ZC4S50GSM PHONE

1 Content For your Safety .................................................................. 4 Mobile Phone Profile ......................................................... 7 Preparation before Use ..................................................... 9 Basic Operation ............................................................... 15 Personalizing ................................................................... 20 Use of Menu Functions .................................................... 24 TELCEL .................................................................................. 24 iTelcel ................................................................................... 24 Ideas .................................................................................... 24 iApps .................................................................................... 25 Music ................................................................................... 25 Portal Movil ......................................................................... 27 MSN Talk Pro ....................................................................... 27 Imk ....................................................................................... 27 Videos .................................................................................. 27 Camera ................................................................................ 28 Mis archives ......................................................................... 30 Plugger ................................................................................. 30 Ijuegos ................................................................................. 30 Google search ...................................................................... 30 Settings ................................................................................ 30 2 iVideos ................................................................................. 40 Mi Telcel ............................................................................... 40 Sound Recorder .................................................................... 40 Calculator ............................................................................. 42 Calendar ............................................................................... 43 Contacts ............................................................................... 47 Downloads ........................................................................... 49 Call logs ................................................................................ 49 Clock .................................................................................... 50 Gallery.................................................................................. 53 FM Radio .............................................................................. 55 iDeportes.............................................................................. 56 iPromocion ........................................................................... 56 Notas ................................................................................... 56 RSS ....................................................................................... 57 Messaging ............................................................................ 57 Phone ................................................................................... 63 iSuscripcion .......................................................................... 70 Latitude ................................................................................ 70 Maps .................................................................................... 70 Market ................................................................................. 70 Places ................................................................................... 71 Video wallpaper ................................................................... 71 3 Youtube ................................................................................ 71 Gmail ................................................................................... 72 Books ................................................................................... 72 G talk ................................................................................... 72 Browser ................................................................................ 72 Google + ............................................................................... 72 iRadio ................................................................................... 73 Messenger ........................................................................... 73 Music ................................................................................... 73 Frequently Asked Questions (FAQ) .................................. 73 Keyboard .............................................................................. 73 Wi‐Fi .................................................................................... 75 Bluetooth ............................................................................. 79 Maintenance & Safety ..................................................... 86 4 For your Safety For your safety and proper use of the mobile phone, please read the following guidelines carefully: Do not switch the mobile phone on when close to chemical factory, gas station or other explosive objects.  While driving, please use headset for safety purposes, unless otherwise in emergency, always stop the car on roadside to have a call conversation.  Because the use of the mobile phone can cause interference in the aircraft, never use the mobile phone in an aircraft. The use of the mobile phone is dangerous and illegal; do switch off the mobile phone before boarding.  Pay special attention to the use of the mobile phone near heart pacemaker, deaf‐aid and some other medical equipment, because the mobile phone ca…

Text truncated - open the document above for the full version.

External Photos

FCC ID: ZC4S50 Label Label Size: 55*25mm Label Location FCC ID FCC ID Label Location

Date: Sept. 21, 2012 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: ZC4S50 Dear Sirs: Corporativo Lanix SA de CV requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier ZC4S50. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22H&24E for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Corporativo Lanix SA de CV proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Corporativo Lanix SA de CV will add the FCC identifier " ZC4S50 " to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter.

Internal Photos

Report No.: SZ12070194E01 Page 2 of 16 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 4 1.3 Facilities and Accreditations ...................................................................................................... 5 1.3.1 Facilities .................................................................................................................................... 5 1.3.2 Test Environment Conditions .................................................................................................... 5 1.3.3 Measurement Uncertainty ......................................................................................................... 5 2. TEST CONDITIONS SETTING............................................................................................... 6 2.1 Test Mode .................................................................................................................................... 6 2.2 Test Setup and Equipments List ................................................................................................ 7 2.2.1 Conducted Emission.................................................................................................................. 7 2.2.2 Radiated Emission ..................................................................................................................... 8 3. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 3.1 Conducted Emission ................................................................................................................. 11 3.1.1 Requirement ............................................................................................................................ 11 3.1.2 Test Description ...................................................................................................................... 11 3.1.3 Test Result ............................................................................................................................... 11 3.2 Radiated Emission .................................................................................................................... 13 3.2.1 Requirement ............................................................................................................................ 13 3.2.2 Test Description ...................................................................................................................... 13 3.2.3 Test Result ............................................................................................................................... 13 Change History Issue Date Reason for change 1.0 September 20, 2012 First edition Report No.: SZ12070194E01 Page 3 of 16 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ..........................Mobile Phone Serial No............................(n.a, marked #1 by test site) Hardware Version ............. .V1.0 Software Version ...............V1.0 Applicant ........................... Manufacturer ..................... Corporativo Lanix S.A.de C.V. Carretera International Hermosillo-Nogales Km 8.5,Hermosillo Sonora, Mexico Shenzhen Tinno Mobile Technology Corp.. 4/F, H-3 Building, OCT Eastern industrial Park, No.1 Xiang Shan East Road, Nan Shan District, Shenzhen, P.R. China. Power Supply ................... .Battery Brand Name: LANIX Model No.: S50-BAT Serial No.: (n.a. marked #1 by test site) Capacitance: 1300mAh Rated Voltage: 3.7V Charge Limit: 4.2V Note 1: The EUT is a Mobile Phone which is equipped with a T-Flash card slot; equipped with a USB port which can be connected to the ancillary equipments supplied by the manufacturer e.g. the AC Adapter and the USB Cable. Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ12070194E01 Page 4 of 16 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2009. Report No.: SZ12070194E01 Page 5 of 16 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 1.3.3 Measurement Uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncertainty in Measurement" (GUM) published by ISO. Uncertainty of Conducted Emission: ±1.8dB Uncertainty of Radiated Emission: ±3.1dB Report No.: SZ12070194E01 Page 6 of 16 2. TEST CONDITIONS SETTING 2.1 Te s t M o d e (1) The first test …
