ZC4R10MOBILE PHONE

1 Contents 1. For your Safety..................................4 2. Mobile Phone Profile........................7 3. Preparation before Use....................9 Install SIM Card ................................. 9 Install Memory card ........................ 11 Install Battery .................................. 12 Charge Battery ................................ 12 Notices on using the battery ........... 14 PIN code .......................................... 15 4. General Instructions........................16 Dial key ............................................ 16 Switch‐on/off key /End key ............. 17 Standard keypad ............................. 17 AM/FM function key ....................... 18 2 Keypad lock ..................................... 18 Icons in Standby State ..................... 19 Language and Input Mode .............. 19 Services ........................................... 20 Callers’ group .................................. 20 5. Use of Menu Functions...................21 Phonebook..................................21 Call logs.......................................24 Multimedia.................................26 Camera........................................33 Fun & Games..............................34 Sociality......................................40 Twitter.........................................40 Messaging...................................41 Opera mini..................................47 Chatting.......................................47 3 Google.........................................48 Services.......................................48 Organizer.....................................51 Files manager.............................56 Settings........................................57 6. Editor Operation..............................70 Basic letter input ............................. 71 Number input .................................. 71 Symbol input ................................... 71 7. Use of USB........................................72 8. Maintenance & Safety....................72 After sales service ........................... 73 Charger and Adapter Safety ............ 73 Battery Information and Care ......... 73 General Notice ................................ 74 Troubleshooting .............................. 75 10. Abbreviations.................................78 4 1. For your Safety For your safety and proper use of the mobile phone, please read the following guidelines carefully: Do not switch the mobile phone on when close to chemical factory, gas station or other explosive objects.  During driving, please use headset for safety purpose; unless otherwise in emergency, always stop the car on roadside to have a call conversation.  Because the use of the mobile phone can cause interference in the aircraft, never use the mobile phone in aircraft. The use of the mobile phone is dangerous and illegal; do switch off the mobile phone before boarding.  Pay special attention to the use of the mobile phone near heart pacemaker, deaf‐aid and some other medical equipments, because the mobile phone can cause interference with them.  None‐original factory’s accessories and parts will lose guarantee. 5  Do not dismantle the mobile phone without permission. In case of failure, please contract the supplier as soon as possible.  Do not plug the charger into the mobile phone and charge without battery. Always power off the mobile phone when taking out the battery; otherwise the memory of the phone may be damaged.  When charging the mobile phone, always keep it in the place with good ventilation, heat sink and away from flammable and explosive objects.  In order to avoid demagnetization, always keep the mobile phone away from magnetic objects such as CD, credit card etc.  Ensure the mobile phone not to contact any liquid; once such case occurs, remove the battery and contact the supplier immediately.  Do not use the mobile phone in the environment at too high or too low temperature, never expose the mobile phone under strong sunshine or too wet environment. The suitable temperature for the phone and accessories is 0°C‐40°C. The height to use the phone shall be less than 6 2,000m.  Do not use liquid or wet cloth with strong cleanser to clean the mobile phone.  This mobile phone has shooting, videoing and audio recording functions, which shall be used as per the related laws and regulations.  Always keep the mobile phone out of children’s reach. Do not throw or vibrate the mobile phone because violent treatment to the mobile phone may damage the inner circuits and precise structures.  Please do not discard the waste battery into general household garbage. Please deal with the waste battery according to provisions where they are definitely made. Tip: This user manual is based on simplified Chinese operation mode; so it may vary in English operation mode. Warning: We will not be bear any responsibility for any incompliance with the above guidelines or improper use of the mobile phone. Our company keeps the right to make modifications to any of the content here in this user guide without public announcement in advance. The content of this manual may vary from the actual content displayed in the mobile phone. In such 7 case, the latter shall govern. 2. Mobile Phone Profile The mobile phone has one keypad, one single screen， one vibration motor, one charger/ data common transmission port. (Below is the front of the mobile phone). 1 2 3 4 7 9 10 5 6 8 8 7 6 1. Speaker 7.QWERTY keypad 2. LCD 8.Phonebook 3. Optical navigation 9.Retreat key 4. Main menu keys 10.End key 5. SEND 1 key(SIM‐1) 11.Speaker 9 11 12 9 6. SEND 2 key(SIM‐2) 12. Camera 3. Preparation before Use Install SIM Card When registering mobile phone number, you can apply for two different phone numbers, two different mobile phone network service providers and thus obtain two SIM (Subscriber Identification Module) cards. With these two SIM cards, you can use all functions of your mobile phone. The SIM car…

Text truncated - open the document above for the full version.

External Photos 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

FCC ID: ZC4R10 1. Label 2. Label Location

Date: June 21, 2011 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: ZC4R10 Dear Sirs: Corporativo Lanix SA de CV. requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier ZC4R10. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22H&24E for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Corporativo Lanix SA de CV. proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Corporativo Lanix SA de CV. will add the FCC identifier " ZC4T99" to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Yours Sincerely,

Internal Photos

Report No.: SZ11030128E05 Page 2 of 12 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 4 1.3 Facilities and Accreditations ...................................................................................................... 5 1.3.1 Facilities .................................................................................................................................... 5 1.3.2 Test Environment Conditions .................................................................................................... 5 1.3.3 Measurement Uncertainty ......................................................................................................... 5 2. TEST CONDITIONS SETTING............................................................................................... 6 2.1 Test Mode .................................................................................................................................... 6 2.2 Test Setup and Equipments List ................................................................................................ 7 2.2.1 Conducted Emission.................................................................................................................. 7 2.2.2 Radiated Emission ..................................................................................................................... 8 3. 47 CFR PART 15B REQUIREMENTS .................................................................................... 9 3.1 Conducted Emission ................................................................................................................... 9 3.1.1 Requirement .............................................................................................................................. 9 3.1.2 Test Description ........................................................................................................................ 9 3.1.3 Test Result ................................................................................................................................. 9 3.2 Radiated Emission .................................................................................................................... 11 3.2.1 Requirement ............................................................................................................................ 11 3.2.2 Test Description ...................................................................................................................... 11 3.2.3 Test Result ............................................................................................................................... 11 Change History Issue Date Reason for change 1.0 June 2, 2011 First edition Report No.: SZ11030128E05 Page 3 of 12 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ....................... Mobile Phone Serial No. ....................... (n.a, marked #1 by test site) Hardware Version ........... v1.0 Software Version ............ v2.0 Applicant ........................ Manufacturer .................. Corporativo Lanix SA de CV Carretera Internacional a Nogales KM 8.5 Hermosillo, Sonora, México 83260 SHENZHEN TINNO MOBILE TECHNOLOGY CORP 4/F, H-3 Building, OCT Eastern Industrial Park. No.1 XiangShan East Road, Nanshan Distict, ShenZhen, P. R. China Modulation Type ............ GPRS/GSM Mode with GMSK Modulation EDGE Mode with 8PSK Modulation Power Supply ................. Battery Model Name: R10-BAT Brand name: LANIX Capacitance: 850mAh Rated voltage: 3.7V Ancillary Equipment 1 ... AC Adapter (Charger for Battery) Model Name: R10-C Brand Name: LANIX Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 50- 60Hz, 120mA Rated Output: 5.0V, 500mA Note 1: The EUT is a Mobile Phone; it supports GSM 850MHz, 1900MHz, GPRS, EGPRS and ISM 2.4GHz Bluetooth module. Note 2: The EUT is equipped with a T-Flash card slot; equipped with a special port which can be connected to the ancillary equipments supplied by the manufacturer e.g. the AC Adapter and the USB Adapter Cable. The EUT outfits an inner Camera. Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ11030128E05 Page 4 of 12 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ11030128E05 Page 5 of 12 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 1.3.3 Measurement Unc…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2．RE
