ZEQJQ-S812-NBluetooth Speakers

Power : Built-in polymer battery 4000mA Charging ways : USB transfer standard DC connector Audio type : two-channel stereo Speaker : Φ55 3Ω 5W SNR : 80dB Power : 5V 1000mA External Audio : standard 3.5 stereo plug input Bluetooth valid acceptance Distance : 15M (Barrier free) Electrical parts icon and function explanation Play/Pause Last song OFF ON : Power switch Voice – Next song DC5V : External power input Voice + Bluetooth LINE : External audio input Features: 1). Simple overall design on appearance, natural bamboo material, natural, simple, beautiful, unique technology. 2). The perfect combination between HiFi amplifier system and high quality restoring system to give the speakers a perfect sound level. 3). High quality speakers with high-quality bass resonance unit, without adding a separate subwoofer, you can produce heavy bass. 4). Overall quality: crisp treble, alto clear and thorough, with plenty of bass. 5). Built-in high-capacity polymer battery, long playback, 10 hours of continuous playback. 6). Using standard universal interface, flexible external sources: mobile phones, MP3, MP4, MP5, IPAD, computers, laptops, etc. Package Include: Main speaker: 1; Instructions: 1; signal input line: 1; power line: 1; warranty card, certificate: 1 Performance Parameters Output power: MAX 3W +3 W Frequency Response：80-20KHz Bamboo Multimedia Bluetooth Speaker Manual Function and Operation explanation 一、 Bluetooth Player 1. Power “ON” (Bluetooth boot by default, Bluetooth reported), Then the Bluetooth indicator light will flash continuously ( Bluetooth waiting for connection) 2. Open the phone (or IPAD) Bluetooth (Phone or IPAD generally will automatically search for nearby Bluetooth devices and automatic pairing, connnecting), Phone (or IPAD) to search for new Bluetooth devices (The machine name: JQ-168A) ,and prompts to connect with this device (connection code: 0000), the machine beeps once after a successful connection with Bluetooth devices to indicate that the connected status. 3. After the success connection with the Bluetooth device, you can play Bluetooth. 4. Click or press or can adjust the volume, Click or can select the program or song(If supported by player.) Click to pause and click againto continue(Note: Some playing software do not support bi- directional operation). 5. To ensure the best sound quality, Please adjust the volume of the mobile or the machine to a moderate size. 二、External audio playback 1. Insert the the audio cable end ( Distributed with the bluetooth speaker) to the LINE port and speakers connected, plug the other end into corresponding audio output jack of your MP3, mobile phones and other OFF ON DC 5VLINE devices that with audio playback function. 2. Click to enter “LINE” status. 3. Choose your favorite songs and regulate the volume according to their likes and environment. 4. To ensure the best sound quality, Please adjust the volume of the external playback device to a moderate size. Meanwhile you can choose sound category according to your preferences (in the player EQ selector) 三、 Charging If your cellphone have already connect with Bluetooth Speaker, when someone call you, the cellphone will ring via Bluetooth Speaker. You can pick up it as usual, and select phone handset, you are through now. Precautions 1. The product constructure is precise, please do not place in cold, hot or humid environment, not disassemble or fall heavily. 2. Do not use organic solvents to scrub the body and avoid exposure to the sun and rain. 3. In order to ensure and extend the life of the product, do not use in larger dust or dirt and other harsh environments. 4. Do not use power identity is unclear 5. Do not place the speakers near an open flame sources, such as lighted candles. 6. If a fault occurs, please contact the after-service department, please do not handle by yourself. speaker phone handset bluetooth FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. 2014/6/23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD.___hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Bluetooth Speakers Trade Name： N/A Model Name： S812-N Serial Model：SXXX-Y（X=0-9, Y=A-Z） FCC ID： ZEQJQ-S812-N Sincerely, Signature Name: Rita Wu Title: Engineer Address: XIA YAOPU INDUSTRIAL ZONE,TONGGU COUNTY,JIANGXI PROVINCE,CHINA SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. 2014/6/23 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD.______hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): Product： Bluetooth Speakers Trade Name： N/A Model Name： S812-N Serial Model：SXXX-Y（X=0-9, Y=A-Z） FCC ID： ZEQJQ-S812-N We affirm that between SIEMIC, Inc. and ______ JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Name: Rita Wu Title: Engineer Address: XIA YAOPU INDUSTRIAL ZONE,TONGGU COUNTY,JIANGXI PROVINCE,CHINA

JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. Model Difference FCC ID: ZEQJQ-S812-N Model : S812-N, SXXX-Y（X=0-9, Y=A-Z） All the models are the same circuit and RF module, except the mode names. Regards, Client’s signature Signature Name: Rita Wu Title: Engineer Address: XIA YAOPU INDUSTRIAL ZONE,TONGGU COUNTY,JIANGXI PROVINCE,CHINA

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Bluetooth Speakers Model NO.: S812-N Rating: DC3.7V/ 4000mAh FCC ID: ZEQJQ-S812-N JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 ANT Photo 5 Photo 6

FCC ID: ZEQJQ-S812-N RF EXPOSURE TEST Applied procedures / limit These devices are not exempted from compliance does not exceed the Commission’s RF exposure guidelines.Unless a device operates at substantially low power levels,with a low gain antenna(s),supporting information is generally needed to establish the various potential operating configurations and exposure conditions of a transmitter and its antenna(s) in order to determine compliance with the RF exposure guidelines. In order to demonstrate compliance with MPE requirement(see Section 2.1091),the following information is typically needed: Calculation that estimates the minimum separation distance(20 cm or more)between an antenna and persons required to satisfy power density limits defined for free space. Antenna installation and device operating instructions for installers(professional/unskilled users),and the parties responsible for ensuring compliance with the RF exposure requirement Any caution statements and/or warming labels that are necessary in order to comply with the exposure limits Any other RF exposure related issues that may affect MPE compliance. FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency(RF) radiation as specified in 1.1307(b). (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density FCC ID: ZEQJQ-S812-N MPE CALCULATION METHOD Calculation Method of RF Safety Distance: P :power input to the antenna in Mw EIRP :Equivalent(effective) isotropic radiated power. S :power density mW/ cm 2 G ;numeric gain of antenna relative to isotropic radiator R :distance to centre of radiation in cm FCC radio frequency exposure limits may be exceeded at distances closer than r cm from the antenna of this device EIRP=10 ( Antenna Gain+Peak Output Power/10) Note: 1. s=1.0 mW /cm 2 for limits for General Population/Uncontrolled Exposures. 2. The time averaged power over 30 minutes will be equaled Output Power. 3. The Power Density at a distance of 20cm calculated from the formula is far below the limit of 1MW/ cm 2 FCC ID: ZEQJQ-S812-N TEST RESULTS Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result BT(1Mbps) 4.966 3.14 1.26(1.0dBi) 0.0008 1 Pass BT(2Mbps) 4.900 3.09 1.26(1.0dBi) 0.0008 1 Pass BT(3Mbps) 4.849 3.05 1.26(1.0dBi) 0.0008 1 Pass NOTE: (For mobile or fixed location transmitters, the maximum power density is 1.0mW/cm 2 even if the calculation indicates that the power density would be larger)

FCC RADIO TEST REPORT FCC ID: ZEQJQ-S812-N Product： Bluetooth Speakers Trade Name： N/A Model Name： S812-N Serial Model： SXXX-Y（X=0-9, Y=A-Z） Report No.： NTEK-2014NT0523831F Prepared for JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. XIA YAOPU INDUSTRIAL ZONE,TONGGU COUNTY,JIANGXI PROVINCE,CHINA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 75 Report No.: NTEK-2014NT0523831F TEST RESULT CERTIFICATION Applicant’s name............. JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. Address ............................. XIA YAOPU INDUSTRIAL ZONE,TONGGU COUNTY,JIANGXI PROVINCE,CHINA Manufacture's Name........ JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. Address ............................. XIA YAOPU INDUSTRIAL ZONE,TONGGU COUNTY,JIANGXI PROVINCE,CHINA Product description Product name ......................Bluetooth Speakers Model and/or type reference .......................... S812-N Serial Model： SXXX-Y（X=0-9, Y=A-Z） Standards......................... FCC Part15.247 Test procedure ..................... ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test........................................ Date (s) of performance of tests ......... 23 May 2014 ~17 Jun. 2014 Date of Issue....................................... 17 Jun. 2014 Test Result........................................... Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 75 Report No.: NTEK-2014NT0523831F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . AVERAGE TIME OF OCCUPANCY 35 5.1 APPLIED PROCEDURES / LIMIT 35 Page 4 of 75 Report No.: NTEK-2014NT0523831F Table of Contents Page 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 36 5.1.4 EUT OPERATION CONDITIONS 36 5.1.5 TEST RESULTS 37 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 TEST PROCEDURE 43 6.1.2 DEVIATION FROM STANDARD 43 6.1.3 TEST SETUP 43 6.1.4 EUT OPERATION CONDITIONS 43 6.1.5 TEST RESULTS 44 7 . BANDWIDTH TEST 50 7.1 APPLIED PROCEDURES / LIMIT 50 7.1.1 TEST PROCEDURE 50 7.1.2 DEVIATION FROM STANDARD 50 7.1.3 TEST SETUP 50 7.1.4 EUT OPERATION CONDITIONS 50 7.1.5 TEST RESULTS 51 8 . PEAK OUTPUT POWER TEST 57 8.1 APPLIED PROCEDURES / LIMIT 57 8.1.1 TEST PROCEDURE 57 8.1.2 DEVIATION FROM STANDARD 57 8.1.3 TEST SETUP 57 8.1.4 EUT OPERATION CONDITIONS 57 8.1.5 TEST RESULTS 58 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 64 9.1 DEVIATION FROM STANDARD 64 9.2 TEST SETUP 64 9.3 EUT OPERATION CONDITIONS 64 9.4 TEST RESULTS 65 10 . ANTENNA REQUIREMENT 73 10.1 STANDARD REQUIREMENT 73 10.2 EUT ANTENNA 73 11 . EUT TEST PHOTO 74 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 75 Report No.: NTEK-2014NT0523831F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 75 Report No.: NTEK-2014NT0523831F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 75 Report No.: NTEK-2014NT0523831F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth Speakers Trade Name N/A Model Name S812-N Serial Model SXXX-Y（X=0-9, Y=A-Z） Model Difference All the mode…

Text truncated - open the document above for the full version.

Page 74 of 75 Report No.: NTEK-2014NT0523831F 11. EUT TEST PHOTO Radiated Measurement Photos Page 75 of 75 Report No.: NTEK-2014NT0523831F CONDUCTED EMISSION Photo
