ZC4S100GSM ANDROID MOBILE PHONE

1 User Manual 2 Index I. Cautions ..................................................................................................... 6 1 Safety Information ..................................................................................... 6 1.1 Traffic Safety First ................................................................................... 6 1.2 Turn Off in Hospital ................................................................................. 6 1.3 Turn Off in Airplane ................................................................................ 6 1.4 Turn Off When Refueling ........................................................................ 6 1.5 Turn Off near Blasting Sites ..................................................................... 6 2 Cautions on Mobile Phone Use ................................................................. 6 2.1 Interference ............................................................................................ 6 2.2Reasonable Use ....................................................................................... 6 2.3 Qualified Maintenance Service .............................................................. 6 2.4 Water‐Resistance .................................................................................... 6 2.5 Emergency Calls ...................................................................................... 6 3 Precautions for use of Battery ................................................................... 6 4 Cautions for Children ................................................................................. 7 II. Keys and Parts ........................................................................................... 7 III. Start to Use .............................................................................................. 8 1 Battery ....................................................................................................... 8 1.1 Remove/Insert the Battery ..................................................................... 8 1.2 Charge the Battery .................................................................................. 9 2 Connecting to Network ........................................................................... 10 2.1 SIM Card ............................................................................................... 10 2.2 Insert and Remove the SIM Card .......................................................... 10 2.3 Insert/Remove the Memory Card. ....................................................... 11 2.4 Switch ON/OFF ..................................................................................... 11 2.5 Unlock SIM Card ................................................................................... 11 2.6 Connection to Network ........................................................................ 12 IV. Basic Functions ...................................................................................... 12 1 Make calls ................................................................................................ 12 1.1 Make Domestic Calls ............................................................................. 12 1.2 Call Extension Phone ............................................................................ 13 1.3 Make International Calls ....................................................................... 13 1.4 Make Listed Calls .................................................................................. 13 2 Emergency Calls ....................................................................................... 14 3 3 Answer Calls ............................................................................................. 14 4 Call History ............................................................................................... 14 5 Connection Option .................................................................................. 14 V. Function Menu Instruction ..................................................................... 15 1. TELCEL ..................................................................................................... 15 2. iTelcel ...................................................................................................... 15 3.Ideas ........................................................................................................ 15 4.iApps ........................................................................................................ 15 5. Music ...................................................................................................... 15 6.Portal Movil ............................................................................................. 16 7.MSNGR .................................................................................................... 16 8.Ideasmusik ............................................................................................... 16 9.Videos ...................................................................................................... 16 10. Camera .................................................................................................. 16 11. File Explorer .......................................................................................... 17 12.Plugger ................................................................................................... 17 13.iJuegos ................................................................................................... 17 14.Google Search ........................................................................................ 17 15. Settings ................................................................................................. 17 15.1 Wireless & networks .......................................................................... 17 15.2.1 Bluetooth ...............................................................................…

Text truncated - open the document above for the full version.

External Photos

FCC ID: ZC4S100 Label Label Location

Date: May 22, 2012 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: ZC4S100 Dear Sirs: Corporativo Lanix S.A. de C.V. requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier ZC4S100. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22H&24E for GSM&WCDMA mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Corporativo Lanix S.A. de C.V. proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Corporativo Lanix S.A. de C.V. will add the FCC identifier " ZC4S100 " to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter.

Internal Photos 2G&3G Antenna BT WIFI FM GPS Antenna

Report No.: SZ12040159E01 Page 2 of 16 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 4 1.3 Facilities and Accreditations ...................................................................................................... 5 1.3.1 Facilities .................................................................................................................................... 5 1.3.2 Test Environment Conditions .................................................................................................... 5 1.3.3 Measurement Uncertainty ......................................................................................................... 5 2. TEST CONDITIONS SETTING............................................................................................... 6 2.1 Test Mode .................................................................................................................................... 6 2.2 Test Setup and Equipments List ................................................................................................ 7 2.2.1 Conducted Emission.................................................................................................................. 7 2.2.2 Radiated Emission ..................................................................................................................... 8 3. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 3.1 Conducted Emission ................................................................................................................. 11 3.1.1 Requirement ............................................................................................................................ 11 3.1.2 Test Description ...................................................................................................................... 11 3.1.3 Test Result ............................................................................................................................... 11 3.2 Radiated Emission .................................................................................................................... 13 3.2.1 Requirement ............................................................................................................................ 13 3.2.2 Test Description ...................................................................................................................... 13 3.2.3 Test Result ............................................................................................................................... 13 Change History Issue Date Reason for change 1.0 May 10, 2012 First edition Report No.: SZ12040159E01 Page 3 of 16 1. GENERAL INFORMATION 1.1 EUT Description EUT Type .......................... GSM Android Mobile Phone Serial No............................ (n.a, marked #1 by test site) Hardware Version .............. N/A Software Version ............... Ilium S100_TELCEL_SW_01 Applicant ........................... Manufacturer ..................... CORPORATIVO LANIX S.A. DE C.V. CARRETERA INTERNACIONAL A NOGALES KM 8.5 C.P. 83160 HERMOSILLO SONORA, MEXICO Shanghai Huaqin Telecom Technology Co., Ltd. NO.1 Building, 399 Keyuan Road, Zhangjiang Hi-Tech Park, Pudong New Area, Shanghai, China 201203 Power Supply .................... Battery Brand Name: Lanix Model No.: S100-BAT Serial No.: (n.a. marked #1 by test site) Capacitance: 1400mAh Rated Voltage: 3.7V Charge Limit: 4.2V Ancillary Equipment 1 ...... AC Adapter (Charger for Battery) Brand Name: Lanix Model Name: S100-C Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 0.15A, 50/60Hz Rated Output: 5V, 500mA Note 1: The EUT is GSM Android Mobile Phone, it supports GSM 850MHz, 1900MHz, GPRS, EGPRS, WCDMA 850MHz, 1900MHz, HSDPA, ISM 2.4G Bluetooth and WIFI bands. Note 2: The EUT is equipped with a T-Flash card slot; equipped with a USB port which can be connected to the ancillary equipments supplied by the manufacturer e.g. the AC Adapter and the USB Cable. Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ12040159E01 Page 4 of 16 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2009. Report No.: SZ12040159E01 Page 5 of 16 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 - 60 Atmospheric Pressure (kPa): 86 - 106 1.3.3 M…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2．RE
