ZKJ-WCATA003WiFi Transceiver

GEAppliances.com Plus Box 49-50298 04-14 GE PBX10W00Y0 Quick Guide IMPORTANT SAFETY INSTRUCTIONS 2 SAVE THESE INSTRUCTIONS Notice: • The Plus Box shall only be used for its intended purpose as described in this Owner’s Manual. • Never force a connector into the Ethernet port. If the connector does not attach with a reasonable amount of force, they do not match. Verify the connector matches the port and that it is orientated correctly. • Extended exposure to high temperature may cause premature failure of electronic components. Do not place the Plus Box on the back of a range. • The only way to turn off power to this Plus Box is to unplug it from the appliance. 3 Regulatory Information REGULATORY INFORMATION FCC/IC Compliance Statement This device complies with Part 15 of the FCC Rules and Industry Canada RSS-210. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment or devices. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult a dealer or experienced radio/TV technician for assistance. FCC CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure - This device is only authorized for use in a mobile application. At least 20 cm of separation distance between the device and the user’s body must be maintained at all times. 4 Mentions règlementaires MENTIONS REGLEMENTAIRES Déclaration de Conformité FCC/IC Cet appareil a été testé et déclaré conforme à la section 15 du règlement de la FCC ainsi qu’à la norme RSS-210 édictée par le Ministère canadien des Sciences et de l’Industrie. Son fonctionnement est soumis aux deux conditions suivantes: 1) l’équipement concerné ne doit pas causer d’interférences dangereuses, et 2) il doit accepter toute interférence reçue, y compris les interférences risquant d’engendrer un fonctionnement indésirable. Ce produit a été testé et déclaré conforme aux limitations prévues dans le cadre de la catégorie B des appareils numériques défini par la section 15 du règlement de la FCC. Ces limitations sont stipulées aux fins de garantir une protection raisonnable contre les interférences gênantes en installation résidentielle. Cet équipement génère, utilise et diffuse des ondes radio, et s’il n’est pas installé ni utilisé en conformité avec les instructions dont il fait l’objet, peut causer des interférences gênantes avec les communications radio. Cependant, nous ne pouvons vous garantir qu’une interférence ne se produira pas dans une installation particulière. Si cet équipement produit des interférences graves lors de réceptions radio ou télévisées qui peuvent être détectées en allumant et en éteignant l’équipement, vous êtes invités à les supprimer de plusieurs manières suivantes: • Réorientez ou déplacez l’antenne de réception. • Augmentez la distance séparant l’équipement et le récepteur. • Connectez l’équipement à un circuit différent de celui auquel le récepteur est connecté. • Contactez votre revendeur ou un technicien radio/TV qualifié. AVERTISSEMENT FCC : Toutes modifications ou tous changements effectués sans l’accord exprès de la partie responsable de la conformité aux normes pourraient contraindre l’utilisateur à ne plus utiliser son équipement. Exposition aux RF – Cet appareil ne peut qu’être utilisé pour des applications mobiles. Une distance d’au moins 20 cm doit toujours séparer l’appareil et le corps de l’utilisateur. Limited Warranty for Plus Box WARRANTY Your use of the Appliance Communicating Module (“Hardware”), online product registration of the Hardware, or your return of the enclosed Registration Card acknowledges that you have read and agree to the terms of this warranty agreement. GE’s warranty obligations for this Hardware are limited to the terms set forth herein. GE warrants that this Hardware shall be free of defects in materials and workmanship under normal use for a period of one (1) year from the date of original retail purchase (“Warranty Period”). If a Hardware defect arises and a valid claim is received within the Warranty Period, your sole and exclusive remedy will be for GE, in its sole discretion and to the extent permitted by law, to (1) repair the Hardware defect at no charge, using new parts or refurbished parts that are equivalent to new in performance and reliability, (2) exchange the Hardware with Hardware that is new or refurbished that is equivalent to new in performance and reliability and is at least functionally equivalent to the original Hardware, or (3) refund the purchase price of the Hardware. Any repaired or replacement Hardware will be warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer. In order to receive the remedy set forth above, you must contact GE during the Warranty Period at 800-220-6899 and provide the model number, serial number, and date of purchase of the Hardware.…

Text truncated - open the document above for the full version.

Regulatory Module Integration Instructions This module has been granted modular approval for mobile applications. OEM integrators for host products may use the module in their final products without additional FCC / IC (Industry Canada) certification if they meet the following conditions. Otherwise, additional FCC / IC approvals must be obtained.  The host product with the module installed must be evaluated for simultaneous transmission requirements.  The users manual for the host product must clearly indicate the operating requirements and conditions that must be observed to ensure compliance with current FCC / IC RF exposure guidelines.  To comply with FCC / IC regulations limiting both maximum RF output power and human exposure to RF radiation, use this module only with the included onboard antenna.  A label must be affixed to the outside of the host product with the following statements: Contains FCCID: ZKJ-WCATA003 Contains IC: 10229A-WCATA003 The final host / module combination may also need to be evaluated against the FCC Part 15B criteria for unintentional radiators in order to be properly authorized for operation as a Part 15 digital device. Device Classifications Since host devices vary widely with design features and configurations module integrators shall follow the guidelines below regarding device classification and simultaneous transmission, and seek guidance from their preferred regulatory test lab to determine how regulatory guidelines will impact the device compliance. Proactive management of the regulatory process will minimize unexpected schedule delays and costs due to unplanned testing activities. The module integrator must determine the minimum distance required between their host device and the user’s body. The FCC provides device classification definitions to assist in making the correct determination. Note that these classifications are guidelines only; strict adherence to a device classification may not satisfy the regulatory requirement as near-body device design details may vary widely. Your preferred test lab will be able to assist in determining the appropriate device category for your host product and if a KDB or PBA must be submitted to the FCC. Note, the module you are using has been granted modular approval for mobile applications. Portable applications may require further RF exposure (SAR) evaluations. It is also likely that the host / module combination will need to undergo testing for FCC Part 15 regardless of the device classification. Your preferred test lab will be able to assist in determining the exact tests which are required on the host / module combination. FCC Definitions Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is / are within 20 centimeters of the body of the user. Mobile: (§2.1091) (b) — A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons. Per §2.1091d(d)(4) In some cases (for example, modular or desktop transmitters), the potential conditions of use of a device may not allow easy classification of that device as either Mobile or Portable. In these cases, applicants are responsible for determining minimum distances for compliance for the intended use and installation of the device based on evaluation of either specific absorption rate (SAR), field strength, or power density, whichever is most appropriate. Simultaneous Transmission Evaluation This module has not been evaluated or approved for simultaneous transmission as it is impossible to determine the exact multi-transmission scenario that a host manufacturer may choose. Any simultaneous transmission condition established through module integration into a host product must be evaluated per the requirements in KDB447498D01(8) and KDB616217D01,D03 (for laptop, notebook, netbook, and tablet applications). These requirements include, but are not limited to:  Transmitters and modules certified for mobile or portable exposure conditions can be incorporated in mobile host devices without further testing or certification when:  The closest separation among all simultaneous transmitting antennas is >20 cm, Or  Antenna separation distance and MPE compliance requirements for ALL simultaneous transmitting antennas have been specified in the application filing of at least one of the certified transmitters within the host device. In addition, when transmitters certified for portable use are incorporated in a mobile host device, the antenna(s) must be >5 cm from all other simultaneous transmitting antennas.  All antennas in the final product must be at least 20 cm from users and nearby persons. OEM Instruction Manual Content Consistent with §2.909(a), the following text must be included within the user’s manual or operator instruction guide for the final commercial product (OEM-specific content is displayed in italics.) Operating Requirements and Conditions: The design of (Product Name) complies with U.S. Federal Communications Commission (FCC) guidelines respecting safety levels of radio frequency (RF) exposure for Mobile devices. Note: In the case where the Host / Module combination has been re-certified the FCCID shall appear in the product manual as follows: FCCID: (Include Standalone FCC ID) Mobile Device RF Exposure Statement (If Applicable): RF Exposure - This device is only authorized for use in a mobile application. At least 20 cm of separation distance between the transmitting antenna device and the user's body must be maintained at all times. Caution Statement for Modifications: CAUTION: Any changes or modifications not expressly approved by GE Appliance could void the user’s authority to operate the equipment. FCC Part 15 Stat…

Text truncated - open the document above for the full version.

1 GE Title or job number 2/10/2015 WCATA002 Module Photos/Drawings TOP BOTTOM

A B C SIZE TITLE 2 3 4 4 3 2 1 A B C D D C DRW VER GEOM VER LOUISVILLE, KY. ELECTRIC GENERAL LOC UNCONTROLLED IF PRINTED 3.500 1.000 R.125 LABEL FCC DWG NO 257C2110A001 SHT 1 BCN . REV 1 AFFECTED SHTS ALL DWG. NO. & FILENAME 257C2110A001 31 STATUS In WorkSHEET:1 OF 1 GEA-REFDEPT Not Released THIS DRAWING DO NOT SCALE TITLE TEXT SEE NOTE 2 LAST 4 DIGITS OF WI-FI MAC ADDRESS TO BE PRINTED IN THIS AREA. PASSWORD TO BE PRINTED IN THIS AREA. SEE NOTE 3 & 4 GROUP NUMBER TO BE PRINTED IN THIS AREA. MAC ID TO BE PRINTED IN THIS AREA. SEE NOTE 1

1 GE Title or job number 2/10/2015 WCATA002 Module Photos/Drawings TOP BOTTOM

731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com MPE Calculation § 1.1310: The criteria listed in table 1 shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of §2.1093 of this chapter. Part 1.1310 Limits for Maximum Permissible Exposure (MPE) 731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com RSS-102 Issue 5 Exposure Limits: 1.1 Test Procedure An MPE evaluation for was performed in order to show that the device was compliant with §2.1091. The maximum power density was calculated for each transmitter at a separation distance of 20cm. For each transmitter the maximum RF exposure at a 20 cm distance using the formula: 10/)( 10 dBmowerConductedP mW PowerConducted= 2 )20(4 . cm mW GainAntPowerConducted tyPowerDensi × × = π 731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com 1.2 Results: • Maximum Conducted Output Power = 276.1mW • Maximum Antenna Gain = 1.47dbi • Maximum Conducted Output Power = (10*log(.2761mW/.001mW) = 24.41db Power Density = (24.41dbm + 1.47dbi) / 5025.6 Power Density = .077mW/cm 2 Limit at 2.4GHz = 1mW/cm 2 RSS-102 Issue 5 Exposure Limit at 2.4GHz = 5.35W/m 2 Power Density = .77W/m 2 The calculated maximum power density at 20cm distance is less that the limit for general population / uncontrolled exposure.

This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report for GE Digital Energy on the GE Wi-Fi Connected Appliance Transciever Page 1 of 46 731 Enterprise Drive Lexington, KY 40510 Telephone: 859-226-1000 Facsimile: 859-226-1040 www.intertek-etlsemko.com WLAN TEST REPORT Report Number: 101968322LEX-001 Project Number: G101968322 Report Issue Date: 4/13/2015 Product Name: GE Wi-Fi Connected Appliance Transciever FCC Standards: Title 47 CFR 15 Subpart B and C Industry Canada Standards: RSS-210 Issue 8 & RSS-GEN Issue 4 Tested by: Client: Intertek Testing Services NA, Inc. 731 Enterprise Drive Lexington, KY 40510 GE Digital Energy AP6-1NW Appliance Park Louisville, KY 40225 Report prepared by Report reviewed by Toby Carrier, Technician Bryan Taylor, Team Leader -- Engineering Intertek Report Number: 101968322LEX-001 Issued: 4/13/2015 EMC Report for GE Digital Energy on the GE Wi-Fi Connected Appliance Transciever Page 2 of 46 TABLE OF CONTENTS 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Description of Equipment Under Test ............................................................................................... 4 4 Peak Conducted Power ....................................................................................................................... 6 5 Occupied Bandwidth ........................................................................................................................... 8 6 Conducted Spurious Emissions ....................................................................................................... 15 7 Power Spectral Density ..................................................................................................................... 19 8 Radiated Spurious Emissions (Transmitter) ................................................................................... 25 9 Radiated Spurious Emissions (Receiver) ........................................................................................ 33 10 AC Powerline Conducted Emissions ........................................................................................... 35 Line 1 .......................................................................................................................................................... 43 11 Antenna Requirement per FCC Part 15.203 ................................................................................. 44 12 Measurement Uncertainty.............................................................................................................. 45 13 Revision History ............................................................................................................................. 46 Intertek Report Number: 101968322LEX-001 Issued: 4/13/2015 EMC Report for GE Digital Energy on the GE Wi-Fi Connected Appliance Transciever Page 3 of 46 1 Introduction and Conclusion The tests indicated in section 2 were performed on the product constructed as described in section 3. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test method, a list of the actual test equipment used, documentation photos, results and raw data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complied with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. The INTERTEK-Lexington is located at 731 Enterprise Drive, Lexington Kentucky, 40510. The radiated emission test site is a 10-meter semi-anechoic chamber. The chamber meets the characteristics of CISPR 16-1 and ANSI C63.4. For measurements, a remotely controlled flush-mount metal-top turntable is used to rotate the EUT a full 360 degrees. A remote controlled non-conductive antenna mast is used to scan the antenna height from one to four meters. The test site is listed with the FCC under registration number 485103. The test site is listed with Industry Canada under site number IC 2042M-1. 2 Test Summary Page Test full name FCC Reference IC Reference Result 6 Peak Conducted Power § 15.247(b)(3)(4) RSS-210 (A8.4) Pass 8 Occupied Bandwidth § 15.247(a)(2) RSS-210 (A8.2), RSS-GEN (6.6) Pass 15 Conducted Spurious Emissions § 15.247(d) RSS-210 (A8.5) Pass 19 Power Spectral Density § 15.247(e) RSS-210 A8.2(B) Pass 25 Radiated Spurious Emissions (Transmitter) § 15.247(d), § 15.209, and § 15.205 RSS-210 (2.2) Pass 33 Radiated Spurious Emissions (Receiver) § 15.109 RSS-Gen (7.1) Pass 35 AC Powerline Conducted Emissions § 15.107, § 15.207 RSS-Gen (8.8) Pass 44 Antenna Requirement per FCC Part 15.203 § 15.203 RSS-Gen (6.7) Pass Intertek Report Number: 101968322LEX-001 Issued: 4/13/2015 EMC Report for GE Digital Energy o…

Text truncated - open the document above for the full version.
