ZC4L200smart phone

1 1 USER MANUAL ILIUM L200 ZC4L200 2 2 Table of Contents LEGAL INFORMATION ........................................................................................................................................................ 3 Safety Information ................................................................................................................................................................ 3 Introduction .......................................................................................................................................................................... 5 SIM/SD card and battery Installation Guide ........................................................................................................................... 5 Call Functions....................................................................................................................................................................... 8 Notifications Bar ................................................................................................................................................................... 9 Contacts .............................................................................................................................................................................. 11 Messaging .......................................................................................................................................................................... 14 Bluetooth & Wi-Fi................................................................................................................................................................ 16 Downloads ......................................................................................................................................................................... 18 Internet Browser ................................................................................................................................................................. 19 Gmail ................................................................................................................................................................................. 20 Play Store ........................................................................................................................................................................... 21 Camera .............................................................................................................................................................................. 22 Gallery................................................................................................................................................................................ 24 Music ................................................................................................................................................................................. 25 FM Radio ........................................................................................................................................................................... 26 Sound Recorder ................................................................................................................................................................. 27 File Manager ...................................................................................................................................................................... 29 Calendar ............................................................................................................................................................................ 29 Alarm Clock ........................................................................................................................................................................ 30 Settings .............................................................................................................................................................................. 31 Storage............................................................................................................................................................................... 36 3 3 LEGAL INFORMATION Copyright © 2015 LANIX. All rights reserved No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of LANIX Corporation. LANIX Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Safety Information Please carefully read the terms below: Use Safely Do not use the phone in situations where it might cause 4 4 danger. Transportation Safety Please observe all transportation laws and regulations. Please drive with both hands on the wheel. Hospital Safety Please follow hospital rules and limitations. Please turn off your mobile phone when near medical instruments. Airport Safety Remember to follow all airport and flight safety regulations. Please do not use your phone during flight. Chemical Warning Do not use your mobile phone around fuels or chemicals. Temperature Warning Do not subject your phone to extreme temperature conditions. Water Hazard 5 5 Your phone is not waterproof. Keep it away from water and liquids. Emergency Calls Make sure your mobile phone is switched on and in a service area. In home screen, tap the phone key and dial the emergency number. Accessories and Batteries Use only Blu authorized batteries and accessories. Information Backup Remember to keep a written record of all important information. Introduction SIM/SD card and battery Installation Guide Installation of the SIM Cards Advisory: Please keep the SIM card out of the reach of children. The SIM card and its contact are easily damaged due 6 6 to scratching or bending. Please be cauti…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Corporativo Lanix S.A. de C.V. 2015.6.8 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Corporativo Lanix S.A. de C.V. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: smart phone model name: Ilium L200 FCC ID: ZC4L200 Sincerely, Client’s signature : Oscar Guzman Client’s name / title: Product Manager Applicant company: Corporativo Lanix S.A. de C.V. address: Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, Mexico.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Corporativo Lanix S.A. de C.V. 2015.6.8 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZC4L200 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Oscar Guzman Client’s name & title : Product Manager Contact information / address: Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, Mexico.

Corporativo Lanix S.A.de C.V. WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : ZC4L200 Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Company Name: Corporativo Lanix S.A.de C.V. Address : 1 Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, Mexico Name / Title : Oscar Guzman / Product Manager Signature : Phone : 6621090800 Email : [email protected] Date :06/23/2015

Project No: STS1506010 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1506010 Photo 3 Photo 4 Project No: STS1506010 Photo 5 Photo 6 Project No: STS1506010 Photo 7 Photo 8 Project No: STS1506010 Photo 9

abel

Project No: STS1506010 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI/GPS ANTENNA GSM/WCDMA ANTENNA 4G ANTENNA Project No: STS1506010 Photo 3 Photo 4 Project No: STS1506010 Photo 5 Photo 6 Project No: STS1506010 Photo 7 Photo 8

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1506010H01 Issued for Corporativo Lanix S.A.de C.V. Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, México Product Name: smart phone Brand Name: LANIX Model No.: Ilium L200 Series Model: N/A FCC ID: ZC4L200 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:1.267 W/kg Body:1.344 W/kg S T L A B S Page 2 of 161 Report No.: STS1506010H01 Test Report Certification Applicant’s name ................. : Corporativo Lanix S.A.de C.V. Address ................................. : Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, México Manufacture's Name ............ : AMER MOBILE CO.,LIMITED Address ................................. : Room A30, 9th floor,Silvercorp International Tower No 707-713, Nathan Road, mongkok, Kowloon, Hong Kong Product description Product name ........................ : smart phone Trademark ........................... : LANIX Model and/or type reference : Ilium L200 Serial Model： N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 08 Jun. 2015 Date of Issue .......................................... : 11 Jun. 2015 Test Result.............................................. : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 161 Report No.: STS1506010H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 12 5.1 Validation System 12 5.2 Validation Result 12 6. SAR Evaluation Procedures 13 7. EUT Antenna Location Sketch 14 7.1 SAR TEST EXCLUSION CONSIDER TABLE 15 8. EUT Test Position 17 9. Uncertainty 19 9.1 Measurement Uncertainty 19 9.2 System validation Uncertainty 21 10. Conducted Power Measurement 23 11. EUT And Test Setup Photo 38 11.1 EUT Photo 38 11.2 Setup Photo 41 12. SAR Result Summary 47 12.1 Head SAR 47 12.2 Body SAR And Hotspot 50 13. Equipment List 55 Appendix A. System Validation Plots 56 Appendix B. SAR Test Plots 80 Appendix C. Probe Calibration And Dipole Calibration Report 161 Page 4 of 161 Report No.: STS1506010H01 1. General Information 1.1 EUT Description Equipment smart phone Brand Name LANIX Model No. Ilium L200 Serial Model N/A FCC ID ZC4L200 Model Difference N/A Adapter Input: AC100-240V,150m A, 50/60 Hz Output: DC 5V, 500mA Battery Rated Voltage: 3.7V Charge Limit: 4.2V Capacity: 1600mAh Hardware Version WMDAb Software Version N/A Frequency Range GSM 850: 824.2~848.8MHz PCS1900: 1850.2~1909.8MHz WCDMA Band II:1852.4~1907.6MHz WCDMA Band V:826.4~846.6MHz LTE Band 2:1850.7~1909.3MHz LTE Band 4:1710.7~1754.3MHz LTE Band 7:2502.5~2567.5MHz LTE Band 17:706.5~713.5MHz WLAN 802.11b/g/n(HT20):2412~2462MHz WLAN 802.11n(HT40):2422~2452MHz Bluetooth:2402~ 2480MHz Transmit Power(MAX): GSM 850: 31.99 dBm GSM 1900: 28.53 dBm WCDMA Band II: 21.98 dBm WCDMA Band V: 22.81 dBm LTE Band 2: 20.75 dBm LTE Band 4: 21.56 dBm LTE Band 7: 21.23 dBm LTE Band 17: 22.87 dBm 802.11b: 11.06 dBm 802.11g: 10.65 dBm 802.11n(HT20): 10.07 dBm 802.11n(HT40): 18.79 dBm Bluetooth: 0.93 dBm Max. Reported SAR(1g): Head: GSM 850: 0373 W/kg GSM 1900: 0.295 W/kg WCDMA Band II: 0.513 W/kg WCDMA Band V: 0.399 W/kg LTE Band 2: 0.413 W/kg LTE Band 4: 1.267 W/kg LTE Band 7: 0.337 W/kg LTE Band 17: 0.149 W/kg WIFI: 0.285 W/kg Body: GSM 850: 0.341 W/kg GSM 1900: 0.321 W/kg WCDMA Band II: 0.722 W/kg WCDMA Band V: 0.507 W/kg LTE Band 2: 0.623 W/kg LTE Band 4: 1.344 W/kg LTE Band 7: 0.307 W/kg LTE Band 17: 0.197 W/kg WIFI: 0.150 W/kg Operating Mode: GSM: GSM Voice; GPRS; EGPRS Class 12; WCDMA:RMC,HSDPA,HSUPA Release 6; LTE:QPSK,16QAM; WLAN: 802.11 b/g/n(HT20) /n(HT40); Bluetooth: V4.0 + EDR (GFSK +π/4DQPSK+8DPSK) ; Antenna Specification: GSM,WCDMA,LTE: PIFA Antenna BT,WIFI: PIFA Antenna SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Hotspot Mode: Support DTM Mode: Not Support Page 5 of 161 Report No.: STS1506010H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building B, Zhuoke Science Park,No.190, Chongqing Road, Fuyong, Baoan District, Shenzhen, Guangdong, China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 Page 6 of 161 Report No.: STS1506010H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 …

Text truncated - open the document above for the full version.

Ref : ACR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING B, ZHUOKE SCIENCE PARK, No.190, CHONGQING ROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONG,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2014 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2014 Checked by : Jérôme LUC Product Manager 9/19/2014 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2014 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2014 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1506010F05 Issued for Corporativo Lanix S.A. de C.V. Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, México Product Name: smart phone Brand Name: LANIX Model No.: Ilium L200 Series Model: N/A FCC ID: ZC4L200 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 39 Report No.: STS1506010F05 TEST RESULT CERTIFICATION Applicant’s name ................. : Corporativo Lanix S.A. de C.V. Address .................................. : Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, México Manufacture's Name ............ : AMER MOBILE CO.,LIMITED Address .................................. : Room A30, 9th floor,Silvercorp International Tower No 707-713, Nathan Road, mongkok, Kowloon, Hong Kong Product description Product name ............................ : smart phone Model and/or type reference : Ilium L200 Serial Model .............................. : N/A Standards ............................. : FCC Part15.247 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, thidocument may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests.............. : 04 June. 2015 ~10 June. 2015 Date of Issue ........................................... : 11 June. 2015 Test Result ............................................... : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 39 Report No.: STS1506010F05 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 19 4.5 TEST RESULTS 19 4.6 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 23 5. CONDUCTED SPURIOUS EMISSIONS 24 5.1 REQUIREMENT 24 5.2 TEST PROCEDURE 24 5.3 TEST SETUP 24 5.4 EUT OPERATION CONDITIONS 24 5.5 TEST RESULTS 25 6. POWER SPECTRAL DENSITY TEST 28 6.1 APPLIED PROCEDURES / LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 Page 4 of 39 Report No.: STS1506010F05 Table of Contents Page 6.4 EUT OPERATION CONDITIONS 28 6.5 TEST RESULTS 29 7. BANDWIDTH TEST 31 7.1 APPLIED PROCEDURES / LIMIT 31 7.2 TEST PROCEDURE 31 7.3 TEST SETUP 31 7.4 EUT OPERATION CONDITIONS 31 7.5 TEST RESULTS 32 8. PEAK OUTPUT POWER TEST 34 8.1 APPLIED PROCEDURES / LIMIT 34 8.2 TEST PROCEDURE 34 8.3 TEST SETUP 34 8.4 EUT OPERATION CONDITIONS 34 8.5 TEST RESULTS 35 9. ANTENNA REQUIREMENT 37 9.1 STANDARD REQUIREMENT 37 9.2 EUT ANTENNA 37 10. EUT TEST PHOTO 38 Page 5 of 39 Report No.: STS1506010F05 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b) Peak Output Power PASS -- 15.247 (c) Radiated Spurious Emission PASS -- 15.247 (d) Power Spectral Density PASS -- 15.205 Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 6 of 39 Report No.: STS1506010F05 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment smart phone Trade Name LANIX Model Name Ilium L200 Serial Model N/A Model Difference N/A Product Description The EUT is a smart phone Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology BLE Number Of Channel 40 Antenna Designation: Please see Note 3. Antenna Gain (dBi) 0 dbi Channel List Please refer to the Note 2. Adapter Adapter Input:AC 100-240V,50/60Hz,150mA Output:DC 5V,500mA Battery Rated Voltage: 3.7V capacity :1600mAh Hardware version number WMDAb Software versioning number -- Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User'…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1506010F04 Issued for Corporativo Lanix S.A. de C.V. Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, México Product Name: smart phone Brand Name: LANIX Model No.: Ilium L200 Series Model: N/A FCC ID: ZC4L200 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 61 Report No.: STS1506010F04 TEST RESULT CERTIFICATION Applicant’s name .................. : Corporativo Lanix S.A. de C.V. Address .................................. : Carretera Internacional Hermosillo - Nogales Km 8.5 Hermosillo, Sonora, México Manufacture's Name ............ : AMER MOBILE CO.,LIMITED Address .................................. : Room A30, 9th floor,Silvercorp International Tower No 707-713, Nathan Road, mongkok, Kowloon, Hong Kong Product description Product name ......................... : smart phone Model and/or type reference . : Ilium L200 Serial Model ........................... : N/A Standards .............................. : FCC Part15.247 Test procedure ............................ : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equip…

Text truncated - open the document above for the full version.
