ZF3-LTL-5310MGInfrared Scouting Camera

Ltl Acorn Mobile Scouting Camera Ltl-5310 Series SMS remote control 720P video USER’S MANUAL TABLE OF CONTENTS General Information ......................................................................................... 1 1.1 Features.................................................................................................1 1.2 Application............................................................................................. 2 1.3 Illustration.............................................................................................. 2 Quick Start ........................................................................................................ 5 2.1 Insert SIM Card..................................................................................... 5 2.2 Load Batteries........................................................................................5 2.3 Insert SD Card....................................................................................... 6 2.4 Enter Test Mode.....................................................................................6 2.5 Enter Live Mode.....................................................................................7 2.6 Advantages of Prep Sensors................................................................. 8 Advanced Settings ......................................................................................... 9 3.1 Parameter Settings.............................................................................. 9 3.2 File Format........................................................................................... 12 3.3 Set up Cameraon PC......................................................................... 12 3.4 Set up MMS Function on PC............................................................... 15 3.5 SMS remote control............................................................................. 17 3.6 Camera Workingwith MMS................................................................. 21 3.7 View Local MNOP Name and Signal Strength on TFT display........... 22 Ltl-5310 Series Products ............................................................................... 24 4.1 Parts.................................................................................................... 24 4.2 Models for Purchase............................................................................ 24 Important Information .................................................................................... 24 5.1 Prevent FromShort-Circuits................................................................ 24 5.2 Power Supply and Battery Box............................................................ 25 5.3 SD Card............................................................................................... 25 5.4 Auto Adjustment on VideoLength........................................................ 25 5.5 850nm and 940nm IR LED.................................................................. 26 5.6 Mount on Tripod................................................................................... 26 5.7 FAQs on MMS Function...................................................................... 27 Firmware Upgrades ....................................................................................... 28 6.1 Firmware Upgrades............................................................................. 28 Warranty Information ..................................................................................... 29 Appendix I Technical Specifications ............................................................ 30 Appendix II Package Contents ..................................................................... 31 Appendix III Instruction on Installing Battery Box ..................................... 32 1 GENERAL INFORMATION Introduction The Ltl Acorn 5310 Series (Model Ltl-5310A/MC and Ltl-5310MM) is the third generation of our Ltl acorn scouting camera. Bundled with the MMS-module (Multimedia Messaging Service) battery box (Part # LTL-MM1)standard scouting camera (Part # Ltl-5310MC) can be upgraded to work as a remote cellular camera. With its highly sensitive Passive Infra-Red (PIR) sensor the camera detects the sudden change of ambient temperature caused by moving game in a region of interest (ROI), triggers to take pictures/videos, and sends the images via GSM network to the user’s cell phone or email account. With newly added SMS remote control feature you can change the related menu of the camera by sending SMS order to the camera in the specific form of the SMS content. 1.1Features: Programmable 5 or 12-Megapixel high-quality resolution. With SMS RCP (remote control program) parameters of camera can be changed by SMS sending. If in request, the camera can take picture and send back simultaneously. No-glow Infrared 940nm LEDs flash range as far as 65 feet, luminance as bright as 850nm. In “Cam + Video” mode, camera takes both pictures and video at every trigger event Ultra low standby power consumption. Extremely long in-field life (in standby mode, up to 6 months with 8 x AA batteries) Unique side Prep Sensor design provides wider sensing angle and enhances camera’s response speed Perform in the most extreme temperatures from -22°F to 158°F Compact size (5 ½ x 3 ½ x 2 ½ inches). Well designed to deploy covertly Impressively quick trigger time (0.8 second) In Time Lapse setting, the camera automatically and constantly takes pictures/videos at specified interval. This is very useful when observing plants flowering, birds building nest, or when monitoring unattended properties such as parking lots With Timer setting on, the camera can be programmed to only work in specified period every day. This feature can work together with Time Lapse feature Backpack-looking tree grabber makes mounting and aiming a snap This manual applies to model: Ltl-5310A Ltl-5310MCLtl-5310MGLtl-5310 WA Ltl-5310WMCLtl-5310WMG. 2 Seria…

Text truncated - open the document above for the full version.

Shenzhen Ltl Acorn Electronics Co., Ltd. FCC ID: ZF3-LTL-5310MG DATE: Feb 25, 2014 To whom it may concern: We the undersigned, hereby authorize Shenzhen Huatongwei International Inspection Co., Ltd to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Shenzhen Huatongwei International Inspection Co., Ltd on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Shenzhen Ltl Acorn Electronics Co., Ltd. Sincerely yours, Wang zhengping/ General Manager Company Name: Shenzhen Ltl Acorn Electronics Co., Ltd. Tel: +86-755-26693981 E-mail: [email protected]

Boly Media Comminicationas ( Asia) Co., Lt Shenzhen Ltl Acorn Electronics Co., Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Shenzhen Ltl Acorn Electronics Co., Ltd. would like the following documents regarding this submission for FCC ID: ZF3-LTL- 5310MG to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Part List 5. Turn-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Wang zhengping/ General Manager Company Name: Shenzhen Ltl Acorn Electronics Co., Ltd. Tel: +86-755-26693981 E-mail: [email protected]

Attestation for FCC Declaration of Conformity FCC ID: ZF3-LTL-5310MG DATE: Feb 25, 2014 Please be notified that we, the undersigned, Shenzhen Ltl Acorn Electronics Co., Ltd. declare that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. Testing in regards to this report was done by Interocean EMC Technology Corp. located atNo.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County 244, Taiwan, R.O.C.., which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827 Sincerely yours, Wang zhengping/ General Manager Company Name: Shenzhen Ltl Acorn Electronics Co., Ltd. Tel: +86-755-26693981 E-mail: [email protected]

External Photos of The EUT

Label

Internal Photos of The EUT GSM Antenna

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No. .................... : FCC ID. ............................................ : TRE1312011102 R/C: 37910 ZF3- LTL-5310MG Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Jan 22, 2014 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Shenzhen Ltl Acorn Electronics Co., Ltd Address ............................................. : 2th floor, Building 8, ShiLing Industrial Park, XinWei, XiLi Town, Nanshan District, Shenzhen, Guangdong, China Test specification .......................... : Standard ........................................... : FCC Per 47 CFR 2.1091(b) KDB447498 v05r02 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Infrared Scouting Camera Trade Mark ....................................... : LTL ACORN Manufacturer ................................... : Shenzhen Ltl Acorn Electronics Co., Ltd Model/Type reference ....................... : Ltl-5310MG Listed Models .................................. : / Ratings .............................................. : DC 6.00V2.0A Modulation ....................................... : GMSK for GPRS/EDGE GPRS/ EGPRS Class ........................ 12 GPRS operation mode ...................... Class B Frequency .......................................... GSM850/ PCS1900 Result ................................................ : PASS Report No.: TRE1312011102 Page 2 of 7 Issued:2014-01-22 MPE T E S T R E P O R T Test Report No. : TRE1312011102 Jan 22, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Infrared Scouting Camera Model /Type : Ltl-5310MG Listed Models : / Applicant : Shenzhen Ltl Acorn Electronics Co., Ltd Address : 2th floor, Building 8, ShiLing Industrial Park, XinWei, XiLi Town, Nanshan District, Shenzhen, Guangdong, China Manufacturer Shenzhen Ltl Acorn Electronics Co., Ltd Address : 2th floor, Building 8, ShiLing Industrial Park, XinWei, XiLi Town, Nanshan District, Shenzhen, Guangdong, China Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1312011102 Page 3 of 7 Issued:2014-01-22 Contents 1. SUMMARY 4 1.1. EUT configuration 4 1.2. Product Description 4 1.3. NOTE 4 2. TEST ENVIRONMENT 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT 5 3.1. Applicable Standard 5 3.2. Limit 6 3.3. MPE Calculation Method 6 4. CONCLUSION 7 Report No.: TRE1312011102 Page 4 of 7 Issued:2014-01-22 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Power Cable Length (m) : / Shield : / Detachable : / ○ Multimeter Manufacturer : / Model No. : / 1.2. Product Description The Shenzhen Ltl Acorn Electronics Co., Ltd.’s Model:Ltl-5310MG or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT Infrared Scouting Camera Model Number Ltl-5310MG FCC ID ZF3- Ltl-5310MG Modilation Type GMSK for GPRS/EGPRS Antenna Type External Hardware version Ltl-5310MG_V003 GSM/EDGE/GPRS Supported GPRS/EDGE Extreme temp. Tolerance -30°C to +60°C Extreme vol. Limits 5.10VDC to 6.90VDC (nominal: 6.00VDC) GPRS Operation Frequency Band GPRS850/EGPRS850/GPRS1900/EGPRS1900 GPRS operation mode Class B GPRS Multislot Class 12 EGPRS Multislot Class 12 1.3. NOTE 1. The EUT is a Infrared Scouting Camera with GPRS function,The functions of the EUT listed as below: Test Standards Reference Report GPRS/EGPRS FCC Part 22/FCC Part 24 TRE1312011101 MPE FCC Part 2 §2.1093 TRE1312011102 . Report No.: TRE1312011102 Page 5 of 7 Issued:2014-01-22 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-755-26748089 The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2009) and CISPR Publication 22. 2.2. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar 2.3. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to TR-100028-01” Electromagnetic compatibility and Radio spectrum Matters (ERM);Uncertainties in the measurement of m…

Text truncated - open the document above for the full version.

FCC PART 22/24 TEST REPORT FCC Part 22 /Part 24 Report Reference No. .................... : FCC ID. ............................................ : TRE1312011101 R/C: 37910 ZF3-LTL-5310MG Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Jan 25, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Shenzhen Ltl Acorn Electronics Co., Ltd. Address............................................. : 2th floor, Building 8, ShiLing Industrial Park, XinWei, XiLi Town, Nanshan District, Shenzhen, Guangdong, China Test specification .......................... : Standard ........................................... : FCC Part 22: PUBLIC MOBILE SERVICES FCC Part 24: PERSONAL COMMUNICATIONS SERVICES TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Infrared Scouting Camera Trade Mark ....................................... : LTL ACORN Manufacturer ................................... : Shenzhen Ltl Acorn Electronics Co., Ltd. Model/Type reference ....................... : Ltl-5310MG Listed Models .................................. : / Ratings.............................................. : DC 6.00 V 2.0A Modulation ....................................... : GMSK for GPRS/EGPRS GPRS Class ...................................... 12 GPRS operation mode ...................... Class B Frequency Band ................................ GPRS850/EGPRS850/GPRS1900/EGPRS1900 Result ................................................ : PASS Report No.: TRE1312011101 Page 2 of 77 Issued:2014-01-25 T E S T R E P O R T Test Report No. : TRE1312011101 Jan 25, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Infrared Scouting Camera Model /Type : Ltl-5310MG Listed Models : / Applicant : Shenzhen Ltl Acorn Electronics Co., Ltd. Address : 2th floor, Building 8, ShiLing Industrial Park, XinWei, XiLi Town, Nanshan District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Ltl Acorn Electronics Co., Ltd. Address : 2th floor, Building 8, ShiLing Industrial Park, XinWei, XiLi Town, Nanshan District, Shenzhen, Guangdong, China Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1312011101 Page 3 of 77 Issued:2014-01-25 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. Normal Accessory setting 6 2.6. EUT configuration 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 2.9. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Test Description 8 3.6. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS 10 4.1. Conducted Emissions Test 10 4.2. OUTPUT POWER 12 4.3. Radiated Spurious Emssion 17 4.4. OCCUPIED BANDWIDTH 21 4.5. EMISSION BANDWIDTH 29 4.6. BAND EDGE COMPLIANCE 37 4.7. Spurious Emssion on Antenna Port 43 4.8. Frequency Stability Test 66 5. TEST SETUP PHOTOS OF THE EUT 68 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 70 Report No.: TRE1312011101 Page 4 of 77 Issued:2014-01-25 1. TEST STANDARDS The tests were performed according to following standards: FCC Part 22 (10-1-12 Edition): PRIVATE LAND MOBILE RADIO SERVICES. FCC Part 24(10-1-12 Edition): PUBLIC MOBILE SERVICES TIA/EIA 603 D June 2010: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. 47 CFR FCC Part 15 Subpart B: - Unintentional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS KDB971168 D01:201: Procedures for Compliance Measurement of the Fundamental Emission Power of Licensed Wideband (> 1 MHz) Digital Transmission Systems ANSI C63.4:2009: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Report No.: TRE1312011101 Page 5 of 77 Issued:2014-01-25 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Dec 14, 2013 Testing commenced on : Dec16, 2013 Testing concluded on : Jan 20, 2014 2.2. Product Description The Shenzhen Ltl Acorn Electronics Co., Ltd.’s Model:Ltl-5310MG or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT Infrared Scouting Camera Model Number Ltl-5310MG FCC ID ZF3- Ltl-5310MG Modilation Type GMSK for GPRS/EGPRS Antenna Type External Hardware version Ltl-5310MG_V003 GSM/EDGE/GPRS Supported GPRS/EDGE Extreme temp. Tolerance -30°C to +60°C Extreme vol. Limits 5.10VDC to 6.90VDC (nominal: 6.00VDC) GPRS Operation Frequency Band GPRS850/EGPRS850/GPRS1900/EGPRS1900 GPRS operation mo…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
