ZKJ-294D2018RFID Module

Draft 225D8714P004 Pub. No. 49-60822 Rev. 7 12-19 GEA IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING GE Appliances website To access the full Owner’s Manual and for more information on your refrigerator’s operation, visit GEAppliances.com (Canada GEAppliances.ca) and search for the model number. This information is also available by scanning the QR code located on the rating plate (silver label on the top-right wall of the refrigerator compartment). Side by Side Refrigerators Quick Guide CAUTION To reduce the risk of injury when using your refrigerator, follow these basic safety precautions. Ŷ Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impact, such as bumping or dropping. Tempered glass is designed to shatter into many small pieces if it breaks. Ŷ Keep fingers out of the “pinch point” areas; clearances between the doors and between the doors and cabinet are necessarily small. Be careful closing doors when children are in the area. Ŷ'RQRWWRXFKWKHFROGVXUIDFHVLQWKHIUHH]HUFRPSDUWPHQWZKHQKDQGVDUHGDPSRUZHWVNLQPD\VWLFNWRWKHVH extremely cold surfaces. Ŷ'RQRWUHIUHH]HIUR]HQIRRGVZKLFKKDYHWKDZHGFRPSOHWHO\ Ŷ In refrigerators with automatic icemakers, avoid contact with the moving parts of the ejector mechanism, or with the heating element that releases the cubes. Do not place fingers or hands on the automatic ice making mechanism while the refrigerator is plugged in. Ŷ Use a sturdy glass when dispensing ice (on models with ice dispenser) WARNING To reduce the risk of fire, explosion, electric shock, or injury when using your refrigerator, follow these basic safety precautions: Ŷ7KLVUHIULJHUDWRUPXVWEHSURSHUO\LQVWDOOHGDQGORFDWHG in accordance with the Installation Instructions before it is used. Ŷ8QSOXJWKHUHIULJHUDWRUEHIRUHPDNLQJUHSDLUVRU cleaning. NOTE: Power to the refrigerator cannot be disconnected by any setting on the control panel. NOTE: Repairs must be performed by a qualified Service Professional. Ŷ5HSODFHDOOSDUWVDQGSDQHOVEHIRUHRSHUDWLQJ Ŷ'RQRWXVHDQH[WHQVLRQFRUG Ŷ'RQRWVWRUHRUXVHJDVROLQHRURWKHUIODPPDEOHYDSRUV and liquids in the vicinity of this or any other appliance. Ŷ'RQRWVWRUHH[SORVLYHVXEVWDQFHVVXFKDVDHURVRO cans with a flammable propellant in this appliance. 7RSUHYHQWVXIIRFDWLRQDQGHQWUDSPHQWKD]DUGVWR FKLOGUHQUHPRYHWKHIUHVKIRRGDQGIUHH]HUGRRUVIURP any refrigerator before disposing of it or discontinuing its use. Ŷ7RDYRLGVHULRXVLQMXU\RUGHDWKFKLOGUHQVKRXOGQRW stand on, or play in or with the appliance. Ŷ&KLOGUHQDQGSHUVRQVZLWKUHGXFHGSK\VLFDOVHQVRU\RU mental capabilities or lack of experience and knowledge can use this appliance only if they are supervised or have been given instructions on safe use and XQGHUVWDQGWKHKD]DUGVLQYROYHG Ŷ7KLVDSSOLDQFHLVLQWHQGHGWREHXVHGLQKRXVHKROG and similar applications such as: staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels, bed & breakfast and other residential environments; catering and similar non-retail applications. Ŷ&RQQHFWWRSRWDEOHZDWHUVXSSO\RQO\$FROGZDWHU supply is required for automatic icemaker operation. The water pressure must be between 40 and 120 psi (275-827 kilopascals). Ŷ'RQRWDSSO\KDUVKFOHDQHUVWRWKHUHIULJHUDWRU Certain cleaners will damage plastic which may cause parts such as the door or door handles to detach unexpectedly. See the Care and Cleaning section for detailed instructions. WARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from refrigerator. Failure to do so can result in fire, explosion, or death. INSTALLATION: For Installation Instructions, please see the full Owner’s Manual at GEAppliances.com (Canada GEAppliances.ca) Draft 249-60822 Rev. 7 Safety PROPER DISPOSAL OF YOUR OLD REFRIGERATOR Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded. The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard SURQJ JURXQGLQJ ZDOORXWOHWWRPLQLPL]HWKHSRVVLELOLW\ RIHOHFWULFVKRFNKD]DUGIURPWKLVDSSOLDQFH Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded. Where a standard 2-prong wall outlet is encountered, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet. Do not use an adapter. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating plate. $9ROW$&+]RUDPSIXVHGJURXQGHG electrical supply is required. This provides the best performance and also prevents overloading house wiring FLUFXLWVZKLFKFRXOGFDXVHDILUHKD]DUGIURPRYHUKHDWHG wires. Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet. Immediately discontinue use of a damaged supply cord. If the supply cord is damaged, it must be replaced by a TXDOLILHGVHUYLFHSURIHVVLRQDOZLWKDQDXWKRUL]HGVHUYLFH part from the manufacturer. When moving the refrigerator away from the wall, be careful not to roll over or damage the power cord. CONNECTING ELECTRICITY WARNING ELECTRICAL SHOCK HAZARD Plug into a grounded 3-prong outlet Do not remove the ground prong Do not use an adapter Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock. READ AND SAVE THESE INSTRUCTIONS WARNING SUFFOCATION AND ENTRAPMENT HAZARD Failure to follow these disposal instructions can result in death or serious injury IMPORTANT: Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators ar…

Text truncated - open the document above for the full version.

Appliance Park, AP2-226, Louisville, KY 40225, United States Tel No : +1-502-852-0021 Fax No : +1-502-452-0371 Special Power of Attorney I, Rob Bultman Haier US Appliance Solutions, Inc. hereby appoint Darin Franks of GE Appliances, a Haier company to represent me to act on my behalf to do any and all of the following : Sign on my behalf the agency, anti-drug and confidentiality cover letters and apply to FCC for the products. The right, powers and authority in fact to exercise any and all of the rights and powers herein granted shell commence and be in full force from 12/6/2019 and continue to e effective unless specifically terminated by either party. Dated 12/6/2019 Sincerely, NAME: Rob Bultman TITLE: Principal – Software Architecture Applicant: Haier US Appliance Solutions, Inc. Address: Appliance Park, AP2-226, Louisville, KY 40225, United States

1 EXTERNAL PHOTOS Top Of Board 2 EXTERNAL PHOTOS Top Of Board (Detailed locations) PMN FCC and IC ID’s HVIN 3 EXTERNAL PHOTOS HVIN Zoomed GB(AH1 Slide 3 GB(AH1 Gasior, Bradford (GE Appliances, Haier), 12/6/2019 4 EXTERNAL PHOTOS Bottom Of Board Antenna Location, Made from traces On back of board

1 EXTERNAL PHOTOS This Board will be on refrigeration platforms. These platforms all have multiple models but the mounting and positioning for these models will be the same for each platform. Any future platforms that adopt this design will have a similar concept MultidoorPangea Bottom Freezer Side By Side The following label will be visible to the end user. This device is for limited modular approval as the module will not be for sale and only sold as part of our host refrigerators. The following “FCC Label” location is shown on Page 3,4 and 5 for our various refrigeration platforms HOST LABEL TO SHOW MODULE IS CONTAINED IN THE HOST TO THE END USER 3 EXTERNAL PHOTOS - MULTIDOOR On Multidoor platform, the Board is located in the Fresh Foods door behind the filter cover cover Door opened, filter cover location above Filter Cover Filter Cover opened Module will be located behind the filter(This is prototype and board housing pocket will be bigger) – the FCC label on page 2 location above is to show end user the device is contained in this host 4 EXTERNAL PHOTOS Pangea Bottom Freezer On Pangea BF platforms the board is located in the Fresh Foods compartment inside a filter cover Opening the Cover exposed the filter Filter and Filter cover located in top right corner of the refrigerator Module is located in a housing behind the filter, FCC label on page 2 location above to show end user the device is contained in the host 5 EXTERNAL PHOTOS SxS On SxS platforms the board is located in the Fresh Food compartment (right hand door) The Board is located behind the filter in the top right hand corner Above shows the filter with a “Cover” Cover Removed Module is located in a housing behind the filter, FCC label on page 2 location above to show end user the device is contained in the host Above shows the housing unmounted showing the module

Intertek 731 Enterprise Drive Lexington, KY 40510 Tel 859 226 1000 Fax 859 226 1040 www.intertek.com Haier US Appliance Solutions Inc. DBA GE Appliances TEST REPORT SCOPE OF WORK EMC TESTING – RFID MODULE REPORT NUMBER 104073059LEX-001 ISSUE DATE 10/2/2019 PAGES 30 DOCUMENT CONTROL NUMBER Non-Specific EMC Report Shell Rev. December 2017 © 2017 INTERTEK This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services NA, Inc. EMC TEST REPORT (FULL COMPLIANCE) Report Number: 104073059LEX-001 Project Number: G104073059 Report Issue Date: 10/2/2019 Model(s) Tested: RFID Module Standards: FCC Part 15B FCC Part 15.225 FCC Part 15.215 RSS-210 Issue 9 ICES-003 Issue 6 Tested by: Client: Intertek Testing Services NA, Inc. 731 Enterprise Dr. Lexington, KY 40510 USA Haier US Appliance Solutions Inc. DBA GE Appliances Appliance Park AP2-121 Louisville KY 40225 USA Report prepared by Report reviewed by Bryan Taylor, Team Leader Brian Lackey, Staff Engineer Evaluation For: Haier US Appliance Solutions Inc. DBA GE Appliances Product: RFID Module EMC Test Report Date: 10/2/2019 Non-Specific EMC Report Shell Rev. December 2017 Page 3 of 30 Report Number: 104073059LEX-001 Table of Contents 1 Introduction and Conclusion ..................................................................................................................... 4 2 Test Summary .......................................................................................................................................... 4 3 Client Information .................................................................................................................................... 5 4 Description of Equipment under Test and Variant Models .......................................................................... 6 5 System Setup and Method ........................................................................................................................ 7 6 Radiated Emissions .................................................................................................................................. 8 7 Radiated Emissions (RFID) ...................................................................................................................... 12 8 Conducted Emissions .............................................................................................................................. 18 9 Frequency Stability ................................................................................................................................. 24 10 Occupied Bandwidth ........................................................................................................................... 26 11 Antenna Requirement ........................................................................................................................ 29 12 Revision History.................................................................................................................................. 30 Evaluation For: Haier US Appliance Solutions Inc. DBA GE Appliances Product: RFID Module EMC Test Report Date: 10/2/2019 Non-Specific EMC Report Shell Rev. December 2017 Page 4 of 30 Report Number: 104073059LEX-001 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 4.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. Intertek does not make any claims of compliance for samples or variants which were not tested. 2 Test Summary Section Test full name Result 6 Radiated Emissions (Transmitters Idle) (ANSI C63.4:2014) Pass 7 Radiated Spurious Emissions (Transmitters Active) (ANSI C63.10:2013, RSS-210 Issue 9) Pass 8 Conducted Emissions (ANSI C63.10:2013, ANSI C63.4:2014) Pass 9 Frequency Stability (ANSI C63.10:2013, RSS-210-Issue 9) Pass 10 Occupied Bandwidth (ANSI C63.10:2013, RSS-Gen Issue 5) Pass 11 Antenna Requirement (FCC Part 15.203, RSS-Gen Issue 5) Pass Evaluation For: Haier US Appliance Solutions Inc. DBA GE Appliances Product: RFID Module EMC Test Report Date: 10/2/2019 Non-Specific EMC Report Shell Rev. December 2017 Page 5 of 30 Report Number: 104073059LEX-001 3 Client Information This product was tested at the request of the following: Client Information Client Name: Haier US Appliance Solutions Inc. DBA GE Appliances Address: Appliance Park AP2-121 Louisville KY 40225 USA Contact: Brad Gasior Email: [email protected] Manufacturer Information Manufacturer Name: Haier US Appliance Solutions Inc. DBA GE Appliances Manufacturer Address: Appliance Park AP2-121 Louisville KY 40225 USA Eval…

Text truncated - open the document above for the full version.

Conducted Emissions Radiated Emissions Below 30MHz Radiated Emissions Above 30MHz
