ZJF-HH-YK-A008Ceiling suspended fan

1 2 3 4 5 6 A BC D 6 5 4 3 2 1 D CB A Title Number Revision Size B Date: 23-Jul-2011 Sheet of File: F:\ ढᅣѻક䌘᭭ \ ϝⳌⳈ⌕偀䖒᥻ࠊ఼ \ ໡ӊϝⳌ⬉ᴎ䘹᥻఼ SCH.DDB Drawn By: 315MHZ shoot a mold piece U2: PT4450 CPU U101: MX7014MHZ KEY CODE DC POWER U2: HT7130 ANT Block Diagram

Technical Description DescriptionFunction Component AntennaTransmit modulation RF signal. ANT(,QWHJUDO ZLUHDQWHQQD Low pass Filter Suppression of spurious emissions C3, L2 RF Power Amplifier and Modulation Modulate the carrier and amplify the modulated RF signal U1 OscillatorGenerate 315MHZ carrier Y1, U1 Encode IC Generate code signal to modulator, ASK transmitU101 Antenna Used: An integral antenna has been used.

 1 2 3 4 5 6 A BC D 6 5 4 3 2 1 D CB A Title Number Revision Size B Date: 23-Jul-2011 Sheet of File: F:\ ढᅣѻક䌘᭭ \ ϝⳌⳈ⌕偀䖒᥻ࠊ఼ \ ϝⳌ⬉ᴎ䘹᥻఼ SCH.DDB Drawn By: C11uF/10V R34K7 P01 1 P02 2 P03 3 VDD 4 P04 5 P05 6 P06 7 P07 8 P10 9 P11 10 VSS 11 P12 12 P13 13 P14 14 U101MX701 1234 8765 SW1 1 2 3 TX G N D +5 V D A T A 12 BATTERY IN 1 G 2 OUT 3 U2HT7130 S44S11S7STOP S22S55S8LAMP S33S66S9MOTO R44K7 R54K7 R247K R11K LED1 SW2 C4104P C715P 104PC3 C3 15P ANT 123 654 U1PT4450 C110P 22nH L2 180nHL1 123 J1 R110K DATAGNDVCC Y1 315MHZ

Remote Contorller Average Factor calculate: The duration of one cycle = 39.20 ms Effective period of the cycle = (0.74 x 12 + 0.26 x 13) ms = 12.26 ms DC = 12.26 ms/39.20 ms = 0.3128 or 31.28 % Therefore, the averaging factor is found by 20log 10 0.3128 = - 10.1 dB

20dB bandwidth = 500kHz 0.25% of the center frequency = 315.07MHz x 0.25% = 787.675kHz > 500kHz

Report No.: GZ11041190-1 Page 2 of 13 Table of Contents TEST REPORT...........................................................................................................................................................1 1 General Description....................................................................................................................................3 1.1 Product Description ......................................................................................................................................3 1.2 Related Submittal(s) Grants ..........................................................................................................................3 1.3 Test Methodology .........................................................................................................................................3 1.4 Test Facility..................................................................................................................................................3 2 System Test Configuration.........................................................................................................................4 2.1 Justification ...................................................................................................................................................4 2.2 EUT Exercising Software .............................................................................................................................4 2.3 Special Accessories.......................................................................................................................................4 2.4 Equipment Modification ...............................................................................................................................4 2.5 Measurement Uncertainty .............................................................................................................................5 2.6 Support Equipment List and Description ......................................................................................................5 3 Radiated Emission Results.........................................................................................................................6 3.1 Field Strength Calculation ............................................................................................................................6 3.2 Radiated Emission Configuration Photograph ..............................................................................................7 3.3 Radiated and Spurious Emission Data ..........................................................................................................7 4 Equipment photo.........................................................................................................................................9 5 Product Labelling........................................................................................................................................9 6 Technical Specifications.............................................................................................................................9 7 Instruction Manual...................................................................................................................................10 8 Miscellaneous Information.......................................................................................................................10 8.1 Bandwidth Plot ...........................................................................................................................................10 8.2 Discussion of Pulse Desensitization............................................................................................................10 8.3 Calculation of Average Factor ....................................................................................................................10 8.4 Emissions Test Procedures..........................................................................................................................12 8.5 Emissions Test Procedures (cont'd) ............................................................................................................12 9 Equipment list...........................................................................................................................................13 Report No.: GZ11041190-1 Page 3 of 13 1 General Description 1.1 Product Description The equipment under test (EUT) is a transmitter for Ceiling suspended fan with RF at 315.00 MHz. The EUT is powered by 12V DC. During normal use, it sends the message to control the fan and light. The duration of each transmission is less than 1s. Antenna Type: Integral wire antenna. For electronic filing, the brief circuit description is saved in the filename: Technical Description.pdf. 1.2 Related Submittal(s) Grants The receiver option of this transmitter is subject to Certification procedure. 1.3 Test Methodology Radiated emission measurements were performed according to the procedures in ANSI C63.4 (2009). Radiated Emission measurement was performed in a Semi-anechoic chamber. Preliminary scans were performed in the Semi-anechoic chamber only to determine worst case modes. For each scan, the procedure for maximizing emissions in Appendices D and E were followed. All Radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise in the “Justification Section” of this Application. 1.4 Test Facility The Semi-Anechoic Chamber facility used to collect the radiated data is Intertek Testing Services Shenzhen ltd. Kejiyuan Branch and located at 6F, Block D, Huahan Building, Langshan Road, Nanshan District Shenzhen, P.R.China. This test facility and site measurement data have been fully placed on file with File Number 242492. Report No.: GZ11041190-1 Page 4 of 13 2 System Test Configuration 2.1 Justification The system was configured for testing in a typical …

Text truncated - open the document above for the full version.

The controller is a manually operated transmitter, according above graph, the “on” duration is less than 1s, it employs a switch that will automatically deactivate the transmitter within not more than 5 seconds of being released.
