ZC4S600Smartphone

Corporativo Lanix S.A. de C.V.
Smartphone - FCC ID ZC4S600 - Corporativo Lanix S.A. de C.V.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 09, 2013
Application Purpose
Original Equipment
Date of Application
Sep 09, 2013
Equipment Note
Smartphone
Frequency Range
2402.00000000 - 2480.00000000
Company
Corporativo Lanix S.A. de C.V.
Country
Mexico

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗
↗
↗
↗
↗
↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Ad-HocCountry Code Cover Letter We, Corporativo Lanix S.A. de C.V., declare that this EUT (FCC ID: Z4CS600) doesn’t have Ad Hoc Mode function on “non-US/Canada frequencies”. In addition, the frequency selection feature is disable by firmware for device marketed to the US/Canada. For DTS part of this device, only channel 1~11 will be used in North America. Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Oscar Guzman Corporativo Lanix S.A. de C.V. Project Manager Te l : 6621090800-243 Fax: 6621090848 Email: [email protected]

Cover Letter(s)

Date: 26 August, 2013 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Corporativo Lanix S.A. de C.V., the undersigned, hereby authorizes Mr. Ivy Zhu from Shenzhen Morlab Communications Technology Co., Ltd.,, to act on the behalf of the Corporativo Lanix S.A. de C.V. solely in matters relating to the application for an FCC equipment authorization for FCC ID: ZC4S600 including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen Morlab Communications Technology Co., Ltd..in connection with the Application shall have the same effect as acts of the Corporativo Lanix S.A. de C.V. The Corporativo Lanix S.A. de C.V. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Yours Sincerely, Oscar Guzman Manager

Cover Letter(s)

Date: 26 August, 2013 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 RE: Corporativo Lanix S.A. de C.V. FCC ID: ZC4S600 FCC Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Corporativo Lanix S.A. de C.V. requests that the following documents regarding this submission for FCC ID: ZC4S600 be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description Operational Description.pdf Part list BOM.pdf Tune-Up-Procedure Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which Corporativo Lanix S.A. de C.V. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Corporativo Lanix S.A. de C.V. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Thank you for your attention to this matter. Yours Sincerely, Oscar Guzman Manager

External Photos

External Photos 1. EUT full view with accessories 2. EUT front view 3. EUT rear view 4. EUT left side view 5. EUT right side view 6. EUT top view 7. EUT bottom view

ID Label/Location Info

FCC label and label location 1. Label 2. Label location Label location

Internal Photos

In ternal Photos 1. EUT uncover view 2. Mainboard front view with shielding 3. Mainboard rear view 4. Mainboard front view without shielding 5. Sub board view 6. GSM/WCDMA chip view 7. CPU chip view 8. BT/WIFI chip view 9. GSM/WCDMA antenna view 10. BT/WIFI antenna view

RF Exposure Info

文件编号: A-BV-0014V1.0 电话:0755-86095550 传真:0755-86095551 供应商 PROVIDER: 硕贝德无线科技股份有限公司 APPROVED BY VENDOR 确认校对审核批准 适用机种 APPLICATION: S9201 日期 DATE: 2013-1-22 物料编码 PART NO:F.0A.BV.0031-000-WA 品牌(制造商) BRAND: 物料描述 DESCRIBE: S9201-BT&WIFI天线 物料型号 PRODUCTS:S9201-BT&WIFI 承 认 书 ( 结构件 类) SPECIFICATION FOR APPROVAL 一、 二、 三、 四、 五、 六、 七 八、 九、 十、 十一、 目 录 包装.........................................................15 QC工程图.............................................11-12 可靠性测试报告..........................................13 材质证明...................................................14 天线结构图................................................8 全尺寸检测报告..........................................9 CPK报告...................................................10 封面.........................................................1 目录.........................................................2 变更履历...................................................3 电特性...................................................4-7 序号 变更日期项目名称版本变更内容备注 12013-1-22S9201-BT&WIFIA新版发行 四、电特性 1. Antenna Structure 2. Matching Network 3. Passive Test 1. Return Loss Test Equipment:HP8753E Test Result: Figure3.1 S11 curve 2. Vswr Test Equipment:HP8753E Result: Figure3.2 S11 curve 3. Smith Test Equipment:HP8753E Result: Figure3.3 smith curve 4. Radiation Pattern Test Equipment:Satimo StarLab, HP8753E, Shielding R Antenna Range Axis Definition figure3.4.1 BT XY plane Antenna patternfigure 3.4.2 BT ZX plane Antenna pattern figure3.4.3 BT YZ plane Antenna pattern 5. 3D radiation pattern 7. Peak gain Test Equipment:Satimo StarLab, HP8753E, Shielding R Figure 3.7 Antenna gain curve 8. Efficiency Test Equipment:Satimo StarLab, HP8753E, Shielding R Figure 3.8 Antenna efficiency curve 8. Main Antenna efficiency and gain table Frequency (MHz) 240024502500 Efficiency (%) 31.832.731.9 Gain (dB) 1.611.681.22 Table1 Main Antenna efficiency and gai 4. Materials Table3 antenna material 5. Conclusion Test results arrive at customer requirement. Recommend that customers to accept materialsFPC Antennamodule bracketPC+ABS 图面所在位置(提供天珑原2D图) Rev(版本 MEASURED DIMENSION(实测尺寸) DISPOSITION DIM. # DIMENSION DRAWING ZONE + TOL.- TOL. NOTE SAMPLE 1SAMPLE 2SAMPLE 3SAMPLE 4 SAMPLE 5 UPPERLOWER 0%-25% 25%-50%50%-75% 75%-100% 100%+ Re-Measure Accept Fix Tool Accept With Variance DIMENSION+ TOL.- TOL. 13.160.10(0.10)3.103.113.123.113.140%-60% 22.700.30(0.30)2.942.872.842.742.7680%0% X 33.590.30(0.30)3.673.643.583.673.6527%-3%X 40.850.05(0.05)0.810.830.820.810.820%-80% 5 6 7 8 9 10 11 2013.1.22 全尺寸测量报告 Tool Number(模号 Comments(设计者 签字) S9201-BT&WIFIA % TOLERANCE USED(公差使用百分比 ACCEPTABLE VARIANCE BV-0031 Cav. Number(穴数)Unit(单位) 硕贝德 材质牌号 S9201- BT&WIFI Part Name (零件名称) 日期 Vendor(供应商) 材质名称 FPC Part NO(料号) INCHESMILLIMETERS Part Number(料号)Vendor(供应商) Description(零件名称)Inspected(确认者) Tool Number(模号) Inches/MM(英寸/毫米) Material Name(材质名称) Material Code(材质牌号) Revision(版本)Date(日期) 1234567891011 9.016.76 0.100.10 -0.10-0.10 9.116.86 8.916.66 9.006.79 9.016.77 9.006.83 8.996.75 9.016.78 9.026.79 9.026.80 8.996.77 8.976.78 8.996.74 8.976.78 9.016.79 8.956.74 8.966.78 9.016.75 9.026.78 9.026.74 9.006.77 9.006.77 9.026.78 8.996.79 9.016.77 8.976.74 9.026.72 9.016.75 9.006.77 9.016.78 8.996.79 9.006.77 8.996.78 9.026.830.000.000.000.000.000.000.000.000.00 8.956.720.000.000.000.000.000.000.000.000.00 9.006.77##########################DIV/0!############### 0.020.02##########################DIV/0!############### 1.761.49##########################DIV/0!############### 1.551.32##########################DIV/0!############### 审核: 杨茂泉制表:邓小玲日期:2013.1.22 CP Cpk TOOLING(测量工具 Cavity(穴号) MAX. MIN. AVERAGE STDEV 27 28 29 30 23 24 25 26 19 20 21 22 15 16 17 18 11 12 13 14 7 8 9 10 3 4 5 6 Upper Limit(规格上限) Lower Limit(规格下限) 1 2 Dim. Designator(尺寸序号) Nominal(公称尺寸) + Tolerance(正公差) - Tolerance(负公差) A2013-1-22 mm CPK Report BV-0031硕贝德 S9201-BT&WIFI邓小玲 A.0 页 码 Page 生效日期 Operation Date 流程编号 Process Number 制程描述 Process Description 产品 Product 频率 Freq 担当 Inspector 记录 record 每批 每批 每批 每批 每批 每批 每批 每批 每批 贴FPC半成品2H/次IPQC IPQC巡检 报告 压FPC半成品2H/次IPQC IPQC巡检 报告 RF测试成品全检RFQCRF检验报表 FQC成品全检FQC FQC检验报 表 包装成品2H/次IPQC IPQC巡检 报告 RoHS符合性 RoHS符合性 IQC IQC IQC检验报 告 IQC检验报 告 1 2 IQC FPC 支架 包装按包装要求进行包装目检符合包装要求 成品检验全检目检 支架不可变形,FPC不可起翘,不 可压伤,贴歪,金手指不可有脏 污,划伤. RF性能 全检 记录50pcs驻波值 网络分析仪RF一致性符合设定要求 FPC/支架 首(末)件5pcs检查,并记录 于IPQC检验报告,每2H巡检1 次/生产自检 目检 支架不可变形,FPC不可起翘、压 伤 FPC 首(末)件5pcs检查,并记录 于IPQC检验报告,每2H巡检1 次/生产自检 目检 FPC不可起翘,贴歪金手指不可有 脏污,划伤, 标识全检 每个包装是否贴有环保标识?标 识是否符合要求? 标识符合要求,无漏贴。 测试按《IQC检验指导书》 核对RoHS检测报告、测试按《 IQC检验指导书》 RoHS检测报告符合要求,测量结果满足 客户要求或《产品环境管理,限、禁用 物质管理标准》(SCT.S/JY8.2-13)要 求 尺寸 5PCS 用数显卡尺、二次元进行量测《支架图纸》 外观、颜色 、材质 抽检,按GB2828-2003一般II 级水平,AQL:CR=0, MAJ=0.25,MIN=1.0抽样 目检、依据《来料检验标准》 《支架图纸》 支架不可有缺胶,缩水,毛刺不良 。 标识全检 每个包装是否贴有环保标识?标 识是否符合要求? 标识符合要求,无漏贴。 测试按《IQC检验指导书》 核对RoHS检测报告、测试按《 IQC检验指导书》 RoHS检测报告符合要求,测量结果满足 客户要求或《产品环境管理,限、禁用 物质管理标准》(SCT.S/JY8.2-13)要 求 盐雾试验 5PCS 《盐水(雾)试验标准》《盐水(雾)试验标准》 尺寸 5PCS 用数显卡尺、二次元进行量测 《FPC图纸》重点管控弹簧内径尺 寸 外观、颜色 、材质 抽检,按GB2828-2003一般II 级水平,AQL:CR=0, MAJ=0.25,MIN=1.0抽样 目检、依据《来料检验标准》 《FPC图纸》 FPC金手指不可有划伤,氧化,基 材不可有折痕,掉漆 适用范围Hold True Range 控制项目 control item 检验方式 check mode 检验方法 Check method 判定标准 Evaluation standard 惠 州 硕 贝 德 无 线 科 技 股 份 有 限 公 司 SPEED WIRELESS TECHNOLOGY CO.,LTD 文件名称 File NameS9101B-BT QC工程图文件编号File NO版本Edition No第1页,共2页 1 Of 2 A.0 页 码 Page 生效日期 Operation Date 每批 每批 每批 每批 支架不可变形,FPC不可起翘,不 可压伤,贴歪金手指不可有脏污, 划伤,不可有混料。 RoHS符合性 外观 抽检,按GB2828-2003一般II 级水平,AQL:CR=0, MAJ=0.25,MIN=1.0抽样 OQC OQC出厂检 验报告 作成:审核:批准: 3出货检验 标识全检 每个包装是否贴有环保标识?标 识是否符合要求? 标识符合要求,无漏贴。 测试按《OQC出货检验指导书 》 核对RoHS检测报告、测试按《 OQC出货检验指导书》 RoHS检测报告符合要求,测量结果满足 客户要求或《产品环境管理,限、禁用 物质管理标准》(SCT.S/JY8.2-13)要 求 包装标识 全检目视 《产品包装标识规范》 适用范围Hold True Range 重点尺寸 5PCS 卡尺/二次元《成品外观图》 成品 每批 目视 惠 州 硕 贝 德 无 线 科 技 股 份 有 限 公 司 SPEED WIRELESS TECHNOLOGY CO.,LTD 文件名称 File NameS9101B-BT QC工程图文件编号File NO版本Edition No第2页,共2页 2 Of 2 客户天珑样品来源 A 项目名称 成品料号 BV-0031 送检人吴娜测试日期2013-1-18 项目测试仪器测试条件判定标准12345 1 恒温恒湿 箱 将样品放置在温度为 85 °C+/-2°C的高温环境内 16H,试验完后在常温下 放置2H后检查外观 部件无裂痕、明显 的变形、脱落现 象,RF测试通过 OKOKOKOKOK 2 恒温恒湿 箱 将样品放置在温度为 - 40°C+/-2°C的低温环境 内…

Text truncated - open the document above for the full version.

RF Exposure Info

SZ13080066S01 Page 2 of 156 DIRECTORY 1. TESTING LABORATORY ......................................................................................................... 4 1.1. Identification of the Responsible Testing Location .............................................................. 4 1.2. Accreditation Certificate ........................................................................................................ 4 1.3. List of Test Equipments .......................................................................................................... 4 2. TECHNICAL INFORMATION ............................................................................................... 5 2.1. Identification of Applicant ..................................................................................................... 5 2.2. Identification of Manufacturer .............................................................................................. 5 2.3. Equipment Under Test (EUT) ................................................................................................ 5 2.3.1. Photographs of the EUT .................................................................................................. 5 2.3.2. Identification of all used EUT ......................................................................................... 6 2.4. Applied Reference Documents ............................................................................................... 6 2.5. Device Category and SAR Limits .......................................................................................... 6 2.6. Test Environment/Conditions ................................................................................................ 7 3. SPECIFIC ABSORPTION RATE (SAR) ................................................................................ 8 3.1. Introduction ............................................................................................................................. 8 3.2. SAR Definition......................................................................................................................... 8 4. SAR MEASUREMENT SETUP ............................................................................................... 9 4.1. The Measurement System ...................................................................................................... 9 4.2. Probe ........................................................................................................................................ 9 4.3. Probe Calibration Process .................................................................................................... 11 4.3.1 Dosimetric Assessment Procedure ........................................................................................ 11 4.3.2 Free Space Assessment Procedure ........................................................................................ 11 4.3.2 Temperature Assessment Procedure..................................................................................... 11 4.4. Phantom ................................................................................................................................. 12 4.5. Device Holder ........................................................................................................................ 12 5. TISSUE SIMULATING LIQUIDS ......................................................................................... 13 6. UNCERTAINTY ASSESSMENT ........................................................................................... 14 6.1. UNCERTAINTY EVALUATION FOR EUT SAR TEST ................................................. 14 6.2. UNCERTAINTY FOR SYSTEM PERFORMANCE CHECK ........................................ 15 7. SAR MEASUREMENT EVALUATION ............................................................................... 17 7.1. System Setup .......................................................................................................................... 17 SZ13080066S01 Page 3 of 156 7.2. Validation Results .................................................................................................................. 18 8. OPERATIONAL CONDITIONS DURING TEST ................................................................ 19 8.1. Informations on the testing .................................................................................................. 19 8.2. Body-worn Configurations ................................................................................................... 20 8.3. Measurement procedure ....................................................................................................... 20 8.4. Description of interpolation/extrapolation scheme ............................................................ 21 9. MEASUREMENT OF CONDUCTED PEAK OUTPUT POWER ..................................... 22 10. TEST RESULTS LIST .............................................................................................................. 26 11. HOTSPOT MODE EVALUATION PROCEDURE .............................................................. 30 12. MULTIPLE TRANSMITTERS EVALUATION ................................................................ 31 ANNEX A GRAPH TEST RESULTS ............................................................................................ 34 Change History Issue Date Reason for change 1.0 Aug. 27, 2013 First edition SZ13080066S01 Page 4 of 156 1. Testing Laboratory 1.1. Identification of the Responsible Testing Location Name: Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory Address: FL.3, Building A, FeiYang Science Park, No.8 LongChang Road, Block 67, BaoAn District, ShenZhen, GuangDong Province, P. R. China 518101 1.2. Accreditation Certificate Accredited Testing Laboratory: No. CNAS L3572 1.3. List of Test Equipments No. Instrument Type Cal. Date Cal. Due 1 PC Dell (Pentium IV 2.4GHz, SN:X10-23533) (n.…

Text truncated - open the document above for the full version.

Test Report

SZ13080066W04 Page 2 of 79 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 6 2.1. Antenna requirement ................................................................................................................. 6 2.2. Peak Output Power.................................................................................................................... 6 2.3. Bandwidth ................................................................................................................................. 9 2.4. Conducted Spurious Emissions and Band Edge ..................................................................... 18 2.5. Power spectral density (PSD) ................................................................................................. 31 2.6. Restricted Frequency Bands.................................................................................................... 40 2.7. Conducted Emission ............................................................................................................... 52 2.8. Radiated Emission................................................................................................................... 55 2.9. RF exposure evaluation ........................................................................................................... 79 Change History Issue Date Reason for change 1.0 August 26, 2013 First Edition SZ13080066W04 Page 3 of 79 1. General Information 1.1. EUT Description EUT Type ............................. : Smartphone Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : V1.0 Software Version .................. : Applicant .............................. : Manufacturer ........................ : V1 Corporativo Lanix S.A. de C.V. Carretera Internacional Hermosillo-Nogales Km 8.5,Hermosillo Sonora, Mexico Tinno Mobile Technology Corp. 4/F, H-3 Building, OCT Eastern industrial Park, No.1 XiangShan East Road.,Nan Shan District, Shenzhen, P.R. China. Frequency Range .................. : 802.11b/g/n-20MHz: 2.412GHz - 2.462GHz 802.11n-40MHz: 2.422GHz- 2.452GHz Channel Number................... : 802.11b/g/n-20MHz: 11 802.11n-40MHz: 7 Modulation Type .................. : DSSS (802.11b), OFDM (802.11g/n) Antenna Type ........................ : PIFA Antenna Antenna Gain ........................ : 1.68dBi Note 1: The EUT is Smartphone, it contains WIFI Module operating at 2.4GHz ISM band; it supports 802.11b, 802.11g, 802.11n and they are all tested in this report. Note 2: For 802.11b/g/n-20MHz, the frequencies allocated is F (MHz) =2412+5*(n-1) (1<=n<=11). The lowest, middle, highest channel numbers of the EUT used and tested in this report are separately 1 (2412MHz), 6 (2437MHz) and 11 (2462MHz). For 802.11n-40MHz, the frequencies allocated is F (MHz) =2412+5*(n-1) (3<=n<=9). The lowest, middle, highest channel numbers of the EUT used and tested in this report are separately 3 (2422MHz), 6 (2437MHz) and 9 (2452MHz). Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 4: The antenna connector of EUT is designed with permanent attachment and no consideration of replacement. SZ13080066W04 Page 4 of 79 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Wi-Fi, 2.4GHz ISM band radiators) for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.203 Antenna Requirement PA S S 2 15.247(b) Peak Output Power PASS 3 15.247(a) Bandwidth PASS 4 15.247(d) Conducted Spurious Emission and Band Edge PASS 5 15.247(d) Restricted Frequency Bands PASS 6 15.207 Conducted Emission PASS 7 15.209 ,15.247(d) Radiated Emission PASS 8 15.247(e) Power spectral density (PSD) PASS 9 15.247(i), 1.1307&2.1093 RF exposure evaluation PA S S The tests of Conducted Emission and Radiated Emission were performed according to the method of measurements prescribed in ANSI C63.4 2009. These RF tests were performed according to the method of measurements prescribed in KDB558074 D01 V03 (04/09/2013). SZ13080066W04 Page 5 of 79 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at FL.1, Building A, FeiYang Science Park, Block 67, BaoAn District, Shenzhen, 518101 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.10 2009, ANSI C63.4 2009 and CISPR Publication 22; the FCC registration number is 695796. 1.3.2. Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 SZ13080066W04 Page 6 of 79 2. 47 CFR Part 15C Requirements 2.1. Antenna requirement 2.1.1. Applicable Standard According to FCC 15.203, an intentional radiator shall be designed to ensure that no antenna…

Text truncated - open the document above for the full version.

Test Report

SZ13080066W03 Page 2 of 36 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 6 2.1. Antenna requirement ................................................................................................................. 6 2.2. Peak Output Power.................................................................................................................... 6 2.3. Average power .......................................................................................................................... 9 2.4. 6dB & 99%Bandwidth ............................................................................................................ 10 2.5. Conducted Spurious Emissions and Band Edge ..................................................................... 13 2.6. Power spectral density (PSD) ................................................................................................. 17 2.7. Restricted Frequency Bands.................................................................................................... 20 2.8. Conducted Emission ............................................................................................................... 24 2.9. Radiated Emission................................................................................................................... 27 2.10. RF exposure evaluation ........................................................................................................... 36 Change History Issue Date Reason for change 1.0 August 26, 2013 First edition SZ13080066W03 Page 3 of 36 1. General Information 1.1. EUT Description EUT Type ............................. : Smartphone Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : V1.0 Software Version .................. : Applicant .............................. : Manufacturer ........................ : V1 Corporativo Lanix S.A. de C.V. Carretera Internacional Hermosillo-Nogales Km 8.5,Hermosillo Sonora, Mexico Tinno Mobile Technology Corp.. 4/F, H-3 Building, OCT Eastern industrial Park, No.1 XiangShan East Road.,Nan Shan District, Shenzhen, P.R. China. Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (40 channels, at intervals of 2MHz); Modulation Type .................. : GFSK Antenna Type ........................ : PIFA Antenna Antenna Gain ........................ : 1.68dBi Note 1: The EUT is Smartphone, it contain Bluetooth 4.0 LE Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth 4.0 LE is F(MHz)=2402+2*n (0<=n<=39). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 19 (2440MHz) and 39 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. SZ13080066W03 Page 4 of 36 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC Certification: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section in CFR 47 Description Result 1 15.203 Antenna Requirement PA S S 2 15.247(b) Peak Output Power PASS 3 15.247(b) Average power PASS 4 15.247(a) 6dB Bandwidth PASS 5 15.247(a) 99% Bandwidth PASS 8 15.247(d) Conducted Spurious Emission and Band Edge PA S S 9 15.247(d) Restricted Frequency Bands PASS 10 15.207 Conducted Emission PASS 11 15.209 15.247(d) Radiated Emission PASS 12 15.247(e) Power spectral density (PSD) PASS 10 15.247(i). §1.1307&2.1093 RF exposure evaluation PASS The tests of Conducted Emission and Radiated Emission were performed according to the method of measurements prescribed in ANSI C63.4 2009. These RF tests were performed according to the method of measurements prescribed in KDB558074 D01 V03 (04/09/2013). SZ13080066W03 Page 5 of 36 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at FL.1, Building A, FeiYang Science Park, Block 67, BaoAn District, Shenzhen, 518101 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.10 2009, ANSI C63.4 2009 and CISPR Publication 22; the FCC registration number is 695796. The IC registration number is 7183A-2. 1.3.2. Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 SZ13080066W03 Page 6 of 36 2. 47 CFR Part 15C Requirements 2.1. Antenna requirement 2.1.1. Applicable Standard According to FCC 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply …

Text truncated - open the document above for the full version.

Test Setup Photos

1 EUT Right Head Touch Cheek Position 2 EUT Right Head Tilt15 Position SZ13070112S01 Page 2 of 7 3 EUT Left Head Touch Cheek Position 4 EUT Left Head Tilt15 Position SZ13070112S01 Page 3 of 7 5 Side Position with earphone 6 Side Position 10mm 10mm SZ13070112S01 Page 4 of 7 7.Face Position 8. Edge A 10mm 10mm SZ13070112S01 Page 5 of 7 9. Edge B 10. Edge C 10mm 10mm SZ13070112S01 Page 6 of 7 11. Edge D Liquid Level Photo Head Liquid Liquid depth: 15.1cm 10mm SZ13070112S01 Page 7 of 7 Liquid Level Photo Body Liquid Liquid depth :15.5cm

Test Setup Photos

Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (9KHz-30MHz) 4. Radiated emission (30MHz-1GHz) 5. Radiated emission (above 1GHz) 6. Conducted emission antenna’s port

Contact Information

Applicant

Max Gaxiola(Product Manager)
[email protected]6621090800Fax: 6621090848

Technical Contact

Shenzhen Morlab Communications Technology Co.,LtdIvy Zhu
[email protected]86-755-36698618

FL.3, Building A, FeiYang Science Park · ShenZhen, GuangDong Province · China

Test Firm

Shenzhen Morlab Communications Technology Co., LtdIvy zhu
[email protected]8675536698555Fax: 86-755-36698525

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.40 GHz - 2.48 GHz2.00 mW
Confidentiality
Long Term
Grant Notes
Power listed is conducted. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to the specific belt-clips / holsters / accessories tested for this filing, and to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.0 cm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, hotspot and simultaneous use conditions are 0.15 W/kg, 0.18 W/kg, 0.18 W/kg and 1.42 W/kg respectively. This device has 20 MHz and 40MHz channel capability.
