USER GUIDE Product Name: Bamboo Keyboard & Mouse Combo Bamboo Keyboard: • Dimensions: 460*160*22mm (L*W*H) • Battery: 2 pcs of 3A • Outer Shell: natural fresh bamboo material • Keycap: natural fresh bamboo material • Compatible with Window95/98/2000/ME/XP/NT/Vista/Win 7, ect. • Laser printed keys, ever lasting • Keystroke life time over 5 million cycles, more durable • Certificate: FCC, CE, RoHs Features: • Revolutionary new green product, low carbon, biodegradable, environmental friendly. • Practical & anti-static. • Sweat absorbent and antibacterial. • Warm in the winter and cool in the summer for optimum comfort. • Bamboo grain absorbs ultraviolet light, anti-radiation. • Unique, elegant, and trendy How to get into on-line Mode: Take off the battery cover, take out of the receiver, then put in the two batteries, fold up the cover, then put the receiver into the USB port of PC. Receiver After insert the battery, Please press “Esc” + “Pause Break” simultaneously, low pressure indicator on the right top corner will be light in red, then straight away you put receiver into USB port of PC. The light goes off, there you can start to use. Indicator light Notice: 1. If after you press the two keys, after 10-15 seconds, you did not put in the receiver, then the checking code mode will expire, you need to restart again. 1. If the light goes off after 15 seconds, while press any other key, the pressure light will be shining, this means disconnected yet. The light will not be on by pressing any key once connected. 2. When the receiver and keyboard are in normal connection, but the low pressure light blinking, means the battery is low, need to change new pairs. FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD 2011-03-22 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product：Wireless keyboard Model： W3Q108,W3B108,W3B104,W2B109,W1B088,WXYZ-YA (X can be 0-9,Y can be A~Z,Z can be 000-999,A can be A~Z ) We affirm that between SIEMIC and JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title Rita Wu/ Engineer Contact information / address TEL：+86-795-8726641 FAX：+86-795-8690955 E-mail：[email protected] Address：XIA YAOPU INDUSTRIAL ZONE，TONGGU COUNTY，JIANGXI PROVINCE，CHINA

2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD 2011-03-22 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: ZEQJQKEYBOARD We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title Rita Wu/ Engineer Contact information / address TEL：+86-795-8726641 FAX：+86-795-8690955 E-mail：[email protected] Address：XIA YAOPU INDUSTRIAL ZONE，TONGGU COUNTY，JIANGXI PROVINCE，CHINA

JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD Date: 2011-03-22 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: ZEQJQKEYBOARD To Whom It May Concern: This letter is to ascertain that JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY.LTD. Wireless Keyboard has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature Client’s name / title Rita Wu/ Engineer Contact information / address TEL：+86-795-8726641 FAX：+86-795-8690955 E-mail：[email protected] Address：XIA YAOPU INDUSTRIAL ZONE，TONGGU COUNTY，JIANGXI PROVINCE，CHINA

EUT - Front View EUT - Rear View .

FCC ID: ZEQJQKEYBOARD This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID Label Location

EUT – Open View EUT – PCB View 1 . EUT – PCB View 2

Wireless Keyboard Type characters by hand, the signal pass by CX5173， Communication Protocol based on the USB of keyboard, use SPI serial communication, sent string into clip of RF SGN6210, and send signal date base on 2.4G of frequency mode via SGN6210. EEPROM24C02 often used to store, recognize, receive the ID code.

FCC Part 15C Measurement And Test Report For JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY. LTD XIA YAOPU INDUSTRIAL ZONE，TONGGU COUNTY， JIANGXI PROVINCE，CHINA Model:W3Q108 ,W3B108,W3B104,W2B109,W1B088,WXYZ-YA (X can be 0-9,Y can be A~Z,Z can be 000-999,A can be A~Z ) Mar.18 ,2011 . This Report Concerns: Original Report Equipment Type: Wireless Keyboard Report Number: MTI110302001RF Test Engineer: Reviewed By: Approved & Authorized By: Test Date: Mar.9-15 ,2011 Prepared By: MTI Technology Laboratory Ltd． 10F, Yinxing Business Hotel, Xixiang Road, Bao'an District, Shenzhen, P,R.China. Tel: +86-755-8885 0135 Fax: +86-755-8885 0136 Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior written consent of MTI Technology Laboratory Ltd． Report No.：MTI110302001RF Page 2 of 22 TABLE OF CONTENTS 1. GENERAL INFORMATION......................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................................3 1.2 RELATED SUBMITTAL(S) / GRANT (S) .............................................................................................................................3 1.3 TEST METHODOLOGY..................................................................................................................................................4 1.4 TEST FACILITY............................................................................................................................................................4 2. SYSTEM TEST CONFIGURATION............................................................................................................ 5 2.1 EUT CONFIGURATION..................................................................................................................................................5 2.2 EUT EXERCISE...........................................................................................................................................................5 2.3 GENERAL TEST PROCEDURES......................................................................................................................................5 2.4 LIST OF MEASURING EQUIPMENTS USED.......................................................................................................................6 3. SUMMARY OF TEST RESULTS................................................................................................................ 7 4. ANTENNA REQUIREMENT....................................................................................................................... 8 4.1 STANDARD APPLICABLE...............................................................................................................................................8 4.2 ANTENNA CONNECTED CONSTRUCTION.........................................................................................................................8 5. §15.205, §15.209, §15.249 (A)- RADIATED EMISSION............................................................................ 9 5.1 STANDARD APPLICABLE...............................................................................................................................................9 5.2 EUT SETUP................................................................................................................................................................9 5.3 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................10 5.4 TEST PROCEDURE.....................................................................................................................................................10 5.5 CORRECTED AMPLITUDE & MARGIN CALCULATION........................................................................................................11 5.6 TEST RESULT............................................................................................................................................................11 6. §15.249(B) OUT OF BAND EMISSIONS.................................................................................................. 16 6.1 LIMITS OF BANDEDGE MEASUREMENT..........................................................................................................................16 6.2 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................16 6.3 TEST PROCEDURE.....................................................................................................................................................16 6.4 TEST RESULT /PLOTS................................................................................................................................................16 APPENDIX A - PRODUCT LABELING........................................................................................................ 19 PROPOSED FCC ID LABEL FORMAT..................................................................................................................................19 PROPOSED LABEL LOCATION ON EUT...............................................................................................................................19 APPENDIX B - EUT PHOTOGRAPHS......................................................................................................... 20 APPENDIX C - EUT INTERNAL PHOTOGRAPHS...................................................................................... 21 Report No.：MTI110302001RF Page 3 of 22 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Applicant: JIANGXI TONGGU JIANGQIAO TIMBER&BAMBOO INDUSTRY COMPANY. LTD Address of applicant: XIA YAOPU INDUSTRIAL ZONE，TONGGU COUNTY， JIANGXI P…
