer : Beijing InHand Networks Technology Co., Ltd Address : WestWing 11 th Floor, Buiding G, Wangjing Science Park, Chaoyang District, Beijing. Equipment : Industrial Cellular Router Model No. : IR701GS55, IR711GS55, IR721GS55, IR731GS55, IR741GS55, IR751GS55, IR761GS55, IR771GS55, IR781GS55, IR791GS55 FCC ID ZAZR7X1GS ‚ The test result refers exclusively to the test presented test model / sample. ‚ Without written approval of Cerpass Technology Corp. the test report shall not be reproduced except in full. ‚ The test report must not be used by the clients to claim product certification approval by NVLAP or any agency of the Government. CERPASS TECHNOLOGY CORP. Report No.:SEFI1111048 FCC ID:ZAZR7X1GS Cerpass Technology Corp. Issued Date : Nov 21,2011 Tel:86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 2 of 50 Table of Contents 1. Report of Measurements and Examinations ............................................................................................ 6 2. Test Configuration of Equipment under Test ........................................................................................... 7 2.1. Feature of Equipment under Test .................................................................................................... 7 2.2. Test Manner ..................................................................................................................................... 8 2.3. Description of Test System .............................................................................................................. 8 2.4. General Information of Test ............................................................................................................. 8 2.5. Measurement Uncertainty ............................................................................................................... 9 3. Test of Conducted Emission.................................................................................................................... 10 3.1. Test Limit........................................................................................................................................ 10 3.2. Test Procedures............................................................................................................................. 10 3.3. Typical Test Setup...........................................................................................................................11 3.4. Measurement Equipment ...............................................................................................................11 3.5. Test Result and Data ..................................................................................................................... 12 4. FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT......................................................... 14 4.1. Test Limit........................................................................................................................................ 14 4.2. Test Procedures............................................................................................................................. 14 4.3. Typical Test Setup.......................................................................................................................... 14 4.4. Measurement Equipment .............................................................................................................. 16 4.5. Test Result and Data ..................................................................................................................... 17 5. Occupied Bandwidth ................................................................................................................................ 29 5.1. Test Limit........................................................................................................................................ 29 5.2. Test Procedures............................................................................................................................. 29 5.3. Test Setup Layout .......................................................................................................................... 29 5.4. Measurement Equipment .............................................................................................................. 29 5.5. Test Result and Data ..................................................................................................................... 30 6. Maximum Peak Output Power ................................................................................................................. 34 6.1. Test Limit........................................................................................................................................ 34 6.2. Test Procedure .............................................................................................................................. 34 6.3. Test Setup Layout .......................................................................................................................... 34 6.4. Measurement Equipment .............................................................................................................. 34 6.5. Test Result and Data ..................................................................................................................... 35 7. ERP & EIRP MEASUREMENT................................................................................................................... 36 7.1. Test Limit......................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 1 of 3 TEST SETUP PHOTOGRAPHS OF EUT AC POWER LINE CONDUCTED EMISSION TEST CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 2 of 3 Radiation EMISSION TEST Above 1G CERPASS TECHNOLOGY CORP. Report No.: SEFI1111048 Cerpass Technology Corp. Issued date : Nov 21,2011 Tel: 86-512-6917-5888 Fax: 86-512-6917-5666 Page No. : 3 of 3 Below 1G

Contact Information

Applicant

Jason Hu(Technology Engineer)
[email protected](86) 10-64391099Fax: (86) 10-64399872

Test Firm

Cerpass Technology (SuZhou) Co., Ltd.Miro Chueh
[email protected]86-0512-69175888Fax: 86-0512-36175666

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
224E1.85 GHz - 1.91 GHz927.00 mW244KGXW2.5 ppm
Confidentiality
Long Term
Grant Notes
Power listed is peak conducted. Radiated output power with dedicated antenna is 2.25W ERP (22H) and 0.32W EIRP (24E). This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
