ZDESD2XHD Wireless PTZ Dome IP Camera

B Physical Description V1.0 Q uick Setup Guide HD W ireless PTZ Dome IP Camera Security Tips Please change the password of your camera regularly, using a combination of numbers, letters and special characters. We recommend that you regularly update your camera to the latest available software and rmware versions to help ensure the best experience for your camera. Package Contents C Setting Up Your Camera: Wired Connection via Foscam App (Recommended) C amera Setup Steps: Setting Up Your Foscam Security Camera A Getting Started N ote: We highly recommend that you first begin the setup process by connecting your camera to your Internet router with an Ethernet cable. After setup is successful, you’ll be able to unplug the cable and login to your wireless network for WiFi operability. 1. P lease mount the antenna and make sure it is in a vertical upright position. 2. Connect the camera to your Internet router using an Ethernet cable. 3. Connect the power adapter to the camera, and wait for a few moments until the camera alerts you that the “Wired connection succeeded” (if the device is connected with the audio output device). 4. From your smartphone, search for “Foscam” via the App Store or Google Play Store. Download, install and open the App to begin conguration. 5. Under “Foscam” select “Tap to add a camera” and then select "Camera", after that scan the QR code, which is located at the bottom of your camera (see illustrations below). 6. On the “Choose Setup Method” screen, conrm that “Wired” is selected (upper-left corner) and tap “Ready for Wired Connection.” Wait a few moments for a message conrming that the setup process has been completed (see illustrations below). S can the QR code which is located on your camera. Scan QR Code < T ap + button T ap to add a camera Foscam Camera added successfully!C onrm “Wired” and then tap “ Ready for Wired Connection” Choose Setup Method < Ready for Wired Connection Wired Wi-Fi Add Cameras Camera added successfully! Minimum Requirements: To help ensure a smoother video experience on the smartphone, it’s recommended that your smartphone has the following: iOS: version 8.1 or higher. Android: 4.1 or higher, using a device with a Graphics Processing Unit (GPU) function. Quick Setup Guide Power Adapter IP Camera Wi-Fi Antenna Q uick Setup Guide W ireless PTZ Dome IP Camera To view this guide in other languages (e.g. Nederlands, Deutsch, Français, Español), and for detailed manuals, tools, etc., please visit foscam.com/downloads. T he cords on this product presents a potential strangulation hazard. For child safety, please keep these cords out of the reach of children. Warning: LAN Power Lens Audio Out Speaker Antenna M icro SD Card Slot R eset Button WPSWPS R outer Expansion Screws Ethernet Cable E Other Ways to Access Your Camera . 264 . 264 F Hardware Installation G Important Notice Your Foscam Cloud service account and password may be used to access both Foscam App and the Foscam Cloud service website. Therefore, you may register the account username & password on either one. Foscam Cloud Service Account Username & Password You can upgrade the rmware of your camera with Foscam App by using the new "One-key Online Upgrade" feature (Open Foscam APP, select Settings > Firmware Upgrade). You also can download the latest version to upgrade your camera from our ocial website foscam.com/upgrades. Firmware Upgrade Storage Media Once you’ve added your camera successfully using the wired connec- tion method above, tap your live camera feed from the My Cameras screen > tap the gear in the upper-right > tap Network > tap the WiFi network you wish to connect to and enter your WiFi password. Note: The camera supports dual-band 2.4GHz & 5GHz WiFi, the speed of 5GHz WiFi is high but the penetrability is weak, so we suggest you use the 2.4GHz WiFi when there is a wall. Please ensure that the proper power supply is used before using the camera. Please install the camera securely using the screws provided. To avoid the risk of re or electric shock, please keep your camera connectors in a cool, dry place. Please keep the camera out of reach of small children. Change your default port to a greater range to help ensure the safety of your connection. Check the logs of your Foscam cameras frequently. Foscam Cameras have embedded logs reminding you which IP addresses are accessing the camera. Safety Tips Camera Username & Password You can access the camera via the Foscam Cloud website: https://www.myfoscam.com Some of the benets of viewing your camera in the cloud: It’s simple and convenient to remotely access and manage all your WiFi security cameras. Enjoy the latest features rst through Foscam Cloud including cloud storage, video sharing, and more. Getting started is fast—if you have already registered an account through Foscam App, you can directly use your login credentials for Foscam Cloud. Foscam Cloud Service Foscam Cloud D Connecting Your Camera Over WiFi WPS Fixate the camera on your preferred location and use the provided screws to mount it. Please Note: Ensure that the rain or water will not reach the connector ports at the end of the pig tail wiring. These connectors are not weather-resistant. CE Certificate Website: https://www.foscam.com/company/ce-certificate.html Exporter and Importer Information Opened to Public: https://www.foscam.com/company/open-information.html www.foscam.com Q uestions? For any issues that occur during the setup process, please write to [email protected] —we’re here to help! A s a result of product upgrades and other reasons, this guide may not be able to update in time, resulting in inconsistency with the ocial website information, please take the ocial website (www.foscam.com) information as the standard. Foscam VMS I f you would like to manage multiple cameras, we suggest you install the Foscam VMS. You can download the “Foscam VMS” from foscam.com/vms. Your camera supports cloud, NVR (Network Video Recorder), and Micro…

Text truncated - open the document above for the full version.

ShenZhen Foscam Intelligent Technology Co., Ltd. Address: 9/F, Block F5, TCL International E City, No.1001, ZhongShanyuan Rd., NanShan District, Shenzhen, China Email: [email protected] Tel: 0755-26745668-8230 Date: 2020-05-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attestation letter Dear Sir or Madam, The RF chip, model: RTL8811CU installed in our product HD Wireless PTZ Dome IP Camera ; Model number: SD2X, FCC ID: ZDESD2X, which supports 5G WIFI function. For use in the US market, this chip only support 5725-5850 MHz, the other 5G WIFI bands was disabled by the manufacturer in the software. The end user has no capability to activate it. Sincerely, Signature David Tu Manager

QA-FR-170-B ShenZhen Foscam Intelligent Technology Co., Ltd. Address: 9/F, Block F5, TCL International E City, No.1001, ZhongShanyuan Rd., NanShan District, Shenzhen, China Email: [email protected] Tel: 0755-26745668-8230 FCC Authorization 2020/04/17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We ( ShenZhen Foscam Intelligent Technology Co., Ltd ), the undersigned, hereby authorize Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Print Name:David Tu Title:Manager

ShenZhen Foscam Intelligent Technology Co., Ltd. Address: 9/F, Block F5, TCL International E City, No.1001, ZhongShanyuan Rd., NanShan District, Shenzhen, China Email: [email protected] Tel: 0755-26745668-8230 FCC Confidential Authorization 2020/04/17 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: ZDESD2X In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, ( ShenZhen Foscam Intelligent Technology Co., Ltd ) hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description • Software Secutity Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Print Name:David Tu Title:Manager

ShenZhen Foscam Intelligent Technology Co., Ltd 9/F, Block F5, TCL International E City, No.1001, ZhongShanyuan Rd., NanShan District, Shenzhen, China Tel: 86-755-26745668-8230 [email protected] 09/03/2020 Product Similarity Declaration To Whom It May Concern, We, Shenzhen Foscam Intelligent Technology Co., Ltd hereby declare that we have a product named as HD Wireless PTZ Dome IP Camera (Model number: SD2X, FCC ID: ZDESD2X) was tested by BACL, meanwhile, for our marketing purpose, we would like to list a series models ( SD2X VX; D2MS;D2MS VX; SD2* VX;SD4;SD4 VX ;SD4* VX; MDS4020;MDS4020 VX;MDS4021VX, MDS4022 VX; MDS4023 VX; MDS4024VX; MDS4025 VX;PS4 VX;Genie 2 VX; Foscam Genie 2 VX ;MDS2060VX, MDS2061 VX; MDS2062 VX; MDS2063VX; MDS2064 VX;MDS2065 VX; Remark: "VX" denote the software version which can be from V0 to V9. The default state is empty while it is V0. and * denote the small version is indentified by letters.) on reports and certificate, all the models are identical schematics, just model number is different. No other changes are made to them. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact with me if you have any question. Signature Printed Name: David Tu Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Antenna Port

EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ200119811-00B FCC Part 15.407 Page 15 of 61 FCC §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Result Calculated Formulary: Predication of MPE limit at a given distance S = 2 4R PG  S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Frequency (MHz) Antenna Gain Max Tune Up Conducted Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm) (mW) 2412-2472 5.0 3.16 18.0 63.10 20 0.04 1.0 5745-5825 5.0 3.16 9.0 7.94 20 0.005 1.0 The 2.4G Wi-Fi can’t transmit with the 5.8G Wi-Fi at the same time. Note: To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: compliance.
